2BC3D-DIPSTERWireless speaker

Speaker with hook 1pc Key func�ons 1.Power on/off: Single click to power on/off 2.Play/Pause: Double click to play/pause the music 3.Call/answer :When an incoming call,one click will answer or hang up, press and hold to reject the call. 4.Paring mold:hold 2s 5. -: volume down-single click,Previous track-hold 2s 6. +: volume up-single click,next track-hold 2s 7.siri:3 click 8.TWS mode:hold power bu�on for 2 seconds and click the - at the same �me (Bule light slow flash) 9.TWS off:5 click 10.LED light display: Power on:Blue Flashing,ready for bluetooth paring. Paired:Blue led off Play mode:Light Con�nuous blue Charging:RED light keeps on while charging,off while charging completed. 11.Tws on:Bule light slow flash 12.While Max /minium volume,you can hear a prompt tone What’s in the box 1 2 USB cable 1pc Bluetooth Connec�on Specifica�ons Speaker Type Waterproof bluetooth wireless speaker Speaker system Stereo Dimensions 131*125*28mm Weight 292g Driver 4Ω 5W φ50mm Audio Play�me Approx 10 hours(@50-60% Volume) BT Version V5.3 Rated Power 5 Wa�s Power Supply Built-in 3.7V 1800mAh Lithium Ba�ery Charging Time Approx 2.5 hours(USB C ) IPX rate IPX7 Frequency Response 100-20KHZ Range up to 10m Input power: DC 5V/1A Built-in Microphone 43 5 Safety Instruc�onsFCC statement 67 1 6 2 4 5 3 Specifica�ons Dipster User manual 1pc Waterproof Wireless Speaker Power button USB-C + - LEDMIC FR ÉTUI + SACHET 1.If it is not paired for 15 minutes a�er boo�ng, it will shut dowm. When low ba�ery,you can hear the prompt tone then the speaker will power off automa�cally Notes: 2.If Apple users feel that the volume is low, you can turn off this se�ng on the phone(Se�ngs-Sounds & Hap�cs-Headphone Safety-Reduce Loud Sounds) 2. A�er open the phone Bluetooth, Click the “Dipster” to pairing 1. Turn on the speaker, you will hear the boot 1.Charging with DC5V/1A adaptor or USB Cable 2.While max/minium volume,you can hear a prompt tone Notes:

Speaker with hook 1pc Key func�ons 1.Power on/off: Single click to power on/off 2.Play/Pause: Double click to play/pause the music 3.Call/answer :When an incoming call,one click will answer or hang up, press and hold to reject the call. 4.Paring mold:hold 2s 5. -: volume down-single click,Previous track-hold 2s 6. +: volume up-single click,next track-hold 2s 7.siri:3 click 8.TWS mode:hold power bu�on for 2 seconds and click the - at the same �me (Bule light slow flash) 9.TWS off:5 click 10.LED light display: Power on:Blue Flashing,ready for bluetooth paring. Paired:Blue led off Play mode:Light Con�nuous blue Charging:RED light keeps on while charging,off while charging completed. 11.Tws on:Bule light slow flash 12.While Max /minium volume,you can hear a prompt tone What’s in the box 1 2 USB cable 1pc Bluetooth Connec�on Specifica�ons Speaker Type Waterproof bluetooth wireless speaker Speaker system Stereo Dimensions 131*125*28mm Weight 292g Driver 4Ω 5W φ50mm Audio Play�me Approx 10 hours(@50-60% Volume) BT Version V5.3 Rated Power 5 Wa�s Power Supply Built-in 3.7V 1800mAh Lithium Ba�ery Charging Time Approx 2.5 hours(USB C ) IPX rate IPX7 Frequency Response 100-20KHZ Range up to 10m Input power: DC 5V/1A Built-in Microphone 43 5 Safety Instruc�onsFCC statement 67 1 6 2 4 5 3 Specifica�ons Dipster User manual 1pc Waterproof Wireless Speaker Power button USB-C + - LEDMIC FR ÉTUI + SACHET 1.If it is not paired for 15 minutes a�er boo�ng, it will shut dowm. When low ba�ery,you can hear the prompt tone then the speaker will power off automa�cally Notes: 2.If Apple users feel that the volume is low, you can turn off this se�ng on the phone(Se�ngs-Sounds & Hap�cs-Headphone Safety-Reduce Loud Sounds) 2. A�er open the phone Bluetooth, Click the “Dipster” to pairing 1. Turn on the speaker, you will hear the boot 1.Charging with DC5V/1A adaptor or USB Cable 2.While max/minium volume,you can hear a prompt tone Notes:

(Rupt Group Corporation) (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BC3D-DIPSTER) [Rupt Group Corporation] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Jason Lucash (Rupt Group Corporation) (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BC3D-DIPSTER) [Rupt Group Corporation] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jason Lucash

Attestation Statements (November 16, 2023) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2BC3D-DIPSTER) (Rupt Group Corporation), the undersigned, hereby authorize (Rupt Group Corporation) to act as our designated U.S. agent for service of process, (Rupt Group Corporation) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Rupt Group Corporation) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: Rupt Group Corporation Contact Name: Jason Lucash Address: PO Box 193 Alamo California the United States Telephone No: 13538214502 Email: [email protected] FRN: 0034293498 Signature [Jason Lucash] U.S. Agent Information: Company name: Rupt Group Corporation Contact Name: Jason Lucash Address: PO Box 193 Alamo California the United States Telephone No: 13538214502 Email: [email protected] FRN: 0034293498 Signature [Jason Lucash]

(Rupt Group Corporation) (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BC3D-DIPSTER) [Rupt Group Corporation] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Jason Lucash (Rupt Group Corporation) (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BC3D-DIPSTER) [Rupt Group Corporation] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jason Lucash

Attestation Statements (November 16, 2023) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2BC3D-DIPSTER) (Rupt Group Corporation), the undersigned, hereby authorize (Rupt Group Corporation) to act as our designated U.S. agent for service of process, (Rupt Group Corporation) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Rupt Group Corporation) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: Rupt Group Corporation Contact Name: Jason Lucash Address: PO Box 193 Alamo California the United States Telephone No: 13538214502 Email: [email protected] FRN: 0034293498 Signature [Jason Lucash] U.S. Agent Information: Company name: Rupt Group Corporation Contact Name: Jason Lucash Address: PO Box 193 Alamo California the United States Telephone No: 13538214502 Email: [email protected] FRN: 0034293498 Signature [Jason Lucash]

Rupt Group Corporation (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Wireless speaker / Dipster / FCC ID: 2BC3D-DIPSTER) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Jason Lucash Title: The general manager

Rupt Group Corporation (November 16, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Jason Lucash Title: The general manager

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 4 Model: Dipster External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 4 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 4 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 4

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 4 Model: Dipster External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 4 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 4 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 4

FCC ID LABEL: Label Location: FCC ID: 2BC3D-DIPSTER Model No.: Dipster

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: Dipster Internal Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 ANT Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: Dipster Internal Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 ANT Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

Shenzhen CTB Testing Co., Ltd. FCC ID:2BC3D-DIPSTER Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.105 0.49 -3±1 -2.00 0.63 <5 0.19558 3.00 YES 2.441 -2.936 0.51 -2±1 -1.00 0.79 <5 0.24821 3.00 YES 2.480 -1.986 0.63 -1±1 0.00 1.00 <5 0.31496 3.00 YES 2.402 -2.216 0.60 -2±1 -1.00 0.79 <5 0.24622 3.00 YES 2.441 -2.074 0.62 -2±1 -1.00 0.79 <5 0.24821 3.00 YES 2.480 -1.125 0.77 -1±1 0.00 1.00 <5 0.31496 3.00 YES 2.402 -1.832 0.66 -1±1 0.00 1.00 <5 0.30997 3.00 YES 2.441 -1.636 0.69 -1±1 0.00 1.00 <5 0.31247 3.00 YES 2.480 -0.724 0.85 0±1 1.00 1.26 <5 0.39651 3.00 YES GFSK π /4DQPSK 8DQPSK BLE:1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.027 0.50 -3±1 -2.00 0.63 <5 0.19558 3.00 YES 2.44 -2.849 0.52 -2±1 -1.00 0.79 <5 0.24816 3.00 YES 2.480 -1.886 0.65 -1±1 0.00 1.00 <5 0.31496 3.00 YES GFSK 2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.07 0.49 -3±1 -1.00 0.79 <5 0.24622 3.00 YES 2.44 -2.901 0.51 -2±1 -1.00 0.79 <5 0.24816 3.00 YES 2.480 -1.897 0.65 -1±1 0.00 1.00 <5 0.31496 3.00 YES GFSK Conclusion: For the max result : 0.39651≤ FCC Limit 3.0 for 1g SAR.

Shenzhen CTB Testing Co., Ltd. FCC ID:2BC3D-DIPSTER Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.105 0.49 -3±1 -2.00 0.63 <5 0.19558 3.00 YES 2.441 -2.936 0.51 -2±1 -1.00 0.79 <5 0.24821 3.00 YES 2.480 -1.986 0.63 -1±1 0.00 1.00 <5 0.31496 3.00 YES 2.402 -2.216 0.60 -2±1 -1.00 0.79 <5 0.24622 3.00 YES 2.441 -2.074 0.62 -2±1 -1.00 0.79 <5 0.24821 3.00 YES 2.480 -1.125 0.77 -1±1 0.00 1.00 <5 0.31496 3.00 YES 2.402 -1.832 0.66 -1±1 0.00 1.00 <5 0.30997 3.00 YES 2.441 -1.636 0.69 -1±1 0.00 1.00 <5 0.31247 3.00 YES 2.480 -0.724 0.85 0±1 1.00 1.26 <5 0.39651 3.00 YES GFSK π /4DQPSK 8DQPSK BLE:1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.027 0.50 -3±1 -2.00 0.63 <5 0.19558 3.00 YES 2.44 -2.849 0.52 -2±1 -1.00 0.79 <5 0.24816 3.00 YES 2.480 -1.886 0.65 -1±1 0.00 1.00 <5 0.31496 3.00 YES GFSK 2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -3.07 0.49 -3±1 -1.00 0.79 <5 0.24622 3.00 YES 2.44 -2.901 0.51 -2±1 -1.00 0.79 <5 0.24816 3.00 YES 2.480 -1.897 0.65 -1±1 0.00 1.00 <5 0.31496 3.00 YES GFSK Conclusion: For the max result : 0.39651≤ FCC Limit 3.0 for 1g SAR.

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.2 (Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to ch ange without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.51.2 -3.61.1 -3.06 0.2 % Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane Manufacturer: Rupt Group Corporation Manufacturer Address: PO Box 193 Alamo California the United States
