2BBXR-CSM9Wireless collar microphone

Dongguan Chensheng Electronic Technology Co., Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 07, 2023
Application Purpose: Original Equipment
Date of Application: Aug 07, 2023
Equipment Note: Wireless collar microphone
Frequency Range: 2402.00000000 - 2480.00000000
Company: Dongguan Chensheng Electronic Technology Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

External Photos

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 7 Product Name: Wireless collar microphone Model No.: CS-M9 EUT Constructional Details External Photo Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 7 Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 7 Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 7 Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 5 of 7 Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 6 of 7 Report No.: HTT202306013 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 7 of 7 ------End------

ID Label/Location Info

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location Model No.: CS-M9 FCC ID : 2BBXR-CSM9

Internal Photos

RF Exposure Info

RF Exposure evaluation FCC ID: 2BBXR-CSM9 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -4.0 -2.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 -1.0 0.7943 0.2487<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

Test Report

Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 1 of 4 Inmm L±± W±± T a±± Function Feeding Point NC Need the layout file of the above? Contact us at: www.johansontechnology.com/en/ask-a-technical-question.html Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved Note: It is recommended that the designer leave available slots for a "pi" (or shunt-series- shunt) network. The antenna matching network values here are used when antenna is mounted on Johanson's evaluation board. The matching values and topology on clinet's PCB will be different. Need our help tuning the antenna on your board? Contact our RF Applications Eng Team at: www.johansontechnology.com/component/techquestion Antenna Tuning services: www.johansontechnology.com/ipcantennaservices No. 1 2 0.0200.0120.500.30 Mounting ConsiderationsTerminal Configuration 0.0630.0081.600.20 0.051 +.004/-.008 1.30 +0.1/-0.2 Reel Quanity3,000 Mechanical Dimensions 0.1260.0083.200.20 Input Power2W max. (CW) Impedance50 Ω Operating Temperature-40 to +125°C Peak Gain0.5 dBi typ. (XZ-V) Average Gain-0.5 dBi typ. (XZ-V) Return Loss9.5 dB min. "High Frequency Ceramic Solutions" General Specifications Part Number2450AT18A100 Frequency Range2400 - 2500 Mhz 7/18/2014 1 2 L W a T * 2.6 4.2 1.6 1.9 0.4 2.7nH 1.0pF 3.9nH a) Without Matching Circuits b) With Matching Circuits Mount these devices with mark facing up. Units: mm * Line width should be designed to provide 50 Ω impedance matching characteristics. * Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 2 of 4 Test Board: P/N: 2450AT18A100-EB1SMA (orderable item) Return Loss with matching circuit @ +25 CVSWR with matching circuit @ +25C and +125C Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Typical Electrical Characteristics (T=25 o C) The antenna matching network values here are used when antenna is monted on Johanson's evaluation board. The matching values on clinet's PCB will be different. Go to: www.johansontechnology.com/ipcantennaservices and see how to obtain the new values. If you need further help, contact our RF Applications Eng Team at: 7/18/2014 GND 13.5mm 6.5mm 39.5mm6.5mm Matching Circuit No Ground 50Feed Line Antenna 19mm This 50ΩFeedline can be as short as needed, this lenth is just for reference to our EVB GND www.johansontechnology.com/component/techquestion Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 3 of 4 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Typical Radiation Patterns at 2.45GHz (+25C) 7/18/2014 XY-V/XY-H 180° 270° 0° 90° X Z Y XY-cut scanning direction XY cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H 180° 270° 0° 90° X Z Y XZ-cut scanning direction 180° 270° 0° 90° X Z Y YZ-cut scanning direction XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 4 of 4 Would you like Johanson Technology's RF team to help you design and tune our antenna on your board? Click on the link below: Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved www.johansontechnology.com/technical-notes/msl-rating.html Suffix = S Suffix = E Suffix = S/E/R 2450AT18A100-EB1SMA (Page 2) Orderable item! www.johansontechnology.com/ipcsoldering-profile Antenna layout review, tuning, and characterization services www.johansontechnology.com/ipcantennaservices Packaging information www.johansontechnology.com/technical-notes/rohs-compliance.html Packaging Style Termination style RoHS Compliance MSL Info "High Frequency Ceramic Solutions" 7/18/2014 P/N Suffix Part Number Explanation Eg. 2450AT18A100R (MOQ Applies) Eg. 2450AT18A100(S, E, R) Soldering Information Evaluation Board(s) (1-port SMA antenna test boards) www.johansontechnology.com/ipcpackaging.html Bulk (loose pieces) 100% Tin (RoHS) T & R Tin / Lead T & R (Reverse)Suffix = R Please consult Factory Eg. 2450AT18A100S Eg. 2450AT18A100E AEC-Q2000 qualification available after special p/n: 2450AT18A100-AEC order. MOQ of 24K PCS applies for AEC and allow 16 weeks for AEC report leadtime. Recommneded Storage Condition and Max Shelf Life www.johansontechnology.com/ipcstorage-shelflife

Test Report

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202306013F01 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 31 TEST Report Applicant: Dongguan Chensheng Electronic Technology Co., Ltd Address of Applicant: Room 302, Building 1, No. 6 Huangyong Commercial Road, Zhongtang Town, Dongguan City, Guangdong Province Manufacturer : Dongguan Chensheng Electronic Technology Co., Ltd Address of Manufacturer : Room 302, Building 1, No. 6 Huangyong Commercial Road, Zhongtang Town, Dongguan City, Guangdong Province Equipment Under Test (EUT) Product Name: Wireless collar microphone Model No.: CS-M9 Series model: CS-K1, CS-K2, CS-K3, CS-K5, CS-K6, CS-K8, CS-K9, CS-K11, CS-J11, CS-J13, CS-K11, CS-K13, CS-K35, CS-K36, CS-K60, CS-K61, CS-K62, CS-K63, CS-K66, CS-K80, CS-K81, CS-K82, CS-K83, CS-K90, CS-K91, CS-K92, CS-K93, CS-M1, CS-M6, CS-M8 Trade Mark: N/A FCC ID: 2BBXR-CSM9 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: May.31,2023 Date of Test: May.31,2023~Jun.06,2023 Date of report issued: Jun.06,2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202306013F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 31 1. Version Version No. Date Description 00 Jun.06,2023 Original Tested/ Prepared By Date: Jun.06,2023 Project Engineer Check By: Date: Jun.06,2023 Reviewer Approved By : Date: Jun.06,2023 Authorized Signature Report No.: HTT202306013F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 31 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 8 6. TEST RESULTS AND MEASUREMENT DATA ............................................................................................ 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED OUTPUT POWER .................................................................................................................. 12 6.3. CHANNEL BANDWIDTH ............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 15 6.5. BAND EDGES ........................................................................................................................................... 17 6.5.1 Conducted Emission Method .......................................................................................................... 17 6.5.2 Radiated Emission Method ............................................................................................................. 18 6.6. SPURIOUS EMISSION ................................................................................................................................ 20 6.6.1 Conducted Emission Method .......................................................................................................... 20 6.6.2 Radiated Emission Method ............................................................................................................. 22 6.7. ANTENNA REQUIREMENT .......................................................................................................................... 30 7. TEST SETUP PHOTO ..............................…
