2BBZIH020SHearing Aid

We refer to the safety regulations and technical information related to Orka Two here. Tech Book Contents 1. Safety and health information Intended use Indications for use Hearing health care information Important safety instructions Warnings Cautions Contraindications 2. Product specifications Dimensions and weight Compatibility Performance parameters Power supply specification Transport and storage conditions 3. Regulatory and legal information Compliance information 05 05 05 05 08 09 10 10 11 11 11 12 14 14 15 15 Classification Expected service life of product and components Disposals Privacy policy Limited warranty Returns and exchanges Information of symbols 20 20 20 21 21 21 22 05 Intended use The Orka Two™ hearing aids are designed for people who have perceived mild to moderate hearing loss. They are wireless air conduction hearing aids that can be customized to fit the user’s needs. Hearing health care information WARNING: People younger than 18 should go to a doctor before using this. People younger than 18 years old need specialized care, and using this without a medical evaluation may worsen impairment or disability. A hearing aid user who is younger than 18 should have a recent medical evaluation from a doctor, preferably an ear-nose-throat doctor (an ENT). Before using this, a doctor should determine that the use of a hearing aid is appropriate. WARNING to Hearing Aid Dispensers: You should advise a prospective hearing aid user to consult promptly with a doctor, preferably an ear spe- cialist such as an ENT, before dispensing a hearing aid if you determine through inquiry, actual observation, or review of any other available information concerning the prospective user, that the prospective user has any of the following conditions: Indication for use The Orka Two™ hearing aids are meant to increase the volume of sound for people who have perceived mild to moderate hearing loss. The user can adjust the device according to their individual hearing needs without any pre-programming or hearing test. These hearing aids are designed for direct-to-consumer sale and usage, without the involvement of a hearing care professional. 1. Safety and health information 06 • Visible deformity of the ear, either congenital or traumatic • Fluid, pus, or blood coming out of the ear within the previous 6 months • Pain or discomfort in the ear • History of excessive ear wax or suspicion that something is in the ear canal • Dizziness, either recent or long-standing • Sudden, quickly worsening, or fluctuating hearing loss within the previous 6 months • Hearing loss or ringing (tinWnitus) only in one ear or a noticeable difference in hearing between ears • Audiometric air-bone gap equal to or greater than 15 dB at 500 Hz, 1000 Hz, and 2000 Hz WARNING to Hearing Aid Dispenser, Outputs over 132 dB SPL: You should exercise special care in selecting and fitting a hearing aid with a maximum output that exceeds 132 dB SPL because it may impair the remaining hearing of the hearing aid user. Caution: This is not hearing protection. You should remove this device if you experience overly loud sounds, whether short or long-lasting. If you’re in a loud place, you should use the right kind of hearing protection instead of wearing this device. In general, if you would use ear plugs in a loud place, you should remove this device and use ear plugs. Caution: The sound output should not be uncomfortable or painful. You should turn down the volume or remove the device if the sound output is uncomfortably loud or painful. If you consistently need to turn the volume down, you may need to further adjust your device. Caution: You might need medical help if a piece gets stuck in your ear. If any part of your hearing aid, like the eartip, gets stuck in your ear, and you can’t easily remove it with your fingers, get medical help as soon as you can. You should not try to use tweezers or cotton swabs because they can push the part farther into your ear, injuring your eardrum or ear canal, possibly seriously. 07 Note: What you might expect when you start using a hearing aid A hearing aid can benefit many people with hearing loss. However, you should know it will not restore normal hearing, and you may still have some difficulty hearing over noise. Further, a hearing aid will not prevent or improve a medical condition that causes hearing loss. People who start using hearing aids sometimes need a few weeks to get used to them. Similarly, many people find that training or counseling can help them get more out of their devices. If you have hearing loss in both ears, you might get more out of using hearing aids in both, especially in situations that make you tired from listening-for example, noisy environments. Note: Tell FDA about injuries, malfunctions, or other adverse events. To report a problem involving your hearing aid, you should submit information to FDA as soon as possible after the problem. FDA calls them “adverse events,” and they might include: skin irritation in your ear, injury from the device (like cuts or scratches, or burns from an overheated battery), pieces of the device getting stuck in your ear, suddenly worsening hearing loss from using the device, etc. Instructions for reporting are available at https://www.fda.gov/Safety/MedWatch, or call 1-800-FDA-1088. You can also download a form to mail to FDA. Note: Hearing loss in people younger than 18 • People younger than 18 should see a doctor first, preferably an earnose-throat doctor (an ENT), because they may have different needs than adults. • The doctor will identify and treat medical conditions as appropriate. • The doctor may refer the person to an audiologist for a separate test, a hearing aid evaluation. • The hearing aid evaluation will help the audiologist select and fit the appropriate hearing aid. A person who is younger than 18 years old with hearing loss should have a medical evaluation by a doctor, preferably an ENT, before buying a hearing aid. The p…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Orka Health Co., Ltd. Address Room 01B101, Building 2, No. 118 Rongke Road, Shanghai, China Grantee Code 2BBZI FCC ID 2BBZIH020S Authorized Contact Name Hongcheng Sun Contact Email [email protected] Contact Phone +86-2162523708 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [Orka Health Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Orka Health Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-07-12 Print Name: Hongcheng Sun Title: CEO *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Orka Health Co., Ltd. Date: 2023-07-12 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2BBZIH020S To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Orka Health Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Hongcheng Sun Title: CEO Signature: On behalf of Company: Orka Health Co., Ltd. Telephone: +86-2162523708

Orka Health Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Orka Health Co., Ltd. Room 01B101, Building 2, No. 118 Rongke Road, Shanghai, China Regarding: Confidentiality Request regarding application for FCC ID: 2BBZIH020S LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Hongcheng Sun Title: CEO Company Name: Orka Health Co., Ltd.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 7 External Photos for SHCR2306001247ME SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 7 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 7 Left Earbud SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 7 Right Earbud SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 7

Remark ： It’s hard to put FCC statement on the product due to device’s irregular appearance. FCC statement will be placed in the user manual which the device is marketed.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 11 Internal Photos for SHCR2306001247ME SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 11 EUT Constructional Details (EUT Photos) Left Earbud SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 11 Right Earbud SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 11 PCB for Both Earbuds SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 11

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124703 Page: 1 of 11 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: SHCR2306001247ME FCC ID: 2BBZIH020S Applicant: Orka Health Co., Ltd. Address of Applicant: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Manufacturer: Orka Health Co., Ltd. Address of Manufacturer: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Factory: Orka Health Co., Ltd. Address of Factory: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Equipment Under Test (EUT): EUT Name: Hearing Aid Model No.: H020S Trade Mark: ORKA Standard(s) : FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-06-20 Date of Test: 2023-06-21 to 2023-06-28 Date of Issue: 2023-07-17 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124703 Page: 2 of 11 Revision Record Version Description Date Remark 00 Original 2023-07-17 / Authorized for issue by: Bill Wu/Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124703 Page: 3 of 11 2 Contents Page 1 COVER PAGE ................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION........................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ......................................................................................................... 4 3.2 DETAILS OF E.U.T. .................................................................................................................................. 4 3.3 SEPARATION DISTANCE ................................................................................................................................. 4 3.4 TEST LOCATION ....................................................................................................................................... 5 3.5 TEST FACILITY .......................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................... 6 5 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS ................................................................ 6 5.1 RF EXPOSURE TEST EXEMPTIONS FOR SINGLE RF SOURCES .......................................................................... 6 5.1.1 Blanket 1 mW Blanket Exemption ................................................................ 6 5.1.2 MPE-based Exemption ..................................................................................... 6 5.1.3 SAR-based Exemption ..................................................................................... 7 5.2 RF EXPOSURE TEST EXEMPTIONS FOR SIMULTANEOUS TRANSMISSION ........................................................ 8 6 MEASUREMENT AND CALCULATION .................................................................................................. 10 6.1 MAXIMUM TRANSMIT POWER ................................................................................................................. 10 6.2 RF EXPOSURE CALCULATION ...................................................................................................................... 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124703 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Power supply: DC 3.7V Li-ion Battery Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. BT Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: FPC Antenna Antenna Gain: 1.9 dBi (Provided by manufacturer) BLE Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: FPC Antenna Antenna Gain: 1.9 dBi (Provided by manufacturer) 3.3 Separation Distance Separation distance between the antenna to person (R): ＜5mm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124703 Page: 5 of 11 3.4 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China. Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.5 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the American Association for Laboratory Accreditation(A2LA). • FCC (Designation Number: CN1301) SGS-CSTC Standard…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124701 Page: 1 of 114 Parlam Zhan Laboratory Manager TEST REPORT Application No.: SHCR2306001247ME FCC ID: 2BBZIH020S Applicant: Orka Health Co., Ltd. Address of Applicant: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Manufacturer: Orka Health Co., Ltd. Address of Manufacturer: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Factory: Orka Health Co., Ltd. Address of Factory: Room 01B101,Building 2, No. 118 Rongke Road, Shanghai, China Equipment Under Test (EUT): EUT Name: Hearing Aid Model No.: H020S Trade Mark: ORKA Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-06-20 Date of Test: 2023-06-21 to 2023-06-28 Date of Issue: 2023-07-17 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124701 Page: 2 of 114 Revision Record Version Description Date Remark 00 Original 2023-07-17 / Authorized for issue by: Wade Zhang/Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124701 Page: 3 of 114 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: The left earbud and right earbud have same schematics design, PCB layout and RF antenna, only the left earbud was chosen and tested for all items. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230600124701 Page: 4 of 114 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 7 4.1 DETAILS OF E.U.T. ............................................................................................................................... 7 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 7 4.3 POWER LEVEL SETTING USING IN TEST ................................................................................................... 7 4.4 MEASUREMENT UNCERTAINTY .............................................................................................................. 8 4.5 TEST LOCATION .................................................................................................................................... 8 4.6 TEST FACILITY ...................................................................................................................................... 9 4.7 DEVIATION FROM STANDARDS ............................................................................................................... 9 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 9 5 EQUIPMENT LIST .................................................................................................................................... 10 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 11 6.1 ANTENNA REQUIREMENT .................................................................................................................... 11 6.1.1 Test Requirement: ....................................................................................................................... 11 6.1.2 Conclusion ................................................................................................................................... 11 6.2 OTHER REQUIREMENTS FREQUENCY HOPPING SPREAD SPECTRUM SYSTEM HOPPING SEQUENCE ........ 12 6.2.1 Test Requirement: ....................................................................................................................... 12 6.2.2 Conclusion ................................................................................................................................... 12 7 RADIO SPECTRUM MATTER TEST RESULTS ...................................................................…

Text truncated - open the document above for the full version.

Orka Two HA Antenna Datasheet 1. Introduction An FPC Antenna is designed to be used for Bluetooth connection in Orka Two Hearing Aids Antenna Manufacturer Name Orka Inc. Antenna Manufacturer Address Building 1, No. 298 Kangqiao East Road, China (Shanghai) Pilot Free Trade Zone Antenna Model Number OKA2G0406-B1 2. Antenna Dimensions Antenna Dimensions 3D Antenna 3. Matching Circuits and Antenna Circuit Antenna Layout π Type Matching Network 4. Electrical Characteristics No. Item Specifications 1 Central Frequency 2473MHz Antenna Gain & Efficiency Frequency Peak Gain(dBi) Avg. Gain(dBi) Efficiency(%) 2 2400 0.6 -6.2 38 3 2450 1.2 -5.7 42 4 2500 1.9 -5.1 48 π Type Matching Network GND VIA 50ohm Feeding Line 5. Characteristic curve 6. Radiation Pattern & Efficiency X-Z Plane Y-Z Plane X-Y Plane 3D Radiation Pattern Efficiency

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 3 Appendix Photographs of Test Setup for SHCR2306001247ME Test Model No.: H020S SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 3 Test Setup Photo RF Conducted Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 3 Radiated Spurious Emissions Above 1GHz The EUT Details of Zoom
