2BCFE-T1Multi-function Wireless Charger

- Shenzhen Sister Digital Technology Co.,Ltd - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/30/2024 U.S. Agent Designation Shenzhen Sister Digital Technology Co.,Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BCFE-T1): Name and company of U.S. agent: UUX GROUP INC Physical U.S. address of agent: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 FRN of U.S. agent: 0033701590 Email address of U.S. agent: [email protected] UUX GROUP INC acknowledges their obligation to accept service of process on behalf of Shenzhen Sister Digital Technology Co.,Ltd. Shenzhen Sister Digital Technology Co.,Ltd with the FRN 0034103044 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature LeXing Xie General Manager Shenzhen Sister Digital Technology Co.,Ltd Signature Jack Fu Manager UUX GROUP INC 48_[model] US_Agent_2.911(d)(7) - U, V05

Page 1 of 4 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 4 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 4 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 4 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 ---The End---

Label Size: L65mm * W40mm 1. The label is silk-screen on the sample Multi-function Wireless Charger Model Name: T1 FCC ID: 2BCFE-T1 L W

Page 1 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 Page 2 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Coil Antenna Page 3 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 Photo 8 Page 5 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 9 Photo 10 Page 6 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 11 Photo 12 Page 7 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 13 Photo 14 Page 8 of 8 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 15 ------End------

Page 1 of 12 Report No.: AiTSZ-240815024W2 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : Multi-function Wireless Charger Brand Name : N/A Model : T1 Series Model : N/A FCC ID : 2BCFE-T1 Applicant : Shenzhen Sister Digital Technology Co., Ltd Address : Room 507, 5th Floor, Building 1, Baokun Science and Technology Park,Dalang Xinling Road, Longhua District, Shenzhen Manufacturer : Shenzhen Sister Digital Technology Co., Ltd Address : Room 507, 5th Floor, Building 1, Baokun Science and Technology Park,Dalang Xinling Road, Longhua District, Shenzhen Standard(s) : FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 Date of Receipt : Aug.15, 2024 Date of Test : Aug.15, 2024 ~ Aug.22, 2024 Issued Date : Aug.22, 2024 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Leon.yi Sean She Page 2 of 12 Report No.: AiTSZ-240815024W2 Report Revise Record Report Version Issued Date Notes M1 Aug.22, 2024 Initial Release Page 3 of 12 Report No.: AiTSZ-240815024W2 Contents 1 GENGENERAL INFORMATION ................................................................................................................................ 4 1.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 4 1.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2.1 DESCRIPTION OF THE TEST MODE ..................................................................................................................................... 6 2.2 SPECIAL ACCESSORIES ................................................................................................................................................... 6 2.3 EQUIPMENT LIST FOR THE TEST ....................................................................................................................................... 6 3 TEST CONDITIONS AND RESULTS ........................................................................................................................... 7 3.1 APPLICABLE STANDARD .................................................................................................................................................. 7 3.2 LIMIT ......................................................................................................................................................................... 7 3.3 TEST SETUP ................................................................................................................................................................. 7 3.4 MEASUREMENT PROCEDURE .......................................................................................................................................... 8 3.5 TEST RESULT OF E AND H FIELD STRENGTH ........................................................................................................................ 8 3.6 EQUIPMENT APPROVAL CONSIDERATIONS ......................................................................................................................... 9 3.7 CONCLUSION ............................................................................................................................................................... 9 4 TEST SETUP PHOTOGRAPHS OF EUT .................................................................................................................... 10 Page 4 of 12 Report No.: AiTSZ-240815024W2 1 GENGENERAL INFORMATION 1.1 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 25°C Relative Humidity: 55 % Air Pressure: 101 kPa 1.2 General Description of EUT Product Name: Multi-function Wireless Charger Model/Type reference: T1 Serial Model: N/A Power Supply: Input: 9V⎓3A Output: 5W/7.5W/10W/15W(Phone) Output: 5W(USB) Output: 5W(Type-C) Output: 2W(Lamp) Hardware version: N/A Software version: N/A Sample(s) Status: AiTSZ-240815024-01(Normal sample) AiTSZ-240815024-02(Engineer sample) Wireless Charger: Operation frequency: 113kHz-205kHz Modulation Technology: ASK Antenna Type: Loop coil Antenna Antenna gain: 0dBi Remark: The above DUT's information was declared by manufacturer. For more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 5 of 12 Report No.: AiTSZ-240815024W2 1.3 Test Facility Test Laboratory: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Com…

Text truncated - open the document above for the full version.

Page 1 of 20 Report No.: AiTSZ-240731002W1 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : Multi-function Wireless Charger Brand Name : N/A Model : T1 Series Model : N/A FCC ID : 2BCFE-T1 Applicant : Shenzhen Sister Digital Technology Co.,Ltd Address : Room 507, 5th Floor, Building 1, Baokun Science and Technology Park,Dalang Xinling Road, Longhua District, Shenzhen Manufacturer : Shenzhen Sister Digital Technology Co.,Ltd Address : Room 507, 5th Floor, Building 1, Baokun Science and Technology Park,Dalang Xinling Road, Longhua District, Shenzhen Standard(s) : FCC CFR Title 47 Part 15 Subpart C Date of Receipt : Aug.15, 2024 Date of Test : Aug.15, 2024 ~ Aug.22, 2024 Issued Date : Aug.22, 2024 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Leon.yi Sean She Page 2 of 20 Report No.: AiTSZ-240731002W1 Report Revise Record Report Version Issued Date Notes M1 Aug.22, 2024 Initial Release Page 3 of 20 Report No.: AiTSZ-240731002W1 Contents 1 TEST SUMMARY .................................................................................................................................................... 4 1.1 TEST STANDARDS.......................................................................................................................................................... 4 1.2 TEST SUMMARY ........................................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2 GENGENERAL INFORMATION ................................................................................................................................ 6 2.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 6 2.3 DESCRIPTION OF THE TEST MODE ..................................................................................................................................... 7 2.4 SPECIAL ACCESSORIES ................................................................................................................................................... 7 2.5 EQUIPMENT LIST FOR THE TEST ....................................................................................................................................... 7 3 TEST CONDITIONS AND RESULTS ........................................................................................................................... 9 3.1 CONDUCTED EMISSIONS TEST ......................................................................................................................................... 9 3.2 RADIATED EMISSIONS .................................................................................................................................................. 12 3.3 20DB BANDWIDTH ..................................................................................................................................................... 18 3.4 ANTENNA REQUIREMENT ............................................................................................................................................. 19 4 TEST SETUP PHOTOGRAPHS OF EUT .................................................................................................................... 20 5 EXTERNAL PHOTOGRAPHS OF EUT ...................................................................................................................... 20 6 INTERNAL PHOTOGRAPHS OF EUT ...................................................................................................................... 20 Page 4 of 20 Report No.: AiTSZ-240731002W1 1 TEST SUMMARY 1.1 Test Standards The tests were performed according to following standards: FCC Rules Part 15.207,15.209, 15.215(c) ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices 1.2 Test Summary Test Item Section in CFR 47 Test Result Electric Field Radiated Emissions FCC Part 15 C (Section15.209) PASS 20dB Bandwidth/99% Bandwidth FCC Part 15 C (Section15.215(c)) PASS AC Power Line Conducted Emission FCC Part 15 C (Section15.207) PASS Antenna Requirement FCC Part 15 C (Section15.203 PASS Page 5 of 20 Report No.: AiTSZ-240731002W1 1.3 Test Facility Test Laboratory: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China The test facility i…

Text truncated - open the document above for the full version.

Specification Number 20240822003 Date Aug22,2024 Customer Product8346SingleChargingCoil PartNumber 20240822003-9T-L=50MM CustomerP/N 【□ √√ NewEdition□Revision】【Total3Pages】【RoHSCompliantParts】 EditCheckApprove Pleasesigntheacknowledgementandsendbackin30days. 【CustomerApproval】Date: Status：□Complete□Conditions□Refuse Approve AuditCheckDoubleCheck Instructions: Specification Customer CustomerP/N PartNumber 20240822003-9T-L=50MM Spec.No. 20240822003 PublishandRevisionRecord EditionEffectiveDate ReasonforRevision Audit 003 Aug22,2024 NewSpecificationRelease EditAuditApprove Specification Customer PartNumber 20240822003-9T-L=50MM Spec.No. 20240822003 Edition 003 ♦、Dimension (Unit:mm) A 83.0±1 B46.0±1 C50.0±1 D6.0±1 E39.0±0.5 F15.5±0.5 G19.0±0.5 H3.0±1 Remarks (1) CableDia.:0.08*105PSilkWire (2) Q’tyofCircle:9TS (3) CableCross:W1Yes;W2No (4) Double-sidedTapeontheBottom ♦、ElectricalCharacteristic: ParameterSpecificationConditionTestInstrument LO 6.8±10%μH 100KHz/1V ■TH1816B ■CH-502BC ■CH-502BC Q>49min 100KHz/2V DCR<45mΩ @25°C ♦、Temperature: OperatingTemp -40°C~125°C BOM NoNameSpecificationSupplierRemarks 1 Magnet8346*0.8PC40MnZnCrMagnet 2 CopperWire0.08*105PStandardCarbanideCopperSilkWire 3 Tape 8MM EnvironmentProtectionTape 4 Tin 107H EnvironmentProtectionTin 5 GlueDouble-sidedEnvironmentProtectionTape EditAuditApprove

Page 1 of 2 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Test Setup Photo DCD Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2BCFE-T1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Radiation (30MHz-1000MHz) ------End------
