ChargePort M TA-8350 INSTALLATION GUIDE 2 ChargePort M Installation Guide 1 ChargePort M Installation Guide Table of Contents 2Products Covered by this Installation Guide 2Part Numbers 3Specifications 3Important Safety Instructions 4Other Notices 4Approval Information 4What is Included in the Box 4Dimensions 5Preparation for Installation 5Installation 6Additional Information 7Warranty 7Contact Details 2 ChargePort M Installation Guide 3 ChargePort M Installation Guide Specifications Input (PSU supplied):USB Type-C, 15V/3A, 12V/3A. Wireless output:15W+5W+5W max. Charging frequencies: 127.7KHz/110-205KHz. Operating temp. range: 0~30°C. Storage temp. range:-20 ~ 40°C. Operating humidity:10% ~ 80% RH. Storage humidity:5% ~ 95% RH. . Size:199*90.8*128.8±0.5mm. Weight:650±10g. Important Safety Instructions • Read these instructions carefully before attempting any installation. Follow all instructions and heed all warnings. These instructions should be kept for future reference. • This equipment is designed for indoor use only. • The power supply must be readily accessible at all times. • Ensure the power cable is uncoiled before installation. • Protect the power cable from being walked on or pinched. • The maximum distance to the receptacle (mains outlet) is determined by the length of the power cable. • Clean only with a dry cloth. • Servicing is required when the equipment has been damaged in any way. Refer all servicing to qualified service personnel. • Unplug this equipment during lightning storms or when unused for long periods of time. • The wireless chargers may get a little warm during use, this is normal. • Do NOT install or use this equipment near water. • Do NOT expose this apparatus to rain or moisture. • Do NOT expose to dripping or splashing. No objects filled with liquid such as vases shall be placed on the equipment. • Do NOT install near any heat sources such as radiators, convection heaters or other apparatus such as amplifiers that produce heat. • Do NOT use corrosive, abrasive or solvent based cleaners on the product. • Do NOT attempt to disassemble this product, it may result in short- circuit or even damage. Products Covered by this Installation Guide ChargePort M is a 3-in-1 Qi wireless charger that is designed for charging your Apple products. iPhone, Apple Watch and AirPods Designed to optimally charge Apple products, ChargePort M is an ideal charging solution for your hotel guests and is compatible with MagSafe equipped iPhones, Apple Watch and AirPods. MagSafe for faster charging MagSafe technology takes wireless charging to the next level by automatically aligning the charging coils and charging an iPhone at up to 15W peak power. Easy Install Simply place on a desktop or at the bedside for ultimate charging convenience.For your peace of mind ChargePort M is fully FCC, CE and MFi certified. Security A security bracket is supplied to allow the ChargePort M to be secured to the desk or nightstand if required, it also retains the power cable to prevent removal. Power ChargePort M is supplied with a 1.8 metre USB cable and a compatible power supply. Part Numbers TA-8350-US-A00ChargePort M, Grey/White, 45W GaN US PSU. TA-8350-UK-A00ChargePort M, Grey/White, 45W GaN UK PSU. TA-8350-EU-A00ChargePort M, Grey/White, 45W GaN EU PSU. 4 ChargePort M Installation Guide 5 ChargePort M Installation Guide Other Notices Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the the operation of this device or its compliance with safety and regulatory standards. Approval Information FCC - 47 CFR FCC Part 15 Subpart B. CE - EN 55032:2012+AC:2013, EN 55024:2010+A1:2015. Apple MFi. WPC Qi Certified. What is Included in the Box • 1 x ChargePort M • 1 x 45W GaN Power Supply • 1 x 1.8 metre cable USB-C power cable • 4 x adhesive rubber feet • 1 x security bracket • 1 x self adhesive pad • 1 x security lanyard • Screws for fixing security bracket and lanyard • 1 x Installation Guide Dimensions 199 mm 109 mm 133 mm Preparation for Installation Before starting installation make sure you have read and understood the “Important Safety instructions”. ChargePort M must be sited so the power outlet can be reached with the cord provided and without modification to the cord. Make sure the installation location is: • flat and even, • out of direct sunlight or other sources of heat, and • dry and away from any sources of water. ChargePort M is not suitable for installation in a bathroom. Installation Select the security option(s) you require. Adhesive Pad Remove the protective sheet from one side of the adhesive pad and carefully stick it to the base of the ChargePort M as shown. Repeat the process with the 4 rubber feet to cover the screw holes in the base. Finally remove the protective sheet from the bottom of the adhesive pad and carefully place ChargePort M on the desk and apply light pressure to fix. Security Bracket If using the security bracket, plug the DC power connector in to the rear of the ChargePort M before fitting the bracket. Attach the bracket to the base of the ChargePort M using the screws provided, then stick the rubber feet over the screws. Ensure the DC power cord is properly retained by the bracket. The bracket can now be screwed to the furniture. 6 ChargePort M Installation Guide 7 ChargePort M Installation Guide Lanyard The lanyard is secured by attaching it to the security bracket using the screw provided. Finishing Installation Plug the supplied adapter into a suitable mains outlet. The indicator on the front should show solid blue. Additional Information ChargePort M has three wireless charging pads, The main iPhone charging pad can charge up to 15W, the other two charge up to 5W each. Place device to be charged on one of the Qi charging pads and adjust position until the charging …
