1 s SINAMICS Smart Adapter Compact Operating Instructions 07/2023 Security informationSecurity information In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions constitute one element of such a concept. For more information about industrial security, please visit https://www.siemens.com/global/en/products/automation/topic-areas/industrial-cybersecurity.html. FunctionalityFunctionality SINAMICS Smart Adapter allows Wi-Fi-based access to the Web server of a supported drive system from a PC or a mobile device, making it easier to perform drive commissioning, diagnostics, and maintenance. Siemens recom- mends that you temporarily connect SINAMICS Smart Adapter to the drive for the intended use. OverviewOverview Note: You can scan the QR code on the label using a standard code scanner or the “Industry Online Support” app to get product data, manuals, declarations of conformity, certificates and other information about your product. Reset button description •Resetting Wi-Fi configuration or administrator password To reset the Wi-Fi configuration to factory settings or reset the administrator password of the Smart Adapter, hold down the button for more than 3 seconds in power-on state until the Wi-Fi communication LED flashes yellow. •Restoring firmware version Proceed as follows to restore the firmware of the Smart Adapter to the factory version: 1. Hold down the reset button in power-off state, and then connect the Smart Adapter to the drive. 2. Keep the button pressed for more than 3 seconds after the connection. 1P 6SL4950-0AJ00-0AA0 S SZVN5553002048 MAC: xxxxxxxxxxxxx 4JFNFOT"( 'SBVFOBVSBDIFS
4US %&
&SMBOHFO.BEF
JO
$IJOB 4*/".*$4
4NBSU
"EBQUFS 1 4-"+"" 4 999999999994/$"& 會獬㣔䋴䄫꪿ホⰰꫀ䒍珔⻰ᄯ 4JFNFOT /VNFSJDBM
$POUSPM -UE /BOKJOH
3VOIVBJ
3PBE
-JTIVJ /BOKJOH

13$ '4
 $.**5* % "1 "DDFTT 4*/".*$4
ESJWF
IUUQTTJOBNJDTOFU"DDFTT
4NBSU
"EBQUFS
IUUQTNBSUB EBQUFSOFU IND. CONT.EQ. 4TR2 3$4 4."35
"%"15&3 $ R 005-103244 CCAN23LP0160T9 ()[CBOE
8 *OEPPSVTF POMZ
FYDFQUDPOOFDUJOH
UP ()[IJHI
QPXFS SBEJ PTUBUJPO 5" )*%' *$
4."35"%15 $"/ *$&4 # /.# # 5IJT
EFWJDF DPNQMJFT
XJUIQBSUPGUIF
'$$
3VMFT 0QFSBUJPO
JTTVCKFDU
UP
UIF
GPMMPXJOH
UXP
DPOEJUJPOT  5IJT
EFWJDF NBZOPU DBVTF IBSNGVMJOUFS GFSFODF
BOE  U IJT
EFWJDFNVTU BDDFQUBOZJOUFS GFSFODFSFDFJWFE JODMVEJO H
JOUFSGFSFODF
UIBU
NBZ DBVTF
VOEFTJSFE
PQFSBUJPO '$$
*% #$6,4."35"%"15&3      5HVHWEXWWRQ EDFNVLGHꝿ &RPPXQLFDWLRQLQWHUIDFH :L)LFRPPXQLFDWLRQ &RQYHUWHUFRPPXQLFDWLRQ 1DPHSODWHH[DPSOH IURQWYLHZ EDFNYLHZ $UWLFOHQXPEHU6/$-$$ 8QLWPP 3URGXFWODEHO EDFNVLGHꝿ 3URGXFWODEHOH[DPSOH *A5E51879348A* 2 LED descriptionLED description LEDStatusDescription Drive communication Solid red The communication between Smart Adapter and the drive system is not established. Solid green The communication between Smart Adapter and the drive system is established. Wi-Fi communication Solid redThe network communication is initializing. Solid yellow The network initialization completes, but Smart Adapter is not connected to a PC or mobile device. Solid green The connection between Smart Adapter and the PC or mobile device is set up. You can open the Web pages now. Flashing yellow Smart Adapter requires a restart because an upgrade completes or the Wi-Fi configuration is modified. Alternating flashing red and yellow Smart Adapter is upgrading. System requirementsSystem requirements Supported operating systemsRecommended browsers • Windows • ≥ Mac OS 10.15 • ≥ Apple iOS 12.2 • Android • ≥ Google Chrome 69.0 • ≥ Microsoft Edge 80.0 • Safari • ≥ Opera 56.0 Establishing initial wireless network connectionEstablishing initial wireless network connection 1.Connect the Smart Adapter to the X127 interface of the supported drive. 2.Activate the Wi-Fi interface inside your PC or mobile device. Make sure that you have enabled the automatic IP settings. 3.Search the wireless SSID of the Smart Adapter: SmartAdapter-xxxxxx. (The “xxxxxx“ stands for the last six characters of the Smart Adapter’s MAC address printed on the product label.) To avoid connecting to unsafe Wi-Fi networks that have the same SSID as your Smart Adapter has, check the properties of the Wi-Fi network and make sure that its MAC address is consistent with the MAC address printed on the product label. 4.Enter the wireless network password to launch the connection (default password: 12345678). Make sure that the Wi-Fi network of the Smart Adapter is the only network your PC or mobile device connects to; otherwise, the Web server of either the Smart Adapter or the drive may not be accessed via domain names. 5.In a supported browser, enter the Web site (https://sinamics.net) to access the drive’s Web server. To configure the Smart Adapter, enter the Web site (http://smartadapter.net). 6.Enter the new Wi-Fi and administrator passwords in the pop-up window, reconnect the wireless network, and refresh the Web page. Note: To achieve better network security, enter a password of 8 to 20 characters that contains numbers, lowercase and uppercase letters, and special symbols (_, -, ~, ! , @, #, $, %, ^, &, and *).    3 Accessing the drive’s Web serverAccessing the drive’s Web server After you have established wireless network connection between the Smart Adapter and your PC or mobile device, access the Web server integrated in the connected drive with one of the following two methods: • Enter the Web site (https://sinamics.net) in a supported browser. • Enter the Web site (http://smartadapter.net) and then click “Drive” on the home page of the Smart Adapter. If you are unable to access the Web server or the Wi-Fi connection between your device and the Smart Adapter is unstable, change the IP add…
