2BCC3-AMTRCR01AMETRA COLORIMETER

Syntes Inc 2023-07-28 Page 1 of 15 AMTRCR01 Colorimeter User Manual V2.0 QR code for app installation Please read this manual carefully before using and reserve it for reference. Syntes Inc 2023-07-28 Page 2 of 15 I. Mobile App Installation The colorimeter APP supports Android operating system 7.0 and above or iOS 7.0 and above. Choose one of the following methods to install: 1. Scan the QR code on the cover with a mobile browser or WeChat, follow the prompts to download and install LScolor application. 2. Search for "LScolor" from the iOS App Store or Google Play App Market and follow the prompts to download and install LScolor application. APP icon Precautions: Open the APP during the installation process or after the first installation, the mobile phone will prompt for permission settings. The customer needs to set “Allow all”, otherwise it will appear that the device can’t be searched and the APP can’t be used. II. Product Introduction The instrument is a portable App smart colorimeter, which greatly improves and expands the functions of the colorimeter by taking advantage of the large memory and convenient screen operation of the mobile phone App. The App comes with multiple electronic color charts to quickly match the measured color to the closest color code and support color sharing through WeChat, WhatsApp, Skype, email, etc. The colorimeter also has a color comparison function, the color difference threshold can be set and a variety of color difference formulas can be selected, which can realize fast QC testing. III. Parameters Illumination geometry 45/0 (45° annular illumination, 0° viewing angle) Syntes Inc 2023-07-28 Page 3 of 15 Illumination light source Full spectrum LED light source Measuring aperture 8mm Measurement conditions Light source D65, field of view 10° Measuring time About 1s Color space CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hex Color difference formula ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00 Repeatability Standard deviation within ΔE*ab 0.03 (Measurement conditions: after calibration, the average value of 30 measurements on the whiteboard at an interval of 3s) Dimension 31.7mm×31.7mm×70.4mm Weight About 51g Battery power Rechargeable lithium battery 3.7V@700mAh, can be used continuously for 10,000 times under full charge Display No Charging port USB (Type-C) Data transmission Bluetooth Operating temperature range 0~45°C, 0~85%RH (no condensation) Storage temperature range -25~55°C, 0~85%RH (no condensation) IV. Features 1. Small size and simple operation with only one button. 2. Built in multiple electronic color charts, quickly match the closest color code, the color code matching accuracy rate is greater than 90%. 3. Equipped with QC testing function, color difference threshold (tolerance value) can be set and a variety of color difference formulas can be selected. 4. A variety of color spaces are available to facilitate color measurement for various needs. 5. Support color data import and sharing to achieve multi-device data sharing. Syntes Inc 2023-07-28 Page 4 of 15 6. Built-in compensation optical path makes the values stable, allowing long-period calibration. 7. Built-in rechargeable lithium battery, can be used continuously for 10,000 times under full charge. V. Operation 1. Power on/off Power on: Short press the power button to turn on the colorimeter, after that, the indicator light will flash. Shut down: Long press the power button to turn off the colorimeter; when the mobile phone is not connected to Bluetooth, it will automatically turn off without any operation in 3 minutes; when the mobile phone is connected to Bluetooth and it will automatically turn off without any operation in 30 minutes. 2. Bluetooth connection Turn on the colorimeter, open the App and first display the logo. After the logo is displayed for 3s, enter the "Connect Device" interface and automatically start searching for Bluetooth devices. The searched devices will be displayed at the bottom of the interface. Click the device that matches the SN of the colorimeter and wait for the device to connect. After the connection is successful, it will jump to "Calibration Interface". Precautions:  If there is a Bluetooth connection error or connection failure, you can restart the App and the colorimeter, or turn off/start Bluetooth in the setting interface and then reconnect.  Click the "Browse" button, you can enter the App to view historical data without connecting to the colorimeter. 3. Calibration After the App is connected to the colorimeter, enter the "Equipment Calibration" interface. The user can perform the calibration operation or skip the calibration.  Equipment calibration After closing the bottom cap of the colorimeter, click the "Calibration" button. If the calibration is successful, the colorimeter will directly enter the measurement interface; if not, it will prompt "Calibration failed". If it prompts that the calibration failed, the possible reasons are as follows: 1. The bottom cap is not closed properly; 2. The standard tile on the bottom cap is too dirty and needs to be cleaned; 3. The attenuation of the light source leads to abnormal use, the colorimeter needs to be returned to Syntes Inc 2023-07-28 Page 5 of 15 the factory for inspection and repair.  Skip calibration The colorimeter skips the calibration operation and enters the measurement interface. When the colorimeter has not been used for a long time, it is recommended to calibrate. 4. Measurement After the App is successfully connected to the colorimeter, enter the main measurement interface. There are two measurement modes: "Color Scan" and "Color Compare". After the App is opened, the default mode is "Color Scan", there are two measurement switch buttons at the bottom of the main interface. The font of the button turns blue when selected. The current measurement mode, battery power, historical records, model and connection status are displayed on the top information bar.  Battery life Display …

Text truncated - open the document above for the full version.

(SYNTES INC) (August 3, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BCC3-AMTRCR01) [SYNTES INC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) TATIANA AUSTIN (SYNTES INC) (August 3, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BCC3-AMTRCR01) [SYNTES INC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) TATIANA AUSTIN

Attestation Statements (August 3, 2023) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2BCC3-AMTRCR01) (SYNTES INC), the undersigned, hereby authorize (SYNTES INC) to act as our designated U.S. agent for service of process, (SYNTES INC) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (SYNTES INC) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: SYNTES INC Contact Name: TATIANA AUSTIN Address: 7272 WISCONSIN AVENUE, SUITE 900, BETHESDA, MARYLAND, 20814, USA TATIANA AUSTIN Telephone No: 13538214502 Email: [email protected] U.S. Agent Information: Company Name: SYNTES INC Address: 7272 WISCONSIN AVENUE, SUITE 900, BETHESDA, MARYLAND, 20814, USA Contact Name: TATIANA AUSTIN Telephone No: 13538214502 Email: [email protected] FRN: 0034081893 Applicant Signature: Agent Signature: Applicant printed name: TATIANA AUSTIN Agent printed name: TATIANA AUSTIN

SYNTES INC (August 3, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (AMETRA COLORIMETER / AMTRCR01/ FCC ID: 2BCC3-AMTRCR01) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: TATIANA AUSTIN Title: Manager

SYNTES INC (August 3, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: TATIANA AUSTIN Title: Manager

External Photos

FCC ID LABEL: Label Location: FCC ID: 2BCC3-AMTRCR01 Model No.: AMTRCR01

Internal Photos ANT

Shenzhen CTB Testing Co., Ltd. FCC ID: 2BCC3-AMTRCR01 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE: 1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -1.333 0.74 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.44 -0.841 0.82 0±1 1.00 1.26 <5 0.39330 3.00 YES 2.480 -0.695 0.85 0±1 1.00 1.26 <5 0.39651 3.00 YES GFSK 2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -1.332 0.741±12.001.58<50.491273.00YES 2.44 -0.825 0.830±11.001.26<50.393303.00YES 2.480 -0.681 0.850±11.001.26<50.396513.00YES GFSK Conclusion: For the max result : 0.49127≤ FCC Limit 3.0 for 1g SAR.
