2BBRB-A17AI Tempset halter speaker

1 2 3 1 2 3 4 5 6 4 6 5 User Manual Heat dissipation port The air outlet is upward, wear it from the rear 1. Long press: power on, and the fans on both sides will automatically turn on. 2. Short press once, the air conditioner is turned on, and language prompt 3. Short press again: the air conditioner is turned off, and language prompt 4. Short press twice in succession: turn off/on the fan 5. Long press: shutdown 1. Long press: Bluetooth power on 2. Incoming call short press once to answer the call 3. Short press again to hang up 4. Long press again: Bluetooth shutdown 5. When playing music, short press once Pause, play music Long press +/- to adjust the speaker volume Short press +/- to adjust the upper and lower tracks Product parameters Product name: Intelligent Audio Air Conditioner Fan Size: 201.3*185*43.5mm EVE: 4.3V 5200mAh Charging input: 5V--2A Rated power: 10W Working temperature: 0-50 Bluetooth transmission distance: ≤10m (no obstacles and no other sources of interference) Wind speed adjustment: Long press "+" or "-" to adjust the wind speed After the air conditioner is turned on: short press the "—" button: turn on the cooling function (and it’s a voice prompt to turn on the cooling) After turning on the refrigeration, short press the "—" button to lower the refrigeration temperature(Minimum refrigeration temperature is ambient temperature -8°C) Note: When the air conditioner is heating, press the "—" button continuously, and the voice prompt "cooling on" will turn on the cooling function. When the air conditioner is cooling, press the "+" button continuously, and the voice prompt "heating on" will turn on the heating function from left to right 25% 50% 75% 100% Wearing Method Switch button Bluetooth switch button Sound adjustment Button Bluetooth indicator light and MIC hole Fan speed/temperature Control button Battery power indicator Air outlet Type-C charging interface Multimedia speaker sound hole Pb X X X Hg Cd Cr(VD)PBBPBDE 1. This product should not be used alone by children under 10 years old, unless parents or guardians have been set up, or children have been given sufficient instructions on how to use it 2. Do not put this product in a baby stroller. 3. When the product is working, please do not put your fingers or other sharp objects into the protective net to prevent injury 4. This product contains high-sensitivity electronic components (including batteries, refrigeration chips, etc.) Dropped, burned, punctured, squeezed, disassembled, or exposed to high temperature, liquid or high-concentration industrial chemicals (including near evaporative liquefied gas, environment such as nitrogen) can cause damage, impairment of function, or personal injury. 5. Some components of this product may interfere with related medical equipment such as cardiac pacemakers and defibrillators. Users who have implanted related medical devices are not recommended to use this product, so as not to cause physical discomfort. If you need to use it, please consult your doctor first and use it under the doctor's advice (when the doctor recommends that the product can be used) If you find this product is interfering with your medical device, please stop using it 6. Please choose the appropriate use time and temperature according to your physical condition and ambient temperature. It is recommended to Attentions: Product Qualified Card Warranty Card Product number: Date of manufacture Inspectors The name and content of harmful substances in the product use the cooling/heating mode continuously for no more than 30 minutes at a time. Avoid continuous use for too long, which may cause over-cold discomfort or the risk of low-temperature burns 7. If you feel unwell in the process of use or after use, please suspend use; if an accident occurs due to improper use, please seek medical attention immediately. requirements. There may be a risk of death or injury when charging with a charger that does not meet certified standards. 14. Please stop using the charging cable if it is damaged. Using a damaged charging cable or charger, or charging in a wet environment creates a risk of fire, electric shock, injury, product damage, or other financial damage. 15. When the product breaks down and needs to be repaired, in order to avoid danger, it must be replaced by professionals from the manufacturer, its maintenance department or similar departments, and other people are not allowed to repair it without authorization; 16. When not in use, please clean up the oil and dust on the surface of the product, cool it to room temperature and store it in a dry and ventilated place to avoid extrusion. This form is prepared according to the provisions of SJ/T11364. Some product models may not contain some of the parts in the table. 0: Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement specified in GB/T26572. X: Indicates that the content of the hazardous substance in at least one homogeneous material of the part exceeds the limit requirement specified in GB/T26572. Parts marked with "X" cannot be replaced by hazardous substances due to the limitation of global technological development level. *Printed circuit board assembly includes printed board and its components, capacitors and connectors, etc. Electronic information products sold within the territory of the People's Republic of China must be marked with the number in the circle of this mark to indicate the environmental protection use period of the product under normal use. Harmful Substance Part Name Metallic Parts other Printed Circuit Boards and Assemblies* In order to meet the laws and regulations and other requirements related to the restriction of hazardous substances in electrical and electronic products in China, the hazardous substances in this product are classified according to the components, and the statement is as follows 8. Please avoid subjecting the product to shocks such as l…

Text truncated - open the document above for the full version.

C5266091_X24_Ed.2 1/1 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. “AttestationStatements” TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 TheCommissionadoptedrulesthatprohibitequipmentauthorizationfor“covered” telecommunicationsequipmentandvideosurveillanceequipmentproducedbyentitiesidentified ontheCommission’sCoveredList 1 ,whichisperiodicallyupdated.SeetheCoveredListformore details.ThisAttestationStatementistoconfirmthatwefollowtheSection2.911(d)(5)(i)-(ii) Applicant Companyname:ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Granteecode:2BBRB FCCID:2BBRB-A17 ContactName:YujunZhou Address:Room601,FenghuaScience&TechnologyBuilding,high-techSouthSevenRoad, YuehaiStreetScienceandTechnologyPark,NanshanDistrict,Shenzhen TelephoneNo:+86-18825278915 FaxNo:+86-18825278915 Email:[email protected] i.[ShenzhentieWeiIntelligentTechnologyCo.,Ltd.](“theapplicant”) certifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto section2.903oftheFCCrules.Theapplicantmustsignthiscertification. ii.[ShenzhentieWeiIntelligentTechnologyCo.,Ltd.](“theapplicant”) certifiesthat,asofthedateofthefilingoftheapplication,theapplicant[is not](asaspecificallynamedentityoranyofitssubsidiariesoraffiliates) identifiedontheCoveredListasanentityproducing“covered”equipment. Theapplicantmustsignthiscertification. [ShenzhentieWeiIntelligentTechnologyCo.,Ltd.](“theapplicant”)certifiesthat, asofthedateofthefilingoftheapplication,theapplicant[isnot]identifiedonthe CoveredListasanentityproducing“covered”equipment. Date:2023/06/19 Applicant’sName:YujunZhou Title:GeneralManager Signature 1 TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedonthe Commission’swebsite.ThisCoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedby particularentities,thatconstitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 LetterofAuthorization ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Company:ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Address:Room601,FenghuaScience&TechnologyBuilding,high- techSouthSevenRoad,YuehaiStreetScienceandTechnologyPark, NanshanDistrict,Shenzhen ProductName:AITempsethalterspeaker ModelNumber:A17 FCCIdentifier:2BBRB-A17 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:YujunZhouDate:2023-06-20 Title:GeneralManager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2023-06-20 Subject:RequestforConfidentiality FCCID:2BBRB-A17 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodofdaysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name:YujunZhou Title:GeneralManager

FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17

FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 FCCID:2BBRB-A17 ANT

Page 1 of 2 RF EXPOSURE EVALUATION FCC ID: 2BBRB-A17 Product Name : AI Tempset halter speaker Model Name : A17 Bluetooth Version : BT BDR and BLE Operating frequency : 2402-2480MHz Numbers of Channel : 40 channels For DTS 79 channels for BDR Antenna Type : PCB Antenna Antenna Gain : 2.853 dBi Type of Modulation : GFSK, Π/4-DQPSK,8DPSK For DSS GFSK(BLE) Power supply : Input:5V--2A 10W Hardware Version : N/A Software Version : N/A Page 2 of 2 Standard Requirement According to § 15.247(i) and § 1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4. 3. 1. The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances ≤ 50mm are determined by: [ (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[ √f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g SAR extremity SAR, where ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison. The test exclusions are applicable only when the minimum test separation distance is ≤ 50mm and for transmission frequencies between 100MHz and 6GHz. When the minimum test separation distance is <5mm, a distance of 5mm is applied to determine SAR test exclusion. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (mW) Distance (mm) Calculation results Limit Operating Mode 2480 -0.52 -0.52 ± 1 1.116863 5 0.351768 3 BDR 2480 -1.57 -1.57 ± 1 0.877001 5 0.276220 3 BLE According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature Ronnie Liu EMC Manager Date: 2023-06-20

ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 1 / 8 AntennaTestReport PRODUCTDESIGNATION:PCBAntenna BRANDNAME:N/A MODELNAME:A17 APPLICANT:TieWeiIntelligentTechnologyCo.,Ltd. DATEOFISSUE:MaY.31,2023 REPORTVERSION:V1.0 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. ReportNo.:TWZN20230615001PA01 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 2 / 8 REPORTREVISERECORD ReportVersionReviseTimeIssuedDateValidVersionNotes V1.0/MAY.06,2023ValidInitialrelease ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 3 / 8 TABLEOFCONTENTS 1.PRODUCTINFORMATON....................................................................................4 2.TESTFACILITY.....................................................................................................5 3.TESTEQUIPMENTLIST......................................................................................5 4.MEASUREMENTUNCERTAINTY........................................................................5 5.TESTSUMMARYLIST........................................................................................5 6TESTRESULTS.....................................................................................................5 6.1.SWR..................................................................................................................5 6.2.GAINANDEFFICIENCY.....................................................................................6 6.3.RADIATIONPATTERN........................................................................................6 APPENDIXA:PHOTOGRAPHSOFTESTSETUP..................................................7 APPENDIXB:PHOTOGRAPHSOFEUT...............................................................7,8 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 4 / 8 1.PRODUCTINFORMATON Generalinformation Applicant ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Address Room601,FenghuaScience&TechnologyBuilding,high-tech SouthSevenRoad,YuehaiStreetScienceandTechnologyPark, NanshanDistrict,ShenzhenCity Manufacturer ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Address Room601,FenghuaScience&TechnologyBuilding,high-tech SouthSevenRoad,YuehaiStreetScienceandTechnologyPark, NanshanDistrict,ShenzhenCity Factory ShenzhentieWeiIntelligentTechnologyCo.,Ltd. Address Room601,FenghuaScience&TechnologyBuilding,high-tech SouthSevenRoad,YuehaiStreetScienceandTechnologyPark, NanshanDistrict,ShenzhenCity ProductDesignationPCBAntenna BrandNameN/A TestModelA17 DateoftestMAY.10,2023toMAY.30,2023 ReportTemplateAGCRT-ER-PA/V1.0 Technicalinformation FrequencyRange2400MHz-2500MHz TestFrequencies2400MHz,2410MHz,2420MHz,2430MHz,2440MHz, 2450MHz,2460MHz, 2470MHz,2480MHz,2490MHz,2500MHz AntennaTypePCBAntenna Dimensions12.1mm*3.6mm Impedance50Ω MaximumtestvaluesGain:2.853dBi;Efficiency:46.320%;VSWR:1.212:1 PreparedByCoolQuan CoolQuan (ProjectEngineer)May.31,2023 ReviewedByCalvinWang CalvinWang (Reviewer)May.31,2023 ApprovedByMaxZhou MaxZhou (AuthorizedOfficer)May.31,2023 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 5 / 8 2.TESTFACILITY TestSiteAttestationofGlobalCompliance(Shenzhen)Co.,Ltd Location1-2/F,Building19,JunfengIndustrialPark,ChongqingRoad,Heping Community,FuhaiStreet,Bao'anDistrict,Shenzhen,Guangdong,China 3.TESTEQUIPMENTLIST EquipmentManufacturerModelCal.DateCal.Due ANTENNA MEASUREMENT SYSTEM ETS-LindgrenAMS-8600Nov.26,2022Nov.25,2023 NetworkAnalyzerR&S101443Oct.14,2022 TestSoftwareETS-LindgrenEMQuest (VerV1.12) N/AN/A 4.MEASUREMENTUNCERTAINTY Theuncertaintyiscalculatedusingthemethodssuggestedinthe“Guidetothe ExpressionofUncertainty inmeasurement”(GUM)publishedbyCISPRandANSI. -UncertaintyofVSWR,Uc=±1.5dB -UncertaintyofGain,Uc=±0.8dB 5.TESTSUMMARYLIST NO.TestitemRemark 1VSWR-- 2Gainandefficiency-- 3Radiationpattern-- 6.TESTRESULTS 6.1.VSWR Frequency(MHz)VSWR 24021.173:1 24101.212:1 24501.203:1 24801.074:1 ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 6 / 8 6.2.GAINANDEFFICIENCY Frequency(MHz)Efficiency(dB)Efficiency(%)Gain(dBi) 2400-4.33137.2301.554 2410-4.26937.7661.450 2420-4.45436.1881.170 2430-4.32137.3201.298 2440-3.89941.1301.744 2450-3.72342.8342.052 2460-3.78742.2092.017 2470-4.05839.6521.774 2480-3.76042.4722.098 2490-3.60244.0552.449 2500-3.38446.3202.853 6.3.RADIATIONPATTERN ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 7 / 8 APPENDIXA:PHOTOGRAPHSOFTESTSETUP APPENDIXB:PHOTOGRAPHSOFEUT TOPVIEWOFEUT ShenzhentieWeiIntelligentTechnologyCo.,Ltd. 8 / 8 BACKVIEWOFEUT Dimensionaldrawingofantenna

Report No.: PTC23052402101E-FC01 Page 1 of 85 FCC TEST REPORT FCC ID: 2BBRB-A17 Product : AI Tempset halter speaker Model Name : A17 Brand : N/A Report No. : PTC23052402101E-FC01 Prepared for Shenzhen tie Wei Intelligent Technology Co. , Ltd. Room 601, Fenghua Science & Technology Building, high-tech South Seven Road, Yuehai Street Science and Technology Park, Nanshan District, Shenzhen Prepared by Precise Testing & Certification Co., Ltd. Building 1, No. 6, Tongxin Road, Dongcheng Street, Dongguan, Guangdong, China Report No.: PTC23052402101E-FC01 Page 2 of 85 1 TEST RESULT CERTIFICATION Applicant’s name : Shenzhen tie Wei Intelligent Technology Co. , Ltd. Address : Room 601, Fenghua Science & Technology Building, high-tech South Seven Road, Yuehai Street Science and Technology Park, Nanshan District, Shenzhen Manufacture's name : Shenzhen tie Wei Intelligent Technology Co. , Ltd. Address : Room 601, Fenghua Science & Technology Building, high-tech South Seven Road, Yuehai Street Science and Technology Park, Nanshan District, Shenzhen Product name : AI Tempset halter speaker Model name : A17 Standards : FCC CFR47 Part 15 Section 15.247 Test procedure : ANSI C63.10:2013 Test Date : Jun. 13, 2023 to Jun. 19, 2023 Date of Issue : Jun. 20, 2023 Test Result : Pass This device described above has been tested by PTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of PTC, this document may be altered or revised by PTC, personal only, and shall be noted in the revision of the document. Test Engineer: Simon Pu / Engineer Technical Manager: Ronnie Liu / Manager Report No.: PTC23052402101E-FC01 Page 3 of 85 Contents Page 1 TEST RESULT CERTIFICATION .............................................................................................................................. 2 2 TEST SUMMARY ......................................................................................................................................................... 5 3 TEST FACILITY ............................................................................................................................................................ 5 4 GENERAL INFORMATION ........................................................................................................................................ 6 4.1 GENERAL DESCRIPTION OF E.U.T. .................................................................................................................... 6 4.2 TEST MODE ........................................................................................................................................................ 7 5 EQUIPMENT DURING TEST ..................................................................................................................................... 9 5.1 EQUIPMENTS LIST............................................................................................................................................... 9 5.2 MEASUREMENT UNCERTAINTY ......................................................................................................................... 11 5.3 DESCRIPTION OF SUPPORT UNITS ................................................................................................................... 12 6 CONDUCTED EMISSION ......................................................................................................................................... 13 6.1 E.U.T. OPERATION ........................................................................................................................................... 13 6.2 EUT SETUP ...................................................................................................................................................... 13 6.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 14 6.4 MEASUREMENT PROCEDURE: .......................................................................................................................... 14 6.5 CONDUCTED EMISSION LIMIT ........................................................................................................................... 14 6.6 MEASUREMENT DESCRIPTION .......................................................................................................................... 14 6.7 CONDUCTED EMISSION TEST RESULT ............................................................................................................. 14 7 RADIATED SPURIOUS EMISSIONS ..................................................................................................................... 17 7.1 EUT OPERATION .............................................................................................................................................. 17 7.2 TEST SETUP ..................................................................................................................................................... 18 7.3 SPECTRUM ANALYZER SETUP .......................................................................................................................... 19 7.4 TEST PROCEDURE ............................................................................................................................................ 20 7.5 SUMMARY OF TEST RESULTS .......................................................................................................................... 21 8 MAXIMUM PEAK OUTPUT POWER TEST .......................................................................................................... 28 8.1 TEST STANDARD AND LIMIT .............................................................................................................................. 28 8.2 TEST SETUP .......................…

Text truncated - open the document above for the full version.

Report No.: PTC23052402101E-FC01 Page 61 of 85 DH5-Ant1-2441-1000~26500 DH5-Ant1-2480-0~Reference Report No.: PTC23052402101E-FC01 Page 62 of 85 DH5-Ant1-2480-30~1000 DH5-Ant1-2480-1000~26500 Report No.: PTC23052402101E-FC01 Page 63 of 85 2DH5-Ant1-2402-0~Reference 2DH5-Ant1-2402-30~1000 Report No.: PTC23052402101E-FC01 Page 64 of 85 2DH5-Ant1-2402-1000~26500 2DH5-Ant1-2441-0~Reference Report No.: PTC23052402101E-FC01 Page 65 of 85 2DH5-Ant1-2441-30~1000 2DH5-Ant1-2441-1000~26500 Report No.: PTC23052402101E-FC01 Page 66 of 85 2DH5-Ant1-2480-0~Reference 2DH5-Ant1-2480-30~1000 Report No.: PTC23052402101E-FC01 Page 67 of 85 2DH5-Ant1-2480-1000~26500 3DH5-Ant1-2402-0~Reference Report No.: PTC23052402101E-FC01 Page 68 of 85 3DH5-Ant1-2402-30~1000 3DH5-Ant1-2402-1000~26500 Report No.: PTC23052402101E-FC01 Page 69 of 85 3DH5-Ant1-2441-0~Reference 3DH5-Ant1-2441-30~1000 Report No.: PTC23052402101E-FC01 Page 70 of 85 3DH5-Ant1-2441-1000~26500 3DH5-Ant1-2480-0~Reference Report No.: PTC23052402101E-FC01 Page 71 of 85 3DH5-Ant1-2480-30~1000 3DH5-Ant1-2480-1000~26500 Report No.: PTC23052402101E-FC01 Page 72 of 85 14 Antenna Requirement 14.1 Test Standard and Requirement Test Standard FCC Part15 Section 15.203 /247(c) Requirement 1) 15.203 requirement: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. 2) 15.247(c) (1)(i) requirement: Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point operations may employ transmitting antennas with directional gain greater than 6dBi provided the maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the directional gain of the antenna exceeds 6 dBi. 14.2 Antenna Connected Construction The antenna is PCB Antenna which permanently attached, and the best case gain of the antenna is 2.853dBi. It complies with the standard requirement. Report No.: PTC23052402101E-FC01 Page 73 of 85 15 APPENDIX I -- TEST SETUP PHOTOGRAPH Conducted Emissions Radiated Emissions From 30M-1GHz Report No.: PTC23052402101E-FC01 Page 74 of 85 Above 1GHz Report No.: PTC23052402101E-FC01 Page 75 of 85 16 APPENDIX II -- EUT PHOTOGRAPH Report No.: PTC23052402101E-FC01 Page 76 of 85 Report No.: PTC23052402101E-FC01 Page 77 of 85 Report No.: PTC23052402101E-FC01 Page 78 of 85 Report No.: PTC23052402101E-FC01 Page 79 of 85 Report No.: PTC23052402101E-FC01 Page 80 of 85 Report No.: PTC23052402101E-FC01 Page 81 of 85 Report No.: PTC23052402101E-FC01 Page 82 of 85 Report No.: PTC23052402101E-FC01 Page 83 of 85 Report No.: PTC23052402101E-FC01 Page 84 of 85 Report No.: PTC23052402101E-FC01 Page 85 of 85 ******THE END REPORT******

FCCID:2BBRB-A17 ConductedEmissions RadiatedEmissions From30M-1GHz FCCID:2BBRB-A17 Above1GHz
