2BCBK-TR4848PANLEE BC02

Shenzhen QM Smart Panlee Technology Co., Ltd. Smart Panlee PANLEE BC02 ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 1 Features: 1. Based on Wireless-Tag’s WT32-S3-WROVER-N16R8（16MB Flash/8Line 8M die inside） 2. 480*480 high-resolution RGB display with capacitive touch 3. 86box product appearance, convenient for embedding in smart home applications 4. Support online rapid prototyping on the 8MS development platform 5. Onboard RS485 chip Core Materials (Tab. 0): No. Name Model Remark 1 ESP32-S3 module WT32-S3-WROVER-N16R8 2 3 Naming instructions ： Specifications illustrate Remark ZX3D95CE01S-TR Contains temperature and humidity sensor and RS485, using on-board antenna ZX3D95CE01S-R RS485 only, use onboard antenna ZX3D95CE01S-i -TR Including temperature and humidity sensor and RS485, use IPEX external antenna Batch to order ZX3D95CE01S-i -R RS485 only, use IPEX external antenna Batch to order ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 2 Hardware Interface: Fig.1 Hardware Interface Interface Description: [1] Debugging Interface(Tab.1) Pin Description Module Pin Voltage Range Remark 1 +5V - 5V 2 +3.3V - 3.3V 3 TXD0 TXD0 3.3V TTL Burning serial port 4 RXD0 RXD0 3.3V TTL Burning serial port 5 EN CHIP_PU 3.3V MAX Chip reset 6 IO0 GPIO 0 3.3V TTL Boot mode 7 GND Selection Grounding ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 3 [2] Sub Board Interface (Tab.2) Pin Description Module Pin Voltage Range Remark 1、2 +5V - +5V±5% Board power supply 3、4 GND - 0V Grounding 5 EXT_IO2 GPIO 20 0~3.3V Output interface 2 6 EXT_IO1 GPIO 9 0-3.3V Output interface 1 7 EXT_IO3 GPIO 19 0-3.3V Output interface 3 8 EXT_IO4 GPIO 7 0-3.3V Output interface 4 9 IIC_SCL GPIO 6 3.3V TTL IIC bus clock, multiplexed with touch screen 10 IIC_SDA GPIO 15 3.3V TTL IIC bus data, multiplexed with touch screen 11 EN EN 0~VCC Chip enable 12 GPIO 0 GPIO 0 0~VCC BOOT selection 13 RXD RXD0 3.3V TTL Download debugging serial port 14 TXD TXD0 3.3V TTL Download debugging serial port 15 485 B - RS485 485 bus negative, not available when output interface is used 16 485 A - RS485 485 bus positive, not available when output interface is used 17 TXD_EXT GPIO 2 3.3V TTL Multiplexed with 485 serial port 18 RXD_EXT GPIO 1 3.3V TTL Multiplexed with 485 serial port 19、20 NC - - not connect ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 4 [3] Display Interface (Tab.3) Description Module Pin Remark TP_RST - Using RC reset TP_SCL GPIO 6 Touch IIC bus clock, multiplexed with external interface TP_SDA GPIO 15 Touch IIC bus data, multiplexed with external interface TP_INT GPIO 4 Touch interrupt LCD_RST - LCD auto reset, use RGB_VS signal to keep working LCD_CS GPIO 38 LCD SPI bus CS LCD_SCLK GPIO 45 LCD SPI bus SCLK LCD_MOSI GPIO 48 LCD SPI bus MOSI RGB_PCLK GPIO 39 LCD RGB INTERFACE PCLK RGB_DE GPIO 40 LCD RGB INTERFACE DE RGB_VS GPIO 41 LCD RGB INTERFACE VS RGB_HS GPIO 42 LCD RGB INTERFACE HS RGB_D0 GPIO 45 LCD RGB INTERFACE D0 RGB_D1 GPIO 48 LCD RGB INTERFACE D1 RGB_D2 GPIO 47 LCD RGB INTERFACE D2 RGB_D3 GPIO 0 LCD RGB INTERFACE D3 RGB_D4 GPIO 21 LCD RGB INTERFACE D4 RGB_D5 GPIO 14 LCD RGB INTERFACE D5 RGB_D6 GPIO 13 LCD RGB INTERFACE D6 RGB_D7 GPIO 12 LCD RGB INTERFACE D7 RGB_D8 GPIO 11 LCD RGB INTERFACE D8 RGB_D9 GPIO 16 LCD RGB INTERFACE D9 RGB_D10 GPIO 17 LCD RGB INTERFACE D10 RGB_D11 GPIO 18 LCD RGB INTERFACE D11 ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 5 RGB_D12 GPIO 8 LCD RGB INTERFACE D12 RGB_D13 GPIO 3 LCD RGB INTERFACE D13 RGB_D14 GPIO 46 LCD RGB INTERFACE D14 RGB_D15 GPIO 10 LCD RGB INTERFACE D15 LCD_BL GPIO 5 LCD backlight control, high level enable Interface Encapsulation (Tab.4): Peripheral Name Description Debugging interface Debugging interface MX1.25-7P External interface External interface 2.0mm 2x10P female header Hardware peripherals： Appearance Name Description SHT20 Temperature and humidity sensor, hanging on IIC bus LCD 480*480 resolution, RGB565 RS485 Use automatic transceiver 485 circuit ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 6 Schematic: Shenzhen QM Smart Panlee Technology Co., Ltd. 7 Specification Parameters: [1]Electrity parameters(Tab.6) MIN. Type MAX. Operating current (@5V)* - 230mA - Operating voltage（USB） 4.8V 5.0V 5.2V Operating temperature -20°C 2 5°C 60°C Storage temperature -30°C 2 5°C 70°C ESD protection voltage (contact) - 8kV - ESD protection voltage (air) - 12kV - Note： （*1）The operating current is 100% of the LCM backlight brightness at 5V power supply and ESP32- S 3 under normal operation （*2&*3）ESD protection refers to the ESD verification of the whole machine (including the shell). [2] Display Parameters (Tab.7) LCD panel size 3.95inch Display type IPS Drive IC model GC9503V Visual angle FREE Physical dimensions 84.00*84.00*3.13mm Resolution 480(H)x3(RGB)x480(V) Interface RGB Color 16.7M Backlit mode 8 white LEDs in 4S2P Backlight brightness ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 8 [3] Touch Parameters (Tab.8) Touchscreen type Capacitive touch Drive IC model FT6336U Interface I2C Touchscreen structure GF Touch mode Surface touch Surface hardness 6H Light transmittance 85% ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 9 Outline Dimensional Drawing (Fig.2) ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 1 Operating Instructions： 1. Prepare the product body and accompanying items（step 1） 2. Solder the attachment to the Debug（step 2） 3. Please see the content below for burning details. （step 3） ZX3D95CE01S-TR-4848 Datasheet Shenzhen QM Smart Panlee Technology Co., Ltd. 1 Firmware Burning: 1. Connect the downloader (ZXACC-ESPDB) via a USB-Type C cable. And then connect the ZX3D95CE01S-TR board with the downloader (ZXACC-ESPDB) through an cable. As the downloader (ZXACC-ESPDB) has automatic data flow processing capabilities, th…

Text truncated - open the document above for the full version.

OasisCompliance,Inc.FCCID: 2BCBK-TR4848 CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation Date:10-12-2023 FCCID:2BCBK-TR4848FRN:0034072777 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern, ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf ofShenzhenQMSmartPanleeTechnologyCo.,Ltd.(“theapplicant”)fortheabove referencedFCCID. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84paragraph 63. U.S.AgentInformation: OasisCompliance,Inc. FRN:0033464157 JamesHe 3313VerdiDr,SanJose,CA95111 Cell:2026028330 Sincerelyyours, JamesHe GlobalMarketAccessManager OasisCompliance,Inc. Email:[email protected]

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen QM Smart Panlee Technology Co., Ltd Grantee code: 2BCBK FCC ID: 2BCBK-TR4848 Contact Name: Fiona Liang Address: Room 805, Block A, Building 6, Shenzhen International Innovation Valley, Xili Community, Nanshan District, Shenzhen Telephone No: 18079567903 Fax No: Email: [email protected] i. [ Shenzhen QM Smart Panlee Technology Co., Ltd ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Shenzhen QM Smart Panlee Technology Co., Ltd ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Shenzhen QM Smart Panlee Technology Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 10.19.2023 Applicant’s Name: Fiona Liang Title: PM Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist FRN:0034072777

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen QM Smart Panlee Technology Co., Ltd Address: Room 805, Block A, Building 6, Shenzhen International Innovation Valley, Xili Community, Nanshan District, Shenzhen Product Name: PANLEE BC02 Model Number: ZX3D95CE01S-TR-4848 FCC Identifier: 2BCBK-TR4848 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Fiona Liang Date: 10/19/2023 Title: PM Signature of applicant:

C5266091_X10_Ed.2 1/1 Shenzhen QM Smart Panlee Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 10/19/2023 Subject: Request for Confidentiality FCC ID: 2BCBK-TR4848 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Fiona Liang Title: PM

Page 1 of 7 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Photographs of the EUT Model: ZX3D95CE01S-TR-4848 External Page 2 of 7 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 7 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 7 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected]

Label Location

Page 1 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: ZX3D95CE01S-TR-4848 Page 2 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ANT

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] RF EXPOSURE Test Report Report No.: MTi230722002-01E3 Date of issue: 2023-10-08 Applicant: Shenzhen QM Smart Panlee Technology Co., Ltd Product: PANLEE BC02 Model(s): ZX3D95CE01S-TR-4848 FCC ID: 2BCBK-TR4848 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6 - Report No.: MTi230722002-01E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6 - Report No.: MTi230722002-01E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] Test Result Certification Applicant: Shenzhen QM Smart Panlee Technology Co., Ltd Address: Room 805, Block A, Building 6, Shenzhen International Innovation Valley, Xili Community, Nanshan District, Shenzhen Manufacturer: Shenzhen QM Smart Panlee Technology Co., Ltd Address: Room 805, Block A, Building 6, Shenzhen International Innovation Valley, Xili Community, Nanshan District, Shenzhen Product description Product name: PANLEE BC02 Trademark: N/A Model name: ZX3D95CE01S-TR-4848 Serial Model: N/A Standards: N/A Test procedure: KDB 447498 D01 v06 Date of Test Date of test: 2023-08-10 to 2023-10-08 Test result: Pass Test Engineer : (Maleah Deng) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) - Page 4 of 6 - Report No.: MTi230722002-01E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1415926 R= distance between observation point and center of the radiator in cm(20cm) Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. - Page 5 of 6 - Report No.: MTi230722002-01E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] Measurement Result BT/BLE: Operation Frequency: 2402-2480MHz, Power density limited: 1mW/ cm 2 2.4GWiFi: Operation Frequency: WIFI 802.11b/g/n HT20: 2412-2462MHz, 802.11n HT40: 2422-2452 MHz Power density limited: 1mW/ cm 2 Antenna Type: PCB antenna; Antenna gain: -0.47 dBi R=20cm mW=10^(dBm/10) antenna gain Numeric=10^(dBi/10)= 10^(-0.47/10)= 0.90 2.4GWiFi: Channel Freq. (MHz) modulation conducted power Tune- up power Max Antenna Evaluation result at 20cm Power density Limits (dBm) (dBm) tune-up power Gain Power density(mW/cm 2 ) (mW/cm 2 ) (dBm) (mW) Numeric 2412 802.11b 18.56 18±1 19 79.433 0.90 0.01418 1 2437 18.03 18±1 19 79.433 0.90 0.01418 1 2462 17.88 17±1 18 63.096 0.90 0.01126 1 2412 802.11g 21.34 21±1 22 158.489 0.90 0.02830 1 2437 20.93 20±1 21 125.893 0.90 0.02248 1 2462 20.81 20±1 21 125.893 0.90 0.02248 1 2412 802.11n H20 20.24 20±1 21 125.893 0.90 0.02248 1 2437 19.76 19±1 20 100.000 0.90 0.01785 1 2462 19.76 19±1 20 100.000 0.90 0.01785 1 2422 802.11n H40 19.15 19±1 20 100.000 0.90 0.01785 1 2437 19.03 19±1 20 100.000 0.90 0.01785 1 2452 18.19 18±1 19 79.433 0.90 0.01418 1 - Page 6 of 6 - Report No.: MTi230722002-01E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86‐755)88850135 Fax: (86‐755) 88850136 Web: www.mtitest.com E‐mail: [email protected] BLE Channe l Freq. (MHz) modulation conducted power Tune- up power (dBm) Max Antenna Evaluation result Power density Limits (dBm) tune-up power Gain (mW/cm2) (mW/c m2) (dBm) (mW) (dBi) Numeric 2402 GFSK-1M 3.27 3±1 4 2.512 -0.47 0.90 0.0004 1 2440 4.03 4±1 5 3.162 -0.47 0.90 0.0006 1 2480 4.20 4±1 5 3.162 -0.47 0.90 0.0006 1 2402 GFSK-2M 3.19 3±1 4 2.512 -0.47 0.90 0.0004 1 2440 4.05 4±1 5 3.162 -0.47 0.90 0.0006 1 2480 4.17 4±1 5 3.162 -0.47 0.90 0.0006 1 Conclusion: Note: BLE and WIFI cannot work at the same time For the max result: 0.02830≤ 1.0, No SAR is required. ----END OF REPORT----

Antenna Specification ITEM SPEC Antenna type PCB Antenna(B) Center Frequency 2400Mhz | -1.71dBi 2450Mhz | -0.92dBi 2500Mhz | -0.47dBi MAX GAIN -0.47dbi Polarization Horizontal Azimuth Beam Pattern Omni-directional Impedance 50ohm Antenna Length Antenna Photo & Length(mm) Coordinate System Reference:Antenna Top view Side view 3D Radiation pattern f = 2400MHz 3D Radiation pattern f = 2450MHz 3D Radiation pattern f = 2500MHz Measurements summary Wireless-Tag Technology Co., Ltd 801, Block A, Building 6, Shenzhen International Innovation Valley, Dashi Road, Xili Community, Xili Street, Nanshan District, Shenzhen Frequency(GHz) Gain(dBi) CP Gain(dBi) CO Gain(dBi) Efficiency(dB) Efficiency(%) 2400 -1.71 -- -- -- 34.23% 2410 -1.46 -- -- -- 36.08% 2420 -1.27 -- -- -- 38.10% 2430 -1.17 -- -- -- 40.00% 2440 -1.06 -- -- -- 42.05% 2450 -0.92 -- -- -- 43.95% 2460 -0.79 -- -- -- 45.37% 2470 -0.72 -- -- -- 46.69% 2480 -0.47 -- -- -- 49.59% 2490 -0.51 -- -- -- 49.35% 2500 -0.47 -- -- -- 50.07%

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230722002-01E1 Date of issue: 2023-10-08 Applicant: Shenzhen QM Smart Panlee Technology Co., Ltd Product: PANLEE BC02 Model(s): ZX3D95CE01S-TR-4848 FCC ID: 2BCBK-TR4848 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 55 Report No.: MTi230722002-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 55 Report No.: MTi230722002-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 7 1.4 Description of support units ....................................................................................................................... 7 1.5 Measurement uncertainty .......................................................................................................................... 7 2 Summary of Test Result .................................................................................................................. 8 3 Test Facilities and accreditations ................................................................................................... 9 3.1 Test laboratory ........................................................................................................................................... 9 4 List of test equipment .................................................................................................................... 10 5 Evaluation Results (Evaluation) .................................................................................................... 11 5.1 Antenna requirement ............................................................................................................................... 11 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 11 6.1 Conducted Emission at AC power line .................................................................................................... 11 6.2 Occupied Bandwidth ................................................................................................................................ 14 6.3 Maximum Conducted Output Power ........................................................................................................ 15 6.4 Power Spectral Density ........................................................................................................................... 16 6.5 Emissions in frequency bands ................................................................................................................. 17 6.6 Band edge emissions (Radiated) ............................................................................................................ 18 6.7 Radiated emissions (below 1GHz) .......................................................................................................... 23 6.8 Radiated emissions (above 1GHz) .......................................................................................................... 27 Photographs of the test setup ............................................................................................................. 34 Photographs of the EUT....................................................................................................................... 35 Appendix A: DTS Bandwidth ............................................................................................................... 36 Appendix B: Maximum conducted output power ............................................................................... 39 Appendix C: Maximum power spectral density .................................................................................. 42 Appendix D: Band edge measurements ............................................................................................. 45 Appendix E: Conducted Spurious Emission ...................................................................................... 47 Appendix F: Duty Cycle ....................................................................................................................... 53 Page 4 of 55 Report No.: MTi230722002-01E1 Address: 101, No. 7, Zone…

Text truncated - open the document above for the full version.

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230722002-01E2 Date of issue: 2023-10-08 Applicant: Shenzhen QM Smart Panlee Technology Co., Ltd Product: PANLEE BC02 Model(s): ZX3D95CE01S-TR-4848 FCC ID: 2BCBK-TR4848 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 77 Report No.: MTi230722002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 77 Report No.: MTi230722002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ........................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 7 1.4 Description of support units ....................................................................................................................... 7 1.5 Measurement uncertainty .......................................................................................................................... 7 2 Summary of Test Result .................................................................................................................... 8 3 Test Facilities and accreditations ..................................................................................................... 9 3.1 Test laboratory ........................................................................................................................................... 9 4 List of test equipment ...................................................................................................................... 10 5 Evaluation Results (Evaluation) ..................................................................................................... 11 5.1 Antenna requirement ............................................................................................................................... 11 6 Radio Spectrum Matter Test Results (RF) ...............................…

Text truncated - open the document above for the full version.
