2BBT3-F12Automatic Wireless Car Charger

正反面印刷 折页时英文折在正面 Automatic Wireless Car Charger F12 USER MANUAL Thanks for choosing and using our multi-functional smart wireless charging mount. Please carefully read the instruction manual and precautions before use. Product Introduction 70.00 mm Specification — - - - Input:5V 2A / 9V 1.67A / 12V 2A Ouput:5W / 7.5W / 10W / 15W(MAX) Operating temperature:- L139.0*W80.0*H58.2mm 10 to 60°C Charging efficiency:≥75% Charging distance:≤8.0mm Product dimensions: — - - - — - - - Functional protection Over temperature protection Over current protection Over voltage protection Executive standard：implement Qi wireless charging standard Support WPC Qi wireless charging protocol F12 * 1 Type-C cable * 1 Car air vent holder * 1 Suction cup mount（Optional) * 1 Screw cap * 1 User manual * 1 Packing box * 1 Package content Assembling description 1.Insert the screw cap into the ball end of the air outlet bracket, and note the direction of inserting the screw cap is from the small round mouth； 2.Press the ball end of the air outlet bracket hard into the thread interface of the F12 host machine； 3.Adjust the air outlet bracket to be perpendicular to the thread interface of the F12 host machine, and tighten the screw cap clockwise 4.Insert the air outlet bracket clip into the car air outlet, pull down button, clamp the product, and adjust the angle Please carefully handle your charger and accessories, the following recommendations will help you effectively use the warranty service. 1.Please keep the equipment dry. Rain, moisture and various water may contain minerals that will corrode the circuit. If the equipment is wet, please dry the product as soon as possible or use a clean soft cloth to wipe. 2.Do not store the equipment in a cold place. Otherwise,when the equipment temperature rises to normal temperature, moisture will be formed inside it and damage the electric appliance. 3.Do not attempt to open the equipment, unauthorized disassembly or modification will damage equipment and wireless charging equipment related regulations. 4.Do not throw, tap or shock the equipment; rough handling of the equipment will damage the internal circuit board and the mechanical structure. 5.Use the clean and moist soft cloth to clean the surface of the equipment. Do not use of store the equipment in dusty or dirty places. 6.Some components of this product are magnetic and metal materials may be adsorbed onto this product. Please do not use bank cards, credit cards or other items with magnetic media near the product so as to avoid losing is stored data due to degaussing zz. Operation instructions 1.Insert the charging cable into the jack at the bottom of the bracket,the product indicator lights up, flashes three times and then lights up continuously, and enters the standby state; 2. Move the mobile phone close to the bracket, open the clamp arm, put it into the mobile phone, the mobile phone starts to charge, and the indicator light is in the state of red light; 3. When you need to remove the mobile phone, touch the touch button on the back of the bracket with your hand, the bracket clamp arm opens, and remove the mobile phone. Precautions 自动车载无线充电器 F12 用户手册 产品介绍 红外传感器 夹臂 触摸按键 LED 氛围灯 输入端口 规格参数 — - - - 输入:5V 2A / 9V 1.67A / 12V 2A 输出:5W / 7.5W / 10W / 15W(MAX) 工作温度:- L139.0*W80.0*H58.2mm 10 to 60°C 充电效率:≥75% 充电距离:≤8.0mm 产品尺寸: — - - - — - - - 功能保护 过温保护 过流保护 过压保护 执行标准：实行Qi无线充电标准 支持WPC Qi无线充电协议 F12 * 1 Type-C 充电线 * 1 汽车出风口支架 * 1 吸盘支架（选配） * 1 螺帽 * 1 用户手册 * 1 包装盒 * 1 包装内容 组装说明 1.将螺帽套入出风口支架球头，注意螺帽套 入方向，是小圆口套入； 2.出风口支架球头用力按入F12主机螺纹接口； 3.调整出风口支架与F12主机螺纹接口垂直， 顺时针拧紧螺帽； 4.将出风口支架夹子插入车内出风口， 按下按钮，夹紧产品，并调整角度。 使用说明 1.将充电线插入支架底部插口，产品指示灯 闪烁三次，然后常亮进入待机状态； 2. 将手机靠近支架，夹臂打开，放入手机， 手机开始充电，红色指示灯常亮； 3. 当您需要取下手机时，用手触摸支架背面的触 摸按钮，支架夹臂打开，取下手机。 注意事项 感谢您选择并使用我们的智能车载无线充， 请仔细阅读用户手册和使用前的注意事项。 无线充电区域 汽车出风口支架 快充模式需使用QC2.0/QC3.0的车载充电器 Fast wireless charging requires QC2.0/QC3.0 quick car charger 请小心处理您的充电器和配件， 以下建议将对您有所帮助有效使用保修服务。 1.请保持设备干燥。 雨，潮湿和各种水可能含 有会腐蚀的矿物质电路。 如果设备是潮湿的， 请将产品干燥尽快或使用干净的软布擦拭。 2.请勿将设备存放在寒冷的地方。 除此以外， 当设备温度升至正常时温度，湿度会在其内部 形成损坏电器。 3.不要试图打开未经授权的设备拆卸或改装会 损坏设备和无线充电设备的相关规定。 4.请勿扔水龙头或敲击设备;设备的粗暴处理会 损坏内部电路板和机械结构。 5.用干净柔软的软布清洁表面设备。不要使用 存储设备在多尘或脏的地方。 6.该产品的一些组件是磁性的金属材料可能被吸 附到该产品上。请勿使用银行卡，信用卡或其他 物品与磁性媒体附近的产品，以避免丢失是由于 消磁而存储的数据 Infrared sersor Wireless charging area Telescopic side arms Touch switch LED ambient Light Type-C input port Car air vent holder is subject to the following two conditions: (1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC's RF Exposure guidelines, This equipment should be installed and operated with minimum 20cm distance between the radiator and your body: Use only the suppli…

Text truncated - open the document above for the full version.

(Shenzhen Yiwen Technology Co., Ltd) (Jun. 28, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2BBT3-F12) [Shenzhen Yiwen Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Yiwen zhang (Shenzhen Yiwen Technology Co., Ltd) (Jun. 28, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2BBT3-F12) [Shenzhen Yiwen Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Yiwen zhang

Shenzhen Yiwen Technology Co., Ltd (2023.06.28) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Automatic Wireless Car Charger / F12 / FCC ID: 2BBT3-F12) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Yiwen zhang Title: RD

Shenzhen Yiwen Technology Co., Ltd (2023.06.28) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Yiwen zhang Title: RD

External Photos

— - - - 1 . V 6 97 / A A / 2 1 2 V V 5 : t1 u . 5 p A n I — - - - — - - - 1 0 W / / W 7 5. 5 1 :W t u / p 5 t u W O — - - - i c t a m o t u A e l e s s i r W C a r C h a r g e r 1 . V 6 97 / A A / 2 1 2 V V 5 : t1 u . 5 p A n I — - - - — - - - . 5 W 7 / / 1 W 0 W 5 : t / u 1 p t 5 u W O S h e n z h e n Y i w e n T e c h n o l o g y C o . , L t d 2 1 F ： l e d o M 2 1 F - 3 T B B 2 : D I C C F

Internal Photos ANT

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page1 of 7 RF EXPOSURE REPORT Compiled by: Reviewed by: Approved by: Arron Liu Bin Mei Rita Xiao / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Automatic Wireless Car Charger FCC ID: 2BBT3-F12 Trademark: N/A Model Number: F12 Prepared For: Shenzhen Yiwen Technology Co., Ltd Address: 605, Yuanxing Building, No. 16, Shandong Bao Community, Wanfeng Dalang, Xinqiao Street, Bao'an District, Shenzhen Manufacturer: Shenzhen Yiwen Technology Co., Ltd Address: 605, Yuanxing Building, No. 16, Shandong Bao Community, Wanfeng Dalang, Xinqiao Street, Bao'an District, Shenzhen Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jun. 13, 2023 Sample tested Date: Jun. 13, 2023 to Jun. 20, 2023 Issue Date: Jun. 20, 2023 Report No.: CTB230614048RFX Test Standards FCC CFR 47 part1, 1.1307(b), 1.1310, 47 CFR§2.1091; KDB 680106 D01 RF Exposure Wireless Charging App v03r01 Test Results PASS Remark: This is wireless charger EMF report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page2 of 7 Table of Contents Page 1 . GENERAL INFORMATION 3 1.1 . Independent Operation Mode 3 1.2 . Test Supporting System 3 2 .LIST OF TEST AND MEASUREMENT INSTRUMENTS 4 2.1 . For conducted emission at the mains terminals test 4 3. METHOD OF MEASUREMENT 5 3. 1.Applicable Standard 5 4. TEST RESULT 5 4.1. Conducted Emission at the Mains Terminals Test 5 4.2. Equipment Approval Considerations: 6 4.3. E and H field Strength 6 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page3 of 7 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: 1.1.1. wireless charger power: 15 W 1.2. Test Supporting System Adapter Description : Adapter Model No. : HP18A-0902000-AU Power Input : AC100-240V~ 1.0A 50/60Hz Output: 9V 2.0A DC Line : Unshielded, Detachable 1.2m Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page4 of 7 2.LIST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Item Equipment Brand Model No. Serial No. Last calibration Calibrated until 1 EMF TESTER Wavecontrol SMP160 19SN0989 2021.08.20 2023.08.29 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page5 of 7 3. METHOD OF MEASUREMENT 3. 1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: RF Exposure Wireless Charging Apps v 03r01. 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Note: Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) The measurement probe was placed at test distance (15cm) which is between the edge of the charger and the geometric centre of probe. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points were completed. e) The EUT were measured according to the dictates of KDB 680106v03r01. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page6 of 7 4.2. Equipment Approval Considerations: The EUT does comply with item 5(b) of KDB 680106 V03R01 1) Power transfer frequency is less than 1MHz Yes, the device operate in the frequency range from 110KHz to 205KHz 2) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power of the primary coil is 15000mW. 3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that able to detect and allow coupling onlybetween individual pair of coils. Yes, the transfer system includes only single primary and secondary coils. 4) Client device is inserted in or placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter. 5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, the EUT is a Mobile Wireless Charger 6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Yes, the EUT field strength levels are less 50% x MPE limit. 4.3. E and H field Strength Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230614048RFX EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page7 of 7 E-Field Stre…

Text truncated - open the document above for the full version.

ANT PHTOT All measurements were performed radiated and therefore additional antenna gain documentation is not required. ANT

Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB230614047RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 21 TEST REPORT Compiled by: Reviewed by: Approved by: Arron Liu Bin Mei Rita Xiao / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Automatic Wireless Car Charger FCC ID: 2BBT3-F12 Trademark: N/A Model Number: F12 Prepared For: Shenzhen Yiwen Technology Co., Ltd Address: 605, Yuanxing Building, No. 16, Shandong Bao Community, Wanfeng Dalang, Xinqiao Street, Bao'an District, Shenzhen Manufacturer: Shenzhen Yiwen Technology Co., Ltd Address: 605, Yuanxing Building, No. 16, Shandong Bao Community, Wanfeng Dalang, Xinqiao Street, Bao'an District, Shenzhen Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jun. 13, 2023 Sample tested Date: Jun. 13, 2023 to Jun. 20, 2023 Issue Date: Jun. 20, 2023 Report No.: CTB230614047RFX Test Standards FCC Part 15 C Test Results PASS Remark: This is wireless charger radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB230614047RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 21 TABLE OF CONTENTS 1. GENERAL INFORMATION ........................................................................................................................ 3 1.1. Report information ................................................................................................................................. 3 1.2. Measurement Uncertainty ..................................................................................................................... 3 1.3. Test Facility ........................................................................................................................................... 3 1.4. Test Uncertainty .................................................................................................................................... 4 2. PRODUCT DESCRIPTION ......................................................................................................................... 5 2.1. EUT Description .................................................................................................................................... 5 2.2. Block Diagram of EUT Configuration ..................................................................................................... 5 2.3. Test Conditions ..................................................................................................................................... 5 2.4. D escriptionOfSupport Units (Conducted Mode) .................................................................................... 6 3. TEST RESULTS SUMMARY ...................................................................................................................... 6 4. TEST EQUIPMENT USED .......................................................................................................................... 7 4.1. MEASUREMENT INSTRUMENTS LIST ............................................................................................... 7 5. CONDUCTED EMISSION TEST ................................................................................................................. 9 5.1. Block Diagram of Test Setup ................................................................................................................. 9 5.2. Test Standard ........................................................................................................................................ 9 5.3. Conducted Emission Limit ..................................................................................................................... 9 5.4. EUT Configuration on Test .................................................................................................................... 9 5.5. Operating Condition of EUT ................................................................................................................ 10 5.6. Test Procedure .................................................................................................................................... 10 5. 7. Test Result .......................................................................................................................................... 10 6. RADIATED EMISSION MEASUREMENT ................................................................................................ 13 6.1. Block Diagram of Test Setup ............................................................................................................... 13 6.2. Test Standard ...................................................................................................................................... 14 6.3. EMI Test Receiver Setup..................................................................................................................... 14 6.4. Test Procedure .................................................................................................................................... 14 6.5. Test Result .......................................................................................................................................... 14 7. OCCUPIED BANDWIDTH ..................................................…

Text truncated - open the document above for the full version.

Radiated Emission 9KHz-30MHz 30MHz-1GHz Conducted emissions
