2BBRZ-MRA1Cordless Power Mop

CONTACT CUSTOMER CARE 1+(619)449-2392 CORDLESS POWER MOP TM Supplemental User Guide IMPORTANT BATTERY SAFETY INSTRUCTIONS WARNING: When using electric devices, basic safety precautions should always be fol- lowed to reduce the risk of fire, electric shock and personal injury, including the following: WARNING: 1. This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause unde- sired operation. YRD#: HI2126 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio fre- quency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Please note that changes or modifications of this product is not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Importer YRDLLC, Address:9545 Pathway Street, Santee, CA 92071 telephone number: 1+ (619) 449-2392 2. Rechargeable Lithium Ion batteries are potentially hazardous and can present a serious FIRE HAZARD if damaged, defective or improperly used. Failure to read, and follow Li-ion safety instructions and warnings may result in personal injury, fire, and property damages if the battery is charged and/or used improperly. DO NOT SHORT CIRCUIT. Short circuits may cause fire, and injury! 3. If liquid leaks from the battery cell, discontinue use immediately and dispose of properly. 4. Do not charge battery in rain or in wet location. 5. Use only the included battery. 6. Battery Type is: Li-ion Battery 11.1v 2000mAh.. 7. Do not attempt to disassemble, remodel or destroy the battery, as it may cause battery leakage, fire, or bursting; and could also create sulfuric acid spills from the battery resulting in possible burns to person and damage to the immediate environ - ment. 8. Charge battery using the specified charger and under the charging conditions as specified. Charging the battery under any other conditions may cause the battery to overheat, emit hydrogen gas, leak, ignite or burst. 9. When charging the battery always do so in a well ventilated area and where you can observe the charging process. 10. Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful

CONTACT CUSTOMER CARE 1+(619)449-2392 CORDLESS POWER MOP TM user guide CONTACT CUSTOMER CARE 1+(619)449-2392 • In order to prevent injury and property damage, please read this manual carefully and avoid misuse. If you use the machine in an incorrect way or ignore the contents of this manual, it may cause serious damage and injury. • Please abide by the following pictures and text * The specifications and design of this product are subject to change without notice. SPECIFICATIONS ProductCordless Power Mop TM ModelMR-A1 Battery Voltage11.1V Battery Capacity2000mAh Power 50W Adapter Input100-240V-50/60Hz 1.5A Max Adapter Output13.2v 1000mA I ATTENTION  Do not use this product outdoors. Disabled persons (persons with impairments in physical, perception and thinking abilities) and children must be accompanied by a guardian when using it.  When the power plug or power cord fails, please stop using it.  When disconnecting the power, you should pull the plug by hand, do not pull the power cord directly.  When adding water to the water tank, do not add other chemical solvents such as detergents, perfumes, essential oils, etc., to avoid damage to parts.  During the cleaning process of the product, please do not turn it upside down or lift it to avoid water tank leakage and cause short circuit.  Please keep the water outlet unobstructed. When it is blocked, please do not disassemble it privately, and contact a professional for handling.  Do not leave the remaining water in the water tank during product cleaning or after using it.  When cleaning the product, do not use alcohol, benzene, or thinner to clean the surface of the product, so as not to damage the appearance of the product.  Do not stand or sit on the machine to avoid damage to the machine or personal injury. SAFETY PRECAUTIONS Please read this manual carefully I WARNING: THIS SYMBOL MEANS THAT IF THE CONTENT OR ACTION IS NOT FOLLOWED, IT MAY CAUSE SERIOUS INJURY. I ATTENTION: THIS SYMBOL MEANS THAT IF THE CONTENT OR ACTION IS NOT FOLLOWED, IT MAY CAUSE PROPERTY DAMAGE OR OTHER INJURIES. INDICATING PROHIBITION, PLEASE REFER TO THE MANUAL FOR DETAILS. IT IS STRONGLY RECOMMENDED TO DO SO, PLEASE REFER TO THE MANUAL FOR DETAILS. When the product leaves the factory, 10-50% of the power is generally reserved. It is recommended to charge the product firstly to ensure the use effect. It takes about 2-3 hours to fully charge at room temperature. The actual charging time varies according to the environment. CONTACT CUSTOMER CARE 1+(619)449-2392 I ATTENTION Please use the original accesso- ries provided by the manufacturer. When the product is not being used or before maintenance, please cut off the power to avoid danger. Be careful of squeezing in the door gap or friction with sharp objects, keep away from heat sources. Before using this product to clean, please tidy up the debris in the area to be cleaned. Before cleaning, please make sure that the cleaning cloth is in- stalled correctly. Please be careful when using the product to clean the corridor. Before removing the cleaning cloth, please cut off the power supply and wait for the product to stop before operating. When cleaning and maintaining the product, please disconnect the power first, and then clean it with a dry/wet cloth. Unplug the power plug after use and during maintenance. Please remove the wet cleaning cloth before storing the product. Please store the product in a dry and ventilated room. If the water hardness in the liv- ing area is high, it is recommended to add filtered water when adding water. In order to avoid danger, when the product fails, it must be re- paired or replaced by professionals from the distributor, its repair department or similar departments. When you need to use a de- tergent, please choose a neutral detergent and dilute with water. I WARNING  The product is strictly prohibit- ed from being immersed in water or other solutions to avoid dangers such as fire, electric shock, etc.  Do not touch the plug or the product body with wet hands, and do not use the product when you are barefoot.  Please avoid clothing or any part of the body (such as hair, fingers, etc.) from getting caught in the rotating wheels of the body, otherwise it may cause personal injury.  Do not try to disassemble or repair the product by yourself. In- correct assembly and maintenance can easily damage the motor and cause potential safety hazards in use. CONTACT CUSTOMER CARE 1+(619)449-2392 A Charger B Cleaning Pads (x4) Water Cup C Cleaning Bucket Water Spray Power Button /Illumination Button/ Cleaning Button Power Indicator Illumination Outlet Host Wheel Water Tank Filling Point D WHAT YOU GET: PARTS FOR YOUR CORDLESS POWER MOP TM CONTACT CUSTOMER CARE 1+(619)449-2392 Cleaning Pads Assembly How To Use The Cordless Power Mop TM Fill the water tank with a water cup. Put down the handle, press and hold the power button for 3 seconds to turn on, the wheels start to rotate, and starts to clean the floor. u v Preparation Before Use CONTACT CUSTOMER CARE 1+(619)449-2392 CR2032 Lithium 3V If you need to wet the surface, press the water spray button, and the water outlet will spray water mist to wet the ground. Water spray function works after mop has been tuned on. Press the Power Button, and the light will be on together. Press the Button on the back side of the handle to remove handle from pole  . Remove cap from end of handle u, unscrew 1 screw from each end of handle v. Lift cover off of handle w. Replace battery x (CR2032) . When charging, the indicator port shows a red light, and a green light shows that the battery is full. Working time: about 60 minutes. The actual use time varies depending on the environment. Charging time: 2-3 hours. Add water to the water level line/hole in the cleaning bucket to ensure that it is below the highest water level line. This hole is the water level, add water below this hole. Water Spray Power button. DC - Charging port This angle is the cle…

Text truncated - open the document above for the full version.

FCC ID Label label location

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230519156GZU FCC ID: 2BBRZ-MRA1 RF Exposure Compliance Requirement Model no.: MR-A1 Calculation formula： E (V/m) = (30*P*G) 0.5/d E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between EUT and antenna (m) Remark: E(V/m)=10 X (dBUV/m) /20 ×10 -6 PG=(E*d) 2 /30 in the formula above, d=3m, field strength= 65dBuV/m (max described by client), So ERP=PG=0.0005mW The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequencies of the device are between 300 MHz and 6 GHz. In KDB 447498 D04 Interim General RF Exposure Guidance v01: 2.1.2 1-mW Test Exemption: A single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 kHz to 100 GHz, regardless of fixed, mobile, or portable device exposure conditions. Transmit Frequency (MHz) Effective Radiated Power (ERP) (mW) 1 mW Test Exemption limit (mW) 315 0.0005 1 According to SAR Exclusion Threshold in KDB 447498 D04 Interim General RF Exposure Guidance v01, the SAR report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Yeiser Research and Development LLC TEST REPORT SCOPE OF WORK EMC TESTING–MR-A1 REPORT NUMBER 230519156GZU-001 ISSUE DATE [REVISED DATE] 04-July-2023 [---------------------] PAGES 23 DOCUMENT CONTROL NUMBER FCC Part 15.231-f © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 23 FCC Part 15.231-f Applicant Name & Address : Yeiser Research and Development LLC 9545 Pathway Street, Santee Ca 92071 Manufacturing Site : Zhejiang Meare Smart Tech Co., Ltd No.6 Xinggong 6th Road, Jianggong District, Jiangshan City, Zhejiang, China Intertek Report No: FCC ID: 230519156GZU-001 2BBRZ-MRA1 Test standards FCC PART 15 Subpart C: 2021 section 15.231 Sample Description Product : Cordless Power Mop Model No. : MR-A1 Electrical Rating : DC 3V CR2032 type Lithium Cell Serial No. : Not Labeled Date Received : 19 May 2023 Date Test Conducted : 10 June 2023-14 June 2023 Prepared and Checked By Dean Liu Project Engineer Approved By: Strong Yao Manager TEST REPORT Intertek Report No.: 230519156GZU-001 Version: 14 December 2022 Page 3 of 23 FCC Part 15.231-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 5 2.3 TEST METHODOLOGY ........................................................................................................... 5 2.4 TEST FACILITY ...................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 7 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 4.0 MEASUREMENT RESULTS ........................................................................................... 9 4.1 ANTENNA REQUIREMENT ...................................................................................................... 9 4.2 RADIATED EMISSIONS ......................................................................................................... 10 4.3 OCCUPIED BANDWIDTH ...................................................................................................... 18 4.4 DWELL TIME ..................................................................................................................... 20 4.5 CONDUCTED EMISSION TEST ................................................................................................ 22 5.0 TEST EQUIPMENT LIST ............................................................................................. 23 TEST REPORT Intertek Report No.: 230519156GZU-001 Version: 14 December 2022 Page 4 of 23 FCC Part 15.231-f 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Radiated Emission FCC PART 15 section 15.231(b) ANSI C 63.10: Clause 6.4, 6.5 and 6.6 PASS Occupied Bandwidth FCC PART 15 section 15.231(c) ANSI C 63.10: Clause 6.9 PASS Dwell Time FCC PART 15 section 15.231(a) FCC PART 15: Section 15.231(a) PASS Conducted Emission FCC PART 15 section 15.207 ANSI C 63.10: Clause 6.2 N/A Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Fr…

Text truncated - open the document above for the full version.

Note: EUT is positioned at the center of the turntable to keep 3 m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (30MHz-1000MHz) Radiated Emission (Above 1GHz)
