2BBG8-EH20Smart Helmet

EH�� Helmet User Manual Shenzhen Digitech Co., Ltd. Table of contents � Product Presentation � � � � � � � � � � � � � � � �� �� Operation Description Routine Maintenance FAQ Product Parameters Product Presentation Packing List Wearing Instructions Switch on/off Charged Connect Ebike Button Connect New Ebike Button Multi-media Features Indicators Low Battery Connect Bikewise Pro APP Warning� Wearing Method Considerations �. The helmet contains electronic parts inside. Please do not take a long ride in the rain although the helmet can prevent the rain from splashing. �. After the helmet gets wet in the rain, the water droplets might occur in the chimney of tail LED lights. The water droplets will disappear when you put the helmet under the ventilation environment for �-� days. �. The helmet contains the battery of �.�V/����mAh. The battery capacity varies with temperature change. The battery life can decay when the helmet is used at low temperatures or below Zero degrees Celsius. �. Trying to clean the golden colour contacts of the charging plug sheet with metal or hard tools such as blades or tweezers is strictly forbidden. Please use cotton swabs with clean water or alcohol in case of cleaning. Please make sure the charging plug is clean and try while charging the helmet. �. If the electronic functions do not work, please charge the helmet for � hours and then check if it works normally. �. The built-in battery is forbidden to be disassembled, squeezed, heated or burned. It is also forbidden to use screwdrivers and other sharp devices breaking down or prying apart the battery. The above operations may make the battery caught fire. �. Please do not place the helmet with sharp objects, avoiding to damage the helmet. �. Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types); �. Dsposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery that can result in an explosion; ��. Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; and ��. Abattery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. Note: To maintain efficient battery life, it is recommended that the helmet be fully charged before any longterm storage (six months to one year). � Warning Warning �. How the helmet should be position on the head to ensure the intended protection is provided (e.g. that it should be placed so as to protect the forehead and not be pushed too far over the back of the head. �. That a helmet cannot always protect against injury. �. That a helmet subjected to a severe impact should be discarded and destroyed. �. A statement of the danger of modifying or removing any of the original component parts of the helmet other than as recommended by the manufacturer, and that helmets should not be adapted for the purpose of fitting accessories in a way not recommended by the manufacturer. �. This device complies with part �� of the FCC Rules. Operation is subject to the following two conditions:(�) This device may not cause harmful interfe- -rence, and (�) this device must accept any interference received, including interference that may cause undesired operation. Faults: �. Can not be charged or turn-off normally; �. The helmet is turn on, but the lights, micphone, speakers etc can not work normally; �. After power on, it turns off automatically in a short time. Note: Please refer to the quick guide of the specific model for function details. Warning � Instructions for Use and Care �.That the helmet can only protect if it fits well and that the buyer should try different sizes and choose the size which feels secure and comfortable on the head. �.That the helmet should be adjusted to fit the user e.g. the straps positioned so that they do not cover the ears, the buckle positioned away from the jawbone and the straps and buckle adjusted to be both comfortable and firm. Product Presentation � Product Brief Presentation Welcome to the Digitech helmet, this manual will guide you how to use this product. This product is a new type of smart helmet, using smart hardware IOT technology, through the Bikewise Pro App, Digitech smart display network connection, to provide you with a full aspects of smart experience, including warning lights, turn light indicators, voice intercom, call reminders, navigation voice, music play etc. Helmet : �pcs Wrong WrongCorrect Type C charging cable Manual �pcs Wearing Description *Reminder: The picture above is product framework, and the final effect is subject to the actual product. Lock Multi-function button Taillight Mic Charging port Integrated earbuds Integrated earbuds Headlight Front drawstring Back drawstring Adjustment buckle Front Back Packing List Operation Description � Wearing Method Switch On/Off Long press Power for � seconds to turn it on. With the headlights flashing briefly and the taillights will turn off after showing a flowing light effect, the voice broadcast begins. After the ride is over, long press Power for � seconds, the taillight is turned out and the voice broadcast powers off. Charged �.At the bottom of helmet, it is the TypeC USB charging port. We recommend that it is charged by DC �V �A or above. Long press �S to turn it on. �.When charging, the � red lights in the middle of the tail light show the charging status. �.The four lights are always on when charging is completed. Head light short flashing Long press �S to turn it off Power Off Power On Adjust the length of the drawstring Leave one-finger gap and check whether the buckle is intact Straighten the helmet Operation Description � Connect Ebike Button Open App to scan display’s QR code on Ebike to bind Ebike. Long press power button for �S, the helmet starts pairing mode. Long press for �S. Open App, it enters the smart equip binding helm…

Text truncated - open the document above for the full version.

UNITED STATES DESIGNATED AGENT LETTER TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant Company Name Grantee Code Contact Name: Address Telephone: Email SHENZHEN DIGITECH CO.. LTD 2BBG8 Quanjin Sun R�om 305, Building A9, 兀anliaoIndustrial Zone, Nanshan, Shenzhen, 518000, China 86- 18123795889 quanjin.sun@riding­ evolved.com Applicable Equipment FCC ID: < 2BBG8-El-120 > ATTN: Di「ecto「ofCertification: Date: 2023-07-28 U.S. designated agent Company Name: United Consulting Techno l ogy Services Co., Ltd FRN: 0033495714 Contact Name Address: Telephone Email: David Wu 17800 CASTLETON ST STE 665 CITY OF INDUSTRY CA 917 48 United States (626)217-4022 [email protected] We,< SHENZHEN DIGITECH CO.,L TD. >and< United Consulting Technology Services Co., Ltd.> understand and acknowledge the applicants consent and the designated agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above We,< SHENZHEN DIGITECH CO.,L TD.> and< United Consulting Technology Services Co., Ltd.> acknowledge the applicant's acceptance of its obligation to maintain an agent for service of p「ocessin the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., o「theconclusion of any Commission-related administrative or丿udicialp「oceedinginvolving the equipment, whichever is later Applicant Na Titl Si U.S. designated agent Name (Printed): David Wu Title: CEO Signatu飞

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 6 External Photos for SZCR2305001443AT FCC ID: 2BBG8-EH20 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 6 of 6

Product: Smart Helmet Model No: EH20 Size: 57-61cm EN 1078: 2012+A1:2012 Weight: 410g Helmet for Pedal Cyclists Date of manufacture: 2022/11 Manufacturer:Shenzhen Digitech Co., Ltd. Address:Tanglang Community, Taoyuan Street, Nanshan District, Shenzhen WARNING! This helmet should not be used by children while climbing or doing other activities whenthere is a risk of strangulation/hanging if the child gets trapped with the helmet. Do not clen with solvents, bleaches and strong detergents, they can damage helmet, sometimes invisibly, use mild soap and water only, read manual. CPSC 1203 FCC ID:2BBG8-EH20

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 5 Internal Photos for SZCR2305001443AT FCC ID: 2BBG8-EH20 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 5 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 1 of 12 Keny Xu EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: SZCR2305001443AT Applicant: Shenzhen Digitech Co., Ltd. Address of Applicant: Room 305, Building A9, Tianliao Industrial Zone, Nanshan, Shenzhen, China Manufacturer: Shenzhen Digitech Co., Ltd. Address of Manufacturer: Room 305, Building A9, Tianliao Industrial Zone, Nanshan, Shenzhen, China Equipment Under Test (EUT): EUT Name: Smart Helmet Model No.: EH20 FCC ID: 2BBG8-EH20 Standard(s) : FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-05-15 Date of Test: 2023-05-26 to 2023-06-06 Date of Issue: 2023-06-19 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2023-06-19 Original Authorized for issue by: Darren Yuan/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 3 of 12 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 General Description of E.U.T. ............................................................................................................ 4 3.2 Separation Distance ........................................................................................................................... 5 3.3 Test Location ...................................................................................................................................... 6 3.4 Test Facility ........................................................................................................................................ 6 3.5 Deviation from Standards ................................................................................................................... 6 3.6 Abnormalities from Standard Conditions ........................................................................................... 6 4 FCC Radiofrequency radiation exposure limits .................................................................................... 7 4.1 Blanket 1 mW Blanket Exemption ...................................................................................................... 7 4.2 MPE-based Exemption ...................................................................................................................... 7 4.3 SAR-based Exemption ....................................................................................................................... 8 5 Measurement and Calculation ............................................................................................................... 11 5.1 Maximum transmit power ................................................................................................................. 11 5.2 RF Exposure Calculation ................................................................................................................. 12 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Power supply: Powered by rechargeable Li-ion battery Battery information Model: 822048 Nominal Voltage: 3.8V DC Rated Capacity: 3.8Wh For BT: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.3 Dual mode Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: Chip Antenna Antenna Gain: 3dBi For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.3 Dual mode Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: Chip Antenna Antenna Gain: 3dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 5 of 12 3.2 Separation Distance Minimum test separation distance: 5mm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144304 Page: 6 of 12 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. All tests were performed at: 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI (Member No. 1937) The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement a…

Text truncated - open the document above for the full version.

2.4GHz Chip Antenna: RAN3216H4R2G45 ______________________________________________________________________________________________________ Application: WLAN, 802.11b/g, Bluetooth, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Electrical Specification Working Frequency Range 2400 ~2484 MHz Peak Gain 3.0dBi (Typ.) Impedance 50 Ohm Return loss 10 dB ( Min) Polarization Linear Azimuth Beamwidth Omni-directional Operation Temperature(°C) -40 ~85°C The specification is defined on EVB. Dimension and Terminal Configuration Part number RAN 3216 H4 R 2G45 (1) (2) (3) (4) (5) (1)Product Type Chip Antenna (2) Size Code 3.2x1.6mm (3) Type Code H4 (4) Packing Tape and reel (5) Frequency 2.45GHz Dimension (mm) No. Terminal Name L 3.2 +-0.20 1 Feeding W 1.6+-0.20 2 Soldering T 1.20+-0.20 A 0.20+-0.20 2.4GHz 2.45HHz Chip Antenna: RAN3216H4R2G45 ______________________________________________________________________________________________________ Evaluation Board Reference PCB Dimension & Antenna Layout Reference unit :mm Electrical Characteristics Return Loss & Radiation Return Loss Frequency (MHz) S11 (dB) 2400 -12.8 2442 -19.8 2484 -11.9 Radiation 2.45GHz Frequency 2445MHz Peak gain 3.0dBi Efficiency 79.2% 2.4GHz 2.45HHz Chip Antenna: RAN3216H4R2G45 ______________________________________________________________________________________________________ Taping Specifications Reel Taping Blister Tape Checking note Index Spec (mm) Internal diameter of reel A 60.20 ± 0.50 External diameter of reel B 178 ± 1.00 Quantity/per reel 3000 pcs Tape material Plastic (embossed) Checking note Index Spec (mm) Sprocket hole D0 1.50 +0.10/-0.00 Distance sprocket hole to outside E1 1.75 ± 0.10 Distance sprocket hole to pocket F 5.50 ± 0.05 Distance sprocket hole to sprocket hole P0 4.00 ± 0.10 Distance pocket to pocket P1 4.00 ± 0.10 Distance sprocket hole to pocket P2 2.00 ± 0.05 Tape width W 12.00 +0.30/-0.10 Pocket width nominal clearance A0 2.28 ± 0.13 Pocket length nominal clearance B0 5.70 ± 0.13 Pocket depth minimum clearance K0 1.58 ± 0.10 Thickness of tape T 0.23 ± 0.02 2.4GHz 2.45HHz Chip Antenna: RAN3216H4R2G45 ______________________________________________________________________________________________________ Reliability Table Test ItemProcedure Requirements Ceramic Type Remark (Reference) Electrical Characterization Fulfill the electrical specification User Spec. Thermal Shock 1. Preconditioning: 50 ± 10°C / 1 hr , then keep for 24 ± 1 hrs at room temp. 2. Initial measure: Spec: refer Initial spec. 3. Rapid change of temperature test: -30°C to +85°C; 100 cycles; 15 minutes at Lower category temperature; 15 minutes at Upper category temperature. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 107 Temperature Cycling 1. Initial measure: Spec: refer Initial spec. 2. 100 Cycles (-30°C to +85°C), Soak Mode=1 (2 Cycle/hours). 3. Measurement at 24 ± 2Hours after test condition. No Visible Damage. Fulfill the electrical specification. JESD22 JA104 High Temperature Exposure 1. Initial measure: Spec: refer Initial spec. 2. Unpowered; 500hours @ T=+85°C. 3. Measurement at 24 ± 2 hours after test. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Low Temperature Storage 1. Initial measure: Spec: refer Initial spec. 2. Unpowered: 500hours @ T= -30°C. 3. Measurement at 24 ± 2 hours after test. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Solderability (SMD Bottom Side) Dipping method: a. Temperature: 235 ± 5°C b. Dipping time: 3 ± 0.5s The solder should cover over 95% of the critical area of bottom side. IEC 60384-21/22 4.10 Soldering Heat Resistance (RSH) Preheating temperature: 150 ± 10°C. Preheating time: 1~2 min. Solder temperature: 260 ± 5°C. Dipping time: 5 ± 0.5s No Visible Damage.IEC 60384-21/22 4.10 Vibration5g's for 20 min., 12 cycles each of 3 orientations Note: Use 8"X5" PCB .031" thick 7 secure points on, one long side and 2 secure points at corners of opposite sides. Parts mounted within 2" from any secure point. Test from 10-2000 Hz. No Visible Damage.MIL-STD-202 Method 204 Mechanical Shock Three shocks in each direction shall be applied along the three mutually perpendicular axes of the test specimen (18 shocks) Peak value: 1,500g’s Duration: 0.5ms Velocity change: 15.4 ft/s Waveform: Half-sine No Visible Damage.MIL-STD-202 Method 213 Humidity Bias 1. Humidity: 85% R.H., Temperature: 85 ± 2 °C. 2. Time: 500 ± 24 hours. 3. Measurement at 24 ± 2hrs after test condition. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 Method 106 2.4GHz 2.45HHz Chip Antenna: RAN3216H4R2G45 ______________________________________________________________________________________________________ Revision History Revision Date Content 1 2020/7/26New issue Board Flex (SMD) 1. Mounting method: IR-Reflow. PCB Size (L:100 × W:40 × T:1.6mm) 2. Apply the load in direction of the arrow until bending reaches 2 mm. No Visible Damage.AEC-Q200 005 AdhesionForce of 1.8Kg for 60 seconds.No Visible Damage Magnification of 20X or greater may be employed for inspection of the mechanical integrity of the device body terminals and body/terminal junction. AEC-Q200 006 Physical Dimension Any applicable method using x10 magnification, micrometers, calipers, gauges, contour projectors, or other measuring equipment, capable of determining the actual specimen dimensions. In accordance with specification. JESD22 JB100

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144302 Page: 1 of 94 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2305001443AT Applicant: Shenzhen Digitech Co., Ltd. Address of Applicant: Room 305, Building A9, Tianliao Industrial Zone, Nanshan, Shenzhen, China Manufacturer: Shenzhen Digitech Co., Ltd. Address of Manufacturer: Room 305, Building A9, Tianliao Industrial Zone, Nanshan, Shenzhen, China Equipment Under Test (EUT): EUT Name: Smart Helmet Model No.: EH20 FCC ID: 2BBG8-EH20 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-05-15 Date of Test: 2023-05-26 to 2023-06-06 Date of Issue: 2023-06-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144302 Page: 2 of 94 Revision Record Version Chapter Date Modifier Remark 01 2023-06-19 Original Authorized for issue by: Darren Yuan/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144302 Page: 3 of 94 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500144302 Page: 4 of 94 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 7 4.3 Measurement Uncertainty .................................................................................................................. 7 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 8 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ........................................................................................... 8 5 Equipment List .......................................................................................................................................... 9 6 Radio Spectrum Technical Requirement ............................................................................................. 13 6.1 Antenna Requirement ...................................................................................................................... 13 6.1.1 Test Requirement: ....................................................................................................................... 13 6.1.2 Conclusion ................................................................................................................................... 13 6.2 Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence ............... 14 6.2.1 Test Requirement: ....................................................................................................................... 14 6.2.2 Conclusion ................................................................................................................................... 14 7 Radio Spectrum Matter Test Results .................................................................................................... 16 7.1 Conducted Peak Output Power...............................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Setup Photos for SZCR2305001443AT FCC ID: 2BBG8-EH20 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Radiated Emissions which fall in the restricted bands Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 Radiated Spurious Emissions Above 1GHz - End of the Appendix -
