2BCF4-T-MSP-USAutomatic cat litter box

NOTTY Automatic Cat Litter Box User Manual Model T-MSP1 Thank you for choosing NOTTY. In order to facilitate proper operation of the machine, please read this manual carefully before use, and store it carefully for future reference. The pictures are for reference only, and the product is subject to the actual product. (Technical specifications in this manual are subject to change) Packaging List Components Product Warranty CardWARRANTY TERMS & CONDITIONS Setting Up Your NOTTY Automatic Cat Litter Box 4. Install Waste Bags Name Addres Tel.No. Date of Purchase Store Nam Warranty Period 1.All quality-related defects on items sold directly by NOTTY o r NOTTY’s authorized resellers are covered by an extensive warranty, starting from the date of purchase. NOTTY‘s limited warranty is restricted to the country of purchase. The limited warranty is void on items taken outside the country they were originally bought in or shipped to direct ly from an authorized online purchase.2.This warranty covers only original NOTTY products. It is not applicable to normal wear and tear, or any defects arising from damage caused by misuse of this product.3.Warranty is for the primary product only. Any free additional product(s) are not covered in this warranty.4.If the product fails regardless of usage in compliance with the user manual and other writtenprecaution, replacement will be provide d free of charge.5.To claim the warranty, contact the services team from the pla tform or store where you bought from 1. Placement-- Place your NOTTY Automatic Cat Litter Box on a firm, level floor; be careful not to push it against the wall.-- Reserve amble space when opening the waste container on the top and left side to ensure the normal use of the product.-- The gear behind the cylinder should be embedded in the groov e to ensure the normal use of the product.-- Do not place any items on top of the device for safety reasons.-- Do not drag the device during the placement process. Lift the cylinder first, then move the base to relocate the device.2. Power on-- Plug the small end of the adaptor into the socket at the back of the base. Then plug the other end into a power outlet. The LED scre en on the front of the device will light up.3. Self-inspection-- The device will perform a self-inspection that will last abo ut 1min. During the self-inspection, the LED screen shows "reset", and t he cylinder will rotate slowly until it gets to the HOME position.-- After the self-inspection is completed, the screen will jump to the default display, "0 toilet visits today".-- The default mode is automatic mode; you can adjust the clean ing mode on the APP. Waste Container Cleaning Screen Anti-stickMat Base Entrance Weight Sensor Display Screen Control Panel Manual*1 NOTTY Automatic Litter Box Waste Bags *1 Adaptor *1 Manual Clean and Care Function How it works EmptyMODEClean it NowSmooth Cat Litter Description ResetWIFI Mode Description SmartMODE AutomaticMODE ---- TimerMODEEmpty MODEClean it NowSmooth Cat Litter Cleaning Mode Product Parameters NOTE Control Panel Product Name: NOTTY Automatic Cat Litter Box Product Model: T-MSP1 Overall Dimension: 531mm * 584mm * 571mm Rated Voltage: 5V 1A Rated Power: 5W Applicable for CatsMade in P.R.C. 531mm 384mm200mm 571mm App Download and Operation 1.Download the APP 2.Pair with the device Collar Tag Chip -- The smart litter box can be remotely controlled through the App. Download and install the latest version of the NOTTY Smart Pet app from the App Store or other third-party app stores. After your cat leaves the Cylinder, NOTTY Automatic Cat Litter Box automatically performs a Cleaning cycle.You may set this mode through APP. Keep pressing the MODE button until the screen displays ‘Clean it Now’Press OK button NOTTY Automatic Cat Litter Box will perform a Clean cycle immediately.NOTTY Automatic Cat Litter Box will rotate 1/4 cycle right and left to help smooth rusty cat litter.NOTTY Automatic Cat Litter Box will empty all of the litter from the Cylinder into the Waste Container for easy disposal. NOTTY Automatic Cat Litter Box will reset the weight sensor.After adding litter, press reset button to reset the Cat sensor.NOTTY Automatic Cat Litter Box will be ready to connect. Go to NOTTY Smart Pet App to complete the pairing Keep pressing the MODE button until the screen displays ‘Smooth Cat Litter’Press OK buttonKeep pressing the MODE button until the screen displays ‘Empty MODE’Press OK buttonKeep pressing the MODE button until the screen displays ‘Reset’Press OK buttonKeep pressing the MODE button until the screen displays ‘WIFI’Press OK button twice NOTTY Automatic Cat Litter Box will automatically performs a Clean cycle at the time you set.You may set this mode through APP.This MODE is designed for cats that tends to have soft poop. NO TTY Automatic Cat Litter Box will help bury and cover the poop with cat litter and start the Clean cycle after 15 minutes.You may set this mode through APP.NOTTY Automatic Cat Litter Box will perform a Clean cycle immediately.You can do it through Control Panel or through APP.NOTTY Automatic Cat Litter Box will rotate 1/4 cycle right and left to help smooth rusty cat litter.You can do it through Control Panel or through APP.NOTTY Automatic Cat Litter Box will empty all of the litter from the Cylin-der into the Waste Container for easy disposal. Use this MODE to change out the whole bed of litter or before cleaning the cylinder.You can do it through Control Panel or through APP. -- Open the APP, turn to ‘devices’ page and click the button on the top right corner of the screen. Press the “FUNCTION” button on the control panel until the screen displays WIFI. Press "OK" twice and follow the instructions in the app to complete the pairing with the device. 3.Pair the smart collar through the APP -- Turn to‘my cat’page and click the button on top r ight corner of the screen. Fill in the pet information according to the instructions. -- Register the smart collar : …

Text truncated - open the document above for the full version.

(Shanghai Qiaojimeng Technology Co, Ltd.) (2023.09.13) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BCF4‐T‐MSP‐US) [Shanghai Qiaojimeng Technology Co, Ltd. ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Jessie Yang (Shanghai Qiaojimeng Technology Co, Ltd.) (2023.09.13) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BCF4‐T‐MSP‐US) [Shanghai Qiaojimeng Technology Co, Ltd. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jessie Yang

Shanghai Qiaojimeng Technology Co, Ltd. Agent Authorization Letter 2023-09-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Most Technology Service Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Jessie Yang Position: CEO Company Name: Shanghai Qiaojimeng Technology Co, Ltd. Address: Room 2886,Floor 2,Block 2,656-658 Wuyi Road,Changning District,Shanghai,China Tel / Fax 18621865631/18621865631 E-Mail: [email protected]

Model difference letter 2023.09.13 Dear MET Reviewer, This is a new Application fromShanghai Qiaojimeng Technology Co, Ltd. Model No.:T-MSP2-US,T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1- TW,T-MSP2-TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 UseT-MSP2-USfor all tests.Only the model name is different. Thank you for your cooperation! Yours sincerely, Signatory: Name:Jessie Yang Position:CEO Company Name: Shanghai Qiaojimeng Technology Co, Ltd. Address:Room 2886,Floor 2,Block 2,656-658 Wuyi Road,Changning District,Shanghai,China Tel / Fax18621865631/18621865631 E-Mail:[email protected]

Model No.: U-MSP2-EUR FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE Model No.: U-MSP2-EUR LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE Model No.: U-MSP2-EUR TOP VIEW OF SAMPLE FRONT VIEW OF SAMPLE Model No.: U-MSP2-EUR Overall photo Adapter

Label size:50mm*40mm Product name: Automatic cat litter box Product model: T‐MSP2‐US FCC ID: 2BCF4‐T‐MSP‐US Manufacturer: Zhejiang Qiaowei Technology Co., Ltd. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includinginterference that may cause undesired operation. Label location

Model No.: U-MSP2-EUR Page 1 of 7 INTERNAL PHOTO OF SAMPLE INTERNAL PHOTO OF SAMPLE Model No.: U-MSP2-EUR Page 2 of 7 INTERNAL PHOTO OF SAMPLE INTERNAL PHOTO OF SAMPLE PCB Model No.: U-MSP2-EUR Page 3 of 7 INTERNAL PHOTO OF SAMPLE PCB INTERNAL PHOTO OF SAMPLE PCB Model No.: U-MSP2-EUR Page 4 of 7 INTERNAL PHOTO OF SAMPLE PCB INTERNAL PHOTO OF SAMPLE PCB Antenna Location Model No.: U-MSP2-EUR Page 5 of 7 INTERNAL PHOTO OF SAMPLE PCB INTERNAL PHOTO OF SAMPLE PCB Model No.: U-MSP2-EUR Page 6 of 7 INTERNAL PHOTO OF SAMPLE PCB INTERNAL PHOTO OF SAMPLE PCB Model No.: U-MSP2-EUR Page 7 of 7 INTERNAL PHOTO OF SAMPLE PCB INTERNAL PHOTO OF SAMPLE PCB

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. RF Exposure Evaluation Report Report Reference No. ..................... : FCC ID.. .......................................... : MTEB23070062-H 2BCF4-T-MSP-US Compiled by ( position+printed name+signature) .. : File administrators Alisa Luo Supervised by ( position+printed name+signature) .. : Test Engineer Sunny Deng Approved by ( position+printed name+signature) .. : Manager Yvette Zhou Date of issue ..................................... : July 11,2023 Representative Laboratory Name .: Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : Shanghai Qiaojimeng Technology Co, Ltd. Address ............................................ : Room 2886,Floor 2,Block 2,656-658 Wuyi Road,Changning District,Shanghai,China Test specification/ Standard ..........: 47 CFR Part 1.1307 47 CFR Part 2.1093 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Automatic cat litter box Trade Mark ...........................: N/A Manufacturer .................................... : Shanghai Qiaojimeng Technology Co, Ltd. Model/Type reference....................... : T-MSP2-US Listed Models .................................. : T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2- TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 Modulation Type ............................... : GFSK CCK/DSSS/OFDM Operation Frequency ........................ : From 2402MHz to 2480MHz From 2412 - 2462MHz Hardware Version .............................. V3.0 Software Version ............................... PET.0009.A.103_FW_WB60_0.4.6_0.4.6.bin Rating ............................................... : (Input：100-240V~50/60Hz 0.3A Output：DC 5V⎓2000mA) Result................................................ : PASS Report No.: MTEB23070062-H Page 2 of 6 T E S T R E P O R T Equipment under Test : Automatic cat litter box Model /Type : T-MSP2-US Listed Models T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2- TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 Remark Only the model name is different. Applicant : Shanghai Qiaojimeng Technology Co., Ltd. Address : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Manufacturer : Shanghai Qiaojimeng Technology Co., Ltd. Address : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTEB23070062-H Page 3 of 6 1. Revision History Revision Issue Date Revisions Revised By 00 2023.07.11 Initial Issue Alisa Luo Report No.: MTEB23070062-H Page 4 of 6 2. SAR Evaluation 2.1 RF Exposure Compliance Requirement 2.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 2.1.2 Limits According to FCC Part1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in part1.1307(b) F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4* Pi * R 2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No.: MTEB23070062-H Page 5 of 6 2.1.3 EUT RF Exposure Measurement Data BLE GFSK Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2402MHz) 5.113 5.113±1 6.113 Middle(2441MHz) 3.970 3.970±1 4.970 Highest(2480MHz) 2.045 2.045±1 3.045 Worst case: GFSK Channel Maximum tune-up Power (dBm) Maximum tune-up Power (MW) Antenna Gain (dBi) Power Density at R = 20 cm (mW/cm2) Limit Result Middle(2437MHz) 6.113 4.09 2.0 0.001 1.0 Pass Note: 1) Refer to report MTEB23070062-R1 for EUT test Maximum tune-up Power. Note: 2) Pd = (Pout*G)/(4* Pi * R2)=(4.09*1.58)/(4*3.1416*20 2 )=0.001 Report No.: MTEB23070062-H Page 6 of 6 WIFI 2.4G 802.11b Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2412MHz) 15.31 15.31±1 16.31 Middle(2437MHz) 12.08 12.08±1 13.08 Highest(2462MHz) 15.77 15.77±1 16.77 802.11g Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2412MHz) 12.60 12.60±1 13.60 Middle(2437MHz) 8.28 8.28±1 9.28 Highest(2462MHz) 13.03 13.03±1 14.03 802.11n(H20) Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2412MHz) 11.31 …

Text truncated - open the document above for the full version.

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. TEST REPORT FCC Rules Part 15.247 Report Reference No. ................. : FCC ID.. ...................................... : MTEB23070062-R1 2BCF4-T-MSP-US Compiled by ( position+printed name+signature): File administrators Alisa Luo Supervised by ( position+printed name+signature): Test Engineer Sunny Deng Approved by ( position+printed name+signature): Manager Yvette Zhou Date of issue................................. : July 11,2023 Representative Laboratory Name ..................................................... : Shenzhen Most Technology Service Co., Ltd. Address ........................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ..................... : Shanghai Qiaojimeng Technology Co., Ltd. Address ........................................ : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Test specification/ Standard ....... : FCC Rules Part 15.247 TRF Originator .............................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : Automatic cat litter box Trade Mark ...........................: N/A Manufacturer .................................: Shanghai Qiaojimeng Technology Co., Ltd. Model/Type reference ....................: T-MSP2-US Listed Models ...............................: T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2- TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 Modulation Type ............................: GFSK Operation Frequency .....................: From 2402MHz to 2480MHz Hardware Version ........................... V3.0 Software Version ............................ PET.0009.A.103_FW_WB60_0.4.6_0.4.6.bin Rating ............................................: (Input：100-240V~50/60Hz 0.3A Output：DC 5V⎓2000mA) Result ............................................: PASS Report No.: MTEB23070062-R1 Page 2 of 38 T E S T R E P O R T Equipment under Test : Automatic cat litter box Model /Type : T-MSP2-US Listed Models T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2- TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 Remark Only the model name is different. Applicant : Shanghai Qiaojimeng Technology Co., Ltd. Address : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Manufacturer : Zhejiang Qiaowei Technology Co., Ltd. Address : 20 Yungeng Avenue, Jinchuan neighborhood, Changshan county, Quzhou, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTEB23070062-R1 Page 3 of 38 Contents 1. REVISION HISTORY ................................................................ 4 2. TEST STANDARDS .................................................................. 5 3. SUMMARY ............................................................................. 6 3.1. General Remarks 6 3.2. Product Description 6 3.3. Equipment Under Test 6 3.4. Short description of the Equipment under Test (EUT) 6 3.5. EUT operation mode 7 3.6. Block Diagram of Test Setup 7 3.7. Test Item (Equipment Under Test) Description* 7 3.8. Auxiliary Equipment (AE) Description 7 3.9. Antenna Information* 8 3.10. EUT configuration 8 3.11. Modifications 8 4. TEST ENVIRONMENT ............................................................... 9 4.1. Address of the test laboratory 9 4.2. Environmental conditions 9 4.3. Test Description 10 4.4. Statement of the measurement uncertainty 10 4.5. Equipments Used during the Test 11 5. TEST CONDITIONS AND RESULTS ............................................ 12 5.1. AC Power Conducted Emission 12 5.2. Radiated Emission 15 5.3. Maximum Peak Output Power 22 5.4. Power Spectral Density 23 5.5. 6dB Bandwidth and 99% Bandwidth 24 5.6. Band Edge Compliance of RF Emission 25 5.7. Spurious RF Conducted Emission 27 5.8. Antenna Requirement 28 6. TEST SETUP PHOTOS OF THE EUT .......................................... 29 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 30 APPENDIX I. Conducted Peak Output Power 31 APPENDIX II. 99% Bandwidth 32 APPENDIX III. 6dB Bandwidth 33 APPENDIX IV. Conducted Out Of Band Emission 34 APPENDIX V. Duty Cycle 36 APPENDIX VI. Power Spectral Density 38 Report No.: MTEB23070062-R1 Page 4 of 38 1. Revision History Revision Issue Date Revisions Revised By 00 2023.07.11 Initial Issue Alisa Luo Report No.: MTEB23070062-R1 Page 5 of 38 2. TEST STANDARDS The tests were performed according to following standards: The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices Report No.: MTEB23070062-R1 Page 6 of 38 3. SUMMARY 3.1. General Remarks Date of receipt of test sample : 2023.07.03 Testing commenced on : 2023.07.04 Testing concluded on : 2023.07.08 3.2. Product Description Product Name: Automatic cat litter box Model/Type reference: T-MSP2-US Power Supply： (Input：AC 100-240V~50/60Hz 0.3A Output：DC 5V⎓2000mA) Testing sample ID： MTYP01986 Bluetooth : Supported Type: BLE Mod…

Text truncated - open the document above for the full version.

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : MTEB23070062-R2 2BCF4-T-MSP-US Compiled by ( position+printed name+signature) . : File administrators Alisa Luo Supervised by ( position+printed name+signature) . : Test Engineer Sunny Deng Approved by ( position+printed name+signature) . : Manager Yvette Zhou Date of issue .................................... : April 14,2023 Representative Laboratory Name . : Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : Shanghai Qiaojimeng Technology Co., Ltd. Address ............................................ : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : AUTOMATIC CAT LITTER BOX Trade Mark ....................................... : N/A Manufacturer .................................... : SHANGHAI QIAOJIMENG TECHNOLOGY CO., LTD. Model/Type reference ...................... : T-MSP2-US Listed Models .................................. : T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2-TW,T- MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T-MSP1,T-MSP2 Modulation Type ............................... : CCK/DSSS/ OFDM Operation Frequency ........................ : From 2412 - 2462MHz Hardware version ............................. : V3.0 Software version .............................. : PET.0009.A.103_FW_WB60_0.4.6_0.4.6.bin Rating ............................................... : (Input：AC 100-240V~50/60Hz 0.3A Output：DC 5V⎓2000mA) Result ............................................... : PASS Report No.: MTEB23070062-R2 Page 2 of 45 T E S T R E P O R T Equipment under Test : Automatic cat litter box Model /Type : T-MSP2-US Listed Models T-MSP1-US,T-MSP1-EUR,T-MSP2-EUR,T-MSP1-TW,T-MSP2- TW,T-MSP1-UK,T-MSP2-UK,T-MSP1-RUS,T-MSP2-RUS,T- MSP1,T-MSP2 Remark Only the model name is different. Applicant : Shanghai Qiaojimeng Technology Co., Ltd. Address : Room2886, Floor 2, Block 2, 656-658 Wuyi Road, Changning District, Shanghai, China Manufacturer : Zhejiang Qiaowei Technology Co., Ltd. Address : 20 Yungeng Avenue, Jinchuan neighborhood, Changshan county, Quzhou, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTEB23070062-R2 Page 3 of 45 Contents 1 REVISION HISTORY ................................................................ 4 2 TEST STANDARDS .................................................................. 5 3 SUMMARY ............................................................................. 6 3.1 General Remarks 6 3.2 Product Description 6 3.3 Equipment Under Test 6 3.4 Short description of the Equipment under Test (EUT) 6 3.5 EUT operation mode 6 3.6 Block Diagram of Test Setup 7 3.7 Test Item (Equipment Under Test) Description* 7 3.8 Auxiliary Equipment (AE) Description 7 3.9 Antenna Information* 7 3.10 Related Submittal(s) / Grant (s) 7 3.11 Modifications 7 4 TEST ENVIRONMENT ............................................................... 8 4.1 Address of the test laboratory 8 4.2 Test Facility 8 4.3 Environmental conditions 8 4.4 Test Description 9 4.5 Statement of the measurement uncertainty 9 4.6 Equipments Used during the Test 10 5 TEST CONDITIONS AND RESULTS ............................................ 11 5.1 AC Power Conducted Emission 11 5.2 Radiated Emission 14 5.3 Maximum Conducted Output Power 21 5.4 Power Spectral Density 22 5.5 6dB Bandwidth 23 5.6 Out-of-band Emissions 24 5.7 Duty Cycle Information 25 5.8 Antenna Requirement 26 6 TEST SETUP PHOTOS OF THE EUT .......................................... 27 7 . EXTERNAL AND INTERNAL PHOTOS OF THE EUT ........................... 28 APPENDIX I. Conducted Peak Output Power 29 APPENDIX II. 99% Bandwidth 30 APPENDIX III. 6dB Bandwidth 32 APPENDIX IV. Conducted Out Of Band Emission 34 APPENDIX V. Duty Cycle 39 APPENDIX VI. Power Spectral Density 44 Report No.: MTEB23070062-R2 Page 4 of 45 1 Revision History Revision Issue Date Revisions Revised By 00 2023.07.11 Initial Issue Alisa Luo Report No.: MTEB23070062-R2 Page 5 of 45 2 TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247 : Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013 : American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: MTEB23070062-R2 Page 6 of 45 3 SUMMARY 3.1 General Remarks Date of receipt of test sample : 2023.07.03 Testing commenced on : 2023.07.04 Testing concl…

Text truncated - open the document above for the full version.

XJ-WB60 Module passive test data XJ-WB60 Frequency Efficiency . dB Efficiency Gain . dBi 2400-4.0439.41 0.61 2410-3.9640.16 2.01 2420-3.8741.02 2.01 2430-3.8541.23 2.05 2440-3.8641.07 1.57 2450-3.940.77 1.10 2460-3.9939.95 1.14 2470-4.1338.64 1.04 2480-4.2837.3 -0.27 2490-4.4336.04 -0.543 2500-4.6234.5 -0.73 ANT

Model No.: U-MSP2-EUR RE TEST SETUP RE TEST SETUP Model No.: U-MSP2-EUR CE TEST SETUP
