2BBYU-BEAGLEV23d printer camera

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Shenzhen Mintion Technology Co., Ltd Grantee code: 2BBYU FCC ID: 2BBYU-BEAGLEV2 Contact Name: Zhang xianshen Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China Telephone: 0755-28536050 Fax: 0755-28536050 E-mail: [email protected] [Shenzhen Mintion Technology Co., Ltd] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Mintion Technology Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK- LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/07/08 Applicant’s Name: Zhang xianshen US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Mintion Technology Co., Ltd Grantee code: 2BBYU FCC ID: 2BBYU-BEAGLEV2 Contact Name: Zhang xianshen Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China Telephone: 0755-28536050 Fax: 0755-28536050 E-mail: [email protected] i. [Shenzhen Mintion Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Mintion Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Mintion Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/07/08 Applicant’s Name: Zhang xianshen Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Mintion Technology Co., Ltd Product function Declaration Company: Shenzhen Mintion Technology Co., Ltd Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China Product Name: 3d printer camera Model Number: Beagle V2 FCC Identifier: 2BBYU-BEAGLEV2 We (Shenzhen Mintion Technology Co., Ltd ) here by state that The product has (BT) function at the beginning of design. However, due to the iteration of the product, this function is no longer required at present, so through the (Software mask) method, the function is forced off, and the product (FCC ID: 2BBYU-BEAGLEV2) no longer has the (BT) function. Signature: Name: Zhang xianshen Date: 2023-07-08 Title: Manager Signature of applicant:

Shenzhen Mintion Technology Co., Ltd 1/1 Letter of Authorization Company: Shenzhen Mintion Technology Co., Ltd Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China Product Name: 3d printer camera Model Number: Beagle V2 FCC Identifier: 2BBYU-BEAGLEV2 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Zhang xianshen Date: 2023-07-08 Title: Manager Signature of applicant:

Shenzhen Mintion Technology Co., Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-07-08 Subject: Request for Confidentiality FCC ID: 2BBYU-BEAGLEV2 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zhang xianshen Title: Manager ☒

C5266091_X13_Ed.1 1/1 Shenzhen Mintion Technology Co., Ltd FCC Software Configuration Control Declaration Date: 2023-07-08 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: 3d printer camera / Beagle V2 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Zhang xianshen Date: 2023-07-08 Title: Manager Signature of applicant:

Size: 22*18mm M/N: Beagle V2 FCC ID: 2BBYU-BEAGLEV2 Label location

ANT

FCC ID: 2BBYU-BEAGLEV2 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 15.118 32.4938 0.01515 1.0 PASS 802.11g 13.509 22.4337 0.01046 1.0 PASS 802.11n HT20 14.506 28.2228 0.01316 1.0 PASS 802.11n HT40 13.744 23.6810 0.01104 1.0 PASS Remark: antenna gain=3.7dBi wifi 5G mode: Band Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Band 4 802.11a 11.737 14.9176 0.00606 1.0 PASS 802.11n HT20 11.454 13.9766 0.00568 1.0 PASS 802.11n HT40 10.915 12.3453 0.00501 1.0 PASS 802.11ac HT20 11.762 15.0038 0.00609 1.0 PASS 802.11ac HT40 11.363 13.6867 0.00556 1.0 PASS 802.11ac HT80 10.857 12.1815 0.00495 1.0 PASS Remark: antenna gain=3.1dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits = 0.01515/1 + 0.00609/1 = 0.02124< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

-1- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com WIFI 2.4/5G antenna test report Jeany Ling Nov. 23, 2022 •Antenna structure -2- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com [RTL8821CS] module antenna test report •Photo mm -4- Copyright © 2010Realtek Semiconductor Corp. www.realtek.com •Return Loss [RTL8821CS] module antenna test report 234567 Frequency (GHz) 40 20 0 Return Loss(dB) 10 30 * C4=C5=NC, L1=0ohm R e a l t e k •Radiation Patterns –Frequency : 2400MHz, 2450MHz, 2480MHz, 5150MHz, 5500MHz, 5850MHz and 5925MHz –Test plane : xy-plane, xz-plane and yz-plane –Input power : SG 0dBm –Place: RTK 4F chamber –Horn h: horizontal polarization –Horn v: vertical polarization [RTL8821CS] module antenna test report[ SG AUT Horn -z xy-plane SG AUT Horn y xz-plane SG AUT Horn x yz-plane y x R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.8-4.8 Pol.peakavg. v-4.8-12.6 xy-plane yz-plane Pol.peakavg. v-2.5-6.7 Pol.peakavg. h-5.5-12.4 Pol.peakavg. v-5.8-11.8 Pol.peakavg. h+1.4-6.1 xz-plane •Radiation Patterns –2400 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.5-4.4 Pol.peakavg. v-5.4-11.3 xy-plane yz-plane Pol.peakavg. v+0.1-4.2 Pol.peakavg. h-4.2-11.8 Pol.peakavg. v-4.4-10.6 Pol.peakavg. h+1.7-5.2 xz-plane •Radiation Patterns –2450 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.7-3.9 Pol.peakavg. v-4.0-10.8 xy-plane yz-plane Pol.peakavg. v-0.5-4.5 Pol.peakavg. h-6.2-12.5 Pol.peakavg. v-4.1-10.2 Pol.peakavg. h+1.8-5.3 xz-plane •Radiation Patterns –2480 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+2.1-2.4 Pol.peakavg. v+0.4-8.5 xy-plane yz-plane Pol.peakavg. v-0.8-5.0 Pol.peakavg. h-2.6-7.7 Pol.peakavg. v+1.7-2.4 Pol.peakavg. h+1.3-4.0 xz-plane •Radiation Patterns –5150 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+3.1-3.6 Pol.peakavg. v-0.1-8.9 xy-plane yz-plane Pol.peakavg. v-0.6-4.1 Pol.peakavg. h-1.6-7.3 Pol.peakavg. v-0.1-3.1 Pol.peakavg. h+2.6-4.0 xz-plane •Radiation Patterns –5500 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.5-2.5 Pol.peakavg. v+2.1-7.2 xy-plane yz-plane Pol.peakavg. v+0.9-2.5 Pol.peakavg. h-2.3-7.7 Pol.peakavg. v+2.2-1.5 Pol.peakavg. h+3.1-3.2 xz-plane •Radiation Patterns –5850 MHz vertical R e a l t e k [RTL8821CS] module antenna test report horizontal Pol.Peakavg. h+1.5-2.8 Pol.peakavg. v+1.3-7.6 xy-plane yz-plane Pol.peakavg. v+1.0-1.9 Pol.peakavg. h-1.6-6.6 Pol.peakavg. v+1.4-1.7 Pol.peakavg. h+2.9-3.5 xz-plane •Radiation Patterns –5925 MHz vertical R e a l t e k [RTL8821CS] module antenna test report •Antenna Gain Table Frequency (MHz)Peak gain (dBi) 2400+1.8 2450+3.5 2480+3.7 Frequency (MHz)Peak gain (dBi) 5150+2.1 5500+3.1 5850+3.1 5925+2.9 Shenzhen Mintion Technology Co., Ltd Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China

Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 1 of 58 FCC Part 15E Test Report FCC ID: 2BBYU-BEAGLEV2 Applicant: Shenzhen Mintion Technology Co., Ltd Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China Manufacturer: Shenzhen Mintion Technology Co., Ltd Address: Room 605, A Block, 2nd Building, COFCO Xiangyun Plaza, Longcheng Street, Longgang District, Shenzhen, 518000, China EUT: 3d printer camera Trade Mark: Mintion Model Number: Beagle V2 Date of Receipt: Jun. 14, 2023 Test Date: Jun. 14, 2023 - Jun. 21, 2023 Date of Report: Jun. 21, 2023 Prepared By: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Applicable Standards: FCC PART 15 E 15.407 ANSI C63.10:2013 Test Result: Pass Report Number: BTF230718R02102 Project Engineer: Elma.yang EMC Manager: Ryan.CJ This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of BTF Testing Lab (Shenzhen) Co., Ltd. Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 2 of 58 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~40GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 26 3.3.1 TEST REQUIREMENT: 26 3.3.2 TEST PROCEDURE 26 3.3.3 DEVIATION FROM TEST STANDARD 26 3.3.4 TEST SETUP 26 3.3.5 EUT OPERATING CONDITIONS 26 4 . AVERAGE OUTPUT POWER 29 4.1 APPLIED PROCEDURES / LIMIT 29 4.1.1 TEST PROCEDURE 29 4.1.2 DEVIATION FROM STANDARD 29 4.1.3 TEST SETUP 29 4.1.4 EUT OPERATION CONDITIONS 29 Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 3 of 58 Table of Contents Page 4.1.5 TEST RESULTS 30 5 . POWER SPECTRAL DENSITY TEST 34 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 5.1.2 DEVIATION FROM STANDARD 34 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 TEST RESULTS 35 6 . 6DB BANDWIDTH TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . DUTY CYCLE TEST SIGNAL 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 TEST PROCEDURE 44 7.1.2 DEVIATION FROM STANDARD 44 7.1.3 TEST SETUP 44 7.1.4 EUT OPERATION CONDITIONS 44 7.1.5 TEST RESULTS 45 8 . FREQUENCY STABILITY 47 8.1 APPLIED PROCEDURES / LIMIT 47 8.1.1 TEST PROCEDURE 47 8.1.2 DEVIATION FROM STANDARD 47 8.1.3 TEST SETUP 47 8.1.4 EUT OPERATION CONDITIONS 47 8.1.5 TEST RESULTS 48 9 . TRANSMISSION IN THE ABSENCE OF DATA 50 9.1 STANDARD REQUIREMENT 50 9.2 TEST RESULT 50 10 . ANTENNA REQUIREMENT 50 10.1 STANDARD REQUIREMENT 50 10.2 EUT ANTENNA 50 11 . TEST SEUUP PHOTO 51 12 . EUT PHOTO 53 Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 4 of 58 Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 5 of 58 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.407(b), 15.209 Radiated Spurious Emission PASS 15.407 (b) Band Edge Emission PASS 15.407 (a) Average Output Power PASS 15.407 (a) Power Spectral Density PASS 15.407(e) 6dB bandwidth PASS 15.407(g) Frequency Stability PASS 15.407(c) Transmission in case of Absence of Information PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 Bandwidth ±0.2MHz 9 Power Spectral Density ±2.45dBm 10 Frequency Stability ±0.3MHz 11 DUTY CYCLE ±0.53dB Test Report Number: BTF230718R02102 Test Report Tel: +86-0755-23146130 Email: [email protected] Page 6 of 58 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: 3d printer camera Trademark Mintion Model No.: Beagle V2 Model Difference N/A Operation Frequency: 5745-5825MHz(802.11a/n/ac(HT20)) 5755-5795MHz(802.11n/ac(HT40)) 5775MHz (802.11ac(HT80)) Channel numbers: See channel list Channel separation: 20MHz/40MHz/80MHz Modulation technology: 64QAM, 16QAM, QPSK, BPSK for OFDM Rate of Transmitter 802.11a: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps,54Mbps 802.11n: Up to 500Mbps Antenna Type: Built-in antenna Antenna gain: 3.1dBi Power supply: DC 5V from adapter Adapter: Model Number: GAT-0501000U Input: AC 100-240V 0.4A 50/60Hz Output: DC 5.0V/1000mA Note: 1.For a more detailed features description, plea…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
