2BCUQ-CS40conferencing speakerphone

CS40 Conferencing Speakerphone Tel: +86-755-2640-2199 E-mail: [email protected] Web: www.fanvil.com FANVIL Technology Co., Ltd. CS40 Conferencing Speakerphone •5W*2 loud speaker for medium meeting rooms •3-meter voice pickup range, ENC/ANS/AGC enabled •Flexible connectivity with USB-A/C and Bluetooth •Modern ID fits all kinds of meeting rooms A loud speakerphone with vocal enhanced features Designed for med-meeting rooms Elegant ID Modern ID with fabric speaker cover and ambience light fits all kind of meeting rooms Cable management keeps the desk clean Loud Speaker + trio-mic 5W*2 loud speaker for medium meeting rooms Tr i o - o m n i d i r e c t i o n a l m i c f o r 3-meter voice pickup range, ENC, ANS and AGC enabled Instant Access touch buttons Pickup/Hangup | Volume Up/Down | Mute | Bluetooth USB-A/C and Bluetooth supported Flexible Connectivity 10h battery runtime 4.5h charging time FEATURES Tel: +86-755-2640-2199 E-mail: [email protected] Web: www.fanvil.com FANVIL Technology Co., Ltd. Microphone •Type: 3 omnidirectional analog microphones •Voice pickup range: 3 meters •Sensitivity: -32dBFs •Frequency: 20Hz~8KHz •SNR: •Environment Noise Cancellation (ENC) •Adjustive Noise suppression (ANS) •Automatic Gain control (AGC) Speaker •Speakerphone: 4Ω 5W/φ52mm*2 •Sensitivity:87dB±2dB •Frequency range:100Hz~20KHz •Music mode bandwidth:100Hz~20KHz •Speak mode bandwidth:1900z~20KHz •Maximum input power: 5W *2 CS40 Conferencing Speakerphone Connectivity •Connect to PC/smartphone: USB-A, Bluetooth •Bluetooth -Version: Bluetooth 5.4 -Profiles: HSP V1.2, HFP V1.7, A2DP V1.2 -Operating range: Up to 20m -Pairing list: Up to 8 devices -Simultaneous connections: 2 Battery •Ta l k t i m e : U p t o 8 . 5 h o u r s •Music time: Up to 10.5 hours •Standby time: 13 hours •Charging time: 4.5 hours •Battery capacity: 4000mA Physical Specifications •Dimensions -Product: 300*120*38mm -Cable length: 1.2m -Gift-box: X -Carton package: X •Weight -Product: 549g -Package Net weight/Gift-box: X/X/Box -Package Gross weight: X/box -Carton Net weight: X -Carton Gross weight: X •Te m p e r a t u r e a n d h u m i d i t y - Working temperature: -10°C--60°C - Storage temperature: -20°C-80°C -Working humidity: 10%-95% Package Contents •CS40 Bluetooth Speakerphone •Quick Installation Guide SPECIFICATIONS Tel: +86-755-2640-2199 E-mail: [email protected] Web: www.fanvil.com FANVIL Technology Co., Ltd. About FANVIL FANVIL Technology Co., Ltd. (FANVIL) is a leading global provider of A&V-IoT (Audio& Video- IoT) devices with three R&D centers in Beijing, Shenzhen, and Suzhou, China, and three factories in Huizhou and Shangrao, China, and Vietnam. FANVIL has focused on Unified Communication technology innovation for more than 20 years and provides SIP phones and SIP security industrial products in the global market. As the pioneer in applying standardized network communication technology and Audio & Video technologies to build A&V IoT, we are boosting the digital transformation for multiple industries. About LINKVIL As the sub-brand of FANVIL, LINKVIL will focus on the research and development of A&V-IoT wireless communication products. Based on Audio & Video -IoT, LINKVIL helps to achieve the full connection of wireless communication systems. LINKVIL builds a wireless communication Eco-system for multi-scenarios to help accelerate digital transformation. Copyright Copyright © 2024 FANVIL Technology Co., Ltd. All rights reserved. No parts of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, photocopying, recording, or otherwise, for any purpose, without the express written permission of FANVIL Technology Co., Ltd. More Information The above specifications may be updated in the future without prior notice. All hardware/software/physical features should be based on the final shipped products. For more information, please visit: www.fanvil.com FANVIL Technology Co., Ltd. Web: www.fanvil.com Add:10/F Block A, Dualshine Global Science Innovation Center, Honglang North 2nd Road, Bao'an District, Shenzhen, China Copyright © 2024 Fanvil Technology Co., Ltd. Compliance

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Fanvil Link Technology Co.,LTD Grantee code: 2BCUQ FRN: 0034227223 FCC ID: 2BCUQ-CS40 Contact Name: mengjiao Hu Address: A03, A08, 3rd Floor, Building 2, Daqian Industrial Plant, Zone 67, Xingdong Community, Xin'an Street, Bao'an District, Shenzhen, C hina. Telephone No: 15089240223 Fax No: Email: [email protected] i. [Fanvil Link Technology Co.,LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Fanvil Link Technology Co.,LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Fanvil Link Technology Co.,LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 07.12.2024 Applicant’s Name: mengjiao Hu Title: manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Fanvil Link Technology Co.,LTD Address: A03, A08, 3rd Floor, Building 2, Daqian Industrial Plant, Zone 67, Xingdong Community, Xin'an Street, Bao'an District, Shenzhen, China. Product Name: conferencing speakerphone Model Number: CS40 FCC Identifier: 2BCUQ-CS40 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: mengjiao Hu Date: 7/12/2024 Title: manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Fanvil Link Technology Co.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 7/12/2024 Subject: Request for Confidentiality FCC ID: 2BCUQ-CS40 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: mengjiao Hu Title: manager

Page 1 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (External Photos) Model: CS40 Page 2 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 3 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected]

Label Location

Page 1 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: CS40 Page 2 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 3 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 4 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 5 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 6 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] ANT Page 7 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Page 8 of 8 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected]

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi240606018-05E2 Date of issue: 2024-06-26 Applicant: Fanvil Link Technology Co., LTD Product name: conferencing speakerphone Model(s): CS40 FCC ID: 2BCUQ-CS40 Shenzhen Microtest Co., Ltd. http:// www.mtitest.cn - Page 2 of 6- Report No.: MTi240606018-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi240606018-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] TEST RESULT CERTIFICATION Applicant’s name .................... : Fanvil Link Technology Co., LTD Address .................................. : A03, A08, 3rd Floor, Building 2, Daqian Industrial Plant, Zone 67, Xingdong Community, Xin'an Street, Bao'an District, Shenzhen Manufacturer's Name ............. : Fanvil Link Technology Co., LTD Address .................................. : A03, A08, 3rd Floor, Building 2, Daqian Industrial Plant, Zone 67, Xingdong Community, Xin'an Street, Bao'an District, Shenzhen Product description Product name ............................ : conferencing speakerphone Trademark ............................. : Model Name .......................... : CS40 Serial Model ............................ N/A Standards ............................... : N/A Test procedure ....................... : KDB 447498 D01 v06 Date of Test Date (s) of performance of tests............. : 2024-06-19 to 2024-06-24 Test Result ............................................. : Pass Testing Engineer : (Maleah Deng) Technical Manager : (David Lee) Authorized Signatory : (Leon Chen) - Page 4 of 6- Report No.: MTi240606018-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi240606018-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When th…

Text truncated - open the document above for the full version.

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi240606018-05E1 Date of issue: 2024-06-26 Applicant: Fanvil Link Technology Co., LTD Product name: conferencing speakerphone Model(s): CS40 FCC ID: 2BCUQ-CS40 Shenzhen Microtest Co., Ltd. http://www.mtitest.cn Page 2 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 7 1.4 Description of support units ....................................................................................................................... 7 1.5 Measurement uncertainty .......................................................................................................................... 7 2 Summary of Test Result .................................................................................................................. 8 3 Test Facilities and accreditations ................................................................................................... 9 3.1 Test laboratory ........................................................................................................................................... 9 4 List of test equipment .................................................................................................................... 10 5 Evaluation Results (Evaluation) .................................................................................................... 11 5.1 Antenna requirement ............................................................................................................................... 11 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 12 6.1 Conducted Emission at AC power line .................................................................................................... 12 6.2 Occupied Bandwidth ................................................................................................................................ 15 6.3 Maximum Conducted Output Power ........................................................................................................ 17 6.4 Channel Separation ................................................................................................................................. 19 6.5 Number of Hopping Frequencies ............................................................................................................. 20 6.6 Dwell Time ............................................................................................................................................... 22 6.7 RF conducted spurious emissions and band edge measurement .......................................................... 24 6.8 Band edge emissions (Radiated) ............................................................................................................ 26 6.9 Radiated emissions (below 1GHz) .......................................................................................................... 29 6.10 Radiated emissions (above 1GHz) .......................................................................................................... 33 Photographs of the test setup ............................................................................................................. 37 Photographs of the EUT....................................................................................................................... 38 Appendix A: 20dB Emission Bandwidth ............................................................................................. 39 Appendix B: Maximum conducted output power ............................................................................... 43 Appendix C: Carrier frequency separation ......................................................................................... 47 Appendix D: Time of occupancy ......................................................................................................... 49 Appendix E: Number of ho…

Text truncated - open the document above for the full version.

Page 61 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Page 62 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Appendix G: Conducted Spurious Emission Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 Page 63 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference Page 64 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] DH5_Ant1_2480_30~1000 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference Page 65 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference Page 66 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 2DH5_Ant1_2480_0~Reference Page 67 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 3DH5_Ant1_2402_0~Reference Page 68 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 3DH5_Ant1_2402_30~1000 3DH5_Ant1_2402_1000~26500 3DH5_Ant1_2441_0~Reference Page 69 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 3DH5_Ant1_2441_30~1000 3DH5_Ant1_2441_1000~26500 3DH5_Ant1_2480_0~Reference Page 70 of 70 Report No.: MTi240606018-05E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 3DH5_Ant1_2480_30~1000 3DH5_Ant1_2480_1000~26500 ----End of Report----

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr - loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 60.2 % Gain (dBi) -0.58 (Peak Gain XZ-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to change without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board -0.70 -0.60-0.58-3.60-3.60-2.99 60.2 % Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Photographs of the test setup Model: CS40 Conducted Emission at AC power line Radiated emissions (below 1GHz) Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel : (86-755) 88850135-1349 Fax: (86-755) 88850136 We b : http://www.mtitest.cn E-mail: [email protected] Radiated emissions (above 1GHz)
