2BCZH-AS1Smart Watch Wireless Charging

PRODUCT SPECIFICATIONS For Apple Watch Charger Charger Color·whiteMaterial: Aluminium alloy+ PC Current: 1A Output: 2.SW Operating Temperature: -1 o·c-so'C Ambient Humidity: 35% -85% Feature • Lightning Port+ TypeC Port • Quick Charger(For a better charging experience, it is recommended to use 5V/2Aadapter or above) • Compatible with Apple Watch Series 8/7/6/ 5/4/3/2/1/SE/Ultra • Compatible with Apple Watch 38mm/40mm/ 41 mm/42mm/44mm/45mm/49mm • Strong Magnetic Suction-Build in latest magnetic adsorption module, charge immediately after contact • Portable Mini Size & Charge on the go, Small and compact wireless charger for your watch, it is easier to take anywhere PLEASE NOTE: Please connect the wireless charger to the original power adapter with an output of 5V/2A or above, and the charging effect will be faster; Do not use the charger with electronic products that do not meet the specifications, so as not to cause any problems due to mismatched specifications; It is normal for the charger to overheat a little during use Instructions 1, You need to prepare an adapter and a lightning cable /a Type c cable; 2. Connect the lightning cable to Magnetic Charging, 3, Align the Apple watch back with Magnetic Charging, it will automatically absorb and start charging; 4, When the watch is fully charged, it will automatically power off; 5. Please tum off the power when you don't need to charge Notice: 1. If the protective case of the watch is too thick, it may cause slow charging or no charging (please remove the protective case so that the watch can charge faster and more stably); 2. If it fails to work, please check whether the power adapter is 5V/2Aor above. It is recommended to try an adapte「with5V/2A or above for belier charging effect; PRECAUTIONS FOR USE If you're not using the Apple Watch charging cable, disconnect it. The wrong charging method can damage the charging cable.Always avoid moisture while charging Liquid (sweat, drinking water, etc.) or foreign matter on theconnector part, Be careful not to allow (fine dust, dust, metalp1eces, etc.) to adhere Do not touch the power supply with wet hands Worn cable, broken insulation. or broken. Never use a devicewith a plug that has a plug Charging your Apple Watch with the case removed And arerecommended Places that get hot (near fire, near stove, etc.) Use or leave in a placewhere flammable gas is generated Please do not Places exposed to direct sunlight or extremely cold, Do not store ina place with high humidity or dust, Apple Watch in a microwave oven,h1gh-pressure container, etc 3. If it cannot work, please contact us in time, we will Do not drop or throw it under strong impact.Do not solve your problem within 24 hours!!! I disassemble or modify Package Included: 1 xSmartWatch Magnetic Charging 1 x Instruction Manual Smart Watch Wireless Charging This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 15cm between the radiator & your body.

2.911 (d)(5)(i) Equipment Type Attestation v1.2 Shenzhen Huanyu Baijia Technology Co., Ltd Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen Product Name: Smart Watch Wireless Charging FCC ID: 2BCZH-AS1 Model(s): A-S1, A-S2 2.911(d)(5)(i) Equipment Type We, [Shenzhen Huanyu Baijia Technology Co., Ltd] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Sun wanli Date: 2023-09-25 Title and Company name: Manager Shenzhen Huanyu Baijia Technology Co., Ltd NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 Shenzhen Huanyu Baijia Technology Co., Ltd Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen Product Name: Smart Watch Wireless Charging FCC ID: 2BCZH-AS1 Model(s): A-S1, A-S2 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Huanyu Baijia Technology Co., Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Sun wanli Date: 2023-09-25 Title and Company name: Manager Shenzhen Huanyu Baijia Technology Co., Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Huanyu Baijia Technology Co., Ltd 2.911 (d)(7)USA Agent v1.4 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen Product Name: Smart Watch Wireless Charging FCC ID: 2BCZH-AS1 Model(s): A-S1, A-S2 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Huanyu Baijia Technology Co., Ltd] (“the applicant”) designate [UGK-LVMUNITEDINC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: UGK-LVMUNITEDINC USA Address: 6547NAcademyBlvd#2266,ColoradoSprin gs,CO80918 FRN Number: 0033476375 Contact Name: Jimmychen Telephone No: 001-323-51 04660 Email: [email protected] Applicant Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 F actory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen FCC Grantee Code: 2BCZH Contact Name: Sun wanli Telephone No: 13168331943 Email: [email protected] Signature: Signature: Title: Manager Shenzhen Huanyu Baijia Technology Co., Ltd 2.911 (d)(7)USA Agent v1.4 Title: Manager Date:2023-09-25 Date: 2023-09-25 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-securit y-threats-to-the-communications-supply-chain-through-the

Shenzhen Huanyu Baijia Technology Co., Ltd Agent Authorization Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen Product Name: Smart Watch Wireless Charging FCC ID: 2BCZH-AS1 Model(s): A-S1, A-S2 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023-09-25 Name: Sun wanli Title: Manager Company: Shenzhen Huanyu Baijia Technology Co., Ltd

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230919039E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 16 TEST REPORT FCC ID: 2BCZH-AS1 Applicant: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen Manufacturer: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Community, Xixiang Street, Bao'an District, Shenzhen EUT: Smart Watch Wireless Charging Trade Mark: N/A Model Number: A-S1 A-S2 Date of Receipt: Sep. 07, 2023 Test Date: Sep. 07, 2023 - Sep. 20, 2023 Date of Report: Sep. 20, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 Subpart C ANSI C63.10:2013 Test Result: Pass Report Number: DL-20230919039E Prepared (Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230919039E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 16 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ................................................................................................................................... 3 2. TEST SUMMARY ..................................................................................................................... 3 3. GENERAL INFORMATION .................................................................................................... 4 4. TEST INSTRUMENT USED ................................................................................................... 5 5. CONDUCTED EMISSION TEST ........................................................................................... 6 6. RADIATION EMISSION TEST ............................................................................................ 10 7. BANDWIDTH TEST ............................................................................................................... 15 8. ANTENNA REQUIREMENT ................................................................................................ 16 9. SETUP PHOTOGRAPHS ..................................................................................................... 16 10. EUT PHOTOGRAPHS ....................................................................................................... 16 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230919039E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 16 1. VERSION Version No. Date Description 00 Sep. 20, 2023 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Spurious Emission 15.209(a)(f) PASS 20dB Bandwidth 15.215 PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230919039E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 16 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: Smart Watch Wireless Charging Trade Mark: N/A Model No.: A-S1 A-S2 Model Difference: The product's different for model number and appearance color. Serial No.: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 115kHz ~ 205KHz Modulation type: MSK Antenna Type: Inductive loop coil Antenna Antenna gain: 0dBi Power supply: Input: DC 5V/1A Watch wireless output:2.5W 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1: Watch wireless output Mode(2.5W) Note: We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 3.5 Test Auxiliary Equipment Adapter (Provide by test lab): Manufacturer: HAIWEI Model: HW-0501000E I/P: AC 100-240V 50/60Hz O/P: DC 5V 1A Watch (Provide by test lab): Manufacturer: Apple Model: Series 6 3.6 Test Uncertainty Conducted Emission Uncertainty(150KHz-30MHz) : ±2.56dB 20dB Bandwidth : ±0.5kHz Radiated Emission Uncertainty(9KHz-1GHz) : ±3.24dB AC Mains EUT Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230919039E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 16 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room ChengYu 843 Room 843 Sep. 20, 2022 Sep. 19, 2025 EMI Receiver R&S ESR 101421 Nov. 05, 2022 Nov. 04, 2023 LISN R&S ENV216 102417 Nov. 05, 2022 Nov. 04, 2023 Clamp COM-POWER CLA-050 431071 Nov. 05, 2022 Nov. 04, 2023 3-Loop Antenna DAZE ZN30401 13021 Nov. 05, 2022 Nov. 04, 2023 ISN T8 Schwarzbeck NTFM 8158 101135 Nov. 05, 2022 Nov. 04, 2023 ISN T5 Schwarzbeck NTFM 8158 101136 Nov. 05, 2022 Nov. 04, 2023 843 Cable 1# ChengYu CE Cable 001 Nov. 05, 2022 Nov. 04, 2023 843 Cable 1# ChengYu CE Cable 002 Nov. 05, 2022 Nov. 04, 2023 For Radiated Emission Test (966 chamber) Equipment Manufacturer Model Serial Last Cal. Next Cal. 966 Chamber ChengYu 966 Room 966 Sep. 20, 2022 Sep. 19, 2025 Spectrum Analyzer Agilent E4408B MY50140780 Nov. 05, 2022 Nov. 04, 2023 EMI Receiver R&S ESRP7…

Text truncated - open the document above for the full version.

Shenzhen Huanyu Baijia Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023-09-25 Subject; Request for Confidentiality FCC ID: 2BCZH-AS1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Date: 2023-09-25 Name: Sun wanli Title: CEO Company: Shenzhen Huanyu Baijia Technology Co., Ltd

Shenzhen Huanyu Baijia Technology Co., Ltd Product Similarity Declaration Company name: Shenzhen Huanyu Baijia Technology Co., Ltd Address: 505 Huichuang Workshop, Building B, No.8 Factory, Shijie Co., Ltd., Gushu Commun ity, Xixiang Street, Bao'an District, Shenzhen Product Name: Smart Watch Wireless Charging FCC ID: 2BCZH-AS1 Model(s): A-S1, A-S2 We (Shenzhen Huanyu Baijia Technology Co., Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Sun wanli Date: 2023-09-25 Title and Company name: Manager Shenzhen Huanyu Baijia Technology Co., Ltd

Model Number: A-S1

Model Number: A-S1 ANT

FCC ID: 2BCZH-AS1 Product Name: Smart Watch Wireless Charging Trade Mark: N/A Model No.: A-S1 A-S2 Model Difference: The product's different for model number and appearance color. Transmitting mode Keep the EUT in continuously wireless charging mode Power supply: Input: DC 5V/1A Watch wireless output:2.5W Date of Receipt: Sep. 07, 2023 Test Date: Sep. 07, 2023 - Sep. 19, 2023 Date of Report: Sep. 19, 2023 Test Modes: Mode1. Mode1: Watch wireless output Mode(2.5W) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. Yes; the device operate in the frequency range from 115 KHz to 205 KHz (2) Output power from each primary coil is less than or equal to 15 watts. Yes; the maximum output power of the primary coil is 2.5W. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. Yes; the transfer system includes only one primary coils. (4) Client device is placed directly in contact with the transmitter. Yes; Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away Yes, see test result in item 6. from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Description of Support Units Adapter (Provide by test lab): Manufacturer: HAIWEI Model: HW-0501000E I/P: AC 100-240V 50/60Hz O/P: DC 5V 1A Watch (Provide by test lab): Manufacturer: Apple Model: Series 6 6 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 25 2023 June. 26 2024 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 25 2023 June. 26 2024 Field Probe ETS HI-6105 / June. 25 2023 June. 26 2024 Laser Data Interface ETS HI-6113 / June. 25 2023 June. 26 2024 7 Test Uncertainty E-Filed Strength : ±0.08V/m H-Filed Strength : ±0.02A/m 8 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.26 0.17 0.15 0.19 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.15 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.06 0.17 0.05 0.13 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.15 1.63 9 Test Set-up Photo

一、Plane structural diagram： Unit:MM 二、Product specifications： Foot position wire diameter number of laps Remark 1 - 20.08*24P14 Hot air twisting line "Technical requirements: 1. Secure the ends of the wires to prevent loose or broken wires. 2. Trim excessive wire lengths and tinplate them according to customer specifications, with a uniform tinning depth of 2±1mm. 3. Apply appropriate white adhesive onto the soft magnetic sheet and attach the coil, ensuring a clean and tidy product surface throughout the process." 4.The soft magnetic sheet used is made with round holes and no damage 5. Additional process (according to customer requirements): Install 7.7x2.0mm magnet in the middle round hole of the finished product and put in the finished product Add 14mm round double-sided adhesive to the back, and the rear packaging M/N:MPA2 四. Electrical activity parameters: 1. Intance value, Q value:PIN 1 — 2 = 8.1uH ±0.2UH，Q value≥35 The above inductance value is Quanhua 1062A instrument, and 10KHZ/0.3Vrms is the standard or equivalent instrument. Q value is Quanhua 1062A instrument, 100KHZ/0.3Vrms as standard or equivalent instrument 五、material list ： Nunmber NameMaterialSupplierRemark 1 Hot wind hanging line 0.08X24P Vihan or equivalent 2 magnetic sheet G25 Soft substrate Tiantong or equivalent 3 tin High temperature environmental protection Thousand Islands 4 alban BY882 Bao month or equivalent 5 Strong magnetic 7.7*2(Strength is gr eater than3000GS) Liansheng or equivalent Additional processes according to customer requirements 6 double faced adhesive tape diameter14mm Hh uiteng or d 东莞市煜耀电子科技有限公司 DONGGUAN YUYAO ELECTRONIC TECHNOLOGY CO.,LTD 工厂地址：东莞市塘厦林村新阳 路1号新太阳城工业城21栋 Dongguan City Tangxia Lin Village Xinyang Road No. 1 new Sun City Industrial City 21 building TEL: 0769-82866410 FAX: 0769-82866409
