2BCR5-F1MOBAVGN DragonFLY F1 Mouse

DragonFly F1 MOBA 名称 DragonFly F1 Moba 型号 F1 Moba 适合手型 Middle hand grip, full hand grip 连接方式 2.4G wireless/ wired 特色 1. Nordic control, low power technology 2. Sprinkling Ringo Ice Berry powder 3. TTC Silver Wheel 4. Color contrast shell comparison of parameters product name DragonFly F1 Moba Specification name F1 Moba 69码 6975943530713 6975943530720 colour Black White top cover Black top cover White top cover coating NONE NONE Sump scheme Black bottom, storage bin and bottom shell of the same color Black bottom, storage bin and bottom shell of the same color size 121.2mm x 63.5mm x 37.6mm weight 55g sensor PAW 3395 DPI 100 – 26000 dpi main control chip Nordic 52840 transmission technology Smart Speed X rate of return 125-4000Hz(默认1000Hz，4K mode requires additional receiver) battery 500mhA endurance 130 hours micro Rhono Iced Berry Powder idler wheel TTCSilver wheel hem facing Big size PTFE connection type 2.4Ghz / wired system support Windows / MacOS / Linux parts list • • Wireless receiver • • Charging/data cordon cable • • Receiver extension adapter • • Small size PTFE foot stickers • • Help manual • • Warranty certificate others Support VGN HUB Daily price 239 首发价 239 detailed specification size 121.2mm x 63.5mm x 37.6mm weight Specification name F1 Moba colour Black White weight 55g connectivity wired USB-C interface 2.4G wireless Connect using a wireless adapter compatibility Windows、macOS、Linux、Chrome OS sensor sensor PAW 3395 DPI 100 – 26000 dpi No-drive gear red-400 DPI green-800 DPI（默认） blue-1600 DPI purple-3200 DPI main control chip Specification name F1 Moba chip type Nordic 52840 rate of return 125-4000Hz (Default 1000Hz, 4K mode requires additional receiver) Battery Specification name F1 Moba battery capacity 500mhA battery life 130小时（实标） fretting Primary key fretting Huannuo, Ice plum powder dot Roller encoder Kaihua GE2.0 foot sticker Name Material Remarks Large size foot stickers PTFE One copy comes with the package Small size foot stickers PTFE Post a copy by factory default. Software support Download driver, support modification and macro definition Packaging Packaging box Standard Accessories List • Wireless receiver • Charging/data cable • Receiver extender • Large size PTFE foot sticker • Help manual • Warranty certificate Extra bonus for the first time • One non-slip sticker, included in the box Packaging requirements  Shikang packaging box using drawer box structure  The accessory box is placed at the bottom and contains data cable, receiver extender, large PTFE foot sticker, help manual, warranty certificate  Non-slip sticker on top of accessory box  The accessory box is a blister box, and the mouse is placed  Sulfuric acid paper covers the mouse • If the accessory box can not place everything, you can put the help manual and warranty certificate on the accessory box, but you need to ensure that the blister box is flat FCC Warning Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 5mm between the radiator and your body.

Fuzhou Geek Cross-Border E-commerce Co., Ltd. Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Fuzhou Geek Cross-Border E-commerce Co., Ltd. Address: Room 1505-73. No.10.Aotou Road, Aofeng Street, Taijiang District, Fuzhou City, Fujian Province. China Product Name: VGN DragonFLY F1 Mouse FCC ID: 2BCR5-F1MOBA Model(s): F1 MOBA 2.911(d)(5)(i) Equipment Type We, [ Fuzhou Geek Cross-Border E-commerce Co., Ltd. ] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Nick Luo Date: 2023-1 2-14 Title and Company name: Manager NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(5)(i) Equipment Type Attestation v1.2

Fuzhou Geek Cross-Border E-commerce Co., Ltd. Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Fuzhou Geek Cross-Border E-commerce Co., Ltd. Address: Room 1505-73. No.10.Aotou Road, Aofeng Street, Taijiang District, Fuzhou City, Fujian Province. China Product Name: VGN DragonFLY F1 Mouse FCC ID: 2BCR5-F1MOBA Model(s): F1 MOBA 2.911(d)(5)(ii) Applicant filing We, [Fuzhou Geek Cross-Border E-commerce Co., Ltd. ] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Nick Luo Date: 2023-12-14 Title and Company name: Manager NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(5)(ii) Applicant Attestation v1.2

Fuzhou Geek Cross-Border E-commerce Co., Ltd * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter December 13, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2BCR5-F1MOBA Per section 2.911(d)(7) of the FCC rules, Fuzhou Geek Cross-Border E-commerce Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 8351 Colima Road Ste 585 Rowland Heights, California, 91748 United States of America Agent name: Benjamin. Smith/Vice President Agent Email Address: [email protected]/[email protected] FRN: 0033379421 Tel No:. +1(626) 341 3408 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Nick Luo Printed name: Benjamin. Smith Title: Manager Title: Vice President Company Name: Fuzhou Geek Cross-Border E- commerce Co., Ltd. Company Name: JOC Australia Inc Date: December 5, 2023 Date: December 13, 2023 FRN Code: 0034207977 FRN Code: 0033379421

Fuzhou Geek Cross-Border E-commerce Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-12-14 Subject; Request for Long Term Confidentiality FCC ID: 2BCR5-F1MOBA To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram BOM Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Nick Luo Title: Manager

Letter of Authorization Company: Fuzhou Geek Cross-Border E-commerce Co., Ltd. Address: Room 1505-73. No.10.Aotou Road, Aofeng Street, Taijiang District, Fuzhou City, Fujian Province. China Product Name: VGN DragonFLY F1 Mouse Model Number: F1 MOBA FCC Identifier: 2BCR5-F1MOBA We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Nick Luo Date: 2023-12-14 Title: Manager

Model: F1 MOBA External Model: F1 MOBA Model: F1 MOBA Model: F1 MOBA

Label&Location VGN DragonFLY F1 Mouse Model: F1 MOBA FCC ID: 2BCR5-F1MOBA

Model: F1 MOBA Internal Model: F1 MOBA Model: F1 MOBA Model: F1 MOBA Model: F1 MOBA

Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 1 of 7 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China RF Exposure Report For Applicant Name: Fuzhou Geek Cross-Border E-commerce Co., Ltd. Address: Room 1505-73. No.10.Aotou Road, Aofeng Street, Taijiang District, Fuzhou City, Fujian Province. China EUT Name: VGN DragonFLY F1 Mouse Brand Name: VGN Model Number: F1 MOBA Issued By Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Report Number: BTF230817R00502 Test Standards: 47 CFR Part 2 Subpart J Section 2.1093 FCC ID: 2BCR5-F1MOBA Test Conclusion: Pass Test Date: 2023-08-22 to 2023-08-30 Date of Issue: 2023-08-31 Prepared By: Chris Liu / Project Engineer Date: 2023-08-31 Approved By: Ryan.CJ / EMC Manager Date: 2023-08-31 Note: All the test results in this report only related to the testing samples. Which can be duplicated completely for the legal use with approval of applicant; it shall not be reproduced except in full without the written approval of BTF Testing Lab (Shenzhen) Co., Ltd., All the objections should be raised within thirty days from the date of issue. To validate the report, you can contact us. Test Report Number: BTF230817R00502 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 2 of 7 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Revision History Version Issue Date Revisions Content R_V0 2023-08-31 Original Note: Once the revision has been made, then previous versions reports are invalid. Test Report Number: BTF230817R00502 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 3 of 7 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Table of Contents 1. Introduction ............................................................................................................................................................................................ 4 1.1 Identification of Testing Laboratory ................................................................................................................................. 4 1.2 Identification of the Responsible Testing Location ...................................................................................................... 4 1.3 Laboratory Condition ........................................................................................................................................................... 4 1.4 Announcement ....................................................................................................................................................................... 4 2. Product Information .............................................................................................................................................................................. 5 2.1 Application Information ....................................................................................................................................................... 5 2.2 Manufacturer Information .................................................................................................................................................... 5 2.3 Factory Information .............................................................................................................................................................. 5 2.4 General Description of Equipment under Test (EUT)................................................................................................... 5 3. Test Requirement ................................................................................................................................................................................. 6 3.1 Assessment Result ............................................................................................................................................................... 6 Test Report Number: BTF230817R00502 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 4 of 7 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China 1. Introduction 1.1 Identification of Testing Laboratory Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Phone Number: +86-0755-23146130 Fax Number: +86-0755-23146130 1.2 Identification of the Responsible Testing Location Test Location: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Description: All measurement facilities used to collect the measurement data are located at F101,201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China FCC Registration Number: 518915 Designation Number: CN1330 1.3 Laboratory Condition Ambient Temperature: 20°C to 25°C Ambient Relative Humidity: 45% to 55% Ambient Pressure: 100 kPa to 102 kPa 1.4 Announcement (1) The test report reference to the report template version v0. (2) The test report is invalid if not marked with the signatures of the persons responsible for preparing, reviewing and approving the test report. (3) The test report i…

Text truncated - open the document above for the full version.

Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 1 of 62 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China RF Test Report For Applicant Name: Fuzhou Geek Cross-Border E-commerce Co., Ltd. Address: Room 1505-73. No.10.Aotou Road, Aofeng Street, Taijiang District, Fuzhou City, Fujian Province. China EUT Name: VGN DragonFLY F1 Mouse Brand Name: VGN Model Number: F1 MOBA Issued By Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Report Number: BTF230817R00501 Test Standards: 47 CFR Part 15.247 Test Conclusion: Pass FCC ID: 2BCR5-F1MOBA Test Date: 2023-08-22 to 2023-08-30 Date of Issue: 2023-08-31 Prepared By: Chris Liu / Project Engineer Date: 2023-08-31 Approved By: Ryan.CJ / EMC Manager Date: 2023-08-31 Note: All the test results in this report only related to the testing samples. Which can be duplicated completely for the legal use with approval of applicant; it shall not be reproduced except in full without the written approval of BTF Testing Lab (Shenzhen) Co., Ltd., All the objections should be raised within thirty days from the date of issue. To validate the report, you can contact us. Test Report Number: BTF230817R00501 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 2 of 62 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Revision History Version Issue Date Revisions Content R_V0 2023-08-31 Original Note: Once the revision has been made, then previous versions reports are invalid. Test Report Number: BTF230817R00501 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 3 of 62 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Table of Contents 1 INTRODUCTION ..........................................................................................................................................5 1.1 Identification of Testing Laboratory ...............................................................................................5 1.2 Identification of the Responsible Testing Location ......................................................................5 1.3 Announcement .................................................................................................................................5 2 PRODUCT INFORMATION ..........................................................................................................................6 2.1 Application Information ...................................................................................................................6 2.2 Manufacturer Information ................................................................................................................6 2.3 Factory Information .........................................................................................................................6 2.4 General Description of Equipment under Test (EUT) ...................................................................6 2.5 Technical Information ......................................................................................................................6 3 SUMMARY OF TEST RESULTS .................................................................................................................7 3.1 Test Standards ..................................................................................................................................7 3.2 Uncertainty of Test ...........................................................................................................................7 3.3 Summary of Test Result ..................................................................................................................7 4 TEST CONFIGURATION .............................................................................................................................8 4.1 Test Equipment List .........................................................................................................................8 4.2 Test Auxiliary Equipment ............................................................................................................. 10 4.3 Test Modes ..................................................................................................................................... 10 5 EVALUATION RESULTS (EVALUATION) ................................................................................................. 11 5.1 Antenna requirement ..................................................................................................................... 11 6 RADIO SPECTRUM MATTER TEST RESULTS (RF) ............................................................................... 11 6.1 Conducted Emission at AC power line ........................................................................................ 11 6.1.1 E.U.T. Operation: .................................................................................................................. 11 6.1.2 Test Setup Diagram: ............................................................................................................. 11 6.1.3 Test Data: ............................................................................................................................ 12 6.2 Occupied Bandwidth .................................................................................................................... 14 6.2.1 E.U.T. Operation: .......................................…

Text truncated - open the document above for the full version.

Antenna Specification Specifications Summary ITEMSPEC. Model Name 2.4 GHz Center Frequency 2403 MHz 2442 MHz 2480 MHz -2.48 dBi -2.44 dBi -4.3 4 dBi MAX. GAIN 0.95 dBi Polarization Vertical Azimuth Beam Pattern Omni-directional Impedance50Ω Antenna Length 2.16cm Antenna Photo & Length (mm) 1.Main antenna : 2403 MHz (blue line: horizontal power) (red line: vert ical power) 1.1 Horizontal Frequency(MHZ):2403Antenna Polarity:Horizontal Maximum Value(dBi): -2. 24 Average Gain(dBi) : -2.48 Minimum Gain(dBi): -55.18 Frequency(MHZ): 24 03Antenna Polarity:Vertical Maximum Value(dBi):-4.51 Average Gain(dBi) :-8.98 Minimum Gain(dBi):-62.3 1. 2 Ve rtical Frequency(MHZ): 24 42 Antenna Polarity:Horizontal Maximum Value(dBi): -6.20 Average Gain(dBi) : -2.44 Minimum Gain(dBi): -64.78 2. Main antenna : 2442 MHz 2.1 Horizontal Frequency(MHZ): 24 42 Antenna Polarity:Vertical Maximum Value(dBi): -10. 00 Average Gain(dBi) : -8.41 Minimum Gain(dBi): -47.4 2.2 Vertical Frequency(MHZ): 2480 Antenna Polarity:Horizontal Maximum Value(dBi): -8.31 Average Gain(dBi) : -4.34 Minimum Gain(dBi): -55.4 2. Main antenna : 2480 MHz 2.1 Horizontal Frequency(MHZ): 24 80 Antenna Polarity:Vertical Maximum Value(dBi): 0.95 Average Gain(dBi) : -14.06 Minimum Gain(dBi): -64.00 2.2 Vertical

Model: F1 MOBA Conducted Emission at AC power line Occupied Bandwidth Maximum Conducted Output Power Power Spectral Density Emissions in non-restricted frequency bands Model: F1 MOBA Band edge emissions (Radiated) Emissions in frequency bands (above 1GHz) Emissions in frequency bands (below 1GHz)
