2BCQA-G65Phone

1 Get Started Insert SIM card You must insert the SIM card before using the phone. 1. Switch off the mobile phone. 2. Insert the SIM card correctly in the card slot. Charge Mobile Phone Your phone is powered by a rechargeable battery. If your phone comes up a message which notifies you that the battery power is too low, at that moment, please recharge the battery, if the charge is too low, it may shorten the life of the battery. 2 PC-Phone File Transfer Once the mobile phone is connected to a PC with USB, the PC will charge the mobile phone automatically. In such case, USB computer connection will appear on your screen. 1. Drag the notification panel down and tap 3 Charging this device via USB. 2. Select Use USB for File Transfer. 3. The device is recognized as a Removable Disk by the computer. Open the folder and transfer or copy files from your phone to PC and vice-versa. 4 Keys and Parts The phone has an exceptional user experience on Camera,Video recorder, FM radio, Music and Sound recorder. Install various APPs, games and more (supports APK format) by downloading on Google Play. 1.SIM card slot To insert the sim card. 2.Receiver To hear the voice of the other side when calling. 5 3. Front Camera Allow you to take pictures while facing the screen. 4.Screen To output information of the deivices, 5..USB jack To connect charger or USB data cable for data exchange. 6.Mic To record your voice. 7. Headset port To connect an earphone so you can listen to music or radio, etc 8.Volume Up/Down Key To adjust the ringer volume, adjust the voice volume during a call and adjust media volume. 9. Power Key Switch the phone on or off. Press and hold to open phone options menu. 10. Loud speaker To listen to music, and other sounds offered by your phone. 11. Flashlight To take photos in low-light conditions. 12. Back Camera For taking photos. 6 Lock and Unlock the Screen Press power button to enter Sleep mode and meanwhile the screen will be locked; press power button again to wake up and then drag the lock upward to unlock. 7 Notification Panel Notification icons on the status bar report the new arrival of messages, calendar events, alarm set and ongoing settings such as when call forwarding is on or the current call status. You can open the Notifications panel to open the message, reminder or event notification and see the mobile operator’s name. Even you can switch on Data connection, WLAN, Bluetooth, etc. -> Opening the Notifications panel Press and hold the status bar, slide your finger downward to open the Notifications panel. If you have several notifications, you can scroll down the status bar to view more notifications. -> Closing the Notifications panel Do one operation of the following: 1. Press and hold the bottom bar of the Notifications panel, then slide your finger up the screen. 2. Press BACK or Home directly. 8 9 Arranging and Rearranging Widgets and Icons Rearrange the widgets and icons on your Home screen to give room for adding more items to the Home screen. -> Press and hold the widget or icon you are desired to move. -> Drag the widget or icon to a new location on the screen. Pause at the left or right edge of the screen to drag the widget or icon onto another Home screen panel. -> When the widget or icon is where you are desired to put it, release your finger. If you've released your finger but a message shows that there's no space to place the widget or icon, drag it right or left again to another Home screen panel. 10 11 Adding Folders on your Screen Use folders to group related applications and other shortcuts to keep your Home screen tidy and organized. -> Adding folder on your screen Press and hold an application icon or a widget that you want to move. Don't release your finger. Drag the application icon or widget and drop it on top of another application icon or widget. Then, simply tap the folder to open it so you can access the applications and widgets inside the folder. -> Deleting folder Drag out all the applications from the folder, then the folder will be deleted automatically. 12 Adjusting Brightness Drag the notification panel down and adjust brightness. Or enter Settings ->Display ->Brightness level, and adjust the brightness level here (by dragging the brightness slider to the left to decrease or to the right to increase the screen Brightness). Note: Lower the brightness of the screen to prolong the battery life. 13 Changing your Wallpaper Personalizing your Home screen wallpaper with your favorite photo is a quick and easy way to change the feel of your phone and give it a fresh look. Browse the collection of wallpapers included in your phone by default or choose from photos that you have taken with the camera. -> Press and hold the screen where there is space. -> The screen will show an optional context. -> Select the wallpaper you want and confirm to set it as wallpaper. Or you can enter Settings->Wallpaper & style, then will show an optional context. 14 Make a Call On the start screen chooseand enter a complete phone number to make a call. 15 Call Log Enter Phone interface,then tap Recents access Call log. In call log options, you can make calls, Create new contact and send message etc. 16 Reject a Call by Sending a Busy Message While there is an incoming call, you are inconvenient to accept the call, and then you can send a busy message for rejecting the call. Tap the message icon, some busy messages will show on the screen, short tap any of them to send out. Add a Contact Tap and enter Contacts and then add a contact (see figure below.) Tap to add a new contact to Phone . 17 18 Messaging Enter Messaging, and then compose new message. You touch a text field where you want to enter text, to open the keyboard. 19 Receiving a New Message When there is a new message comes, a new message icon will appears in the notifications area of the status bar to notify you of a new text or multimedia message. To open the message, press and hold the status bar, and then slide…

Text truncated - open the document above for the full version.

FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65

FCC ID: 2BCQA-G65 Phone M/N: G65 FCC ID:2BCQA-G65

FCC ID: 2BCQA-G65 GMS/PCS/WCDMA /LTE ANT BT/WIFI/5G WIFI ANT LTE RXD ANT FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65 FCC ID: 2BCQA-G65

Page 1 of 9 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 750 MHz Head System Performance Check 835 MHz Head System Performance Check 1750 MHz Head System Performance Check 1900 MHz Head System Performance Check 2450 MHz Head System Performance Check 2600 MHz Head System Performance Check 5250 MHz Head System Performance Check 5750 MHz Head Page 2 of 9 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/1/2 Test Laboratory: LCS-SAR Lab System Check_750Mhz DUT: D750V3; Type: D750V3; Serial: 1191 Communication System: UID 0, CW (0); Frequency: 750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 750 MHz; σ = 0.902 S/m; ε r = 41.818; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.66, 9.66, 9.66); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 2.70 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.66 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 3.29 W/kg SAR(1 g) = 2.15 W/kg; SAR(10 g) = 1.41 W/kg Maximum value of SAR (measured) = 2.75 W/kg 0 dB = 2.75 W/kg = 4.39 dBW/kg Page 3 of 9 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/1/4 Test Laboratory: LCS-SAR Lab System Check_835Mhz DUT: D835V2; Type: D835V2; Serial: 4d124 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.911 S/m; ε r = 41.591; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (5x18x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 3.22 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.00 V/m; Power Drift = -0.09 dB Peak SAR (extrapolated) = 3.79 W/kg SAR(1 g) = 2.48 W/kg; SAR(10 g) = 1.62 W/kg Maximum value of SAR (measured) = 3.18 W/kg 0 dB = 3.18 W/kg = 5.02 dBW/kg Page 4 of 9 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2023/12/29 Test Laboratory: LCS-SAR Lab System Check_1750Mhz DUT: D1750V2; Type: D1750V2; Serial: 1035 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1750 MHz; σ = 1.383 S/m; ε r = 40.248; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(8.16, 8.16, 8.16); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 11.2 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 82.14 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 16.5 W/kg SAR(1 g) = 9.32 W/kg; SAR(10 g) = 5.01 W/kg Maximum value of SAR (measured) = 12.5 W/kg 0 dB = 12.5 W/kg = 10.97 dBW/kg Page 5 of 9 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2023/12/27 Test Laboratory: LCS-SAR Lab System Check_1900Mhz DUT: D1900V2; Type: D1900V2; Serial: 5d055 Communication System: UID 0, CW (0); Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.39 S/m; ε r = 39.66; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 13.5 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 90.91 V/m; Power Dr…

Text truncated - open the document above for the full version.

Page 1 of 30 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B Detailed Test Results 1. GSM GSM850 for Head& Body GSM1900 for Head& Body 2. WCDMA WCDMA Band II for Head& Body WCDMA Band V for Head& Body 3. LTE LTE Band 12 for Head& Body LTE Band 13 for Head& Body LTE Band 25 for Head& Body LTE Band 26 for Head& Body LTE Band 41 for Head& Body LTE Band 66 for Head& Body LTE Band 71 for Head& Body 4. WIFI WIFI 2.4GHz for Head& Body WIFI 5.2GHz for Head& Body WIFI 5.8GHz for Head& Body 5 Bluetooth for Head Page 2 of 30 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/1/4 Test Laboratory: LCS-SAR Lab GSM 850 190CH Right Cheek DUT: G65; Type: Phone; Serial: A12043052-1 Communication System: UID 0, GSM (0); Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 837 MHz; σ = 0.895 S/m; ε r = 41.133; ρ = 1000 kg/m 3 Phantom section: Right Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (8x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.139 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.011 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 0.155 W/kg SAR(1 g) = 0.122 W/kg; SAR(10 g) = 0.093 W/kg Maximum value of SAR (measured) = 0.141 W/kg 0 dB = 0.141 W/kg = -8.51 dBW/kg Page 3 of 30 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/1/4 Test Laboratory: LCS-SAR Lab GSM 850 GPRS 4TX 190CH Rear side 10mm DUT: G65; Type: Phone; Serial: A12043052-1 Communication System: UID 0, GPRS (0); Frequency: 836.6 MHz;Duty Cycle: 1:2 Medium parameters used: f = 837 MHz; σ = 0.895 S/m; ε r = 41.133; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (8x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.144 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.965 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.165 W/kg SAR(1 g) = 0.126 W/kg; SAR(10 g) = 0.096 W/kg Maximum value of SAR (measured) = 0.146 W/kg 0 dB = 0.146 W/kg = -8.36 dBW/kg Page 4 of 30 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2023/12/27 Test Laboratory: LCS-SAR Lab GSM 1900 512CH Right Cheek DUT: G65; Type: Phone; Serial: A12043052-1 Communication System: UID 0, GSM (0); Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.404 S/m; ε r = 40.15; ρ = 1000 kg/m 3 Phantom section: Right Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (8x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.458 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 11.29 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 0.617 W/kg SAR(1 g) = 0.323 W/kg; SAR(10 g) = 0.169 W/kg Maximum value of SAR (measured) = 0.361 W/kg 0 dB = 0.361 W/kg = -4.42 dBW/kg Page 5 of 30 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2023/12/27 Test Laboratory: LCS-SAR Lab GSM 1900 GPRS 4TX 512CH Rear side 10mm DUT: G65; Type: Phone; Serial: A12043052-1 Communication System: UID 0, GPRS (0); Frequency: 1850.2 MHz;Duty Cycle: 1:2 Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.404 S/m; ε r = 40.15; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn419; Calibrated: 2023/6/20  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (8x11x1): Mea…

Text truncated - open the document above for the full version.

Page 1 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix C Calibration certificate 1. Dipole D750V3-SN 1191(2023-06-15) D835V2-SN 4d124(2023-10-24) D1750V2-SN 1035(2023-06-12) D1900V2-SN 5d055 (2023-10-20) D2450V2-SN 808(2023-10-23) D2600V2-SN 1071(2023-06-20) D5GHzV2-SN 1046(2023-10-23) 2. DAE DAE3-SN 419(2023-06-20) 3. Probe EX3DV4-SN 3805(2023-11-23) Page 2 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 3 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 4 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 5 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 6 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 7 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 9 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 10 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 11 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 12 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 13 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 15 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 16 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 17 of 58 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Indu…

Text truncated - open the document above for the full version.

Page 1 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix D Photographs 1. SAR measurement System 2. Photographs of Tissue Simulate Liquid 3. Photographs of EUT test position 4. EUT Constructional Details Page 2 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 1. SAR measurement System Page 3 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Photographs of Tissue Simulate Liquid Photo 1: Tissue Simulant Liquid for Head 650-900 Photo 2: Tissue Simulant Liquid for Head 1700-2000 Photo 3: Tissue Simulant Liquid for Head 2300-2500 Photo 4: Tissue Simulant Liquid for Head 2500-2700 Photo 5: Tissue Simulant Liquid for Head 5000-6000 N/A Page 4 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Photographs of EUT test position Photo 6: Left touch cheek Photo 7: Left tilted 15 degree Photo 8: Right touch cheek Photo 9: Right tilted 15 degree Photo 10: Front side 10mm Photo 11: Back side 10mm Page 5 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Photo 12: Left side 10mm Photo 13: Right side 10mm Photo 14: Top side 10mm Photo 15: Bottom side 10mm Page 6 of 6 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. EUT Constructional Details Photo 16: Front View Photo 17: Back View

Page 1 of 102 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For Clover Industrial Co.,Ltd Phone Test Model: G65 Prepared for : Clover Industrial Co.,Ltd Address : Building 4, Hengchangrong High-tech Industrial Park, Shangnan East Road, Hongtian, Huangpu Community, Xinqiao Street, Baoan District, Shenzhen Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (86)755-82591330 Fax : (86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : December 26, 2023 Number of tested samples Sample number : : 1 A12043052-1 Serial number : Prototype Date of Test : December 27, 2023 ~ January 8, 2023 Date of Report : January 10, 2023 Page 2 of 102 FCCID: 2BCQA-G65 Report No.: LCSA12043052E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT Report Reference No. ................. : LCSA12043052E Date Of Issue ............................. : January 10, 2023 Testing Laboratory Name ........... : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .................... : Clover Industrial Co.,Ltd Address ...................................... : Building 4, Hengchangrong High-tech Industrial Park, Shangnan East Road, Hongtian, Huangpu Community, Xinqiao Street, Baoan District, Shenzhen Test Specification: Standard ..................................... : FCC 47CFR §2.1093, ANSI/IEEE C95.1-2019, IEEE 1528-2013 Test Report Form No. ................. : LCSEMC-1.0 TRF Originator ............................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................ : Dated 2014-09 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial …

Text truncated - open the document above for the full version.
