2BCN6-HEADSETBluetooth headset

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the users authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 3 Appearance of EUT -Left Photo 4 Appearance of EUT-Left FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 5 Appearance of EUT -Left Photo 6 Appearance of EUT -Left FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 7 Appearance of EUT - Right Photo 8 Appearance of EUT - Right FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 9 Appearance of EUT -Right Photo 10 Appearance of EUT - Right

FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Appendix IID Label Appendix II ID Label Location FCC ID: 2BCN6-HEADSET

FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 11 Internal of EUT Photo 12 Internal of EUT FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 13 Battery parameters Photo 14 Appearance of PCB - Left FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 15 Appearance of PCB - Left Photo 16 Appearance of PCB - Right Antenna FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 17 Appearance of PCB - Right Photo 18 Appearance of PCB – Left & Right FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo 19 Appearance of PCB – Left & Right

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202503-1210-1 Page: 1 of 8 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Maximum Permissible Exposure Evaluation FCC ID: 2BCN6-HEADSET Report No. : TBR-C-202503-1210-1 Applicant : Shen Zhen Leyifeng Technology Co., Ltd Equipment Under Test (EUT) EUT Name : Bluetooth headset Model No. : Headset Series Model No. : ---- Brand Name : ---- Sample ID : HC-C-202503-1210-02-1#&HC-C-202503-1210-02-2# Receipt Date : 2025-04-01 Test Date : 2025-04-01 to 2025-04-16 Issue Date : 2025-04-16 Standards : FCC Part 2.1093 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily Zhang Reviewed By : Emily Tang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202503-1210-1 Page: 2 of 8 TB-RF-074-1.0 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. SAR TEST EXCLUSION CALCULATIONS .......................................................................... 7 Report No.: TBR-C-202503-1210-1 Page: 3 of 8 TB-RF-074-1.0 Revision History Report No. Version Description Issued Date TBR-C-202503-1210-1 Rev.01 Initial issue of report 2025-04-16 Report No.: TBR-C-202503-1210-1 Page: 4 of 8 TB-RF-074-1.0 1. General Information about EUT 1. 1 Client Information Applicant : Shen Zhen Leyifeng Technology Co., Ltd Address : 3/F.Buiding B, Xinzhongtai Science and Technology park, Gushuyi, Xixiang,Bao’an District, Shenzhen, China Manufacturer : Shen Zhen Leyifeng Technology Co., Ltd Address : 3/F.Buiding B, Xinzhongtai Science and Technology park, Gushuyi, Xixiang,Bao’an District, Shenzhen, China 1.2 General Description of EUT (Equipment Under Test) EUT Name : Bluetooth headset Models No. : Headset Model Different : ---- Product Description : Operation Frequency: Bluetooth V5.4: 2402MHz~2480MHz Modulation Type: Bluetooth&BLE: GFSK, Pi/4-DQPSK Antenna Gain: 2.5dBi Ceramic Antenna Power Rating : Input: DC 5V Power Rating : 3.7V by 28mAh Rechargeable Li-ion battery Software Version : V240 Hardware Version : DHF-LYFD8-V1.4.1(69X3D) Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: TBR-C-202503-1210-1 Page: 5 of 8 TB-RF-074-1.0 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (U Lab ) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB RF Power-Conducted Level Accuracy: Above 1000MHz ±0.95 dB Power Spectral Density- Conducted Level Accuracy: Above 1000MHz ±3dB Occupied Bandwidth Level Accuracy: 30MHz to 1000 MHz Above 1000MHz ±3.8% Unwanted Emission- Conducted Level Accuracy: 30MHz to 1000 MHz Above 1000MHz ±2.72 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202503-1210-1 Page: 6 of 8 TB-RF-074-1.0 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredited Test Site Number: 854351. Designation Number: CN1223. IC Registration No.: (11950A) The Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. The site registration: Site# 11950A. CAB identifier: CN0056. Report No.: TBR-C-202503-1210-1 Page: 7 of 8 TB-RF-074-1.0 4. SAR Test Exclusion Calculations 4.1 FCC: According to KDB 447498 D01 v06 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g S…

Text truncated - open the document above for the full version.

Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 1 OF 12 2.0X1.2X0.2 (mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification 1. Product Number 6 5 4 3 2 1 02 2G45 P 4F 2012 YF 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City Prepared by:JIEXIDesigned by :JasonChecked by :JasonApproved by：MR.FANG TITLE：2.0x 1.2x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C)Engineering Specification YF2012F4P2G4502 DOCUMENT REV. NO. B PAGE2OF 12 2.Features *Stable and reliable in performances *Low temperature coefficientof frequency *Low profile, compact size *RoHS compliance *SMT processes compatible 3.Applications *Bluetooth earphone systems *Hand-held devices when WiFi /Bluetooth functions are needed, e.g., Smart phone. *IEEE802.11 b/g/n *ZigBee *Wireless PCMCIA cards or USB dongle 4.Description Yingfeng chipantenna series are specially designedfor WiFi/Bluetooth applications.Based on yingfengproprietary design and processes, this chipantenna has excellent stability and sensitivityto consistently provide high signal reception efficiency. 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd TECHNOLOGYCO.,LTD Block, Taoyuan Sub-district, Nanshan District, Shenzhen City Prepared by:JIEXIDesigned by :JasonChecked by :JasonApproved by：MR.FANG TITLE：2.0x 1.2x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C)Engineering Specification YF2012F4P2G4502 DOCUMENT REV. NO. B PAGE3OF 12 5.Electrical Specifications (80 x 40 mm 2 ground plane) 5-1.ElectricalTable Characteristics Specifications Unit Outline Dimensions 2.0x1.2x0.2 mm Working Frequency 2400~2500 MHz VSWR 2 Max. Impedance 50  Polarization Linear Polarization Gain Peak 2.5 (typical) dBi Efficiency 75(typical) % 5-2. Return Loss & VSWR Return Loss (S 11 ) VSWR(S 11 ) 6.Antenna Dimensions& Test Board (unit: mm) 深圳市迎丰天线技术有限公 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 4 OF 12 a. Antenna Dimensions b. Test Board with Antenna 40 80 Unit: mm 7. Radiation Pattern (80 x 40 mm 2 ground plane) No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 5 OF 12 7-1. 3D Gain Pattern @ 2442 MHz Z Y X Z X Y Y X X Y Z No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 6 OF 12 7-2. 3D Efficiency Table Frequency( MHz) 2400 2410 2420 2430 2442 2450 2460 2470 2480 2490 2500 Efficiency (dB) -1.4 -1.0 -0.9 -0.7 -0.7 -0.8 -0.9 -1.1 -1.2 -1.3 -1.4 Efficiency (%) 72.8 73.7 74.3 74.4 75.5 75.0 74.0 73.6 73.1 72.6 71.5 Gain (dBi) 2.1 2.2 2.3 2.4 2.5 2.5 2.4 1.8 1.7 1.6 1.4 7-3. 3D Efficiency vs. Frequency 8. Layout Guide a. Solder Land Pattern: Land pattern for soldering (gray marking areas) is as shown below. Depending on Customer’s requirement, matching circuit as shown below is also recommended. Efficiency vs. Frequency 50 60 70 80 90 100 24002410242024302442245024602470248024902500 Frequency(MHz) Efficiency(%) 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 7 OF 12 Top View Bottom View Unit： mm No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4502 REV. NO. B PAGE 8 OF 12 9. Frequency tuning a. Chip antenna tuning scenario： b. Matching circuit：(Center frequency is about 2442 MHz @ 80 x 40 mm 2 ground plane) System Matching Circuit Component Location Description Vendor Toleranc e 1 1.2 pF* Murata (0402) ±0.1 pF 2 10PF* Murata(0402) ±0.5 PF 3 N/A* - - Fine tuning element 4 1.5 pF* Murata (0402) ±0.1 pF *Typical reference values which may need to be changed when circuit boards or part vendors are different. Matching circuit Feed 4. Fine tuning elemet 1 2 3 No. 412, Building 7, Phase 2, Nanhai Cloud Valley Innovation Park, Pingshan Road 2nd Block, Taoyuan Sub-district, Nanshan District, Shenzhen City 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOGYCO.,LTD Prepared by : JIEXI Designed by : Jason Checked by : Jason Approved by：MR.FANG TITLE：2.0 x 1.2 x 0.6(mm) WiFi/Bluetooth Ceramic Chip Antenna (YF2012C) Engineering Specification DOCUMENT YF2012F4P2G4…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 1 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 RF Test Data for Bluetooth (Conducted Measurements) General Description of EUT Product Name: Bluetooth headset Test Model: Headset Sample ID: HC-C-202503-1210-02-2# Environmental Conditions Temperature: 24.2°C Relative Humidity: 51% Test Voltage: DC 3.7V Test Engineer: Lily Zhang Note: For a more detailed features description, please refer to the report TBR-C-202503-1210-31 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 2 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Contents 1. Duty Cycle ........................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ................................................................................................................................................. 7 3. -20dB Bandwidth .............................................................................................................................................................................. 13 4. Occupied Channel Bandwidth ......................................................................................................................................................... 17 5. Band Edge ........................................................................................................................................................................................ 21 6. Band Edge(Hopping) ........................................................................................................................................................................ 26 7. Conducted RF Spurious Emission .................................................................................................................................................. 31 8. Restrict Band .................................................................................................................................................................................... 38 9. Carrier Frequencies Separation....................................................................................................................................................... 43 10. Number of Hopping Channel ......................................................................................................................................................... 45 11. Dwell Time ....................................................................................................................................................................................... 47 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 3 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT 1-DH1 2402 Ant1 31.2 5.06 2.56 NVNT 1-DH1 2441 Ant1 31.2 5.06 2.56 NVNT 1-DH1 2480 Ant1 31.2 5.06 2.56 NVNT 2-DH1 2402 Ant1 32 4.95 2.5 NVNT 2-DH1 2441 Ant1 32 4.95 2.5 NVNT 2-DH1 2480 Ant1 32 4.95 2.5 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 4 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Test Graphs Duty Cycle NVNT 1-DH1 2402MHz Ant1 Duty Cycle NVNT 1-DH1 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 5 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Duty Cycle NVNT 1-DH1 2480MHz Ant1 Duty Cycle NVNT 2-DH1 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 6 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Duty Cycle NVNT 2-DH1 2441MHz Ant1 Duty Cycle NVNT 2-DH1 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 7 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT 1-DH1 2402 Ant1 3.779 21 Pass NVNT 1-DH1 2441 Ant1 0.828 21 Pass NVNT 1-DH1 2480 Ant1 2.53 24 Pass NVNT 1-DH3 2441 Ant1 0.596 21 Pass NVNT 1-DH5 2441 Ant1 0.574 21 Pass NVNT 2-DH1 2402 Ant1 5.007 21 Pass NVNT 2-DH1 2441 Ant1 1.357 21 Pass NVNT 2-DH1 2480 Ant1 3.504 21 Pass NVNT 2-DH3 2441 Ant1 1.474 21 Pass NVNT 2-DH5 2441 Ant1 1.482 21 Pass Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 8 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Test Graphs Power NVNT 1-DH1 2402MHz Ant1 Power NVNT 1-DH1 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202503-1210-31 Page: 9 of 50 FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Power NVNT 1-DH1 2480MHz Ant1 Power NVNT 1-DH3 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Ht…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202503-1210-31 Page: 1 of 34 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Test Report FCC ID: 2BCN6-HEADSET Report No. : TBR-C-202503-1210-31 Applicant : Shen Zhen Leyifeng Technology Co., Ltd Equipment Under Test (EUT) EUT Name : Bluetooth headset Model No. : Headset Series Model No. : ---- Brand Name : ---- Sample ID : HC-C-202503-1210-02-1#&HC-C-202503-1210-02-2# Receipt Date : 2025-04-01 Test Date : 2025-04-01 to 2025-04-16 Issue Date : 2025-04-16 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily Zhang Reviewed By : Emily Tang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202503-1210-31 Page: 2 of 34 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT AND TEST SITE ................................................................................... 11 5. CONDUCTED EMISSION ....................................................................................................... 13 5.1 Test Standard and Limit .................................................................................................... 13 5.2 Test Setup ........................................................................................................................... 13 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 19 7.5 EUT Operating Mode ........................................................................................................ 19 7.6 Test Data ............................................................................................................................. 19 8. 99% OCCUPIED AND 20DB BANDWIDTH ........................................................................ 20 8.1 Test Standard and Limit .................................................................................................... 20 8.2 Test Setup ...................................…

Text truncated - open the document above for the full version.

FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Appendix V EUT Test Photographs Photo of Setup for Radiated Emission (Below 1 GHz) Photo of Setup for Radiated Emission (Above 1 GHz) FCC ID: 2BCN6-HEADSET TB-RF-074-1.0 Photo of Setup for Conducted Emission Photo of Setup for Conducted Emission -----END OF THE REPORT-----
