2BBO6-Z10repeater

3.2 3.1 3.3 WIRELESS 2.4G-XXXX WIRELESS 5G-XXXX WIRELESS 2.4G-XXXXWIRELESS 5G-XXXX 192.168.11.1 Routing Mode Settings: Product Description This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: XiXi Technology (Shenzhen) CO,Ltd Grantee code: 2BBO6 FCC ID: 2BBO6-Z10 FRN: 0033897315 Contact Name: Liu xiaodong Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen Telephone: 18607534171 Fax: 18607534171 E-mail: [email protected] [XiXi Technology (Shenzhen) CO,Ltd] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [XiXi Technology (Shenzhen) CO,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/10/31 Applicant’s Name: Liu xiaodong US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: XiXi Technology (Shenzhen) CO,Ltd Grantee code: 2BBO6 FCC ID: 2BBO6-Z10 FRN: 0033897315 Contact Name: Liu xiaodong Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen Telephone: 18607534171 Fax: 18607534171 E-mail: [email protected] i. [XiXi Technology (Shenzhen) CO,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [XiXi Technology (Shenzhen) CO,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [XiXi Technology (Shenzhen) CO,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/10/31 Applicant’s Name: Liu xiaodong Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

XiXi Technology (Shenzhen) CO,Ltd Product Similarity Declaration Company: XiXi Technology (Shenzhen) CO,Ltd Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen Product Name: repeater Model Number: Z10, Z10A FCC Identifier: 2BBO6-Z10 We (XiXi Technology (Shenzhen) CO,Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Liu xiaodong Date: 2023-10-31 Title: Manager Signature of applicant:

XiXi Technology (Shenzhen) CO,Ltd 1/1 Letter of Authorization Company: XiXi Technology (Shenzhen) CO,Ltd Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen Product Name: repeater Model Number: Z10, Z10A FCC Identifier: 2BBO6-Z10 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Liu xiaodong Date: 2023-10-31 Title: Manager Signature of applicant:

XiXi Technology (Shenzhen) CO,Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-10-31 Subject: Request for Confidentiality FCC ID: 2BBO6-Z10 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Liu xiaodong Title: Manager ☒

C5266091_X13_Ed.1 1/1 XiXi Technology (Shenzhen) CO,Ltd FCC Software Configuration Control Declaration Date: 2023-10-31 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: repeater / Z10, Z10A Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Liu xiaodong Date: 2023-10-31 Title: Manager Signature of applicant:

Z10 ANT3 WIFI 5G ANT1 WIFI 2.4G ANT4 WIFI 5G ANT2 WIFI 2.4G Z10A

Size: 26*20mm M/N: Z10 FCC ID: 2BBO6-Z10 Label location

FCC ID: 2BBO6-Z10 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4Gmode: ANT1&ANT2 MIMO Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Antenna1 Antenna2 Antenna1 Antenna2 Antenna1 Antenna2 802.11b 16.515 16.777 44.8229 47.6102 0.02090 0.02220 1.0 PASS 802.11g 13.379 13.585 21.7721 22.8297 0.01015 0.01065 1.0 PASS 802.11n20 14.244 14.406 26.5705 27.5804 0.01239 0.01286 1.0 PASS 802.11n40 13.611 13.885 22.9668 24.4625 0.01071 0.01141 1.0 PASS Remark: antenna gain=3.7dBi wifi 5G mode: ANT3&ANT4 MIMO Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Antenna3 Antenna4 Antenna3 Antenna4 Antenna3 Antenna4 802.11a 7.137 7.144 5.1725 5.1808 0.00210 0.00210 1.0 PASS 802.11n HT20 7.422 7.336 5.5233 5.4150 0.00224 0.00220 1.0 PASS 802.11n HT40 6.746 6.215 4.7272 4.1831 0.00192 0.00170 1.0 PASS 802.11ac HT20 6.642 6.713 4.6153 4.6914 0.00187 0.00191 1.0 PASS 802.11ac HT40 6.612 6.011 4.5835 3.9912 0.00186 0.00162 1.0 PASS 802.11ac HT80 6.504 5.979 4.4710 3.9619 0.00182 0.00161 1.0 PASS Remark: antenna gain=3.1dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits = 0.02090/1 + 0.02220/1 + 0.00224/1 + 0.00220/1 = 0.04758< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

-1- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com M/N: WIFI 2.4/5.8G antenna test report Jeany Ling Nov. 23, 2022 •Antenna structure(mm) -2- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com [RTL8821CS] module antenna test report •Photo -4- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com •Return Loss [RTL8821CS] module antenna test report 234567 Frequency (GHz) 40 20 0 Return Loss(dB) 10 30 * C4=C5=NC, L1=0ohm R e a l t e k •Radiation Patterns –Frequency : 2400MHz, 2450MHz, 2480MHz, 5150MHz, 5500MHz, 5850MHz and 5925MHz –Test plane : xy-plane, xz-plane and yz-plane –Input power : SG 0dBm –Place: RTK 4F chamber –Horn h: horizontal polarization –Horn v: vertical polarization SG AUT Horn -z xy-plane SG AUT Horn y xz-plane SG AUT Horn x yz-plane y x R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.8-4.8 Pol.peakavg. v-4.8-12.6 xy-plane yz-plane Pol.peakavg. v-2.5-6.7 Pol.peakavg. h-5.5-12.4 Pol.peakavg. v-5.8-11.8 Pol.peakavg. h+1.4-6.1 xz-plane •Radiation Patterns –2400 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.5-4.4 Pol.peakavg. v-5.4-11.3 xy-plane yz-plane Pol.peakavg. v+0.1-4.2 Pol.peakavg. h-4.2-11.8 Pol.peakavg. v-4.4-10.6 Pol.peakavg. h+1.7-5.2 xz-plane •Radiation Patterns –2450 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.7-3.9 Pol.peakavg. v-4.0-10.8 xy-plane yz-plane Pol.peakavg. v-0.5-4.5 Pol.peakavg. h-6.2-12.5 Pol.peakavg. v-4.1-10.2 Pol.peakavg. h+1.8-5.3 xz-plane •Radiation Patterns –2480 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+2.1-2.4 Pol.peakavg. v+0.4-8.5 xy-plane yz-plane Pol.peakavg. v-0.8-5.0 Pol.peakavg. h-2.6-7.7 Pol.peakavg. v+1.7-2.4 Pol.peakavg. h+1.3-4.0 xz-plane •Radiation Patterns –5150 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.1-3.6 Pol.peakavg. v-0.1-8.9 xy-plane yz-plane Pol.peakavg. v-0.6-4.1 Pol.peakavg. h-1.6-7.3 Pol.peakavg. v-0.1-3.1 Pol.peakavg. h+2.6-4.0 xz-plane •Radiation Patterns –5500 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.5-2.5 Pol.peakavg. v+2.1-7.2 xy-plane yz-plane Pol.peakavg. v+0.9-2.5 Pol.peakavg. h-2.3-7.7 Pol.peakavg. v+2.2-1.5 Pol.peakavg. h+3.1-3.2 xz-plane •Radiation Patterns –5850 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.5-2.8 Pol.peakavg. v+1.3-7.6 xy-plane yz-plane Pol.peakavg. v+1.0-1.9 Pol.peakavg. h-1.6-6.6 Pol.peakavg. v+1.4-1.7 Pol.peakavg. h+2.9-3.5 xz-plane •Radiation Patterns –5925 MHz vertical R e a l t e k [RTL8821CS] module antenna test report •Antenna Gain Table Frequency (MHz)Peak gain (dBi) 2400+1.8 2450+3.5 2480+3.7 Frequency (MHz)Peak gain (dBi) 5150+2.1 5500+3.1 5850+3.1 5925+2.9 XiXi Technology (Shenzhen) CO,Ltd 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 69 FCC Part 15E Test Report FCC ID: 2BBO6-Z10 Applicant: XiXi Technology (Shenzhen) CO, Ltd Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen Manufacturer: XiXi Technology (Shenzhen) CO, Ltd Address: 5 / F, Building 2, Watsi Science Park, Datang Road, Guanlan, Longhua District, Shenzhen EUT: repeater Trade Mark: N/A Model Number: Z10 Z10A Date of Receipt: Sep. 01, 2023 Test Date: Sep. 01, 2023 - Sep. 14, 2023 Date of Report: Sep. 14, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 E 15.407 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20230914012E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 69 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~40GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 25 3.3.1 TEST REQUIREMENT: 25 3.3.2 TEST PROCEDURE 25 3.3.3 DEVIATION FROM TEST STANDARD 25 3.3.4 TEST SETUP 25 3.3.5 EUT OPERATING CONDITIONS 25 4 . PEAK OUTPUT POWER 28 4.1 APPLIED PROCEDURES / LIMIT 28 4.1.1 TEST PROCEDURE 28 4.1.2 DEVIATION FROM STANDARD 28 4.1.3 TEST SETUP 28 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 69 Table of Contents Page 4.1.4 EUT OPERATION CONDITIONS 28 4.1.5 TEST RESULTS 29 5 . POWER SPECTRAL DENSITY TEST 37 5.1 APPLIED PROCEDURES / LIMIT 37 5.1.1 TEST PROCEDURE 37 5.1.2 DEVIATION FROM STANDARD 37 5.1.3 TEST SETUP 37 5.1.4 EUT OPERATION CONDITIONS 37 5.1.5 TEST RESULTS 38 6 . 6DB BANDWIDTH TEST 46 6.1 APPLIED PROCEDURES / LIMIT 46 6.1.1 TEST PROCEDURE 46 6.1.2 DEVIATION FROM STANDARD 46 6.1.3 TEST SETUP 46 6.1.4 EUT OPERATION CONDITIONS 46 6.1.5 TEST RESULTS 47 7 . DUTY CYCLE TEST SIGNAL 54 7.1 APPLIED PROCEDURES / LIMIT 54 7.1.1 TEST PROCEDURE 54 7.1.2 DEVIATION FROM STANDARD 54 7.1.3 TEST SETUP 54 7.1.4 EUT OPERATION CONDITIONS 54 7.1.5 TEST RESULTS 55 8 . FREQUENCY STABILITY 58 8.1 APPLIED PROCEDURES / LIMIT 58 8.1.1 TEST PROCEDURE 58 8.1.2 DEVIATION FROM STANDARD 58 8.1.3 TEST SETUP 58 8.1.4 EUT OPERATION CONDITIONS 58 8.1.5 TEST RESULTS 59 9 . TRANSMISSION IN THE ABSENCE OF DATA 61 9.1 STANDARD REQUIREMENT 61 9.2 TEST RESULT 61 10 . ANTENNA REQUIREMENT 61 10.1 STANDARD REQUIREMENT 61 10.2 EUT ANTENNA 61 11 . TEST SEUUP PHOTO 62 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 69 Table of Contents Page 12 . EUT PHOTO 64 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 69 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.407(b), 15.209 Radiated Spurious Emission PASS 15.407 (b) Band Edge Emission PASS 15.407 (a) Averaging Output Power PASS 15.407 (a) Power Spectral Density PASS 15.403(i) 15.407(e) 6dB bandwidth PASS 15.407(g) Frequency Stability PASS 15.407(c) Transmission in case of Absence of Information PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230914012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 69 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: repeater Trademark N/A Model No.: Z10 Z10A Model Difference The product's different for model number and appearance …

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
