2BCCC-Y83Smart watch

SMART WATCH OPERATING GUIDE Y83 Thank you for buying our smart watch. Please read this manual carefully before. ·······01 ~11 ·······12~22 ·······23~33 ·······34~44 English Español 日本語 中文 Setting Use H Band APP on iOS or Android smartphones (excluding tablets and computers) as follows. Note: The hardware and system of your smartphones should meet the following requirements. IOS 8.0 or above mobile Android 4.4 or above Bluetooth 4.0 1. Search and download H Band APP 1. IOS users please search and download "H Band" from APP Store; 2. Android users please search for "H Band" and download and install rt in Google Play and 360 application markets, as well as the application markets provided by Huawei, Xiaomi, OPPO and Vivo. Scan the QR code. There may be problems opening the link with the smartphones scanning tool. Please copy the link and open it through the browser. -1 - 2.Watch and mobile phone binding connection 1.APP connect Y83: Turn on the Bluetooth of the mobile phone, enter "Mine" in the APP page, find "Device" and click on the name of the device to be connected "Y83". Choose Y83 to connect, please choose to allow access to location information, if there are multiple devices nearby, please filter according to the MAC address of the watch, and the MAC address can be viewed in About Devices in the watch settings function. The symbol in the upper left corner is displayed as: If you see the symbol it means not connection succeeded, Please try again. 2.Considerations when connecting: ① Bluetooth is turned on ② The watch has sufficient electricity ③ When connecting smartphones and watch, please keep it within 50cm ,lf the smartphones cannot find the watch in the APP please open all permissions of H Band software in the smartphones setting. FAQ: Could not find the device while connecting? 1. Make sure your smartphone's Bluetooth is turned on, and your smartphone's operating system should be Android 4.4 and above; or IOS 8.0 and above. 2. Ensure that the distance between the smartphones and the device is less than 0.5 meters. After connection, the device should be kept within the effective range (usually less than 10 meters). 3: Ensure that the device has sufficient power If there are still problems after charging, please feel free to contact us. -2- Tip: When the APP is linked to the watch, please open the Bluetooth inside the phone settings, find Y83 inside the Bluetooth list and connect it before the watch can make calls and use it as a speaker. Music Information Reminder 3. Appearance ① Names of different parts Step counting Heart rate Countdown Note: To ensure the data is valid, please enter the real gender, height weight and skin color in APP's personal data. 4. Function Introduction (1) Interface Remote control photographing Setup Interface Make sure the watch and APP are connected well. Enter APP , click My Device- Y83-Dial Setting-Select the corresponding style,and the watch screen shows that the replacement was successful. -3- Screen touch area Side button/Home key Main Interface Stopwatch Sleep Activity Blood pressure blood glucose Screen Operation: Slide up and down, left and right (2)Screen drop-down interface function introduction (3) Turn on/off Turn on: when the device is off status, long press the key button for 4 seconds to turn it on and enter the time interface, After 5 seconds without operation, the device will turn off the screen automatically and enter the stand by mode. Turn off: Long press the side button for 4 seconds and slide the screen to turn off the smartwatch. -4- Communication Settings Do-not-disturb mode Device Information (4) Function interface Press the side button to enter the function selection interface, slide up and down to select the desired function for operation, and then press the side button to return to the main interface. (5) Steps, calories and miles Enter the step counting screen, which displays the current step count, target progress, calories and distance for the day. the screen will turn off after 5 seconds. The number of steps detected by the acceleration sensor has a small error (within 10%) within a reasonable range. Swipe down the screen from the top of the screen and tap on the communication function. It is only by tapping the switch for Bluetooth audio that you can allow the sound of media audio to be played through the watch only. If you do not want the sound of media audio to be played through the smartwatch, tap the switch for Bluetooth audio to turn this function off. (6) Manual detection and automatic monitoring of heart rate Slide the right screen on the main interface of the device to enter the heart rate detection interface and click the icon to start the detection. After the measured results are obtained, the real-time heart rate value will be continuously measured and displayed. No matter whether the results are measured or not, the device will automatically extinguish the screen and stand by after 60 seconds of cumulative testing. The heart rate measured on the device will not be saved.you can also enter the heart rate manual test interface on the APP's data panel-Y83- More Operations-Heart Rate icon, and the heart rate test results operated on the APP will not be saved. Turn on the heart rate automatic detection switch at the APP end, and the device will automatically monitor the heart rate 24 hours a day collect data every 10 minutes and display data every 30 minutes. After synchronizing the data, the test results can be viewed on the APP for details. APP Test Mode Heart Rate Data Panel 1. As long as you put on your watch, it will automatically detect your heart rate, number of steps and calories and synchronize to the APP 2, The default is automatic heart rate monitoring function, which automatically detects the heart rate to be turned off every 30 minutes. Please set it in APP: My Device-Y83- Switch Setting-Automatic Heart Rate Monitoring-Turn 3,ln order to monitor the heart rate more accurately please make it tighter t…

Text truncated - open the document above for the full version.

(SHENZHEN YIHU TECHNOLOGY CO.,LTD) (August 2, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BCCC-Y83) [SHENZHEN YIHU TECHNOLOGY CO.,LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) zhu zhiqiang (SHENZHEN YIHU TECHNOLOGY CO.,LTD) (August 2, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BCCC-Y83) [SHENZHEN YIHU TECHNOLOGY CO.,LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) zhu zhiqiang

SHENZHEN YIHU TECHNOLOGY CO.,LTD Model Difference Data：August 2, 2023 Product description: Smart watch Model name: Y83, Y9, Y9PRO, Y80, y82, y85, y86, y88, y22, y23, y25, y26, y28, y92, y93 Trade Name: N/A FCC ID: 2BCCC-Y83 All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature : Client’s name / title : zhu zhiqiang（General manager） Contact information / address：4th Floor, Building 4, Zone A, Yalian Haoshida Industrial Zone, Bantian Street, Longgang District, Shenzhen

SHENZHEN YIHU TECHNOLOGY CO.,LTD (August 2, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart watch / Y83, Y9, Y9PRO, Y80, y82, y85, y86, y88, y22, y23, y25, y26, y28, y92, y93 / FCC ID: 2BCCC-Y83 ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: zhu zhiqiang Title: General manager

SHENZHEN YIHU TECHNOLOGY CO.,LTD (August 1, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: zhu zhiqiang Title: General manager

External Photos

FCC ID LABEL: Label Location: FCC ID: 2BCCC-Y83 Model No.: Y83

Internal Photos ANT

Shenzhen CTB Testing Co., Ltd. FCC ID: 2BCCC-Y83 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 5.66 3.685±16.003.98<51.234003.00YES 2.441 5.96 3.945±16.003.98<51.243983.00YES 2.480 5.777 3.785±16.003.98<51.253883.00YES 2.402 6.261 4.236±17.005.01<51.553523.00YES 2.441 6.492 4.466±17.005.01<51.566083.00YES 2.480 6.286 4.256±17.005.01<51.578543.00YES GFSK π /4DQPSK BLE: 1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 5.526 3.57 5±1 6.00 3.98 <5 1.23400 3.00 YES 2.44 5.759 3.77 5±1 6.00 3.98 <5 1.24373 3.00 YES 2.480 5.743 3.75 5±1 6.00 3.98 <5 1.25388 3.00 YES GFSK 2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 5.255 3.35 5±1 6.00 3.98 <5 1.23400 3.00 YES 2.44 5.915 3.90 5±1 6.00 3.98 <5 1.24373 3.00 YES 2.480 5.935 3.92 5±1 6.00 3.98 <5 1.25388 3.00 YES GFSK Conclusion: For the max result : 1.57854≤ FCC Limit 3.0 for 1g SAR.

中科达科技（深圳）有限公司 中科达科技（深圳）有限公司 Zhongkeda Technology (Shenzhen) Co., LTD 承认书 供应商名称 Supplier name 中科达科技（深圳）有限公司 Zhongkeda Technology (Shenzhen) Co., LTD 客户名称 Customer name 深圳市益虎科技有限公司 SHENZHEN YIHU TECHNOLOGY CO.,LTD 产品名称 Product name Y83 BT ANT 应用频段 Application frequency band 2.4G 日期 2023年7月7日 供应商 确 认 外观 性能 结构 核准 张凡清 蔡卫东 郭鹏飞 蔡卫东 客户 承认 外观 性能 结构 核准 中科达科技（深圳）有限公司 1：物料规格书Material specification 图1 BT天线ICD图Figure 1 ICD diagram of BT antenna 中科达科技（深圳）有限公司 2：可靠性报告Reliability report 驻波比(VSWR): 天线效率 增益Antenna efficiency gain Test Point ID Freq(Mhz) Efficiency(%) Gain(dBi) 1 2400 45.3% 2.54 2 2410 45.6% 2.87 3 2420 46.6% 2.89 4 2430 48.3% 3.12 5 2440 48.9% 3.24 6 2450 48.1% 3.46 7 2460 49.6% 3.52 8 2470 49.8% 3.64 9 2480 49.0% 3.05 10 2490 47.8% 2.77 11 2500 46.2% 2.13 中科达科技（深圳）有限公司 天线方向图Antenna pattern

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230727049RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 53 TEST REPORT Compiled by: Reviewed by: Approved by: Zhou Kui Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Smart watch FCC ID: 2BCCC-Y83 Trademark: N/A Model Number: Y83, Y9, Y9PRO, Y80, y82, y85, y86, y88, y22, y23, y25, y26, y28, y92, y93 Prepared For: SHENZHEN YIHU TECHNOLOGY CO.,LTD Address: 4th Floor, Building 4, Zone A, Yalian Haoshida Industrial Zone, Bantian Street, Longgang District, Shenzhen Manufacturer: SHENZHEN YIHU TECHNOLOGY CO.,LTD Address: 4th Floor, Building 4, Zone A, Yalian Haoshida Industrial Zone, Bantian Street, Longgang District, Shenzhen Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jul. 17, 2023 Sample tested Date: Jul. 17, 2023 to Jul. 27, 2023 Issue Date: Jul. 27, 2023 Report No.: CTB230727049RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230727049RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 53 TABLE OF CONTENT Test Report Declaration Page 1. VERSION .......................................................................... 4 2.TEST SUMMARY ................................................................... 5 3.MEASUREMENT UNCERTAINTY ..................................................... 6 4.PRODUCT INFORMATION AND TEST SETUP .......................................... 7 4.1 Product Information .................................................................... 7 4.2 Test Setup Configuration ............................................................... 7 4.3 Support Equipment .................................................................... 7 4.4 Channel List .......................................................................... 8 4.5 Test Mode ............................................................................ 8 4.6 Test Environment ...................................................................... 8 5.TEST FACILITY AND TEST INSTRUMENT USED ....................................... 9 5.1 Test Facility ........................................................................... 9 5.2 Test Instrument Used .................................................................. 9 6.AC POWER LINE CONDUCTED EMISSION ............................................ 11 6.1 Block Diagram Of Test Setup .......................................................... 11 6.2 Limit ................................................................................ 11 6.3 Test procedure ....................................................................... 11 6.4 Test Result .......................................................................... 13 7.RADIATED SPURIOUS EMISSION ................................................... 15 7.1 Block Diagram Of Test Setup .......................................................... 15 7.2 Limit ................................................................................ 15 7.3 Test procedure ....................................................................... 16 7.4 Test Result .......................................................................... 17 8.BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS .......................... 26 8.1 Block Diagram Of Test Setup .......................................................... 26 8.2 Limit ................................................................................ 26 8.3 Test procedure ....................................................................... 26 8.4 Test Result .......................................................................... 27 9. COUDUCTED PEAK OUTPUT POWER ............................................... 32 9.1 Block Diagram Of Test Setup .......................................................... 32 9.2 Limit ................................................................................ 32 9.3 Test procedure ....................................................................... 32 9.4 Test Result .......................................................................... 33 10.20DB OCCUPIED BANDWIDTH...................................................... 36 10.1 Block Diagram Of Test Setup ......................................................... 36 10.2 Limit ............................................................................... 36 10.3 Test procedure ...................................................................... 36 10.4 Test Result ......................................................................... 36 11.CARRIERFREQUENCIES SEPARATION .............................................. 39 11.1 Block Diagram Of Test Setup ......................................................... 39 11.2 Limit ............................................................................... 39 11.3 Test procedure ...................................................................... 39 11.4 Test Result ......................................................................... 39 12. HOPPING CHANNEL NUMBER ...................................................... 42 12.1 Block Diagram Of Test Setup ....…

Text truncated - open the document above for the full version.

Radiated Emission Below 1G Above 1G Conducted emissions
