This document is protected by copyright by Advanced Digital Broadcast, Inc.: © 2011 through 2024. vuTyme™ Installation & User Guide Document Version: Version R01_9_6_2023 Author: David Mailand, ADB Important: These installation instructions require that a professional installation technician conduct the install and configuration of this product. Copyrights: This document is protected by copyright by Advanced Digital Broadcast, Inc.: © 2011 through 2024. Contact Information: Advanced Digital Broadcast, Inc. Email: support‐trc‐[email protected] Revision History: DescriptionDate/Version Initial release.Version R01_9_6_2023 ADB vuTyme™ Install & User Guide • Version R01_9_6_20231 Copyright ADB - Cannot be Reproduced or Copied Contents Chapter 1: ADB‐2682WF SBB Installation & Use . . . . . . . . . . . . . . . . . . . . . . . . . . 2 ADB‐2682WF Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Interface Connections: Operational Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Connection Use Cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Standard‐Basic Connection ‐ Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 VOIP/SIP Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 2nd SBB Connected Over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Standard Basic Connection ‐ WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 2nd SBB Connected Over WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Build Out the Property in vuTyme Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Load Correct vuTyme Firmware to Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Download Firmware to a USB Stick & Upgrade Box . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 SBB Wi‐Fi Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 SBB Installation ‐ Connect the SBB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 SBB Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Register the SBB to the Property & Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Registration Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Connect other Devices to SBB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Chapter 2: Mount the SBB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using a USB Stick to Control SBB Network Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 USB Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Box Support Menus & Diag Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Standards and Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 ADB Global - http://www.adbglobal.com/supportChapter 1: ADB-2682WF SBB Installation & Use ADB vuTyme™ Install & User Guide • Version R01_9_6_20232 CHAPTER 1: ADB‐2682WF SBB INSTALLATION & USE Use the following procedures to complete an on‐site installation of the vuTyme‐enabled ADB‐2682WF set‐ back box (SBB). Important: This SBB is a power‐over‐ethernet (POE) device with two Ethernet ports and a WiFi interface. It is important to pay attention to what connection use cases are possible when the power‐supply (PSU) is used versus the SBB powered over Ethernet (POE). The WiFi connection use cases are also impacted. Seep. 3. 1.1 ADB‐2682WF OVERVIEW See below for SBB renderings and specifications. General: Decoder: ItemDescription Hardware platform / SoC Mediatek MTK5251A (C2U); quad core ARM / 17000DMIPS RAM Memory2 GB DDR4 system memory Flash Memory16GB eMMC *) *) eMMC used for both the SBB firmware and as a storage for DVR‐Lite™. DVR‐Lite™ uses 13GB (out of the total 16GB). Network Connectivity (Wired) 2x Ethernet 10/100 Mbps *) 2 x PoE (1xPoE source + 1xPoE sink) *) 1x 10Base‐T/100Base‐TX (PoE sink port) 1x 10Base‐Te/100Base‐TX (PoE source port) IPv6 is supported Network Connectivity (WiFi) Wi‐Fi client 802.11ax tri‐band 2.4GHz/5GHz/6GHz switchable, WPA2‐PSK and WPA3‐SAE are supported Security CA/DRMPlayReady SL 3000 HDCP 2.3 for HDMI 2.0b NOTE: Irdeto FKPS is not supported with the selected C2U Processor SoftwareADB vuTyme Client EnvironmentalOperating Temperature Range from 5 to 45°C Anti‐tamperSticker (label/seal) ItemDescription Video OutputSD: 576i HD: 576p60, 720p60, 1080i60, 1080p60 4K: 2160p60 Video DecodersMPEG‐2: MP@ML, MP@HL H.264 (AVC) p.10: [email protected], [email protected] H.265 (HEVC) MP‐[email protected] AV1: MP‐[email protected] HDR:HDR10, HLG ADB Global - http://www.adbglobal.com/support1.2 Interface Connections: Operational Rules ADB vuTyme™ Install & User Guide • Version R01_9_6_20233 Interfaces: 1.2 INTERFACE CONNECTIONS: OPERATIONAL RULES See below for a general explanation of how the SBB operates in POE or non‐POE environment. There are some restrictions depending up how the interfaces are used and if POE or regular PSU power is used. 1. Ethernet Ports: By …
Text truncated - open the document above for the full version.
Confidential Request letter Date: October 27, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for confidentiality FCC ID: 2BBO4-ADB-SG23004A Long-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: � Block Diagrams �S chematics �Th eory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified be nefits to its competitors. T he applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Short-Term Confidentiality {STC} P ursuant to DA04-1705 June 15, 2004 of the Commission's public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: � Internal Photos D External Photos D User's Manual � Test Set-up Photos Justification: Due to market confidential, we ask for the short-term confidentiality. Planned Release Date STC: If no date is given, 180 days from grant date will be used. Sincerely, Signature Gl@t!2 �u&t Contact Name: Grz� Nowak Job Title: Product Validation Engineer Email: [email protected]
Report No.: 2380907R-Product Photos Page: 1 of 6 (1) EUT Photo (2) EUT Photo Report No.: 2380907R-Product Photos Page: 2 of 6 (3) EUT Photo (4) EUT Photo Report No.: 2380907R-Product Photos Page: 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 2380907R-Product Photos Page: 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 2380907R-Product Photos Page: 5 of 6 (9) EUT Photo (10) EUT Photo Report No.: 2380907R-Product Photos Page: 6 of 6 (11) EUT Photo (12) EUT Photo
Artwork- Charter SBB Scale 1:1 Prepared by : Sam Huang Housing color : Black Version : 1.0Date : 10/04/2023 Logo, Wording and Symbol color : Pantone 11-0601TCX (White) Advanced Digital Broadcast, Ltd. 86mm 77mm Logo centered vertically and horizontally on top cover of device ETHERNETIRUSBPOWER 12V 3.0A 48V 0.35A max ETHERNETRESET PoE sourcePoE sink 33mm 10mm10mm 48V 0.35A max
4 5 . 0 0 555.00 Model : ADB-2682WF ADB P/N: 151179101 S/N: BHTJAYWWXXXXX MAC ETH Sink: C4 77 AF XX XX XX MAC ETH Source: C4 77 AF XX XX XX MAC WIFI: C4 77 AF XX XX XX Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Made in China Housing & gift box Label Manufactured by Advanced Digital Broadcast SA C5 E537145 FCC ID: 2BBO4-ADB-SG23004A Indoor use only CARTON S/N : PCBHTJYWWXXXXX Qty : XX ADB P/N : 151179101 Made in China S/N : BHTJAYWWXXXXX ADB-2682WF Manufactured by Advanced Digital Broadcast SA 60.00 1 1 0 . 0 0 S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX Carton Label S/N : BHTJAYWWXXXXX S/N : BHTJAYWWXXXXX Qty :XXX ADB P/N : 151179101 PALLET S/N : PPBHTJYWWXXXXX Made in China ADB-2682WF Manufactured by Advanced Digital Broadcast SA CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX Pallet label SCALE 1:2 297 210 CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX CARTON S/N : PCBHTJYWWXXXXX
7 BT Ant2Ant1 Antenna Photo and Information
7 BT Ant2Ant1 Antenna Photo and Information
7 BT Ant2Ant1 Antenna Photo and Information
Report No.: 2380907R-Product Photos Page: 1 of 13 (1) EUT Photo (2) EUT Photo Report No.: 2380907R-Product Photos Page: 2 of 13 (3) EUT Photo (4) EUT Photo Report No.: 2380907R-Product Photos Page: 3 of 13 (5) EUT Photo (6) EUT Photo Report No.: 2380907R-Product Photos Page: 4 of 13 (7) EUT Photo (8) EUT Photo RF Module Report No.: 2380907R-Product Photos Page: 5 of 13 (9) EUT Photo (10) EUT Photo Report No.: 2380907R-Product Photos Page: 6 of 13 (11) EUT Photo (12) EUT Photo Report No.: 2380907R-Product Photos Page: 7 of 13 (13) EUT Photo (14) EUT Photo Report No.: 2380907R-Product Photos Page: 8 of 13 (15) EUT Photo (16) EUT Photo Report No.: 2380907R-Product Photos Page: 9 of 13 (17) EUT Photo (18) EUT Photo WLAN Antenna WLAN Antenna BT Antenna Report No.: 2380907R-Product Photos Page: 10 of 13 (19) EUT Photo (20) EUT Photo Report No.: 2380907R-Product Photos Page: 11 of 13 (21) EUT Photo (22) EUT Photo Report No.: 2380907R-Product Photos Page: 12 of 13 (23) EUT Photo (24) EUT Photo Report No.: 2380907R-Product Photos Page: 13 of 13 (25) EUT Photo (26) EUT Photo
Report No.: 2380907R-RFUSV17S-A Page: 1 of 7 Test report No.: 2380907R-RFUSV17S-A RF Exposure Report Product Name Set Back Box with Wi-Fi6E, BT & PoE Trademark ADB, Charter Model and /or type reference ADB-2682WF FCC ID 2BBO4-ADB-SG23004A Applicant ́s name / address ADB SA Route de Lausanne 319, CH-1293 Bellevue, Switzerland Manufacturer ́s name ADB SA Test method requested, standard KDB 447498 D01 v06 Minimum test separation distance ≥ 20 cm For low power devices Verdict Summary IN COMPLIANCE Documented By (Senior Project Specialist / Joanne Lin) Approved By (Senior Engineer / Alan Chen) Approved By (Manager / Tim Sung) Date of Receipt 2023/08/30 Date of Issue 2023/11/10 Report Version V1.0 Report No.: 2380907R-RFUSV17S-A Page: 2 of 7 Competences and Guarantees DEKRA is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA has a calibration and maintenance program for its measurement equipment. DEKRA guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated in the report and it is based on the knowledge and technical facilities available at DEKRA at the time of performance of the test. DEKRA is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA. General conditions 1. The test results relate only to the samples tested. 2. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. 3. This report must not be used to claim product endorsement by TAF or any agency of the government. 4. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. 5. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2380907R-RFUSV17S-A Page: 3 of 7 Revision History Report No. Ve r s i o n Description Issued Date 2380907R-RFUSV17S-A V1.0 Initial issue of report. 2023/11/10 Report No.: 2380907R-RFUSV17S-A Page: 4 of 7 1. General Information 1.1. EUT Description Product Name Set Back Box with Wi-Fi6E, BT & PoE Trademark ADB, Charter Model and /or type reference ADB-2682WF Note: For more detailed information please refer to report No.: 2380907R-RFUSV01S-A, 2380907R-RFUSV01S-B, 2380907R-RFUSV01S-C, 2380907R-RFUSV03S-A, 2380907R-RFUSV03S-B, 2380907R-RFUSV03S-C, 2380907R-RFUSV03S-D, Report No.: 2380907R-RFUSV17S-A Page: 5 of 7 2. Test Facility USA FCC Registration Number: TW0033 Canada CAB Identifier Number: TW3023 / Company Number: 26930 Site Description Accredited by TAF Accredited Number: 3023 Test Laboratory DEKRA Testing and Certification Co., Ltd. Linkou Laboratory Address No.5-22, Ruishukeng Linkou District, New Taipei City, 24451, Taiwan, R.O.C Performed Location No. 26, Huaya 1st Rd., Guishan Dist.,Taoyuan City 333411, Taiwan, R.O.C. Phone Number +886-3-275-7255 Fax Number +886-3-327-8031 Report No.: 2380907R-RFUSV17S-A Page: 6 of 7 3. RF Exposure Evaluation 3.1. Standard Applicable According to KDB 447498 D01 (7.1), A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. 3.2. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f2) 6 30-300 61.4 0.163 1.0 6 300-1,500 f/300 6 1,500-100,000 5 6 (B) Limits for General Population/ Uncontrolled Exposures 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in a host device is ≤ 1.0 Report No.: 2380907R-RFUSV17S-A Page: 7 of 7 3.3. Test Result of RF Exposure Evaluation Product Set Back Box with Wi-Fi6E, BT & PoE Test Item RF Exposure Evaluation Band Conducted output power (dBm) Antenna Gain (dBi) E.I.R.P (dBm) E.I.R.P (mW) Power Density at R = 20 cm (mW/cm2) Limit (mW/cm2) Bluetooth 11.12 3.80 14.920 31.046 0.0062 1 2.4 GHz 21.20 3.13 24.330 271.019 0.0539 1 5 GHz 21.06 3.49 24.550 285.102 0.0567 1 6 GHz -- -- 15.000 31.623 0.0063 1 Note: The conducted output power is refer to report No.: 2380907R-RFUSV01S-A, 2380907R-RFUSV01S-B, 2380907R-RFUSV01S-C, 2380907R-RFUSV03S-A, 2380907R-RFUSV03S-B, 2380907R-RFUSV03S-C from the DEKRA. Results PASS
1 規 格 承 認 書 Approval Sheet 客 戶 名 稱 Customer Name: 百一 產 品 名 稱 Product description: Ant1 產 品 型 號 Model Name: ADB-2682WF 泓 淋 料 號 Hong Lin P/N: 290-70464 客 戶 料 號 Customer P/N: 版 別 日 期 V ersion:X2 D at e: 20 23.10.12 客戶承認簽印 CUSTOMER APPROVED BY 供應商承認簽印 VENDER APPROVED BY Checked By: Checked By: 李源泉 Approval By: Approval By :严加星 49031-01103-HB 工厂/Factory: 1.越南,北宁省,桂武县,扶梁社,桂武三工业区CN17A-2地块 Lot No. CN17A-2 Que Vo 3 Industrial Park - Phu Luong Commune - Que Vo District - Bac Ninh Province-VietNam. 2.江蘇省常熟市高新技術產業園柳州路 8 號 No.8 Liuzhou Road, Yushan Industrial Park, Hi‐t ech Development Zone, Changshu, Jiangsu, China 2 Content ItemPage 1.规格表...................................................................................3 2.测试资料....................................................................4-40 3.成品图..............................................................................41 3 一、 规格表 1.1 Electrical Properties 1.1.1 Frequency Range---------------------- 2402-2484MHz ---------------------- 5150 -5850MHz ---------------------- 5935 -7115MHz 1.1. 2 Impedance-------- ---------------------- 50Ω 1.1.3 Return Loss----------------------------- -10dB or Less 1.1.4 Peak Gain--------------------------------3.13dBi @2402-2484MHz --------------------------------2.61dBi @5150-5250MHz --------------------------------2.29dBi @5250-5350MHz --------------------------------3.49dBi @5470-572 5MHz --------------------------------3.49dBi @5725-587 5MHz --------------------------------3.44dBi @5925-642 5MHz --------------------------------2.28dBi @6425-652 5MHz --------------------------------2.48dBi @6525-6875MHz -------------------------------- 2.70dBi @6875-712 5MHz 1.1.5 Admitted Power-------------------------- 1W 1.1.6 Cable-------------------------------------Ø 1.13 LLS Cable 1.1.7 Antenna type---------------------------- PCB 1.2 Physical Properties 1.2.1 Antenna Body----------------------- FR4 1.2.2 Operating Temp -------------------- -10°C~+60°C 1.2.3 Storage Temp----------------------- -10°C~+70°C 2023/10/111 Prepared by: Lay Cheng Date: 4th of September,2023 Version: V5.0 Antenna Evaluation Report for ADB-2682WF Project -Passive measurement report - 2 Version DescriptionDate V1.0Simulation Evaluation20230414 V2.0Factory Sample Fine Tuning20230510 V3.0 Ant1 and BT Location Change. Add Cable Routing. 20230510 V4.0Horizontal Measurement.20230710 V4.1Vertical Measurement.20230710 V5.0Fine tuning20230904 Version information 3 •Test Environment and Equipment •DUT Orientation Setting •Testing Contents –Antenna Photo and Information –Measurement Results: •Return Loss & Isolation •Antenna Efficiency, Peak gain •Antenna 2D Radiation Patterns Executive Summary 4 •ETS-Lindgren AMS-8500 Antenna Measurement System • EM Quest EMQ-100 Software • Model 3164-04 Diagonal Dual Polarized Horn antenna • Frequency range: 700 MHz –7.2 GHz • Positioning Systems • Chamber Room Size: 7.32 m L x 3.66 m W x 3.66 m H VSWR were performed using an Agilent S-parameter Network Analyzer. •SATIMO SG 24 Multi-Probe Antenna Measurement System • Angle between probes: 15° •Frequency range: 400 MHz –8.5 GHz • Chamber Room Size: 4.0 m L x 4.0 m W x 4.0 m H Test Environment & Equipment 6 Antenna Photo and Information Y X Z 8 Antenna Photo and Information DesignatorFrequency RangeAntenna TypeDimension Cable Length (Total) Cable ColorCable TypeConnector Type Ant1 2402 -2484 MHz 5150 -5875 MHz 5925-7125 MHz PCB Antenna35x 20 x 0.6 mm82mmBlack ∅ 1.13 Low Loss IPEX Ant2 2402 -2484 MHz 5150 -5875 MHz 5925-7125 MHz PCB Antenna35x 20 x 0.6 mm145mmWhite ∅ 1.13 Low Loss IPEX BT2402 -2484 MHzPCB Antenna35x 20 x 0.6 mm180mmGray ∅ 1.13 Low Loss IPEX 9 Measurement Results •Return Loss & Isolation •Antenna Efficiency, Peak Gain •Antenna 2D Realized Gain Radiation Patterns @Total Polarization Return Loss & Isolation 10 Ant1 11 Ant2 12 BT Isolation Between Antennas 13 -40.00 -35.00 -30.00 -25.00 -20.00 -15.00 -10.00 -5.00 0.00 2000250030003500400045005000550060006500700075008000 Isolation (dB) Frequency (MHz) Ant1-Ant2 Ant1-BT Ant2-BT Ant1 Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402661.835150682.615925673.44 2412661.885200652.356095662.97 2422651.995250652.136255652.23 2432662.245325662.296425642.28 2442672.485400662.526475642.25 2452682.615470662.576525652.27 2462672.735500672.906715682.43 2472662.835600663.466735642.14 2484663.135725653.496875662.48 5775663.356975662.59 5825673.157075652.70 5875693.317125642.27 14 Antenna Efficiency & Peak Gain Ant2 Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402562.415150632.055925652.86 2412562.595200611.836095632.62 2422572.695250612.026255623.06 2432572.795325611.996425653.56 2442593.005400642.216475633.34 2452593.025470642.416525623.44 2462583.015500662.716715633.39 2472572.925600662.866735603.23 2484582.955725642.546875613.19 5775632.586975642.94 5825642.867075622.62 5875642.867125632.56 15 16 BT Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402683.70 2412683.69 2422683.64 2432683.66 2442703.80 2452703.78 2462693.69 2472683.58 2484683.76 17 2D Radiation Patterns Of Ant1 in 2G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 18 2D Radiation Patterns Of Ant1 in 2G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X Z Z X 19 2D Radiation Patterns Of Ant1 in 2G Band at YZ Plan Gain Theta Gain PhiGain Total Y Z Y Z Y Z Z Y 20 2D Radiation Patterns Of Ant1 in 5G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 21 2D Radiation Patterns Of Ant1 in 5G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X Z Z X 22 2D Radiation Patterns Of Ant1 in 5G Band at YZ Plan Gain Theta Gain PhiGain Total Y Z Y Z Y Z Z Y 23 2D Radiation Patterns Of Ant1 in 6G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 24 2D Radiation Patterns Of Ant1 in 6G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X…
Text truncated - open the document above for the full version.
1 規 格 承 認 書 Approval Sheet 客 戶 名 稱 Customer Name: 百一 產 品 名 稱 Product description: Ant2 產 品 型 號 Model Name: ADB-2682WF 泓 淋 料 號 Hong Lin P/N: 290-70465 客 戶 料 號 Customer P/N: 版 別 日 期 V ersion:X2 D at e: 20 23.10.12 客戶承認簽印 CUSTOMER APPROVED BY 供應商承認簽印 VENDER APPROVED BY Checked By: Checked By: 李源泉 Approval By: Approval By:严加星 49031-01104-HB 工厂/Factory: 1.越南,北宁省,桂武县,扶梁社,桂武三工业区CN17A-2地块 Lot No. CN17A-2 Que Vo 3 Industrial Park - Phu Luong Commune - Que Vo District - Bac Ninh Province-VietNam. 2.江蘇省常熟市高新技術產業園柳州路 8 號 No.8 Liuzhou Road, Yushan Industrial Park, Hi‐t ech Development Zone, Changshu, Jiangsu, China 2 Content ItemPage 1.规格表...................................................................................3 2.测试资料....................................................................4-40 3.成品图..............................................................................41 3 一、 规格表 1.1 Electrical Properties 1.1.1 Frequency Range---------------------- 2402-2484MHz ---------------------- 5150 -5850MHz ---------------------- 5935 -7115MHz 1 .1.2 Impedance------------------------------ 50Ω 1.1.3 Return Loss----------------------------- -10dB or Less 1.1.4 Peak Gain--------------------------------3.02dBi @2402-2484MHz --------------------------------2.05dBi @5150-5250MHz --------------------------------2.02dBi @5250-53 50MHz --------------------------------2.86dBi @5470-5 725MHz --------------------------------2.86dBi @5725-5875MHz --------------------------------3.56dBi @5925-642 5MHz --------------------------------3.56dBi @6425-652 5MHz --------------------------------3.44dBi @6525-687 5MHz --------------------------------3.19dBi @6875-7125MHz 1.1.5 Admitted Power-------------------------- 1W 1.1.6 Cable-------------------------------------Ø 1.13 LLS Cable 1.1.7 Antenna type---------------------------- PCB 1.2 Physical Properties 1.2.1 Antenna Body----------------------- FR4 1.2.2 Operating Temp -------------------- -10°C~+60°C 1.2.3 Storage Temp----------------------- -10°C~+70°C 2023/10/111 Prepared by: Lay Cheng Date: 4th of September,2023 Version: V5.0 Antenna Evaluation Report for ADB-2682WF Project -Passive measurement report - 2 Version DescriptionDate V1.0Simulation Evaluation20230414 V2.0Factory Sample Fine Tuning20230510 V3.0 Ant1 and BT Location Change. Add Cable Routing. 20230510 V4.0Horizontal Measurement.20230710 V4.1Vertical Measurement.20230710 V5.0Fine tuning20230904 Version information 3 •Test Environment and Equipment •DUT Orientation Setting •Testing Contents –Antenna Photo and Information –Measurement Results: •Return Loss & Isolation •Antenna Efficiency, Peak gain •Antenna 2D Radiation Patterns Executive Summary 4 •ETS-Lindgren AMS-8500 Antenna Measurement System • EM Quest EMQ-100 Software • Model 3164-04 Diagonal Dual Polarized Horn antenna • Frequency range: 700 MHz –7.2 GHz • Positioning Systems • Chamber Room Size: 7.32 m L x 3.66 m W x 3.66 m H VSWR were performed using an Agilent S-parameter Network Analyzer. •SATIMO SG 24 Multi-Probe Antenna Measurement System • Angle between probes: 15° •Frequency range: 400 MHz –8.5 GHz • Chamber Room Size: 4.0 m L x 4.0 m W x 4.0 m H Test Environment & Equipment 6 Antenna Photo and Information Y X Z 8 Antenna Photo and Information DesignatorFrequency RangeAntenna TypeDimension Cable Length (Total) Cable ColorCable TypeConnector Type Ant1 2402 -2484 MHz 5150 -5875 MHz 5925-7125 MHz PCB Antenna35x 20 x 0.6 mm82mmBlack ∅ 1.13 Low Loss IPEX Ant2 2402 -2484 MHz 5150 -5875 MHz 5925-7125 MHz PCB Antenna35x 20 x 0.6 mm145mmWhite ∅ 1.13 Low Loss IPEX BT2402 -2484 MHzPCB Antenna35x 20 x 0.6 mm180mmGray ∅ 1.13 Low Loss IPEX 9 Measurement Results •Return Loss & Isolation •Antenna Efficiency, Peak Gain •Antenna 2D Realized Gain Radiation Patterns @Total Polarization Return Loss & Isolation 10 Ant1 11 Ant2 12 BT Isolation Between Antennas 13 -40.00 -35.00 -30.00 -25.00 -20.00 -15.00 -10.00 -5.00 0.00 2000250030003500400045005000550060006500700075008000 Isolation (dB) Frequency (MHz) Ant1-Ant2 Ant1-BT Ant2-BT Ant1 Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402661.835150682.615925673.44 2412661.885200652.356095662.97 2422651.995250652.136255652.23 2432662.245325662.296425642.28 2442672.485400662.526475642.25 2452682.615470662.576525652.27 2462672.735500672.906715682.43 2472662.835600663.466735642.14 2484663.135725653.496875662.48 5775663.356975662.59 5825673.157075652.70 5875693.317125642.27 14 Antenna Efficiency & Peak Gain Ant2 Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402562.415150632.055925652.86 2412562.595200611.836095632.62 2422572.695250612.026255623.06 2432572.795325611.996425653.56 2442593.005400642.216475633.34 2452593.025470642.416525623.44 2462583.015500662.716715633.39 2472572.925600662.866735603.23 2484582.955725642.546875613.19 5775632.586975642.94 5825642.867075622.62 5875642.867125632.56 15 16 BT Frequency (MHZ) Efficiency (%) Peak Gain (dBi) 2402683.70 2412683.69 2422683.64 2432683.66 2442703.80 2452703.78 2462693.69 2472683.58 2484683.76 17 2D Radiation Patterns Of Ant1 in 2G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 18 2D Radiation Patterns Of Ant1 in 2G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X Z Z X 19 2D Radiation Patterns Of Ant1 in 2G Band at YZ Plan Gain Theta Gain PhiGain Total Y Z Y Z Y Z Z Y 20 2D Radiation Patterns Of Ant1 in 5G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 21 2D Radiation Patterns Of Ant1 in 5G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X Z Z X 22 2D Radiation Patterns Of Ant1 in 5G Band at YZ Plan Gain Theta Gain PhiGain Total Y Z Y Z Y Z Z Y 23 2D Radiation Patterns Of Ant1 in 6G Band at XY Plan Gain Theta Gain PhiGain Total Y X Y X Y X X Y 24 2D Radiation Patterns Of Ant1 in 6G Band at XZ Plan Gain Theta Gain PhiGain Total X Z X Z X Z …
Text truncated - open the document above for the full version.
1 規 格 承 認 書 Approval Sheet 客 戶 名 稱 Customer Name: 百一 產 品 名 稱 Product description: Ant2 產 品 型 號 Model Name: ADB-2682WF 泓 淋 料 號 Hong Lin P/N: 290-70465 客 戶 料 號 Customer P/N: 版 別 日 期 V ersion:X2 D at e: 20 23.10.12 客戶承認簽印 CUSTOMER APPROVED BY 供應商承認簽印 VENDER APPROVED BY Checked By: Checked By: 李源泉 Approval By: Approval By:严加星 49031-01104-HB 工厂/Factory: 1.越南,北宁省,桂武县,扶梁社,桂武三工业区CN17A-2地块 Lot No. CN17A-2 Que Vo 3 Industrial Park - Phu Luong Commune - Que Vo District - Bac Ninh Province-VietNam. 2.江蘇省常熟市高新技術產業園柳州路 8 號 No.8 Liuzhou Road, Yushan Industrial Park, Hi‐t ech Development Zone, Changshu, Jiangsu, China 2 Content ItemPage 1.规格表...................................................................................3 2.测试资料....................................................................4-40 3.成品图..............................................................................41 3 一、 规格表 1.1 Electrical Properties 1.1.1 Frequency Range----…
Text truncated - open the document above for the full version.
No.26, Huaya 1st Rd., · Taoyuan City · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15C | 2.41 GHz - 2.46 GHz | 500.00 mW |
