AntennaSpecification Specifications Summary ITEMSPEC. ModelNameIBM2.4GHz CenterFrequency2402MHz 2441MHz 2480MHz 2.24dBi 2.20dBi 1.81dBi MAX.GAIN2.24dBi PolarizationHorizontal AzimuthBeamPatternOmni-directional Impedance50Ω AntennaLength 9.15 mm AntennaPhoto&Length(mm) 1.Mainantenna:2402MHz (greenline:horizontalpower) (redline:verticalpower) 1.1Horizontal Frequency(MHZ): 2402 AntennaPolarity: Horizontal MaximumValue(dBi):2.24 AverageGain(dBi):-2.48 MinimumGain(dBi):-55.18 1.2Vertical Frequency(MHZ):2402AntennaPolarity:Vertical MaximumValue(dBi):-4.51 AverageGain(dBi):-8.98 MinimumGain(dBi):-62.3 2.Mainantenna:2441MHz 2.1Horizontal Frequency(MHZ):2441AntennaPolarity:Horizontal MaximumValue(dBi):2.20 AverageGain(dBi):-2.44 MinimumGain(dBi):-64.78 2.2Vertical Frequency(MHZ):2441AntennaPolarity:Vertical MaximumValue(dBi):-4.29 AverageGain(dBi):-8.41 MinimumGain(dBi):-47.4 2.Mainantenna:2480MHz 2.1Horizontal Frequency(MHZ):2480AntennaPolarity:Horizontal MaximumValue(dBi):1.81 AverageGain(dBi):-4.34 MinimumGain(dBi):-55.4 2.2Vertical Frequency(MHZ):2480AntennaPolarity:Vertical MaximumValue(dBi):-4.95 AverageGain(dBi):-14.06 MinimumGain(dBi):-64.00

Page 1 of 5 Report No.: 8231EU010104W-AB ANNEX B EXTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 5 Report No.: 8231EU010104W-AB PHOTO 3 PHOTO 4 Page 3 of 5 Report No.: 8231EU010104W-AB PHOTO 5 PHOTO 6 Page 4 of 5 Report No.: 8231EU010104W-AB PHOTO 7 PHOTO 8 Page 5 of 5 Report No.: 8231EU010104W-AB PHOTO 9 PHOTO 10 --- End ---

Label Location On EUT Label Sizes : 45mm*50mm

Page 1 of 2 Report No.: 8231EU010104W-AC ANNEX C INTERNAL PHOTOS PHOTO 1 PHOTO 2 PCB Antenna Page 2 of 2 Report No.: 8231EU010104W-AC PHOTO 3 --- End ---

RF EXPOSURE EVALUATION FCC ID: 2BCXN-F110900001 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (dBm) Distance (mm) Calculation results Limit Operating Mode 2402 -7.95 -7.95±1 -6.95 5 0.063 3 BLE 2440 -7.75 -7.75±1 -6.75 5 0.066 3 2480 -8.10 -8.10±1 -7.10 5 0.061 3 Test Results: PASS.

TEST REPORT Report No.: 8231EU010104W Applicant: Guangzhou Issyzone Tech Co., Limited Address: Unit J101, No. 31-5, Xicha Road, Baiyun District, Guangzhou, China Product Name: Heated clothes Model No.: F1109-00001 (refer to clause 2.4) Trademark: FCC ID: 2BCXN-F110900001 Test Standard(s): 47 CFR Part 15 Subpart C Date of Receipt: Jul. 01, 2024 Test Date: Jul. 01, 2024 – Jul. 24, 2024 Date of Issue: Aug. 01, 2024 ISSUED BY: SHENZHEN EU TESTING LABORATORY LIMITED Prepared by: Reviewed and Approved by: ____________________ _____________________ Mikey Zhu/ Engineer Sally Zhang/ Manager Page 2 of 32 Report No.: 8231EU010104W TRF No.: FCC Part 15.247_BLE (A01) Revision Record Report Version Issued Date Description Status V0 Aug. 01, 2024 Original Valid Page 3 of 32 Report No.: 8231EU010104W TRF No.: FCC Part 15.247_BLE (A01) Table of Contents 1 COVER PAGE .................................................................................................................................. 1 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 APPLICANT INFORMATION .................................................................................................................. 5 2.2 MANUFACTURER INFORMATION .......................................................................................................... 5 2.3 FACTORY INFORMATION ..................................................................................................................... 5 2.4 GENERAL DESCRIPTION OF E.U.T. ..................................................................................................... 5 2.5 TECHNICAL INFORMATION OF E.U.T. .................................................................................................. 6 3 TEST SUMMARY ...................................................................................................................................... 7 3.1 TEST STANDARD ............................................................................................................................... 7 3.2 TEST VERDICT ................................................................................................................................... 7 3.3 TEST LABORATORY ........................................................................................................................... 7 4 TEST CONFIGURATION .......................................................................................................................... 8 4.1 TEST ENVIRONMENT .......................................................................................................................... 8 4.2 TEST EQUIPMENT .............................................................................................................................. 8 4.3 DESCRIPTION OF SUPPORT UNIT ........................................................................................................ 9 4.4 TEST MODE ...................................................................................................................................... 9 4.5 MEASUREMENT UNCERTAINTY ........................................................................................................... 9 4.6 DEVIATION FROM STANDARDS ........................................................................................................... 9 4.7 ABNORMALITIES FROM STANDARD CONDITION ................................................................................... 9 5 TEST ITEMS ........................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT .................................................................................................................. 10 5.1.1 Test Requirement .............................................................................................................. 10 5.1.2 Antenna Anti-Replacement Construction .......................................................................... 10 5.1.3 Antenna Gain .................................................................................................................... 10 5.2 CONDUCTED EMISSION AT AC POWER LINE ..................................................................................... 11 5.2.1 Test Requirement .............................................................................................................. 11 5.2.2 Test Setup Diagram .......................................................................................................... 11 5.2.3 Test Procedure .................................................................................................................. 11 5.2.4 Test Data ........................................................................................................................... 11 5.3 OCCUPIED BANDWIDTH ................................................................................................................... 14 5.3.1 Test Requirement .............................................................................................................. 14 5.3.2 Test Setup Diagram .......................................................................................................... 14 5.3.3 Test Procedure .................................................................................................................. 14 5.3.4 Test Data ........................................................................................................................... 14 5.4 MAXIMUM CONDUCTED OUTPUT POWER .......................................................................................... 15 5.4.1 Test Requirement .............................................................................................................. 15 5.4.2 Test Setup Diagram ................................................................…

Text truncated - open the document above for the full version.

Page 1 of 24 Report No.: 8231EU010104W-AD ANNEX D TEST DATA For Project No.: 8231EU010104W Client: Guangzhou Issyzone Tech Co., Limited Product Name: Heated clothes Model No.: F1109-00001 FCC ID: 2BCXN-F110900001 Technology: Bluetooth BLE Test Engineer: Test Date: 2024-07-12 Page 2 of 24 Report No.: 8231EU010104W-AD Test Summary Item Result Duty Cycle Pass Bandwidth Pass Maximum Conducted Output Power Pass Maximum Power Spectral Density Pass Unwanted Emissions In Non-restricted Frequency Bands Pass Page 3 of 24 Report No.: 8231EU010104W-AD 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 2.094 3.124 67.03 1.74 16.78 2440 2.094 3.124 67.03 1.74 16.78 2480 2.094 3.125 67.01 1.74 16.78 Page 4 of 24 Report No.: 8231EU010104W-AD 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 5 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV Page 6 of 24 Report No.: 8231EU010104W-AD 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 1.014 / Pass 2440 1 1.014 / Pass 2480 1 1.014 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.642 >=0.5 Pass 2440 1 0.642 >=0.5 Pass 2480 1 0.639 >=0.5 Pass Page 7 of 24 Report No.: 8231EU010104W-AD 2.2 Test Graph 2.2.1 OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 8 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV Page 9 of 24 Report No.: 8231EU010104W-AD 2.2.2 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 10 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV Page 11 of 24 Report No.: 8231EU010104W-AD 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -7.95 <=30 Pass 2440 -7.75 <=30 Pass 2480 -8.10 <=30 Pass Page 12 of 24 Report No.: 8231EU010104W-AD 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm/3kHz) Verdict ANT1 Limit 1M SISO 2402 -23.45 <=8 Pass 2440 -23.33 <=8 Pass 2480 -23.41 <=8 Pass Page 13 of 24 Report No.: 8231EU010104W-AD 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 14 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV Page 15 of 24 Report No.: 8231EU010104W-AD 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 -8.32 2440 1 -8.01 2480 1 -8.52 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 -8.32 -28.32 Pass 2440 1 -8.01 -28.01 Pass 2480 1 -8.52 -28.52 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 16 of 24 Report No.: 8231EU010104W-AD 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 17 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV Page 18 of 24 Report No.: 8231EU010104W-AD 5.2.2 CSE 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV Page 19 of 24 Report No.: 8231EU010104W-AD 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV Page 20 of 24 Report No.: 8231EU010104W-AD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 21 of 24 Report No.: 8231EU010104W-AD 1M_MCH_2440MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 22 of 24 Report No.: 8231EU010104W-AD 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV Page 23 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV Page 24 of 24 Report No.: 8231EU010104W-AD 1M_HCH_2480MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV --------- End of Report -------

Page 1 of 2 Report No.: 8231EU010104W-AA ANNEX A TEST SETUP PHOTOS PHOTO 1 Photo of Power Line Conducted Emission Test PHOTO 2 Photo of Radiated Emission Test (below 1GHz) Page 2 of 2 Report No.: 8231EU010104W-AA PHOTO 3 Photo of Radiated Emission Test (above 1GHz) --- End ---
