2BBDC-TYNESS-V3-01IoT Sensor with LoRa functionalities

TYNESS-FACTORY USA ENGLISH TYNESS-FACTORY USA ENGLISH by Ewattch Documentation 1 / 12 TYNESS-FACTORY USA ENGLISH 1. Hazards and warnings .................................................................................. 3 2. Homologations and compliances ............................................................... 3 3. Presentation .................................................................................................. 4 4. Product description ...................................................................................... 4 5. Product installation ...................................................................................... 5 6. Power supply of the sensor ......................................................................... 8 7. Measurements ............................................................................................... 9 8. Cleaning the product .................................................................................. 10 9. Technical Specifications ............................................................................. 10 10. Contact ...................................................................................................... 11 2 / 12 TYNESS-FACTORY USA ENGLISH 1. Hazards and warnings The manufacturer cannot be held responsible if the instructions in this manual are not followed. The product may only be installed by a professional. Any intervention on the product must be carried out by a professionnal. The product must be replaced by a professionnal. The device must be used in accordance with the specifications in this documentation, otherwise there is a risk of danger. If the device is used in a manner not specified by the manufacturer, the protection provided by the device may be compromised. No part of the device should be replaced or removed. Disconnect all power supplies before servicing this unit. Only accessories conforming to the manufacturer’s specifications should be used (current clamps, temperature probes and connecting cables) 2. Homologations and compliances FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC §15.21 The Federal Communications Commission (FCC) warns the users that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC §15.203 This equipment must be installed by qualified professionals or contractors in accordance with FCC Part 15.203, Antenna Requirements. Do not use any antenna other than the one provided with the unit. FCC §15.105 (b) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. 3 / 12 TYNESS-FACTORY USA ENGLISH Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC ID: 2BBDC-TYNESS-V3-01 3. Presentation 4. Product description The TYNESS-FACTORY is a multifunctional LoRaWan radio sensor equipped with a remote omnidirectional magnetic antenna. It enables to perform : 3 current measurements by current clamps 2 temperature measurements by PT100 probes 2 digital input measurements 2 analog measurements 0-24V 4 / 12 TYNESS-FACTORY USA ENGLISH 5. Product installation Positioning of the product The product must be positioned in a way that does not make it difficult to operate disconnector devices. The product must be installed in an indoor environment. Product dimensions 5 / 12 TYNESS-FACTORY USA ENGLISH Mounting on DIN rail The product must be installed on a 35mm DIN rail fixed in an electrical panel. Be careful to lock the housing on the DIN rail. The DIN rail mount consists of 2 parts: a base and a movable and adjustable latch. It is used to fix the Tyness horizontally or vertically on a DIN rail. The Tyness can be removed from the DIN rail by manipulating the movable latch with a screwdriver like any other bracket of the same type. It is delivered with 2 mounting screws. 6 / 12 TYNESS-FACTORY USA ENGLISH Adjustment of the tongue : Depending on the positioning of the FIX-RAIL, the height of the latch must be adjusted in order to remain accessible. When the upper part of the latch protrudes from the Tyness (for example with a Tyness in a low axial position), it can be cut with a wire cutter. 7 / 12 TYNESS-FACTORY USA ENGLISH 6. Power supply of the sensor The product must be powered by a 24VDC power supply and provide a minimum current of 1A. Connect the cable marked power supply of the product to this power supply. The red wire on the 24V and the black wire on the 0V. It is very important to respect this polarity. 8 / 12 TYNESS-FACTORY USA ENGLISH 7. Measurements The sensor enables to make different measurements. Here below are the wiring methods for each one. The technical characteristics are described at the bottom of the documentation. Measurements of current: The measurement o…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia. MD 21046 USA Date: 08/02/2023 Ref: Attestation Statement Part 2.91 l(d)(7) Filing Validity Period: Permanent FCC ID: 2BBDC-TYNESS-V3-0l Ewattch Manufacturer Name Address 13 Rue Maurice Jeandon. Saint-Die-des-Vosges. Grand Est 88100, France certifies that. as of the dates of this application. Americas Compliance Consulting LLC dba iCertifi •'iCertifi" is our designated U.S. agent for service of process for the above referenced FCC ID. We accept to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program. Repo1t and Order FCC 22-84. and clause* 2.911. iCertifi accepts. as of the date of the filing of the application. the obligation of the designated U.S. agent for service process for the above: Designated U.S. Agent Information: Name FCCFRN Address Contact Person Telephone Email Sincerely. Ewattch Guillaume Michelin V02072023 Americas Compliance Consulting. LLC dba iCertifi 00333994 l l I 00 I SW Disk Drive. Suite 250 Bend. Oregon 97702 USA Paul Preston (866)885-4575 fccagent!cilicertifi .com Americas Com 1 LLC dba iCertifi Paul Preston c i SEAL � 2011 -, n e � .,,_�/4(.S

Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH 05 December 2023 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID : 2BBDC-TYNESS-V3-01 To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics ☐ Parts List ☒ Block Diagram ☐ Tune-Up Info ☒ Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☐ for an initial period of days ☐ until: ☒ not applicable ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Sabrina Berghahn

Tyness-Factory Product Label The Tyness-Factory Product Label is a BRADYBONDZ™ B-423 THERMAL TRANSFER PRINTABLE GLOSSY WHITE POLYESTER Label manufactured by BRADY. The technical specificaƟon and material composiƟon is as documented below: DescripƟonvalue SubstrateGloss white polyester50.8 microns AdhesivePermanent acrylic adhesive25.4 microns Total (excluding liner)76.2 microns Adhesion on ABSPeel adhesion aŌer 24 hours100 N/m The label is affixed by hand and placed on the right side of the ABS housing, as illustrated below:

Siège Social : Emitech - 3, avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B RRA-EMIESS21G095EWA-04A v2 Certain services reported in this document are not covered by the accreditation. They are identified by the symbol (*) Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. LISTE DES SITES ACCREDITES ET PORTEES DISPONIBLES SUR WWW.COFRAC.FR ACCREDITATIONS N° 1-0107, 1-0826, 1- 0827, 1-1925, 1-2069,1-2070, 1-2206, 1- 2376 & 1-6086 “This report cancels and replaces the test report N° RRA-EMIESS21G095EWA-04A v1” Test report issued under the responsibility of: EMITECH ILE DE FRANCE Laboratory MRA US-EU Designation Number: FR0004 IC Assigned Code: 4379A RADIO TEST REPORT FCC 47 CFR PART 15 : 2021 RSS-Gen_Issue 5 : 2019 Company ....................................... : EWATTCH Address. .......................................... : 13 Rue Maurice Jeandon 88100 SAINT DIE DES VOSGES FRANCE Test item description. .................. : TYNESS-FACTORY Trade Mark. .................................... : Not communicated Manufacturer................................... : EWATTCH Model/Type reference. .................... : TYNESS_V3 Ratings. ........................................... : 24Vdc ±5% Testing Laboratory ....................... : EMITECH ILE DE FRANCE Laboratory Address. .......................................... : 30-32, avenue des 3 Peuples 78180 MONTIGNY-LE-BRETONNEUX FRANCE Report Reference No. ................... : RRA-EMIESS21G095EWA-4A v2 Test procedure. .............................. : FCC and CANADA marking Diffusion. ......................................... : Mr. MICHELIN Applicant’s name. ........................... : EWATTCH Date of issue. .................................. : 07/11/2023 Total number of pages. ................... : 26 Revision. ......................................... : 2 Compiled by. ................................... : C.A. ROBERT (Test technician) Technical verification...................: Quality approval..........................: RRA-EMIESS21G095EWA-04A v2 Page 2 out of 26 REPORT INDEX: 1. GENERAL INFORMATIONS .......................................................................................................................... 3 2. REFERENCE DOCUMENTS .......................................................................................................................... 4 3. EQUIPMENT TECHNICAL DESCRIPTION .................................................................................................... 5 3.1. TEST CONDITIONS ................................................................................................................................... 5 3.2. E.U.T OVERVIEW .................................................................................................................................... 6 3.3. E.U.T MARKING PLATE ............................................................................................................................ 8 3.4. E.U.T ELECTRONIC BOARD ...................................................................................................................... 9 3.5. E.U.T MECHANICAL AND ELECTRICAL DESIGN .........................................................................................10 3.6. E.U.T INPUT/OUTPUT PORTS..................................................................................................................10 3.7. SUPPORTING EQUIPMENT USED DURING TEST ........................................................................................11 3.8. AUXILIARY EQUIPMENT ...........................................................................................................................11 3.9. E.U.T RADIO SPECIFICATIONS ................................................................................................................13 4. RESULT SUMMARY .....................................................................................................................................14 5. MEASUREMENT UNCERTAINTY ................................................................................................................15 6. TEST CONDITIONS AND RESULTS ...........................................................................................................16 6.1. MEASUREMENT OF CONDUCTED EMISSION ON AC MAINS PORTS ...............................................................16 6.2. UNINTENTIONAL RADIATED EMISSIONS IN THE BAND 30 MHZ – 10 GHZ .....................................................21 REVISION HISTORY: Revision Date Modified pages Modifications 0 26/03/2023 / Creation 1 12/10/2023 5 Add of FCC and IC ID 13 Add of number of channel 2 07/11/2023 4 Retry off ANSI 63.10 Standard 16 ; 19 ; 20 Table modification RRA-EMIESS21G095EWA-04A v2 Page 3 out of 26 1. GENERAL INFORMATIONS This document submits the results of Radio tests performed on the equipment (denominated hereafter E.U.T.: equipment under test) according to documents listed in §2 of this test report. TESTING PROCEDURE AND TESTING LOCATION: Testing Laboratory ................................... : EMITECH ILE DE FRANCE Laboratory Address. ..................................................... : 30-32, avenue des 3 Peuples 78180 MONTIGNY-LE-BRETONNEUX FRANCE Test procedure. .......................................... : CE Marking Tested by .................................................... : C.A. ROBERT / F. LHEUREUX Test supervisor ........................................... : B. PELLERIN Dat…

Text truncated - open the document above for the full version.

ProductDatasheet www.cowinante.com 1 CW-WZ-0133 GSMMagenticAntenna Key Features Frequency:890-960/1710-1880MHz RP SMAMaleConnector ExternalMagneticBase Dimensions275*45mm Cowin Antenna ProductDatasheet www.cowinante.com 2 1. AntennaElectricalCharacteristics 2. Materialand environmentalcharacteristics Band(MHz) Frequency(MHz)890-960/1710-1880MHz VSWR2.0 Efficiency(%)50.62%/52.07% PeakGain(dBi)2.64/3.17 Impendance(Ohm)50 PolarisationVertical Max.InputPower(W)10 ConnectorTypeRP SMAMale Innerstructure Coppertube Materialof Plastic ABS/TPE CableType RG174 ConnectorType RP SMAMale Dimensions(mm)275*45MM AntennacolorBlack OperationTemperature -40 to +80 StorageTemperature -40 to +80 AntennaStoragelife(year) 10 SubstanceComplianceROHS Cowin Antenna ProductDatasheet www.cowinante.com 3 Cowin Antenna ProductDatasheet www.cowinante.com 4 4. Antennatest parameters AntennaMeasurementConditions: Mountedon GroundPlaneof 280 x 80 mm Measuredin Certified3D AnechoicChamber The networkanalyzeris Agilent5071c The comprehensivetesteris Agilentcmv500 Cowin Antenna ProductDatasheet www.cowinante.com 5 2 3 4 5 6 7 8 9 10 1 1 Pb 0 dBm Ch1fbStart400 MHzStop3 GHz Trc1S11SWR1 U /Ref 1 U Cal int • M1 M2 M3 M4 890.00000 960.00000 1.710000 1.880000 MHz MHz GHz GHz 1.2605 1.1925 1.2787 1.2970 U U U U S11 M1 M2 M3 M4 8/22/2023, 3:41 AM 4.1 VSWR Cowin Antenna ProductDatasheet www.cowinante.com 6 4.2 Efficiency 4.3 Peakgain Cowin Antenna ProductDatasheet www.cowinante.com 7 4.4 3D&2DRadiationPatterns Cowin Antenna ProductDatasheet www.cowinante.com 8 Cowin Antenna ProductDatasheet www.cowinante.com 9 Cowin Antenna ProductDatasheet www.cowinante.com 10 Cowin Antenna ProductDatasheet www.cowinante.com 11 Cowin Antenna
