2BBRX-S1Moogo Misting System

Mosquito Misting System User Manual Installation Videos moogo.com/pages/installation Installation APP Quickstart Quickstart via Device Device Functions Important Safety Instructions Notes for the Cord Product Specifications & Packing List Troubleshooting Product Warranty Customer Service Taking Care of Your Moogo 01 03 04 05 08 12 14 18 19 20 21 Important Safety Instructions Please read all instructions before using Moogo for the first time. Keep all electrical components (plug, cords) away from liquids to prevent electrical shock. Close supervision is necessary when using Moogo near children. Do not activate this system near people, pets, or food. Direct nozzles towards the targeted area, but away from food, cooking areas, and bodies of water including swimming pools & ponds. Insecticides may cause phototoxicity (burns) in certain plants. Follow instructions on chemical labels, and do not use insecticides that are marked as "not compatible with outdoor misting systems." Unplug the unit when not in use, before cleaning, adding or removing parts, and when cleaning. When emptying the Moogo device, ensure that Moogo is turned off and unplugged. Do not operate Moogo if the cord or plug is damaged. Similarly, do not operate if Moogo malfunctions or is dropped or damaged. Please contact our support team for examination or repair. Do not use any attachments not recommended or sold by Moogo as these could damage the device. Moogo is intended for outdoor use only. Do not let the cord hang or touch hot surfaces. Keep the unit out of direct sunlight and away from any appliances which produce heat. Visit moogo.com for more info. User Manual 1.0 - 01 Always connect the cord to your Moogo device before plugging into a wall outlet. To disconnect, turn off Moogo and remove the plug from the outlet. Make sure your Moogo device is on a flat surface during operation, or if it is wall mounted, that the device is level. When Moogo is not in use, ensure the glass panel remains closed. Do not use Moogo for anything other than its intended use. Do not alter or adapt Moogo in any way. Do not submerge the device in water. Visit moogo.com for more info. User Manual 1.0 - 02 *PLEASE SAVE THESE INSTRUCTIONS WARNING: IF CONNECTING TO A PORTABLE WATER SYSTEM, THE SYSTEM SHALL BE PROTECTED AGAINST BACKFLOW AVERTISSEMENT: SI L'APPAREIL EST RACCORDÉ À UN RÉSEAU D'EAU POTABLE, IL DOIT ÊTRE PROTÉGÉ CONTRE LES REFOULEMENTS Notes for the Cord: a) A short power-supply cord is provided to reduce risks resulting from entanglement or tripping. b) Extension cords can be used with extra care (purchased separately.) c) If an extension cord is used: 1) The electrical rating of the extension cord should be at least equal to the electrical rating of the appliance. 2) The extension cord should be a grounding type 3-wire cord. 3) The longer cord should be arranged so that it will not drape over countertops or tabletops where it can be tripped over, snagged, or pulled on unintentionally (especially by children). Visit moogo.com for more info. User Manual 1.0 - 03 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L'emetteur/recepteur exempt de licence contenu dans le present appareil est conforme aux CNRd'Innovation, Sciences et Developpement economique Canada applicables aux appareils radioexempts de licence. L'exploitation est autorisee aux deux conditions suivantes: (1) L'appareil ne doit pas produire de brouillage; (2) L'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptibled'en compromettre le fonctionnement. Product Specifications Packing List Device Mister Device Accessories Model No: S1 Product Name: Mosquito Misting System Rated Voltage: 120 Vac Rated Power: 650 W Voltage Frequency: 60 Hz Product Size: 21 x 10 x 16 inches Water Tank Capacity: 3 L/0.8 Gal Packaging Size Per Unit: 23 x 13 x 18 inches Net Weight: 46 Ibs Plastic anchorConcrete screw positioning card Concrete screwStandard silicone pad Thick silicone pad 1/4" X 3/4" Hose Bib Adapter 1/4" Metal plug QTY: 2QTY: 1QTY: 2QTY: 2QTY: 2QTY: 1QTY: 1 Control panel 01 Dilute Cover Funnel Glass panel Inlet Bracket Insecticide tank Outlet Mixed fluid tank 02 Concentrate Cover Antenna Visit moogo.com for more info. User Manual 1.0 - 04 Installation Drill into the marks you made on the wall, and insert the plastic anchor and concrete screw in succession Please follow the below steps to install the device, or watch the installation video for reference. To ensure operational efficiency, it is recommended to attached no more than 60 nozzles for the whole misting system, with a suggested installation distance of 8-10ft for each nozzle. 1 Use the concrete screw positioning card to mark areas for drilling holes on walls you have selected. When marking, ensure that the card is parallel with the ground. Visit moogo.com for more info. User Manual 1.0 - 05 Align the holes on the back of the device with the nail and hang the device in an appropriate position on the wall. Note: Before connecting the inlet pipe to the inlets, open the spigot to release air from the water inlet pipe, before connecting it to the inlets of the device. Connect the 3/4" hose bib adapte to the spigot, and connect the inlet pipe to the inlets of your device. Inlet Visit moogo.com for more info. User Manual 1.0 - 06 To reduce shock and protect your walls, attach four silicone pads to the back panel of the device. Place two standard silicone pads side by side on top, and two thick silicone pads side by side on the bottom. Outlet Nozzle Tee Connect the union tee outlet of the device to the misting nozzle at the water outlet’s end. Plug the other outlet of the u…

Text truncated - open the document above for the full version.

120X165MM MODEL NO: S1 This device complies with Part 15 of the FCC rules. 5000020A FCC ID: 2BBRX-S1 IC: 31089-S1 READ INSTRUCTIONS BEFORE USE Rating Input: 120 Vac, 60 Hz Capacity: 3 L/0.8 Gal Rating Power: 650 W DO NOT IMMERSEOUTDOOR USE ONLY POUR USAGE DOMESTIQUE SEULEMENT LIRE LES DIRECTIVES AVANT L’EMPLOI NE PAS IMMERGER Designed in Houston Texas. Made in PRC. FOR SUPPORT, PLEASE CONTACT: [email protected] MOSQUITO MISTING SYSTEM OTHER CERTIFICATIONS PENDINGPATENT PENDING Operation is subject to the following two conditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) This device must accept any interference received, including interference that may cause undesired operation. CONFORMS TOUL STD. 73 CERTIFIED TOCSA STD. C22. 2 No. 68 SN码贴附区域 WARNING: IF CONNECTING TO A PORTABLE WATER SYSTEM, THE SYSTEM SHALL BE PROTECTED AGAINST BACKFLOW AVERTISSEMENT: SI L'APPAREIL EST RACCORDÉ À UN RÉSEAU D'EAU POTABLE, IL DOIT ÊTRE PROTÉGÉ CONTRE LES REFOULEMENTS

FCC ID and IC ID of ESP32-S3-WROOM-1U FCC ID: 2AC7Z-ESPS3WROOM1U IC: 21098-ESPS3WROOMU

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230608165GZU FCC ID: 2BBRX-S1 Version: 06 November 2020 Page 1 of 3 FCC simultaneously transmitter-Mobile (MPE) RF Exposure Compliance Requirement Model no.: S1 1. Standard requirement Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100000 -- -- 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230608165GZU FCC ID: 2BBRX-S1 Version: 06 November 2020 Page 2 of 3 FCC simultaneously transmitter-Mobile (MPE) 2. MPE Calculation Method E (V/m)=(30*P*G) 0.5 /d Power Density: Pd(W/m 2 )=E 2 /377 E=Electric Field (V/m) P=Peak RF output Power (W) G=EUT Antenna numeric gain (numeric) d= Separation distance between radiator and human body (m) The formula can be changed to Pd= (30*P*G)/(377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. 3. Calculated Result and Limit WIFI: Peak Output Power = 17.1dBm(max.value declared by client), antenna gain = 4.55dBi Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2412-2462 2.851 17.1 51.29 0.0291 1 Complies MPE ratio: 0.0291(mW/cm 2 )/1(mW/cm 2 ) = 0.0291 Bluetooth: Peak Output Power = 9.56dBm(max.value declared by client), antenna gain = 4.55dBi Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2402-2480 2.851 1.57 9.04 0.0051 1 Complies MPE ratio: 0.0051(mW/cm 2 )/1(mW/cm 2 ) = 0.0051 Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230608165GZU FCC ID: 2BBRX-S1 Version: 06 November 2020 Page 3 of 3 FCC simultaneously transmitter-Mobile (MPE) Sum of the MPE ratio for all simultaneously transmitting antennas: 0.0291+0.0051 = 0.0342 < 1 According to MPE test Exclusion condition in KDB 447498 (D01) General RF Exposure Guidance D01 v06, the MPE report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Vego Garden Inc. TEST REPORT SCOPE OF WORK EMC TESTING–S1 REPORT NUMBER 230608165GZU-003 ISSUE DATE [REVISED DATE] 29-July-2023 [---------------------] PAGES 83 DOCUMENT CONTROL NUMBER FCC ISED WIFI-c © 2021 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 83 FCC ISED WIFI-c Applicant Name & Address : Vego Garden Inc. 1521 Greens Rd. # 100, Houston, TX 77032 Manufacturing Site : Same as applicant Intertek Report No : 230608165GZU-003 FCC ID : 2BBRX-S1 ISED ID : 31089-S1 Test standards 47 CFR PART 15 Subpart C: 2021 section 15.247 RSS-247 Issue 2: February 2017 RSS-Gen Issue 5: April 2018+A1: March 2019+A2: February 2021 Sample Description Product : Moogo Misting System Model No. : S1 Electrical Rating : 120V/60Hz,650W Serial No. : Test sample 1 Date Received : 08 June 2023 Date Test Conducted : 20 July 2023-27 July 2023 Prepared and Checked By Ace Yao Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 230608165GZU-003 Version: 14 December 2022 Page 3 of 83 FCC ISED WIFI-c CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 6 2.1 PRODUCT DESCRIPTION ........................................................................................................ 6 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 7 2.3 TEST METHODOLOGY ........................................................................................................... 7 2.4 TEST FACILITY ...................................................................................................................... 7 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 7 3.1 JUSTIFICATION ..................................................................................................................... 7 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 8 3.3 SPECIAL ACCESSORIES ........................................................................................................... 8 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 9 3.5 EQUIPMENT MODIFICATION .................................................................................................. 9 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION ........................................................................ 10 4.0 MEASUREMENT RESULTS ......................................................................................... 11 4.1 ANTENNA REQUIREMENT .................................................................................................... 11 4.2 6 DB BANDWIDTH (DTS BANDWIDTH) .................................................................................. 12 4.3 DUTY CYCLE ...................................................................................................................... 27 4.4 MAXIMUM AVERAGE CONDUCTED OUTPUT POWER ................................................................ 31 4.4 PEAK POWER SPECTRAL DENSITY .......................................................................................... 33 4.5 OUT OF BAND CONDUCTED EMISSIONS ................................................................................. 41 4.6 OUT OF BAND RADIATED EMISSIONS .................................................................................... 50 4.7 RADIATED EMISSIONS IN RESTRICTED BANDS .......................................................................... 50 4.8 BAND EDGES REQUIREMENT ................................................................................................ 74 4.9 CONDUCTED EMISSION TEST ................................................................................................ 80 5.0 TEST EQUIPMENT LIST ............................................................................................. 83 TEST REPORT Intertek Report No.: 230608165GZU-003 Version: 14 December 2022 Page 4 of 83 FCC ISED WIFI-c 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C section 15.247 (c) and S…

Text truncated - open the document above for the full version.

Vego Garden Inc. TEST REPORT SCOPE OF WORK EMC TESTING–S1 REPORT NUMBER 230608165GZU-004 ISSUE DATE [REVISED DATE] 29-July-2023 [---------------------] PAGES 52 DOCUMENT CONTROL NUMBER FCC BT 4.0- f © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 52 FCC BT 4.0-f Applicant Name & Address : Vego Garden Inc. 1521 Greens Rd. # 100, Houston, TX 77032 Manufacturing Site : Same as applicant Intertek Report No FCC ID : : 230608165GZU-004 2BBRX-S1 Test standards 47 CFR PART 15 Subpart C: 2021 section 15.247 Sample Description Product : Moogo Misting System Model No. : S1 Electrical Rating : 120V/60Hz,650W Serial No. : Test sample 1 Date Received : 08 June 2023 Date Test Conducted : 20 July 2023-27 July 2023 Prepared and Checked By Ace Yao Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 230608165GZU-004 Version: 14 December 2022 Page 3 of 52 FCC BT 4.0-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 6 2.3 TEST METHODOLOGY ........................................................................................................... 6 2.4 TEST FACILITY ...................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 8 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 9 4.0 MEASUREMENT RESULTS ......................................................................................... 10 4.1 ANTENNA REQUIREMENT .................................................................................................... 10 4.2 6 DB BANDWIDTH (DTS BANDWIDTH) .................................................................................. 11 4.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ..................................................................... 16 4.4 PEAK POWER SPECTRAL DENSITY .......................................................................................... 21 4.5 OUT OF BAND CONDUCTED EMISSIONS ................................................................................. 26 4.6 OUT OF BAND RADIATED EMISSIONS .................................................................................... 30 4.7 RADIATED EMISSIONS IN RESTRICTED BANDS .......................................................................... 30 4.8 BAND EDGES REQUIREMENT ................................................................................................ 45 4.9 CONDUCTED EMISSION TEST ................................................................................................ 49 5.0 TEST EQUIPMENT LIST ............................................................................................. 52 TEST REPORT Intertek Report No.: 230608165GZU-004 Version: 14 December 2022 Page 4 of 52 FCC BT 4.0-f 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth (DTS bandwidth) FCC PART 15 C section 15.247 (a)(2) ANSI C63.10: Clause 11.8 PASS Maximum Peak Conducted Output Power FCC PART 15 C section 15.247(b)(3) ANSI C63.10: Clau…

Text truncated - open the document above for the full version.

深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 1 / 7 SPECIFICATION 1 、主要部件组成Part specification 产品名称Name：2.4G Antenna 型号Part no：HC24011015225J 1 连接器 Connector Type SMA 2 连接器镀层 Connector Coating AU 3 线材 Cable Type RG174 4 外壳 Cover TPE、Black 5 特殊标识 Label - 6 特殊工艺 Technology Ultrasonic fusion 7 辐射阵子 Radiating Element carbon steel Explain ：Applicable to ROSH 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 2 / 7 2 、特性参数Pharacteristic parameter 频率范围 Frenquency Rang 2400-2500MHz 输入阻抗 Impedance 50Ω 驻波比 VSWR ＜2.0 增益 Gain 4.55dBi 辐射方向 Radiation 全向 极化方式 Polarization Vertical 镀层 Coating - 天线高度 Height 225±4mm 馈线长度 Cable Length 1500±30mm 工作温度 working Temperature -45-＋85°C 存储温度 Storage Temperature -45-＋85°C 适用频段 Applicable Band WIFI、Bluetooth 湿度 Humidity ＜95% 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 3 / 7 3、尺寸规格Drawing 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 4 / 7 4、电性能测试VSWR experiment Frenquency （MHz） VSWR VSWR RANGE reference value Judge reference value Judge 2400MHz 1.77 ≤2.0 PASS ＞2.0 NG 2450 MHz 1.40 ≤2.0 PASS ＞2.0 NG 2500 MHz 1.30 ≤2.0 PASS ＞2.0 NG - - Test Instrument ：5071C 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 5 / 7 5、效率与增益Efficiency and Gain Freqency(MHz) Gain(dbi) Efficiency(db) Efficiency(%) 2400 4.15 -2.35 58.26 2410 4.29 -2.14 61.12 2420 4.45 -1.96 63.69 2430 4.51 -1.84 65.4 2440 4.55 -1.77 66.49 2450 4.47 -1.74 66.97 2460 4.35 -1.79 66.19 2470 4.23 -1.87 65.05 2480 4.17 -1.92 64.32 2490 4.31 -1.93 64.12 2500 4.22 -1.98 63.44 6、方向图Radiation Patterns 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 6 / 7 深圳华科通讯有限公司 Shenzhen Huake Communications Co., Ltd. -------专注射频领域 服务全球客户------- 网站：www.huake-china.com 电话：0755-82595196 地址：深圳市宝安区蚝业路35号A栋4楼 518000 4th floor, building A, 35 Haoye Road, Baoan District, Shenzhen, Guangdong, China 518000 7 / 7 6、测试环境Test environment

Note: EUT is positioned at the center of the turntable to keep 3m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz) Conducted Emissions
