2BBM4-E1000Portable Power Station

E1000 Power Station / User Manual Central Eléctrica / Manual de Usuario WARNING: This manual contains important information to ensure the safe operation, handling and storage of this product. To reduce the risk of injury read and understand this manual prior to use. Save the manual for future reference. ADVERTENCIA: Este manual contiene información importante para garantizar la operación, manipulación y al-macenamiento seguros de este producto. Para reducir el riesgo de lesiones, lea y comprenda este manual antes de usarlo. Guarde el manual para futuras consultas. Portable Power Station ENGLISH - 2 IMPORTANT SAFETY RULES WARNING: Risk of Electric Shock. If misused, the voltage generated by this power station can be deadly. Always use common sense and adhere to the manufacturer’s instructions when using this product. WARNING: Explosion Hazard. Do not burn or incinerate the power station. Do not expose this unit to temperatures above 140°F (60°C). Exposure to fire and extreme temperatures can cause an explosion resulting in property damage, personal injury, and death. WARNING: Prior to using the DC charging feature, consult the vehicle operator’s manual or the manufacturer’s website to obtain the vehicle fuse ratings. Verify that the vehicle’s electrical system and fuses can safely supply the energy required to charge the power station. If a fuse opens repeatedly during charging, disconnect the power station and determine the cause of the overload. Do not replace the fuse with a fuse rated higher than the vehicle manufacturer’s recommendation or attempt to circumvent the safety features of the fuse. Doing so could create a risk of fire. SAVE THESE INSTRUCTIONS „ Follow the manufacturer’s instructions when using this product. Misuse can reduce the protection provided by this equipment. „Do not use this device to power life support devices or other necessary medical equipment. „ Do not overload the power station. Exceeding the unit’s wattage/amperage capacity can damage the unit and/or electrical devices connected to it. „ Risk of electric shock. This tool does not provide an electrical path to earth ground when used with a grounded appliance. „ Do not operate, store or handle the power station in wet conditions. Do not submerge the power station. Water entering the power station will increase the risk of electric shock. „ To reduce the risk of electric shock and property damage, the power station should only be used in dry locations. „ Always use the power station in well-ventilated areas. Do not use it in areas where flammable fumes or gases can accumulate, such as an inadequately vented bilge of a boat or near propane tanks. „ Always closely supervise this product when it is used near children. „ Do not insert fingers, hands, or foreign objects into the product. „ To avoid overheating the power station, do not obstruct the unit’s vents. If the power station becomes too hot, it will automatically shut off. „ Keep power station cool. Do not place the unit near heat sources or expose it to excessive heat. „ Keep the power station away from fire or extreme temperatures. Exposure to fire or temperatures may cause an explosion. „ Do not operate or store the power station in locations colder than 4°F (-15.5°C) or hotter than 113°F (45°C). This product should not be stored outside or in your vehicle. „ Do not use the power station or it’s charger if it has been dropped or received a sharp blow. A damaged power station will increase the risk of fire and electric shock. „ Do not charge the power station with a damaged cord, plug, or adapter. „ The power station should only be charged using the power sources listed in the product specifications. „ To avoid damaging the unit, only use cords that are provided or approved by the manufacturer to charge the power station. „ Do not attempt to modify this product or use it with accessories that are not recommended or sold by the product manufacturer. Using incompatible accessories may result in a risk of fire, electric shock, property damage, or injury to persons. „ Be careful when connecting/disconnecting the power station from an outlet or connecting/disconnecting loads from the power station. Do not force the power station’s plug into an outlet. Do not force plugs into the power station. „Do not force a polarized plug (one prong larger than the other) into this product. Flip plug over and retry. „ When disconnecting loads, pull the plug instead of the cord. Pulling the cord may damage the cord or the plug. „ Do not power items with damaged or frayed power cords. „ Do not disassemble the power station. All repairs should be performed by the manufacturer or authorized service person. Using an incorrectly reassembled power station may create a risk of fire or electric shock. „ Do not store the power station near fertilizers, gasoline, or other chemicals. „ Store the product indoors in a dry secure location away from children. „ To avoid damaging the internal battery, the power station should be stored in a partially charged state. ENGLISH - 3 SPECIFICATIONS GENERAL ModelE1000 Capacity907Wh (21.6V) Size13.4 in. (341 mm) [L] x 8.6 in. (219 mm) [W] x 8.4 in. (213 mm) [H] Net Weight20 lbs. (9.1 kg) INPUT DC Input 12-30V DC, 8.5A Max Charge time is approximately 5-6 hours OUTPUT AC (x3) 120V AC, 60Hz, 1000W Max Rated USB-A (x2) 5V DC, 2.4A, 12W Max Per Port USB-A Fast Charge (x2) 5V DC, 3A/9V DC, 2A/12 V DC, 1.5A 18W Max Type-C Fast Charge (x2) 5V DC, 3A/9V DC, 3A/12 V DC, 3A/15V DC, 3A/20V DC, 3.25A 100W 5V DC, 3A/9V DC, 3A/12 V DC, 3A/15V DC, 3A/20V DC, 3.25A 65W DC Output13V DC, 10A Wireless10W OTHERS Cell TypeNCM Cycle Life 500 cycles to 80% capacity @25°C charge and discharge environment 0.5C charge (1.45A per cell), 1 C discharge (2.9A per cell) Protection Overcharge protection, high temperature protection, low temperature protection, over-discharge protection, overload protection, short circuit protection, over-current protection, battery f…
