2BCYV-EARBUDSwireless earphone
Shenzhen Whale Wave Technology Co., Ltd
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Oct 09, 2023
- Application Purpose
- Original Equipment
- Date of Application
- Oct 09, 2023
- Equipment Note
- wireless earphone
- Frequency Range
- 2402.00000000 - 2480.00000000
- Country
- China
