2BBQS-GC596910Sewing Machine for household use

INSTRUCTION MANUAL SE9150 / SE9155 SE9180 / SE9185 IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic safety precautions should always be followed, including the following: Read all instructions before using this sewing machine. Keep the instructions at a suitable place close to the machine. Make sure to hand them over if the machine is given to a third party. DANGER – TO REDUCE THE RISK OF ELECTRIC SHOCK: A sewing machine should never be left unattended when plugged in. The electrical socket, to which the machine is plugged in should be easily accessible. Always unplug this sewing machine from the electric outlet immediately after using and before cleaning, removing covers, lubricating or when making any other user servicing adjustments mentioned in the instruction manual. WARNING – TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSON: • This appliance is intended for use by adults. The appliance can be used with adult supervision by (i) children aged from 8 to 12 years and (ii) persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given instruction concerning use of the appliance in a safe way and understand the hazards involved. Cleaning and user maintenance shall not be made by children without supervision. It is not allowed for anyone to play with the machine. Children up to 8 years are not allowed to use the machine. • Do not allow to be used as a toy. Close attention is necessary when this sewing machine is used by or near children. • Use this sewing machine only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as contained in this manual. • Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the sewing machine to the nearest authorized dealer or service center for examination, repair, electrical or mechanical adjustment. • Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the sewing machine and foot control free from the accumulation of lint, dust, and loose cloth. • Keep fingers away from all moving parts. Special care is required around the sewing machine needle. • Always use the proper needle plate. The wrong plate can cause the needle to break. • Do not use bent needles. • Do not pull or push fabric while stitching. It may deflect the needle causing it to break. • Wear safety glasses. • Switch the sewing machine off (“0”) when making any adjustment in the needle area, such as threading needle, changing needle, threading bobbin, or changing presser foot, etc. • Never drop or insert any object into any opening. • Do not use outdoors. • Do not operate where aerosol (spray) products are being used or where oxygen is being administrated. • To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet. • Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. • The foot control is used to operate the machine. Never place other objects on the foot control. • Do not use the machine if it is wet. • If the LED lamp is damaged or broken, it must be replaced by the manufacturer or its service agent or a similarly qualified person, in order to avoid a hazard. • If the cord connected with the foot control is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person, in order to avoid a hazard. • The noise level under normal operating conditions is less than 76dB(A). • The machine must only be used with foot control of type 33911.00025 manufactured by Shang Gong Group Co., Ltd. Jiangsu Household Sewing Machine Branch (China). SAVE THESE INSTRUCTIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To satisfy radio frequency exposure requirements, a separation distance of 8” (20 cm) or more should be maintained between this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. The built-in antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the authorized SINGER® retailer or an experienced radio/TV technician for help. The included interface cable should be used in order to ensure compliance with the limits for a Class B digital device. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Federal Communication Commission Interference Statement For the USA and Canada Responsible party:Singer Sourcing Limited LLC 1714 Heil Quaker Boulevard, Suite 130, LaVergne, TN 37086 …

Text truncated - open the document above for the full version.

MANUEL D’INSTRUCTIONS SE9150 / SE9155 SE9180 / SE9185 CONSIGNES DE SÉCURITÉ IMPORTANTES Lors de l’utilisation d’un appareil électrique, les précautions de sécurité essentielles doivent toujours être respectées, y compris les suivantes : Lisez attentivement toutes les consignes avant d’utiliser cette machine. Conservez les consignes de sécurité dans un lieu approprié à proximité de la machine. Assurez-vous de les remettre avec la machine si vous la donnez à un tiers. DANGER – POUR RÉDUIRE LE RISQUE D’ÉLECTROCUTION : Une machine à coudre ne doit jamais être laissée sans surveillance lorsqu’elle est branchée. La prise électrique sur laquelle la machine est branchée doit être facilement accessible. Débranchez toujours cette machine à coudre de la prise immédiatement après l’avoir utilisée et avant de la nettoyer, d’enlever les protections ou de la lubrifier, ou lorsque vous effectuez tout autre réglage parmi ceux mentionnés dans le manuel d’instruction. AVERTISSEMENT – POUR RÉDUIRE LE RISQUE DE BRÛLURES, D'INCENDIE, DE DÉCHARGE ÉLECTRIQUE OU DE BLESSURES CORPORELLES : • Cet appareil est destiné à être utilisé par des adultes. L’appareil peut être utilisé sous la supervision d’un adulte par (i) des enfants âgés de 8 à 12 ans et par (ii) des personnes ayant des capacités physiques, sensorielles ou mentales réduites ou un manque d’expérience et de connaissances s’ils ont reçu des instructions concernant l’utilisation de l’appareil en toute sécurité et comprennent les dangers encourus. Le nettoyage et l’entretien à effectuer par l’utilisateur ne doivent pas être réalisés par des enfants sans surveillance. Il est interdit à quiconque de jouer avec la machine.Les enfants de moins de 8 ans ne sont pas autorisés à utiliser la machine. • Ne laissez pas les enfants jouer avec la machine. Il est fortement recommandé de redoubler d’attention lorsque cette machine à coudre est utilisée par des enfants ou à proximité d’enfants. • N’utilisez cette machine à coudre que pour l’usage prévu, comme décrit dans ce manuel. N’utilisez que les accessoires recommandés par le fabricant, conformément aux indications fournies dans ce manuel. • N’utilisez jamais cette machine à coudre si la prise ou le cordon sont endommagés, si elle ne fonctionne pas correctement, si elle est tombée par terre ou dans l’eau ou si elle a été endommagée. Retournez la machine au vendeur ou au centre technique agréé le plus proche de chez vous pour toute révision, toute réparation, ou tout réglage mécanique ou électrique. • N’utilisez jamais la machine à coudre alors qu’une ouverture de ventilation est bouchée. Évitez toute présence de peluches, poussières, chutes de tissus dans la ventilation ou dans la pédale de commande. • N’approchez pas vos doigts des parties mobiles. Faites particulièrement attention autour de l’aiguille de la machine. • Utilisez toujours la plaque à aiguille appropriée. L’aiguille risque de se casser avec une plaque non adaptée. • N’utilisez jamais d’aiguilles courbes. • Ne tirez pas sur le tissu et ne le poussez pas pendant la couture. Vous éviterez ainsi de désaxer l’aiguille puis de la casser. • Portez des lunettes de sécurité. • Éteignez la machine (position « 0 ») lors des réglages au niveau de l’aiguille, par exemple : enfilage de l’aiguille, changement d’aiguille, bobinage de la canette, changement de pied-de-biche, etc. • Ne faites jamais tomber ou ne glissez aucun objet dans les ouvertures. • N’utilisez pas la machine à l’extérieur. • N’utilisez pas votre machine à proximité de bombes aérosol ou de vaporisateurs ou lorsque de l’oxygène est administré. • Pour débrancher, commencez toujours par éteindre votre machine (interrupteur en position « 0 »). • Ne débranchez pas la machine en tirant sur le cordon. Pour débrancher, saisissez la prise et non le cordon. • La pédale est utilisée pour faire fonctionner la machine. Ne placez jamais d’autres objets sur la pédale de commande. • N’utilisez pas la machine si elle est mouillée. • Si le voyant LED est endommagé ou cassé, il doit être remplacé par le fabricant ou son agent de service, ou toute autre personne quali iée, a in d’éviter les risques. • Si le cordon de la pédale est endommagé, il doit être remplacé par le fabricant ou son agent de service, ou toute autre personne quali iée, a in d’éviter les risques. •Cette machine à coudre est équipée d’une prise polarisée à sens unique (une fiche est plus large que l’autre). Afin de ré-duire le risque d’électrocution, cette fiche est destinée à être branchée dans une prise polarisée à sens unique. Si la fiche ne rentre pas totalement dans la prise, retournez-la. Si la prise ne rentre toujours pas, contactez un électricien qualifié pour qu’il installe une prise adéquate. Toute modification de la prise est à proscrire. • La machine ne doit être utilisée qu’avec une pédale du type 33911.00025 fabriquée par Shang Gong Group Co., Ltd. Jiangsu Household Sewing Machine Branch (China). CONSERVEZ CES CONSIGNES DE SÉCURITÉ Cet appareil est conforme à la Partie 15 des normes de la FCC. L'utilisation est soumise aux deux conditions suivantes : (1) Cet appareil ne doit pas provoquer d'interférences nocives et (2) cet appareil doit accepter de recevoir des interférences, y compris des interférences pouvant impliquer un dysfonctionnement. Pour satisfaire aux exigences d’exposition en matière de radiofréquences, une distance de séparation de 20 cm (8") ou plus doit être maintenue entre cet appareil et les personnes pendant son fonctionnement. Pour faire en sorte que les opérations soient conformes, il n’est pas recommandé de les effectuer à une distance inférieure à cette distance. L’antenne intégrée utilisée pour cet émetteur ne doit pas être installée à proximité d’une autre antenne ou d’un autre émetteur. Selon des tests effectués, cet équipement respecte les limites d'un dispositif numérique de Classe B, conformément à la Partie 15 des normes de la FCC. Ces limites sont conçues pour offrir une protection raisonnable face aux inter…

Text truncated - open the document above for the full version.
