2BCPB-HR1288Remote control

Dongguan Xiyue Home Furnishing Co., Ltd Covered Equipment Certification Attestation Letter 9/22/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BCPB-HR1288 Dongguan Xiyue Home Furnishing Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. Dongguan Saipin Electronic Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. <Signature> Name: Jianji Li Title: CEO Applicant Company: Dongguan Xiyue Home Furnishing Co., Ltd Date: 9/22/2023

DongguanXiyue Home FurnishingCo., Ltd * the applicantmust designatea contactlocatedin the UnitedStatesfor purposesof actingas the applicant’s agent for serviceof process,regardlessof whetherthe applicantis a domesticor foreign entity.An applicantlocatedin the UnitedStatesmay designateitself as the agent for serviceof process. U.S. Agent Designationfor Serviceof Process- CertificationAttestationLetter 9/7/2023 FederalCommunicationsCommission Authorizationand EvaluationDivision 7435 OaklandMills Road Columbia,MD 21046 USA ATTN.:ReviewingEngineer FCC ID:2BCPB-HR1288 Per section2.911(d)(7)of the FCC rules,DongguanXiyue Home FurnishingCo., Ltd(“the applicant”) certifiesthat the equipmentfor which authorizationis soughtis designatedto the followingU.S.agent*forserviceof process: CompanyName:VISHTECLLC PhysicalU.S. CompanyAddress:Room 1059, 9888 W BelleviewAve Ste 2142 Denver,CO 80123 ContactPerson:Alan Graham Agent Email Address:[email protected] FCC RegistationNumber(FRN):0033407131 The abovecontactpersonacceptsthe obligationfor serviceof process. The applicantacceptsto maintainan agent for no less than one year after the granteehas terminatedall marketingand importationor the conclusionof any Commission-related proceedinginvolvingthe equipment. ApplicantSigned:AgentSigned(if differentto Applicant): Signed: Signed: Printedname:Jianji LiPrintedname:VISHTECLLC Title: CEOTitle:Import ComplianceManager CompanyNameCompanyName:VISHTECLLC DongguanXiyue HomeFurnishingCo., Ltd Date: 9/7/2023Date: 9/7/2023 FRN: 0034184101

DATE:2023-03-10 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent Onourbehalf,IappointDongguan New Testing Centre Co., Ltd；3F, No. 1 the 1st North Industry Road, Songshan Lake Science &Technology Park, Dongguan, Guangdong, China, 523808. toactasouragentinthepreparationofthisapplicationforequipmentcertification.Icertifythatsubmitte ddocumentsproperlydescribethedeviceorsystemforwhichequipmentcertificationissought.Ialsoc ertifythateachunitmanufactured,importedormarketed,asdefinedintheFederalCommunicationsC ommission’sregulationswillhaveaffixedtoit a label identical to that submitted for approval with thisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,Iack nowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification,stillres ideswith Dongguan Xiyue Home Furnishing Co., Ltd; Miaobian Community, No. 29 Yanhe West Road, Liaobu Town, Dongguan, Guangdong, China <Signature> Name: Jianji Li Title: CEO Applicant Company: Dongguan Xiyue Home Furnishing Co., Ltd

DATE 2023-09-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BCPB-HR1288 Product Name: Remote control Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Jianji Li Title: CEO Applicant Company: Dongguan Xiyue Home Furnishing Co., Ltd

FCC: 2BCPB-HR1288 Page 1 of 2 Report No.: NTC-ER2308056 External Photos of EUT FCC: 2BCPB-HR1288 Page 2 of 2 Report No.: NTC-ER2308056

FCC: 2BCPB‐HR1288 Page 1 of 1 Report No.: NTC‐ER2308056 FCC‐ID Label Information 1. Label location: Remote control Model: HR1288 FCC ID: 2BCPB‐HR1288

FCC: 2BCPB‐HR1288 Page 1 of 2 Report No.: NTC‐ER2308056 Internal Photos of EUT Antenna FCC: 2BCPB‐HR1288 Page 2 of 2 Report No.: NTC‐ER2308056

RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 Ant gain = 0dBi Field strength =77.61 dBμV/m @3m @433.92MHz EIRP=77.61-95.2=-17.59dBm So Pt= -17.59-0=-17.59dBm So ERP=-17.59-2.15=-19.59dBm Worse case 10^-1.759= 0.0174mW<22mW Then SAR evaluation is not required

1.Antenna photo Applicant : Dongguan Xiyue Home Furnishing Co., Ltd Address : Miaobian Community, No. 29 Yanhe West Road, Liaobu Town, Dongguan, Guangdong, China Model/Type reference : HR1288 70mm 28mm 35mm width：1.6mm Operation frequency: 433.92MHz Channel number: 1 Antenna type: PCB antenna Antenna gain: 0dBi

Dongguan New Testing Centre Co., Ltd E-mail： [email protected] 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 FCC TEST REPORT Report No. ...................................... : NTC-ER2308056 Applicant’s name ........................... : Dongguan Xiyue Home Furnishing Co., Ltd Address .......................................... : Miaobian Community, No. 29 Yanhe West Road, Liaobu Town, Dongguan, Guangdong, China DONGGUAN NEW TESTING CENTRE CO., LTD ◎Address: 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Tel: +86-769-22212079 Web: http://www.ntc-cert.com E-mail: [email protected] Dongguan New Testing Centre Co., Ltd E-mail： [email protected] 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 1 of 23 Report No.: NTC-ER2308056 TEST REPORT DECLARE Test Standard Used: FCC Rules and Regulations Part 15 Subpart C 15.231, ANSI C63.10:2020. We Declare: The equipment described above is tested by Dongguan New Testing Centre Co., Ltd and in the configuration tested the equipment complied with the standards specified above. The test results are contained in this test report and Dongguan New Testing Centre Co., Ltd is assumed of full responsibility for the accuracy and completeness of these tests. After test and evaluation, our opinion is that the equipment provided for test compliance with the requirement of the above FCC standards. Report No.: NTC-ER2308056 Date of Test: Aug. 24, 2023 to Sep. 04, 2023Date of Report: Sep. 05, 2023 Prepared By: Approved By: ________________ _____________________ Jack Liu/Engineer Dave Gao/LAB Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan New Testing Centre Co., Ltd FCC ID : 2BCPB-HR1288 Applicant : Dongguan Xiyue Home Furnishing Co., Ltd Address : Miaobian Community, No. 29 Yanhe West Road, Liaobu Town, Dongguan, Guangdong, China Equipment under Test : Remote control Model/Type reference : HR1288 List Model(s) N/A Trade Mark : Joyly Home Manufacturer : Dongguan Xiyue Home Furnishing Co., Ltd Address : Miaobian Community, No. 29 Yanhe West Road, Liaobu Town, Dongguan, Guangdong, China Test Laboratory Dongguan New Testing Centre Co., Ltd Address : 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 2 of 23 Report No.: NTC-ER2308056 ** Modified History ** Version Description Issued DataReport No. Remark Version 1.0 Initial Test Report Release2023-09-05 NTC-ER2308056 Dave Gao Page 3 of 23 Report No.: NTC-ER2308056 Table of Contents Page 1. SUMMARY............................................................................................................................................................ 4 1.1. TEST STANDARDS.......................................................................................................................................................... 4 1.2. TEST DESCRIPTION ........................................................................................................................................................ 4 1.3. TEST FACILITY .............................................................................................................................................................. 5 2. GENERAL INFORMATION ....................................................................................................................................... 6 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 6 2.3. RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................................................ 6 2.4. MODIFICATIONS ........................................................................................................................................................... 6 3. TEST CONDITIONS AND RESULTS ........................................................................................................................... 8 3.1. CONDUCTED EMISSION (AC MAIN) ................................................................................................................................. 8 3.2. RADIATED EMISSION ..................................................................................................................................................... 9 3.3. 20DB BANDWIDTH ..................................................................................................................................................... 15 3.4. DEACTIVATION TIME ................................................................................................................................................... 16 3.5. ANTENNA REQUIREMENT ............................................................................................................................................. 17 4. TEST SETUP PHOTOS OF THE EUT ........................................................................................................................ 18 5. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................................................................................. 19 Page 4 of 23 Report No.: NTC-ER2308056 1. SUMMARY 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.231: Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. ANSI C63.10:2020 : American National Standard for Testing Unlicensed Wireless Devices 1.2. Test Descrip…

Text truncated - open the document above for the full version.

FCC: 2BCPB‐HR1288 Page 1 of 1 Report No.: NTC‐ER2308056 Test Setup Photos of the EUT
