2BCUE-TBOAT20UNMANNED SURFACE VEHICLE

Guangzhou TokSurvey Information Technology Co.,ltdGuangzhou TokSurvey Information Technology Co.,ltd www.toknav.cn Tboat20 UNMANNED SURFACE VEHICLE © 2025 Copyright Guangzhou Toksurvey Information Technology Co., Ltd Contents 1. Overview--------------------------------- 03 1.1 Control Console------------------------- 03 1.2 Motor Kit ------------------------------ 03 1.3 Receiver Kit ---------------------------- 04 1.4 Others --------------------------------- 06 2. Equipment Installation--------------------- 09 2.1 Tablet --------------------------------- 09 2.2 Motor --------------------------------- 09 2.3 Receiver ------------------------------- 10 3. Software Introduction---------------------- 11 3.1 Open the Software ---------------------- 11 3.2 Icons ---------------------------------- 12 3.3 Icons In Settings ------------------------ 13 3.4 Registration --------------------------- 14 3.5 Base Station Settings ------------------- 16 3.6 Vehicle Parameter Settings -------------- 17 3.7 Farm Tool Parameter Settings ----------- 19 Water Quality Monitoring Tboat20-B Water Quality Sampling Tboat20-C Water Surface Inspection Tboat20-D Tboat20-A Bathymetric Survey 1.3 Heat-dissipating Subsea Mounting & Expansion Rail (1) The Remote Controller is built around a 6 nm, octa-core Qualcomm SoC running Android 13 (64-bit). A high-power 2.4 GHz / 5.8 GHz dual-band radio module delivers low-latency, high-definition video with extended range and robust interference rejection. (2) A built-in 7-inch high-brightness HD panel (1920 × 1200) provides real-time video feedback from the survey payload. Dual internal fans maintain thermal stability for continuous field operation. (3) Interfaces include SIM card, USB and Type-C ports for differential corrections uplink, data logging and peripheral expansion. (4) A high-energy-density Li-ion pack gives 6–8 h of autonomous runtime per charge. (5) It is made of meteorological silicone, matte rubber, and ABS material. The G20 has taken dust-proof protection 1. Overview 1.1 Introduction to Unmanned Surface Vehicle Tboat20 Unmanned Surface Vehicle (USV) is built on a fully modular, plug-and-play architecture. The vehicle integrates seven line-replaceable modules—hull shell, mission-control core, propulsion unit, collision-avoidance suite, high-precision positioning package, wireless telemetry link, and hot-swappable power pack—into a single, watertight assembly. The shore-side segment is a single Android-based, long-range telemetry controller that unifies differential corrections uplink, real-time data downlink and remote control. All onboard and post-mission workfl ows are handled by tSail, an integrated vessel-control and hydrographic-processing application. Detailed functional descriptions of each hardware unit and software module are provided in the following sections. 1.2 Hull and Hardware Architecture 0403 360° Camera Power/RC-link indicator light Single-beam Echosounder (SBES) Heat-dissipating Subsea Mounting & Expansion Rail Thruster Start Switch Thruster Omnidirectional Bumper Obstacle Avoidance Radar Signal Antenna 4G Antenna2.4 G Antenna Differential-fix Indicator Light Hull Support Hatch Switch Radio-antenna Port Positioning Antenna Positioning Antenna 1.4 Controller Operations measures on the body, control switches, and all peripheral interfaces to ensure stable and smooth operation in harsh environments. Controller Specifications 0506 Operating voltage Weight Endurance Battery Firmware update Charge port RAM Internal storage Channels 16 4.2 V (internal battery) RF power 2 1 2.4 GHz 277 mm (L)×138 mm (W)×96 mm (H) hopping enabled 1.2 kg 6–8 h 20000 mAh OTA / on-line TYPE-C 4 GB 64 GB 23 dBm @CE/FCC 3 4 5 6 7 8 9 10 11 12 13 Dimensions Dynamic FHSS Band 3-position toggle switch (FWD: Auto / MID: Hold / AFT: Manual) L2 – safety-settings shortcut Microphone R2 – USV status shortcut R1 – vessel-control parameters shortcut Power key Right stick (port/starboard control) 2.4 GHz antenna Back key 2 1 3 4 5 6 7 8 9 10 11 12 L1 – mission-planning shortcut Return-to-home (RTH) key Left stick (forward/reverse control) Operating Environment a. Ambient temperature: –10 °C to +45 °C b. Storage temperature: –20 °C to +50 °C c. Relative humidity: 85 % RH d. Atmospheric pressure: 86 kPa – 106 kPa e. Location must be free of explosive, corrosive or electrically conductive media; gases that attack metals or degrade insulation; significant water vapour; and heavy mould growth f. Site shall provide protection against rain, snow, wind-blown sand and dust Power Supply & Safety Notes a. The ground station contains an integrated, rechargeable Li-ion battery and can be charged through the market-standard TYPE-C port using any certified USB charger (e.g., phone or camera adapter). b. If smoke, odour or electrolyte leakage is observed during charging, discontinue immediately and return the unit to an authorised service centre. c. Keep the charging area out of reach of children to prevent electric-shock hazards. d. Do not charge at ambient temperatures exceeding 60 °C. Pre-operation Checks a. Verify that the controller battery is adequately charged before use. b. Confirm that all antennas are positioned as specified to ensure optimum performance. c. Do not operate the unit while under the influence of 0708 Battery Indicator Light Data-logging stop key Linking Indicator Light 14 13 15 TF-card / SIM-card slot B1 key (reserved) Spring-return thumb-wheel for gimbal pan control Camera-view toggle key Lanyard eyelet TYPE-C port 16 17 18 19 20 21 22 B2 key (reserved) Photo-capture key 23 24 USB port alcohol or any impairing substance. e. Use only certified, professional-grade chargers for the battery. f. The antennas are fragile—avoid excessive force or impact. 2. Hardware Operation 2.1 Accessory Installation (1) Install battery → mate aviation power plug → switch battery ON. (2) Connect main-camera Ethernet and power cables. (3) Close hatch; tighten thumb-screws. 2.2 Pre-Launch Checks (…
