2BBUV-T6Air Conduction Earphone

Product manual Gulanxo Air conduction Bluetooth earphones statement First of all, thank you for using our company's products! Please read this manual carefully before use to use this product correctly. For better service, the content of this user manual may change. Any weight changes due to the performance and functionality of the product will not be notified separately. Product Introduction The air conduction earphones are equipped with Bluetooth 5.3 chips and are compatible with mainstream Bluetooth devices such as mobile phones and tablets. With directional conduction technology, they achieve high-quality sound quality at CD level, long-lasting battery life, dual speakers on both sides, open directional pronunciation, and unobstructed reception of external sound. They can always access environmental information, ensuring safety, intelligence, health, and convenience. Packaging List Host, charging cable, user manual. ` Product parameters Product brand: Gulanxo Product model: T6 Product Name: Air Conductive Bluetooth Earphones Headphone transmission method: air directional transmission Sound channel: dual speaker stereo Product weight: 30g Bluetooth version: 5.3 Bluetooth distance: about 10 meters, automatically shuts down after leaving the effective distance for 10 minutes Music endurance: about 15 hours Call endurance: about 17 hours Theoretical standby time: 200h Battery capacity: 200mAh Charging time: approximately 1.5-2 hours Charging method: Tpye-C Charging input MAX: 1000mA instructions （1） On/Off key 1. Power on: Press and hold the volume button for 3 seconds, and the red and blue lights will flash alternately waiting for connection. 2. Shutdown: Long press and hold the volume button for 3 seconds （2） Music status 1. When playing music, click "+" to increase the volume and "-" to decrease the volume Double click "+" to play the next track, double click "-" to play the previous track 2. Click the Touch switch to pause the song when the music is in use, and click the Touch switch again to continue playing the song （3） Incoming call mode 1. Click '+' to answer the call 2. Click '-' to reject the call, click '-' to hang up during the call （4） Other functions 1. In working mode, by continuously clicking the volume button three times and summoning a voice assistant, you can achieve functions such as sending text messages, WeChat, making WeChat calls, making video calls, listening to music, navigation, asking about the weather, stocks, listening to jokes, translating, recording, taking photos, recording, setting an alarm clock, and so on. Once again, by continuously clicking the volume button three times, you can exit the voice assistant. （5） LED light prompt 1. Charging: The red light remains on for a long time 2. Fully charged: the blue light remains on for a long time 3. Waiting for link: alternating blue and white lights flashing 4. Successfully connected: Blue light flashing slowly reminder Charging time: 1.5-2 hours When not in use for a long time, charge the battery at least once every month. Tips 1. Before using this product, please read the manual carefully and keep it. 2. For first use, please fully charge this product first. 3. If the product does not charge for a long period of time (more than two weeks), please charge it before use. 4. Please use a certified DC5V-1A adapter from a reputable manufacturer. 5. Repeated charging and discharging can affect the performance of the battery over time, which is a normal phenomenon. warning 1. Do not dismantle, repair or modify this product for any reason, as it may cause fire, electronic breakdown, or even complete damage to the product. 2. Do not place the device in an environment with low or high temperatures (below 0C or above 45 ° C). 3. Do not touch or even immerse the product in liquid. 4. Do not expose the product to prolonged sunlight, as it may deform, age, or break. 5. Do not place the magnetic suction end of the charging line close to metal objects to prevent short circuit hazards caused by magnetic suction of metal objects. FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this unit not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Important safety information 1. Before using this product, please read all safety information to ensure correct and safe use. 2. Using power supplies, chargers, or batteries that are not approved by the original manu…

Text truncated - open the document above for the full version.

Shenzhen Shenghongchi Technology Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Shenghongchi Technology Co., Ltd Address: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product Name: Air Conduction Earphone FCC ID: 2BBUV-T6 Model(s): T6, F7,R8,A9 2.911(d)(5)(i) Equipment Type We, [Shenzhen Shenghongchi Technology Co., Ltd] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Zhaoxian Feng Date: Jun.30, 2023 Title and Company name: chairman/ Shenzhen Shenghongchi Technology Co., Ltd NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Shenghongchi Technology Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Shenghongchi Technology Co., Ltd Address: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product Name: Air Conduction Earphone FCC ID: 2BBUV-T6 Model(s): T6, F7,R8,A9 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Shenghongchi Technology Co., Ltd] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Zhaoxian Feng Date: Jun.30, 2023 Title and Company name: chairman / Shenzhen Shenghongchi Technology Co., Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Shenghongchi Technology Co., Ltd 2.911 (d)(7)USA Agent v1.3 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Shenghongchi Technology Co., Ltd Address: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product Name: Air Conduction Earphone FCC ID: 2BBUV-T6 Model(s): T6, F7,R8,A9 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Shenghongchi Technology Co., Ltd] (“the applicant”) designate [Electronic Mac, Inc.] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Electronic Mac, Inc. Address: 6525 Crown Blvd, # 20805, San Jose, CA 95120 FRN: 0033414541 Contact Name: Ray Sia Telephone No: 408-332-2399 Email: [email protected] Applicant Company name: Shenzhen Shenghongchi Technology Co., Ltd Address: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen FCC Grantee Code: 2BBUV Contact Name: Zhaoxian Feng Telephone No: 13502885358 Email: [email protected] Signature: Title: General Manager Signature: Title: chairman Date: Jun.30, 2023 Date: Jun.30, 2023 Shenzhen Shenghongchi Technology Co., Ltd 2.911 (d)(7)USA Agent v1.3 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhen Shenghongchi Technology Co., Ltd Agent Authorization Company: Shenzhen Shenghongchi Technology Co., Ltd Address: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product Name: Air Conduction Earphone Model Number(s): T6, F7,R8,A9 Product Description: Air Conduction Earphone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jun.30, 2023 Name: Zhaoxian Feng Title: chairman Company: Shenzhen Shenghongchi Technology Co., Ltd

Shenzhen Shenghongchi Technology Co., Ltd Family models declaration letter. Date: July 11, 2023 We Shenzhen Shenghongchi Technology Co., Ltd Of 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product: Air Conduction Earphone Model Name: T6 Serial Model: F7,R8,A9 Difference description of series models: All the model are the same circuit and RF module, except the model names and colors Thanks Sincerely Signature Name: Zhaoxian Feng Date: Jun.30, 2023 Title: chairman

Shenzhen Shenghongchi Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 11, 2023 Subject; Request for Confidentiality FCC ID: 2BBUV-T6 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Zhaoxian Feng Name: Zhaoxian Feng Title: chairman

- Page 1 of 3 - ET-23060673 Product Name: Air Conduction Earphone Test Model No.: T6 Ext Photos - Page 2 of 3 - ET-23060673 - Page 3 of 3 - ET-23060673 -----END-----

型号Model:T6 输入Input:5V 1000mA 气传导耳机Air Conduction Earphone 中国制造Made In China FCC ID: 2BBUV-T6 Manufacturer: Shenzhen Shenghongchi Technology Co., Ltd 20mm*40mm

- Page 1 of 3 - ET-23060673 Product Name: Air Conduction Earphone Test Model No.: T6 Internal photos - Page 2 of 3 - ET-23060673 BT ANT - Page 3 of 3 - ET-23060673 ------END-----

FCC ID: 2BBUV-T6 RF Exposure Evaluation TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). FCC ID: 2BBUV-T6 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(i)(A). (B) in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where: a = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(B) of Part 1.1307 for Pth, including existing exempt transmitters and those being added. b = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(C) of Part 1.1307 for Threshold ERP, including existing exempt transmitters and those being added. c = number of existing fixed, mobile, or portable RF sources with known evaluation for the specified minimum distance including existing evaluated transmitters. Pi = the available maximum time-averaged power or the ERP, whichever is greater, for fixed, mobile, or portable RF source i at a distance between 0.5 cm and 40 cm (inclusive). Pth,i = the exemption threshold power (Pth) according to paragraph (b)(3)(i)(B) of this section for fixed, mobile, or portable RF source i. FCC ID: 2BBUV-T6 ERPj = the ERP of fixed, mobile, or portable RF source j. ERPth,j = exemption threshold ERP for fixed, mobile, or portable RF source j, at a distance of at least λ/2π according to the applicable formula of paragraph (b)(3)(i)(C) of Part 1.1307. Evaluatedk = the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limitk = either the general population/uncontrolled maximum permissible exposure (MPE) or specific absorption rate (SAR) limit for each fixed, mobile, or portable RF source k, as applicable from § 1.1310. Test Result of RF Exposure Evaluation Protocol Fre. (GHz) Output power (dBm) Tune-up power (dBm) Max tune-up power (dBm) ANT Gain ( dBi) Max EIRP (dBm) Max EIRP (mW) Separation distance (cm) Limit (mW) Result BT 2.402 1.08 1±1 2 2.0 4.0 2.51 0.5 2.76 PASS Note: 1. This device is portable device. 2. The source of the evaluation data results is based on the test report ET-23060673E 3. The Maxinum power is less than the limit, complies with the exemption requirements.

2.4GHz2012ChipAntenna:RANT2012F245X5 Dimension(mm) L2.05+-0.15 W1.20+-0.15 T0.85+-0.10 No.TerminalName 1Feeding/GNG 2GND Application: WLAN,802.11b/g,Bluetooth,WLAN,etc... Features SMD,highreliability,ultraImpact,Omni-directional... PartnumberInformation RANT2012F245X5 (A)(B)(C)(D)(E)(F) (A)ProductTypeChipAntenna (B)SizeCode2.0x1.2mm(+-0.2mm) (C)MaterialHighKmaterial (D)Frequency2.4~2.5GHz (E)FeedingmodePIFA&SingleFeeding (F)AntennatypeType=5 ElectricalSpecification WorkingFrequencyRange2400~2484MHz Bandwidth84(Min.) PeakGain2.0dBi(Typ.) Impedance50Ohm Returnloss10dB(Min) PolarizationLinear AzimuthBeamwidthOmni-directional OperationTemperature( °C )-40~85 °C ResistancetoSolderingHeats 10sec.(@280°C) TerminationNi/Au(Leadless) ThespecificationisdefinedonEVB. DimensionandTerminalConfiguration RAINInternationalTechnologyCo.,Ltd.TEL:13530576606 Evaluation BoardReference PCB DimensionAntenna Layout Reference Unit :mm Electrical Characteristics Return Loss Return Loss & Radiation 1 Frequency(MHz) S11 (dB) 2400-10.77 2450-24.81 2484-10.243 Radiation Z Y X 2400MHz2450MHz2500MHz Efficiency70.56%75.25%71.01% Peak Gain1.72 dBi1.95 dBi1.69 dBi Directivity2.26 dBi 2.69 dBi2.11 dBi Frequency 2.4GHz2012ChipAntenna:RANT2012F245X5 TapingSpecifications ReelandTapingSpecification ReelSpecification TYPESIZEABCD 20127”5K/Reel 9.0±0.5 60±213.5±0.5178±2 TappingSpecification PackagingTypeABWEFGHTDP PaperType2012 1.50±0.202.30±0.208.0±0.201.75±0.103.5±0.054.0±0.102.0±0.050.75±0.101.57±0.104.0±0.1 2.4GHz2012ChipAntenna:RANT2012F245X5 ReliabilityTable TestItemProcedure Requirements CeramicType Remark (Reference) Electrical Characterization Fulfilltheelectrical specification UserSpec. Thermal Shock 1.Preconditioning: 50±10°C/1hr,thenkeepfor24±1hrsatroomtemp. 2.Initialmeasure:Spec:referInitialspec. 3.Rapidchangeoftemperaturetest: -30°Cto+85°C;100cycles; 15minutesatLowercategorytemperature; 15minutesatUppercategorytemperature. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 107 Temperature Cycling 1.Initialmeasure:Spec:referInitialspec. 2.100Cycles(-30°Cto+85°C),SoakMode=1(2Cycle/hours). 3.Measurementat24±2Hoursaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. JESD22 JA104 HighTemperature Exposure 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered;500hours@T=+85°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 LowTemperature Storage 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered:500hours@T=-30°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 Solderability (SMDBottomSide) Dippingmethod: a.Temperature:235±5°C b.Dippingtime:3±0.5s Thesoldershouldcover over95%ofthecritical areaofbottomside. IEC60384-21/22 4.10 SolderingHeat Resistance (RSH) Preheatingtemperature:150±10°C. Preheatingtime:1~2min. Soldertemperature:260±5°C. Dippingtime:5±0.5s NoVisibleDamage.IEC60384-21/22 4.10 Vibration5g'sfor20min.,12cycleseachof3orientations Note:Use8"X5"PCB.031"thick7securepointson,onelong sideand2securepointsatcornersofoppositesides.Parts mountedwithin2"fromanysecurepoint.Testfrom10-2000 Hz. NoVisibleDamage.MIL-STD-202 Method204 Mechanical Shock Threeshocksineachdirectionshallbeappliedalongthethree mutuallyperpendicularaxesofthetestspecimen(18shocks) Peakvalue:1,500g’s Duration:0.5ms Velocitychange:15.4ft/s Waveform:Half-sine NoVisibleDamage.MIL-STD-202 Method213 Humidity Bias 1.Humidity:85%R.H.,Temperature:85±2°C. 2.Time:500±24hours. 3.Measurementat24±2hrsaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 Method106 2.4GHz2012ChipAntenna:RANT2012F245X5 2.4GHz2012ChipAntenna:RANT2012F245X5 _ Board Flex (SMD) 1.Mountingmethod: IR-Reflow.PCBSize(L:100×W:40×T:1.6mm) 2.Applytheloadindirectionofthearrowuntilbendingreaches 2mm. NoVisibleDamage.AEC-Q200 005 AdhesionForceof1.8Kgfor60seconds.NoVisibleDamage Magnificationof20Xor greatermaybeemployed forinspectionofthe mechanicalintegrityofthe devicebodyterminalsand body/terminaljunction. AEC-Q200 006 Physical Dimension Anyapplicablemethodusingx10magnification,micrometers, calipers,gauges,contourprojectors,orothermeasuring equipment,capableofdeterminingtheactualspecimen dimensions. Inaccordancewith specification. JESD22 JB100 RevisionHistory RevisionDateContent 12020/10/15NewDatasheet

Report No.: ET-23060673E This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: Shenzhen Shenghongchi Technology Co., Ltd Address of Applicant: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Manufacturer/Factory: Shenzhen Shenghongchi Technology Co., Ltd Address of Manufacturer/Factory: 401, Building C, Wancheng Tongsheng Science and Technology Park, Dalang Street, Longhua District, Shenzhen Product Name: Air Conduction Earphone Model No.: T6,F7,R8,A9 Trade Mark: Gulanxo FCC ID: 2BBUV-T6 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: Jun.25, 2023- Jun.28, 2023 Date of report issued: Jul.11, 2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Remark: The results shown in this test report refer only to the sample(s) tested , this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 43 - Report No.: ET-23060673E Report Revision History Report No. Description Issue Date ET-23060673E Original Jul.11, 2023 - Page 3 of 43 - Report No.: ET-23060673E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1 TEST SUMMARY ......................................................................................................................................4 2 GENERAL INFORMATION .......................................................................................................................5 2.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 2.2 TEST MODE .........................................................................................................................................7 2.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 2.4 DEVIATION FROM STANDARDS ..............................................................................................................7 2.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 2.6 TEST FACILITY.....................................................................................................................................7 2.7 TEST LOCATION...................................................................................................................................7 2.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 3 TEST INSTRUMENTS LIST ......................................................................................................................8 4 TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 4.1 ANTENNA REQUIREMENT ......................................................................................................................9 4.2 CONDUCTED EMISSIONS ....................................................................................................................10 4.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................13 4.4 20DB EMISSION BANDWIDTH ..............................................................................................................14 4.5 CARRIER FREQUENCIES SEPARATION .................................................................................................17 4.6 HOPPING CHANNEL NUMBER .............................................................................................................20 4.7 DWELL TIME ......................................................................................................................................22 4.8 BAND EDGE.......................................................................................................................................26 4.8.1 Conducted Emission Method ......................................................................................................26 4.8.2 Radiated Emission Method .........................................................................................................29 4.9 SPURIOUS EMISSION .........................................................................................................................31 4.9.1 Conducted Emission Method ......................................................................................................31 4.9.2 Radiated Emission Method ..............................…

Text truncated - open the document above for the full version.
