2BC87-BD0060EBCOEglister Multi-action Power Toothbrush

文件编号： SG--2757-IM Rev.:A/5 Warning signs instructions The following signs are used to classify and describe the degree of danger, injury and property damage caused by ignoring the sign description and improper use. Warning Indicates a potential hazard that could result in serious injury or death. attention Indicates a potential hazard that could result in Minor injury or property damage. The following marks are used to classify and describe the types of instructions to be followed. The mark is used to remind the user of the prohibited operation steps. The mark is used to remind users of the operation steps that must be followed in order to operate the product safely. TIPS The mark is used to remind users of the operation steps correcting. All product outward appearance, the color take the material object as, the picture only su pply the reference. Safety instructions Warning ·Prevention of accidents Please don’t put the product where child or baby can touch. And , please prevent them touching or operating the product. - TO prevent of baby or child eating parts to cause danger. please make sure to put the package of product somewhere safe that baby can not touch with. -TO prevent of causing danger. ·charge Do not use wet hands to connect the charging cable interface or unplug the power adapter. And do not use wet hands to connect or unplug the power adapter from the household power outlet. -TO prevent of electric shock and injury Please don’t charge the product in bathroom or somewhere damp. -To prevent of electric shock or casing fire by short-circuit. Do not adjacent to or stacked with other electrical equipment should be avoided because it could result in improper operation When the charging cable or power adapter is damaged or loosely connected to the product's charging interface , please don’t charge the product. Do not expect damage, damage threat to modify power play. Don't stretch, bend or twist the gauge can press a weight on a power cord or jam a cable between objects. -To prevent of electric shock or casing fire by short-circuit. Do not exceed the rating of the domestic power socket or wiring when charging. -If the load of socket or wire exceeds the standard, it may cause fire. Please use a DC 5V power adapter .Please plug the power plug into the power supply socket. -TO prevent of electric shock ,injury or fire. If there are any abnormality and failure Please stop using or charging the product. -TO prevent of electric shock ,injury or fire. Abnormality and failure: Product or wire is deformation or abnormal heating. Product or wire gives off a burning smell. Product or wire makes an abnormal sound in using. -Please contact customer service center. The product Please don’t drop or bump it. -To prevent of injury. Please don’t refit, disassemble or repair the product by yourself. -To prevent of fire or injury. -Please contact customer service center. The product is not designed for someone with physical, sensory or mental disabilities or lack of experience and knowledge such as children.they can use it with the help of guardian. And guardian is responsible for the safety of users and take care of children and make sure they don't play with the product. -To prevent of accident or injury. For this product, special protective measures for electromagnetic compatibility (EMC) shall be taken. If you have a heart rate regulator or other device, please consult your physician or the manufacturer of the device before use. Portable and mobile RF communication product may affect this product. When using this product, keep away from other medical devices, otherwise it may cause electromagnetic interference. If there is interference, please stop using the product immediately and move the product to other places for use. -To prevent of accident or injury. Cleaning When cleaning the power adapter and charging cable, please be sure to remove the power adapter from the household power outlet. -To prevent of accident or injury. Please clean the charging line interface and power adapter plug regularly every 6 month to prevent dust accumulation. Otherwise, insulation failure may be caused by humidity, which may cause fire. Please unplug the power adapter plug and charging cable, and then wipe them with a dry cloth. attention Prevent damage to teeth and gums This product should not be used by people with no operation ability. This product should not be used by people who are not sensitive to oral sensation. Otherwise, it may cause damage to teeth or teeth. Those who have serious periodontal disease, whose teeth are under treatment, or who are worried about discomfort in the oral cavity should consult a dentist before use. Otherwise, it may cause damage to teeth and gums. Do not use the product for any purpose other than oral cleaning. Otherwise, accidents or injuries may be caused when water flows to the eyes, nose, ears or throat. Do not share the brush head with family or others. Otherwise, it may cause infection or inflammation. Do not allow needles or foreign objects to adhere to the charging line or power adapter. Otherwise, it may cause electric shock or fire due to short circuit. Please do not wrap the charging cable on the body when storing. Otherwise, the charging line may be broken, scald, electric shock or fire due to short circuit may occur. Please do not pull the charging cable and hold the power adapter and pull it out when disconnecting the charging plug, Otherwise, it may cause electric shock or fire due to short circuit. Please clean and maintain the equipment after use. (reference routine maintenance) Otherwise, it will damage the health due to the reproduction of mould and miscellaneous bacteria. Please do not repair and maintain it When using the product. Otherwise, accidents and injuries may occur. The adapter authentication provided by the user needs to meet the requirements of an altitude of 5000m and have at least 2MOOP Product parameters Material ABS/TPE Size Handle: About 28.…

Text truncated - open the document above for the full version.

EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 1 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 2 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 3 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 4 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 5 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. a: EUT EUT Appearance Report No.: R2401A0067 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-030E Page 6 of 6 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. b: USB Cable Picture 1: Constituents of EUT

LOT CODE : ����MXYK MANUFACTURING DATE/วันที่ผลิต : ����.�� PRODUCT NAME/ชื่อผลิตภัณฑ์ : GLISTER™ MULTI-ACTION POWER TOOTHBRUSH /แปรงสีฟันไฟฟ้า กลิสเทอร์ มัลติ-แอ็คชั่น MODEL NAME/ชื่อรุ่น : BD����EBCOE DIMENSION/ขนาด : ด้ามจับ : Handle/มม.: ���.� x ��.� x ��.� mm(มม.) / ��� mm(มม.) (with bristle/รวมขนแปรง), UV Sanitizer/ฆ่าเชื้อ UV : ���.� x ��.� x ���.� mm(มม.) INPUT VOLTAGE/แรงดันไฟฟ้า : �V INPUT POWER/กําลังไฟเข้า : �.� W MANUFACTURER/ ผู้ผลิต : KNK CO., LTD COUNTRY OF ORIGIN/ประเทศต้นกําเนิด : KOREA/เกาหลี FCC ID: 2BC87-BD0060EBCOE

Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 1 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 2 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 3 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 4 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 5 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 6 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 7 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 8 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 9 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 10 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 11 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 12 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 13 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 14 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 15 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 16 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BC87-BD0060EBCOE Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 17 of 17 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd.

Electric toothbrush part Model: SG-2757 Serial Number Name Material remarks 1 Main body component 2 Button ABS 3 Button ring ABS 4 Bracket assembly 5 O-ring Silica gel 6 Breather valve ABS 7 Permeable membrane 8 Lower cap PC Serial Number Name Material remarks 1 Decorative ring ABS 2 Main body ABS 3 encapsulating TPE Serial Number Name Material remarks 1 Presoft gel Silica gel 2 Waterproof ring Silica gel 3 Electric machine 4 support POM 5 attachment POM 6 screw 7 Light shade ABS 8 Circuit board 9 Coil holder PC 10 coil PC 11 battery 12 foam 13 foam 14 foam Item Specifications Requirements 1 Product size 28.0*28.0*165.4mm (see attached picture) 2 weight 136g Note: 1. Product size tolerance: ±0.5mm 2. Product size does not include accessories 3. Product weight does not include accessories 1. Function Description 1.1 Waterproof design. 1.2 The brush head can be replaced. 1.3 Gear memory function. 1.4 Periodic reminder function. 1.5 Charging mode: Wireless charging (WX-1). 1.6 Battery overcharge and overdischarge protection. 1.7 Power indicator. 1.8 Anti-splash function. 1.9 Pressure sensing function. 2. Usage method 2.1 Normal operation: 2.1.1 Turning the machine on and off: Long press the upper button to turn on the product, and long press the upper button again to turn off the product. (Long press for about 1 second) 2.1.2 Mode switching: After the product is turned on, the upper button is triggered to switch modes. The mode switching sequence is mode 1 → Mode 2 → Mode 3 → Mode 4 → Mode 5 → Mode 1...... 2.1.3 Intensity switching: When the product is on, press the button to switch the intensity of the current mode. The switching sequence of gear intensity is first gear → second gear → third gear → first gear...... 2.1.4 Overpressure alarm: After the product is turned on, the toothbrush vibration becomes weak after excessive force is applied at the brush head, and all gear lights and mode lights blink rapidly at an interval of 0.5 seconds, and the alarm is stopped after being lifted. 2.1.5 Anti-splash function: After the product is opened, the motor will start slowly, the time is 3 seconds, and there is a key trigger during the slow start, which will skip the slow start and respond to the shift operation. 2. Usage method 2.1 Normal operation: 2.1.1 Turning the machine on and off: Long press the upper button to turn on the product, and long press the upper button again to turn off the product. (Long press for about 1 second) 2.1.2 Mode switching: After the product is turned on, the upper button is triggered to switch modes. The mode switching sequence is mode 1 → Mode 2 → Mode 3 → Mode 4 → Mode 5 → Mode 1...... 2.1.3 Intensity switching: When the product is on, press the button to switch the intensity of the current mode. The switching sequence of gear intensity is first gear → second gear → third gear → first gear...... 2.1.4 Overpressure alarm: After the product is turned on, the toothbrush vibration becomes weak after excessive force is applied at the brush head, and all gear lights and mode lights blink rapidly at an interval of 0.5 seconds, and the alarm is stopped after being lifted. 2.1.5 Anti-splash function: After the product is opened, the motor will start slowly, the time is 3 seconds, and there is a key trigger during the slow start, which will skip the slow start and respond to the shift operation. 2.3 Power indicator: 2.4 Charge management: When the 5 mode indicators blink or the product cannot be started normally after use, it indicates that the battery power is insufficient and the product needs to be charged. When charging, the product can be charged by placing it on the charging base of the power supply. 2.5 Charging Instructions: 2.6 Abnormal Indicator: Indication mode Charge state Power indicates when and how to turn on Charging indicator light is not on, the product does not work Charge less than 10% Opening time: after shutdown. Open mode: According to the remaining battery power, indicate 10 seconds. After shutdown, the five mode indicators blink for 1 second Electricity is about 10%-20% After shutdown, the two modes are on Electricity is about 20%-40% After shutdown, the three modes light up The electricity is about 40%-60% After shutdown, the four modes light up Electricity is about 60%-80% Five modes light up after shutdown Charge greater than 80% Indication mode Charge state The charging indicator light is off Charge less than 10% Gear light from bottom to top, cycle indication. Electricity is about 10%-90% The charging indicator light is off Electricity is about 90%-100% Exception name Indication mode Response condition Recommended action Overvolta ge alarm Light position light and mode light white light flashing, motor vibration becomes weak Brush head press too much Brush less 3. Precautions 3.1 First use If the product does not work, it may be caused by insufficient battery power, please charge the product. 3.2 The indicator light may not be on 5 minutes before charging if it is used for the first time or not used for a long time, which is a normal phenomenon caused by insufficient battery power. 3.3 If the product does not vibrate or vibrates weakly, it may be caused by insufficient battery power, please charge it in time. 3.4 If the bristles are deformed or used for more than three months, please replace the toothbrush head in time. 3.5 Do not place the product in a place where it is easy to fall. 3.6 Install the brush head as instructed; otherwise, the product may be damaged. 3.7 Before replacing a new brush head, clean the installation position of the brush head; otherwise, it may be difficult to install the brush head. 4. Technical parameters 4.1 Rated operating voltage: DC3.7V 4.2 Rated working power: 2W 4.3 Rated input voltage: The toothbrush part is not nominal, and the base has a nominal rated input voltage 4.4 Rated input power: The toothbrush part is not nominal, and the base has a nominal rated input power 4.5 Static consumption: ≤0.05mA 4.6 Timing…

Text truncated - open the document above for the full version.

Prepared by: Liu Wei Approved by: Fan Guangchang Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant Ningbo Seago Electric Co.,Ltd FCC ID 2BC87-BD0060EBCOE Product glister Multi-action Power Toothbrush Model BD0060EBC0E Report No. R2401A0067-R1V3 Issue Date August 20, 2024 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C (2023). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: R2401A0067-R1V2 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-041R Page 2 of 30 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................... 5 1.1. Notes of the Test Report ......................................................................................................... 5 1.2. Test facility .............................................................................................................................. 5 1.3. Testing Location ...................................................................................................................... 5 2. General Description of Equipment Under Test ............................................................................... 6 2.1. Applicant and Manufacturer Information ................................................................................ 6 2.2. General Information ................................................................................................................ 6 3. Applied Standards ........................................................................................................................... 7 4. Test Configuration ........................................................................................................................... 8 5. Test Case Results ........................................................................................................................... 9 5.1. Occupied Bandwidth ............................................................................................................... 9 5.2. Radiates Emission ................................................................................................................ 11 5.3. Conducted Emission ............................................................................................................. 19 6. Main Test Instruments................................................................................................................... 22 ANNEX A: The EUT Appearance ......................................................................................................... 23 ANNEX B: Test Setup Photos .............................................................................................................. 29 RF Test Report Report No.: R2401A0067-R1V2 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-041R Page 3 of 30 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Version Revision Description Issue Date Rev.0 Initial issue of report. June 3, 2024 Rev.1 Updated information and data. July 25, 2024 Rev.2 Updated data. July 26, 2024 Rev.3 Updated data. August 20, 2024 Note: This revised report (Report No.: R2401A0067-R1V3) supersedes and replaces the previously issued report (Report No.: R2401A0067-R1V2). Please discard or destroy the previously issued report and dispose of it accordingly. RF Test Report Report No.: R2401A0067-R1V2 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-041R Page 4 of 30 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Summary of Measurement Results Number Test Case Clause in FCC rules Verdict 1 Occupied Bandwidth §2.1049 §15.215 PASS 2 Radiated Emissions Measurement §15.201(a), §15.205(a), §15.209(a), §15.215(a) PASS 3 AC Conducted Emissions §15.207(a) PASS Date of Testing: January 24, 2024 ~ January 25, 2024 and August 16, 2024 Date of Sample Received: January 22, 2024 Note: PASS: The EUT complies with the essential requirements in the standard. FAIL: The EUT does not comply with the essential requirements in the standard. All indications of Pass/Fail in this report are opinions expressed by Eurofins TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. RF Test Report Report No.: R2401A0067-R1V2 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-041R Page 5 of 30 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. A2LA (Certificate Number: 3857.01) Eurofins TA Technology (Shanghai) Co., Ltd. …

Text truncated - open the document above for the full version.

文件 名称 SG-987 线圈 文件 编号 2.01.62.202 页面/ 页次 1/2 宁波赛嘉电器有限公司 版本 A/0 编制 董竹汀 校验 审核 批准 日期 20240701 日期 日期 日期 1.塑件尺寸要求如图： 2.技术要求： 2.1 用 0.21mm 漆包线绕 100 圈。 2.2 电感量:135-155μH. 2.3 线圈外绕胶带 3 圈，胶带不能绕到骨架外。 3.检验要求： 3.1 测试电感量：135-155μH(1KHZ,串行模式) 3.2 目检外观。 3.3 用卡尺测量各尺寸。 All measurements were performed radiated and therefore additional antenna gain documentation is not required. 线头要求如左图：线从中间槽出， 橙色长度25-30mm，2-3mm镀锡. 文件 名称 SG-987 线圈 文件 编号 2.01.62.202 页面/ 页次 2/2 宁波赛嘉电器有限公司 版本 A/0 编制 董竹汀 校验 审核 批准 日期 20240701 日期 日期 日期 All measurements were performed radiated and therefore additional antenna gain documentation is not required.

Prepared by: Wei Fangying Approved by: Fan Guangchang Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE TEST REPORT Applicant Ningbo Seago Electric Co.,Ltd FCC ID 2BC87-BD0060EBCOE Product glister Multi-action Power Toothbrush Model BD0060EBCOE Report No. R2401A0067-M1V1 Issue Date July 25, 2024 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC Part 1 Subpart I / FCC Part 2 Subpart J. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Test Report Report No.: R2401A0067-M1V1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-017S Page 2 of 21 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ................................................................................................................................. 4 1.1 Notes of the Test Report ............................................................................................................ 4 1.2 Test Facility ................................................................................................................................ 4 1.3 Testing Location......................................................................................................................... 4 1.4 Laboratory Environment ............................................................................................................ 4 2 Statement of Compliance .................................................................................................................. 5 3 Description of Equipment Under Test ............................................................................................... 6 4 Test Specification, Methods and Procedures ................................................................................... 7 5 Equipment Under Test ....................................................................................................................... 8 5.1 Description of EUT ..................................................................................................................... 8 5.1 KDB 680106 D01 v04 Equipment Approval Considerations ..................................................... 8 5.2 Description of Test Setup .......................................................................................................... 9 6 Main Test Instruments ..................................................................................................................... 10 7 Maximum Permissible RF Exposure ............................................................................................... 11 7.1 FCC Limits and Summary........................................................................................................ 11 7.2 Maximum Permissible Exposure Test Results ........................................................................ 12 ANNEX A: The EUT Appearance ........................................................................................................... 13 ANNEX B: Test Setup Photos ................................................................................................................ 19 Test Report Report No.: R2401A0067-M1V1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-017S Page 3 of 21 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Version Revision Description Issue Date Rev.0 Initial issue of report. June 3, 2024 Rev.1 Updated information. July 25, 2024 Note: This revised report (Report No.: R2401A0067-M1V1) supersedes and replaces the previously issued report (Report No.: R2401A0067-M1). Please discard or destroy the previously issued report and dispose of it accordingly. Test Report Report No.: R2401A0067-M1V1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-017S Page 4 of 21 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2 Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. 1.3 Testing Location Company: Eurofins TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Fan Guangchan…

Text truncated - open the document above for the full version.
