2BC3X-A-H13MINISmart watch

smart wristband user's Guide Wear it p roperly The br acelet i s best wor n a�er the ulnar styloid Adjust the size of the wrist acc or ding to the adjustment hole; buckle the wrist s tr ap buckle. The sensor should be close to the skin to avoid moving Charge th e bracelet Use it for the fir st �me to ensure that the ba�ery is in normal condi�on. If th e power is not turned on normally, pl ease connect the charger to charge the device. Install the bracelet app on your phone Sc an the QR code or go to the App Stor e, app download and install the app. Android/IOS System requirements: Andr oid 5. 0 and above; iOS9.0 and above; support for Bluetooth 4.0. Devi ce connec�on  For the first use, you need to connect the APP for calibra�on. A�er the connec�on is successful, the br acelet will automa�cally synchronize the �me.  Turn on the Bluetooth switch of the mobile phone system → enter the app device module se�ngs → click “Bind device, experience more features” to enter, it will automa�cally se arch for nearby Bluetooth devices on the br acelet, find and connect th e br acelet device.  A�e r t he pairing is successful, t he APP will pop up a guide page . According to the instruc�ons, jump to the mobile phone system Bluetooth search t the connec�on is successful, you can mak e / receive calls and lis ten to music (Note: If the mobile phone system Bluetooth has not been searched equipment, please enter the Dual mode menu and se t it to On, you cannot make calls without connec�ng the equipment.)  APP will automa�cally save t he Blue tooth addre ss of t he brace let, and the APP will open and run in the background, and will automa�cally search and connect the bracelet;  Android phones use all no�fica�on permissions to read contact in forma�on and give the app background running in the phone se�ngs. Bracelet f unc�on descrip�on  Slide down the standby page to enter the no�fica�on reminder, and slide up to enter the contr ol center  Swipe le� or right on the standby page to cycle through the dials  Long pr ess 2 seconds on any dial page to start the la nguage assistant. (R emarks: The mobile phone also needs to be connected to the device, and the smart phone needs to set th e user's voice in advance in the voice menu)  Click the screen on the standby page to enter the main menu, th e style of the main menu can be switched  Br acelet reset devi ce This func�on will clear all data of the br acelet (such as step coun�ng)  Switch to the heart rate three-in-one in terface to start the test, heart rat e three-in-one in terface 60s �meout automa�cally off screen (heart r ate and blood pressure need bracelet hardwar e support). Clock interface A�er synchronizin g with the phone, the bracelet will automa�call y calibrate the �me; Swipe le� or right on the standby page to cycle through the dials St ep Number of steps Wear the br acelet and recor d the number of daily movement steps to view the current r eal-�me steps. distance The distance of mo�on is es�mated based on the number of walking steps. Calories Es�mate the calories burned based on the number of walking steps Heart rate, blood pr essur e, blood oxygen three-in-one A�er entering the heart rate three-in-one test interf ace for a few seconds, the current heart rate, blood pr essure, and blood oxygen test results are displayed. This feature requires a wristband to support heart rate and blood pressure sensor s. di al Dial pad for making calls (note: the phone also needs to be connected to a device) phone book Add 8 commonly used contacts in the APP. A�er the br acelet is successfully connected with the APP Bl uetooth, the contacts can be displayed in the br acelet phone book. Click the contact to make a call (Not e: The phone needs to be connected to a device) Music contr ol The br acelet can contr ol the pr evious song and the next song, and pause / start playback. (Note: devices need to be connected to use this feature phone) Dual mode switch This switch needs to be turned on for the phone to search for the device. If the phone is not connected to th e device within 5 minutes a�er the br acelet is turned on, the switch will be turned off automa�cally, and it needs to be turned on manually when it is used again. exer cise mor e All sports modes can recor d the calories and dura�on of skipping rope. Sleep mode When you fall asleep, the br acelet will automa�cally enter the sleep monitoring mode; automa�cally detect your deep sleep / light sleep / wak e up all night, calculate your sleep quality; the wristband only shows the tot al length of deep sleep / li ght sleep / sleep, APP end can View sleep data details. Note: Sleep data will be available when you wear your wristband and sleep will be detected fr om 10:00 pm. Sleeping data for 3/4 hours can be synchronized to the app while sleeping. Infor ma�on mode Infor ma�on menu can view the latest news c ontent St opwatch func�on Enter the stopwatch and click the star t bu�on to start �ming, click the pause bu�on to stop, and click the reset bu�on to clear the �ming. Custom dia l You need to connect to the APP to get the dial se�ngs, you can choose the recommended dial / default dial / album custom dial to synchronize to the bracelet. APP func�on and se�ngs Per sonal in for ma�on Please set your personal in forma�on a�er entering the app. Se�ngs → Personal Informa�on, you can set gender - age - height - weight - dis tance You can also set your dail y goal s teps to monitor daily comple�ons. Appli ca�on push SMS no� fica�on: In the connected state, if the SMS reminder func�on is enabled, the br acelet will vibrate when there is a t ext message. Other reminders: In the connected state, if this func�on is enabled, when there ar e messages such as WeChat, QQ, Facebook, etc., the br acelet will vibrate to remind and display th e content received by th e app (Y ou need to give the APP permission to get system no�fica�ons, and the wristband can display 20-40 wor ds). Note: Incoming cal l reminder system …

Text truncated - open the document above for the full version.

Dongguan Langchen Technology Co.,Ltd. Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-7 To whom it may concern: We, Dongguan Langchen Technology Co.,Ltd., hereby certify that the equipment for which authorization is sought (FCC ID: 2BC3X-A-H13MINI) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Lan Zhou Manager Dongguan Langchen Technology Co.,Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Dongguan Langchen Technology Co.,Ltd. Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town, Dongguan City, Guangdong Province, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/08/05 U.S. Agent Designation Dongguan Langchen Technology Co.,Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BC3X-A-H13MINI): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Dongguan Langchen Technology Co.,Ltd. Dongguan Langchen Technology Co.,Ltd. with the FRN [0034327130] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Lan Zhou Manager Dongguan Langchen Technology Co.,Ltd. Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Dongguan Langchen Technology Co.,Ltd. Add: Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Date: 2024-8-7 FCC ID: 2BC3X-A-H13MINI Dear Sir/Madam, We, Dongguan Langchen Technology Co.,Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Smart watch Model no.: H13MINI, HB13, D14, D10NIMI, GTS4MINI, D17MINI, H18MINI Sincerely, Name/Title： Lan Zhou/Manager Company: Dongguan Langchen Technology Co.,Ltd. Address: Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Phone: 18823709181 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-8-7> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BC3X-A-H13MINI H13MINI For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Lan Zhou/Manager Company: Dongguan Langchen Technology Co.,Ltd. Address: Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Phone: 18823709181 Fax: N/A E-Mail: [email protected]

Dongguan Langchen Technology Co.,Ltd. Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-7 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BC3X-A-H13MINI including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Lan Zhou/Manager Company: Dongguan Langchen Technology Co.,Ltd. Address: Room 704, No. 27 East, Wusha Xingfa South Road, Chang'an Town,Dongguan City, Guangdong Province China Phone: 18823709181 Fax: N/A E-Mail: [email protected]

FCC ID: 2BC3X-A-H13MINI External Photos of the EUT FCC ID: 2BC3X-A-H13MINI FCC ID: 2BC3X-A-H13MINI

Label and Location Size: L: 1.0cm*W: 0.2cm Label and Location FCC ID : 2BC3X-A-H13MINI

FCC ID: 2BC3X-A-H13MINI Internal Photos of the EUT FCC ID: 2BC3X-A-H13MINI ANT FCC ID: 2BC3X-A-H13MINI

RF Exposure evaluation FCC ID: 2BC3X-A-H13MINI 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -2.0 -2.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BLE 2.450 5 0.0 1.000 0.3130<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model H13 Frequency range 2400-2500MHz Manufacturer Dongguan Langchen Technology Co.,Ltd. ANT Peak Gain 1.90 dBi 2. Antenna Photo: Length :2.86mm Width:1.96mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz
