2BD4K-BSP-D3MOBILE GAME CONTROLLER

手机手柄 产品说明书 User Manual X A B Y BSP-D3 MOBILE GAME CONTROLLER 功能按键示意图： 电源键 左摇杆/L3键 LED1/LED2/LED3 右摇杆/R3键 A/B/X/Y键 充电接口SELECT键START键 上下左右键 X A B Y 适用说明： 1、本产品采用人体工学设计，手感舒适。 2、具有拉伸收缩功能，可以拉伸收纳不同长度为 135-173mm 的手机。 3、采用蓝牙 5.0 EDR/BLE 连接，手柄通过蓝牙与手机等各主机连接。 4、支持 ShootingPlus V3 APP，APP 可以通过各手机应用市场下载。 5、支持安卓与鸿蒙 HID 标准模式，可玩支持 HID 标准模式的各类游戏厅游戏。 6、支持安卓 6.0 以上系统（即 ShootingPlus V3 安卓模式）。 7、支持 iOS 10.1 至 13.3.1 系统（即 ShootingPlus V3 iOS 模式）多个触控；支持iOS13.4 及以上系统单点触控。 8、支持 iOS 13.0 以上系统 MFi 游戏，MFi 游戏可以到 ShanWan MFi app 下载。 9、支持 PS3 /SWITCH 游戏主机蓝牙连接玩游戏，但没有陀螺仪功能。 10、支持 Windows 10 系统笔记本电脑蓝牙连接，玩 X-Input 游戏。 11、支持 USB 有线，可以玩 PC/PS3/SWITCH 的游戏。 12、其他模式下，M1和M2可以设置背键单键和宏。 13、按键带炫酷 LED 背光（同时按下 R3+ 键可开启或关闭按键背光）。 因手机系统问题，个别手机可能不支持此设备 因官方游戏平台软件升级或源代码变更等不可抗拒的因素造成部分游戏无法与本产 品连接操作，我公司不负任何责任。对此我公司保留最终解释权。 RT键 RB键 M2键 M1键 产品使用说明： 产品特性参数： 1、工作电压：DC3.7V 2、工作电流：约 10mA 3、持续使用时间：>20H 4、休眠电流：<5uA 5、充电电压/电流：DC5V/500mA 6、蓝牙传输距离：〈=8M 7、电池容量：350mAh 8、待机时间：满电放置 60 天 安卓 ShootingPlus V3 模式（鸿蒙系统与安卓 ShootingPlus V3 模式相同）： 使用本产品时，请保持设备横向放 置，且确保摄像头在左边，并将游 戏的键位恢复默认设置。 长亮 LED1 12：00 开启 已配对的设备 可用设备 BTIP-G2 IDKYX X2 BSP—D3 X A B Y 同时按 A + 2 秒进入 V3 安卓模式，手柄 LED1 快闪，当安卓手机搜索到“BSP—D3 ”设备 名时，选择连接。连接成功后，手柄 LED1 长亮。 已成功连接过，可以直接按 ，LED1 灯慢闪，自动回连。 LT键 LB键 X A B Y 同时按 Y+ 2 秒进入 V3 iOS 模式，手柄 LED2快闪，当苹果手机搜索到“BSP—D3” 设备名时，选择连接。连接成功后，手柄 LED2长亮。 已成功连接过，可以直接按 ，LED2灯慢闪，自动回连。 12：00 我的设备 BSP—D3 现在可被发现为“张小燕的iphone”。 已连接 中国移动 iOS ShootingPlus V3 模式： 安卓/鸿蒙/iOS 按键映射功能： 关注公众号“ShootingPlus”,查看公众号内的默认操作说明，如需设置映射键位，请下 载安装“ShootingPlus V3”APP，在 APP 内进行按键映射以及调整按键位。 ShootingPlus V3 App，iOS 系统可以到 APP Store 下载，安卓与鸿蒙系统可以到各手机应 用市场下载。 1、同时按 X+ 进入标准安卓模式，手柄 LED2 快闪，当安卓/鸿蒙手机搜索到 “BSP—D3”设备名时，选择连接。连接成功后，手柄 LED2长亮。 已成功连接过，可以直接 ，LED2 灯慢闪，自动回连。 2、安卓/鸿蒙标准模式游戏下载，可下载各种游戏厅，进入平台下载所需要的游戏。 安卓标准模式： 长亮 LED2 X A B Y 同时按 B+ 2 秒进入 iOS MFi 模式，手柄 LED3 快闪，当苹果手机搜索到“DUALSHOCK 4 Wireless Controller”设备名时，选择连接。连接成功后，手柄 LED3长亮。 已成功连接过，可以直接按 ，LED3灯慢闪，自动回连。 MFi 游戏可以到 ShanWan MFi app 下载。 iOS MFi 模式： 长亮 LED3 12：00 开启 已配对的设备 可用设备 BTIP-G2 IDKYX X2 BSP—D3 X A B Y 12：00 我的设备 DUALSHOCK4 ... Controller 现在可被发现为“张小燕的iphone”。 已连接 中国移动 长亮 LED3 X A B Y PC X-input 蓝牙模式: 同时按 RB + 2 秒进入 X-input 蓝牙模式，手柄 LED1/ LED2快闪 ，当 PC 搜索到 “Xbox Wireless Controller”设备名时，选择连接。连接成功后，手柄 LED1/ LED2长亮。 控制面板 Xbox Wireless Controller (已连接，已配对） 已成功连接过，可以直接按 ，LED1 与 LED2灯慢闪，自动回连。 SEL A STA X Y B 在 SWITCH 主机，选择 手柄 Controllers 更改握把/顺序 Change Grip/order，进入到 SWITCH 主机配对模式界面 Press L+R on the controller。 按住 RT+ 2 秒进入 SWITCH 模式配对，手柄 LED1 与 LED2快闪 ，配对成功为 LED3 长亮。成功连接过，可以直接按 ,LED1 与 LED2灯慢闪，自动回连。 SWITCH 模式： 手柄 主机 手柄 更改握法/顺序 搜索手柄 新手柄的匹配方法 关闭 SEL A STA X Y B 快闪 LED1 快闪 LED2 X A B Y 快闪 LED1 快闪 LED2 X A B Y 有线模式下自动识别各个系统平台，可以支持的系统平台有安卓、PC(D-input 与 X-input)、 PS3 与Switch。 1、X-input 有线模式连接成功后 LED 1常亮。D-input有线模式连接成功后 LED 2常亮 2、在 PC 上，按 2 秒可以对 D-input 与 X-input 之间切换。 3、PS3/SWITCH主机默认LED3长亮 2.4G模式下自动识别各个系统平台，可以支持的系统平台有安卓、PC(D-input 与 X-input)、 PS3 与Switch。 1、按住L1+ 2 秒进入2.4G模式，手柄LED1与LED2快闪，连接成功后LED1与LED2长亮。 2、在 PC 上，按住SELECT+START键3秒可以对 D-input 与 X-input 之间切换。 3、已成功连接过，可以直接按 ，手柄LED1与LED2慢闪，自动回连。 将手柄用 TYPE-C USB 数据线直接与 PS3主机连接，按 进行对码，手柄 LED1与LED2 快闪，连接成功后LED3长亮。 已成功连接过，可以直接按 ，LED1 与 LED2灯慢闪，自动回连。 PS3模式： 有线模式： 2.4G模式（需选配）： 背部单个扩展设置： 1、按住SEL键不放再按M1，此时指示灯快闪。 2、设置模式开启后，手柄键入什么键就会录入什么键至M1。 （如：按一下X键，则M1等用于X键） 3.如要设置宏连招、则按顺序键入所需按键即可。 （如:按A→B→X→Y,则M1等用于按A、B、X、Y的功能顺序连招） 最高可设置十二个键 4.按键按完后再按M1即可完成编程此时LED灯长亮。 1、手柄充电功能： A、低电时，右边青色LED指示灯快闪提示； B、充电时，右边青色LED指示灯慢闪提示； C、充满时，右边青色LED指示灯长亮提示； 2、手柄休眠/唤醒/关机功能： A、手柄在 15 分钟内没有任何按键操作时自动关机休眠； B、当需要重新使用时需按 键唤醒即可回连； C、在开机状态下，长按 键 3 秒，产品关机，所有 LED 指示灯熄灭。 手柄充电/休眠/唤醒功能： 背部按键清除： 1、 请不要把本产品放在潮湿或高温地方存储； 2、 不要敲击、摔打、棒打、刺穿、或试图去分解本产品，以免对产品造成不必要的损害； 3、 产品内置电池，请勿和垃圾一起丢弃； 4、 不要在靠近火或其它热源的地方对手柄进行充电； 5、 非专业人员请勿拆卸本产品，否则不在售后保修服务内。 1、按住SEL键不放再按M1，此时指示灯快闪。 2、清除模式开启后，此时再次按下M1就能清除M1所有键位。 注意：此时不要按下任何按键 3、按键按完后，即为完成清除编程，此时灯光长亮。 M2键清除方式同上 （注意：此设置方式可支持MFI、SWITCH 主机、PC电脑) 产品清单： 注意事项： 无线手柄 X1 说明书 X1 TYPE-C USB 线 X1。 X A B Y Function key diagram： HOME Button Left joystick L3 Button Right joystickr R3 Button A/B/X/Y Button Charging interface SELECT Button START Button Up Down LeftRight Button Description of application: Due to the problem of mobile phone system, some mobile phones may not support this device Some games cannot be connected to this product due to irresistible factors such as software upgrade or source code change of the official game platformOur company is not responsible for the operation. Our company reserves the right of final interpretation. 1. This product adopts ergonomic design and feels comfortable. 2. With stretch and shrink function, it can stretch and store mobile phones with different lengths of 135-173mm. 3. Bluetooth 5.0 EDR / ble connection is adopted, and the controller is connected with mobile phones and other hosts through Bluetooth. 4. It supports shootingplus V3 app, which can be downloaded through various mobile application markets. 5. Support Android and Hongmeng hid standard mode, and can play all kinds of game hall games that support HID standard mode. 6. Support systems above Android 6.0 (i.e. shootingplus V3 Android mode). 7. Support multiple touch of IOS 10.1 to 13.3.1 systems (i.e. shootingplus V3 IOS mode); Support single touch for IOS 13.4 and above systems 8. Support MFI games for systems above IOS 13.0. MFI games can be downloaded from Shanwan MFI app. 9. PS3 / switch game console is supported to play games with Bluetooth connection, but there is no gyroscope function. 10. Support Bluetooth connection of windows 10 system laptop and play X-input games. 11. Support USB cable and can play PC / PS3 / switch games. 12.In other modes, M1 and M2 can set back key, single key and macro. 13. The key is equipped with cool LED backlight (press R3 + at the same time to turn on or off the key backlight). LED1/LED2/LED3 X A B Y 12：00 open Paired devices Available equipment BTIP-G2 IDKYX X2 ShanWan Q17 Operation instructions： Characteristic parameters： 1. Working voltage: DC3.7v 2. Working current: About 10mA 3. Duration: > 20h 4. Sleep current: < 5uA 5. Charging voltage / current: DC5V / 500mA 6. Bluetooth transmission distance: ＜ = 8M 7. Battery …

Text truncated - open the document above for the full version.

CoveredEquipmentCertificationAttestationLetter 2025.10.25 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA ATTN.:ReviewingEngineer FCCID:2BD4K-BSP-D3 GuangliHechuangTechnologyCo.,Ltd.(“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. GuangliHechuangTechnologyCo.,Ltd.(“theapplicant”)certifiesthat,asofthedateof thefilingoftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. GuangliHechuangTechnologyCo.,Ltd.(“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtdoesnotincludecybersecurityoranti-virussoftware producedorprovidedbyKasperskyLab,Inc.oranyofitssuccessorsandassignees, includingequipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsand assignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01 CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:JiangHaiping Title:CEO CompanyName:GuangliHechuangTechnologyCo.,Ltd. Date:2025.10.25

2025-10-25 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID：2BD4K-BSP-D3 ProductName:MOBILEGAMECONTROLLER RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommission’srules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...) Schematics  Blockdiagram Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. Name:JiangHaiping Title:CEO Company:GuangliHechuangTechnologyCo.,Ltd.

2025.10.25 FederalCommunicationsCommission Authorization&EvaluationDivision 7345OaklandMillsRoad Columbia,Maryland21046 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorizeShenzhenBangceTestingTechnologyCo.,Ltd.toacton ourbehalfinallmattersrelatingtoapplicationforequipmentauthorization,includingthesigningofall documentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothedenialof benefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21 U.S.C.853(a). Sincerely, Name ： JiangHaiping Title:CEO Company:GuangliHechuangTechnologyCo.,Ltd.

version01 GuangliHechuangTechnologyCo.,Ltd. Modeldifferencestatement Itisherebydeclaredthattheproduct FCCID:2BD4K-BSP-D3 ProductName:MOBILEGAMECONTROLLER Model(s):BSP-D3,BSP-D3S,BSP-D3+,BSP-D3PRO,BSP-D3A,BSP-D3B,BSP-D3C,BSP-D3D,BSP-D3E,BSP- D3F,BSP-D4,BSP-D4S,BSP-D4+,BSP-D4PRO,BSP-D4A,BSP-D4B,BSP-D4C,BSP-D4D,BSP-D4E,BSP-D4F Mark:/ Thenyareelectricalidentical,theSchematic,PCBlayout,structureandsoftwarearesame,onlythe differenceisthemodelnameformarketpurpose. Sincerely, Signature Name:JiangHaiping Title:CEO ApplicantCompany:GuangliHechuangTechnologyCo.,Ltd.

ReportNo.:CISRR25090807001 Page 43 of 65 7.EXTERNALANDINTERNALPHOTOS 7.1.ExternalPhotos ReportNo.:CISRR25090807001 Page 44 of 65 ReportNo.:CISRR25090807001 Page 45 of 65

FCCID:2BD4K-BSP-D3 Label FCC ID:2BD4K-BSP-D3 Model:BSP-D3 Product Name:MOBILE GAME CONTROLLER LabelLocation

ReportNo.:CISRR25090807001 Page 46 of 65 7.2.InternalPhotos ReportNo.:CISRR25090807001 Page 47 of 65 ReportNo.:CISRR25090807001 Page 48 of 65 ANT ReportNo.:CISRR25090807001 Page 49 of 65 ReportNo.:CISRR25090807001 Page 50 of 65

RFExposureevaluation FCCID2BD4K-BSP-D3 ProductNameMOBILEGAMECONTROLLER ModelNo.BSP-D3 ListedModel(s) BSP-D3S、BSP-D3+、BSP-D3PRO、BSP-D3A、BSP-D3B、 BSP-D3C、BSP-D3D、BSP-D3E、BSP-D3F、BSP-D4、BSP-D4S、 BSP-D4+、BSP-D4PRO、BSP-D4A、BSP-D4B、BSP-D4C、 BSP-D4D、BSP-D4E、BSP-D4F ExposurecategoryGeneralpopulation/uncontrolledenvironment EUTTypeProductionUnit DeviceTypePortableDevice 1.Reference ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposureto RadioFrequencyElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01GeneralRFExposureGuidancev06:MobileandPortable DevicesRFExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1093:Radiofrequencyradiationexposureevaluation:portabledevices 2.Requirement AccordingtoKDB447498D01GeneralRFExposureGuidancev06Section4.3.1Standalone SARtestexclusionconsiderations:“UnlessspecificallyrequiredbythepublishedRFexposure KDBprocedures,standalone1-gheadorbodyand10-gextremitySARevaluationforgeneral populationexposureconditions,bymeasurementornumericalsimulation,isnotrequired whenthecorrespondingSARTestExclusionThresholdcondition,listedbelow,issatisfied. Thesetestexclusionconditionsarebasedonsource-basedtime-averagedmaximum conductedoutputpoweroftheRFchannelrequiringevaluation,adjustedfortune-uptolerance, andtheminimumtestseparationdistancerequiredfortheexposureconditions.22The minimumtestseparationdistanceisdeterminedbythesmallestdistancefromtheantenna andradiatingstructuresoroutersurfaceofthedevice,accordingtothehostformfactor, exposureconditionsandplatformrequirements,toanypartofthebodyorextremityofauser orbystander(see5)ofsection4.1).ToqualifyforSARtestexclusion,thetestseparation distancesappliedmustbefullyexplainedandjustifiedbytheoperatingconfigurationsand exposureconditionsofthetransmitterandapplicablehostplatformrequirements,typicallyin theSARmeasurementorSARanalysisreport,accordingtotherequiredpublishedRF exposureKDBprocedures.WhennootherRFexposuretestingorreportingisrequired,a statementofjustificationandcompliancemustbeincludedintheequipmentapproval,inlieuof theSARreport,toqualifyfortheSARtestexclusion.Whenrequired,thedevicespecific conditionsdescribedintheotherpublishedRFexposureKDBproceduresmustbesatisfied beforeapplyingtheseSARtestexclusionprovisions;forexample,handheldPTTtwo-way radios,handsets,laptops&tabletsetc.23” [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR,where: •f(GHz)istheRFchanneltransmitfrequencyinGHz •PoweranddistanceareroundedtothenearestmWandmmbeforecalculation •Theresultisroundedtoonedecimalplaceforcomparison •3.0and7.5arereferredtoasthenumericthresholdsinthestep2below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingto5)insection4.1isappliedto determineSARtestexclusion. Whenoneofthefollowingtestexclusionconditionsissatisfiedforallcombinationsof simultaneoustransmissionconfigurations,furtherequipmentapprovalisnotrequiredto incorporatetransmittermodulesinhostdevicesthatoperateinthemixedmobileandportable hostplatformexposureconditions.Thegranteeisresponsiblefordocumentingthisaccording toClassIpermissivechangerequirements.AntennasthatqualifyforstandaloneSARtest exclusionmustapplytheestimatedstandaloneSARtodeterminesimultaneoustransmission testexclusion. a)The[∑of(thehighestmeasuredorestimatedSARforeachstandaloneantenna configuration,adjustedformaximumtune-uptolerance)/1.6W/kg]+[∑ofMPEratios]is≤ 1.0. b)TheSARtopeaklocationseparationratiosofallsimultaneouslytransmittingantennapairs operatinginportabledeviceexposureconditionsareall≤0.04,andthe[∑ofMPEratios]is≤ 1.0. 3.ConductedPeakOutputPower ModulationPacketTypeChannel PeakOutput Power (dBm) PeakOutput Power (mW) GFSKDH5 01.651.46 391.721.49 781.301.35 π/4DQPSK2-DH5 02.491.77 392.611.82 782.181.65 8DPSK3-DH5 02.611.82 392.821.91 782.421.75 ModulationPacketTypeChannel PeakOutput Power (dBm) PeakOutput Power (mW) GFSKBLE1M 00.361.09 190.681.17 390.201.05 4.ManufacturingTolerance BR/EDR DH5 ChannelChannel0Channel39Channel78 Target(dBm)111 Tolerance±(dB)1.01.01.0 2DH5 ChannelChannel0Channel39Channel78 Target(dBm)111 Tolerance±(dB)1.01.01.0 3DH5 ChannelChannel0Channel39Channel78 Target(dBm)222 Tolerance±(dB)1.01.01.0 BLE 1M ChannelChannel0Channel19Channel39 Target(dBm)000 Tolerance±(dB)1.01.01.0 5.EvaluationResult Band/Modef(GHz) Antenna Distance (mm) RFoutputpower SARTest Exclusion Threshold SARTest Exclusion dBmmW BR/EDR2.48053 2.00 0.6284<3.0Yes BLE2.48051 1.26 0.3902<3.0Yes Remark: 1.Outputpowerincludingtuneuptolerance; 2.Whentheminimumtestseparationdistanceis<5mm,adistanceof5mmaccordingtof)in section4.1isappliedtodetermineSARtestexclusion. 6.Conclusion ThemeasurementresultscomplywiththeFCCLimitper47CFR2.1093fortheuncontrolled RFExposureandSARExclusionThresholdperKDB447498D01V06. ------Endofthereport------

ReportNo.:CISRR25090807002 Thetestresultsrelateonlytothetestedsamples. ThetestreportshouldnotbereproducedexceptinfullwithoutthewrittenapprovalofShenzhenBangce TestingTechnologyCo.,Ltd. Page1of43 TESTREPORT ReportNo.CISRR25090807002 ProjectNo.CISR250908070 FCCID2BD4K-BSP-D3 ApplicantGuangliHechuangTechnologyCo.,Ltd. Address No.213ShajingRoadShatouVillageShajingStreetBaoanDistrict, Shenzhen,China ManufacturerGuangliHechuangTechnologyCo.,Ltd. Address No.213ShajingRoadShatouVillageShajingStreetBaoanDistrict, Shenzhen,China ProductNameMOBILEGAMECONTROLLER TrademarkN/A Model/TypereferenceBSP-D3 ListedModel(s) BSP-D3S、BSP-D3+、BSP-D3PRO、BSP-D3A、BSP-D3B、BSP- D3C、BSP-D3D、BSP-D3E、BSP-D3F、BSP-D4、BSP-D4S、BSP- D4+、BSP-D4PRO、BSP-D4A、BSP-D4B、BSP-D4C、BSP-D4D、 BSP-D4E、BSP-D4F Standard 47CFRPart15.247 TestdateSeptember10,2025toSeptember12,2025 IssuedateSeptember15,2025 TestresultComplied Preparedby:LucasHuangApprovedby:HansHu ReportNo.:CISRR25090807002 Page 2 of 43 Contents 1.REPORTVERSION..........................................................................................................................................3 2.TESTDESCRIPTION.......................................................................................................................................4 3.SUMMARY........................................................................................................................................................5 3.1.ProductDescription*..................................................................................................................................5 3.2.RadioSpecificationDescription*..............................................................................................................5 3.3.ModificationofEUT.....................................................................................................................................6 3.4.Deviationfromstandards...........................................................................................................................6 3.5.TestingSite...................................................................................................................................................6 4.TESTCONFIGURATION.................................................................................................................................7 4.1.Testfrequencylist.......................................................................................................................................7 4.2.Descriptionsoftestmode...........................................................................................................................7 4.3.Supportunitusedintestconfiguration....................................................................................................7 4.4.Testsampleinformation.............................................................................................................................7 4.5.Environmentalconditions...........................................................................................................................7 4.6.Statementofthemeasurementuncertainty.............................................................................................8 4.7.EquipmentUsedduringtheTest................................................................................................................8 5.TESTRESULTS.............................................................................................................................................10 5.1.EvaluationResults(Evaluation)...............................................................................................................10 5.1.1.AntennaRequirement............................................................................................................................10 5.2.RadioSpectrumMatterTestResults(RF)...............................................................................................11 5.2.1.ConductedEmissionatACpowerline.................................................................................................11 5.2.2.6dBBandwidth........................................................................................................................................14 5.2.3.MaximumConductedOutputPower.....................................................................................................15 5.2.4.PowerSpectralDensity..........................................................................................................................16 5.2.5.Conductedbandedgeandspuriousemission...................................................................................17 5.2.6.Radiatedbandedgeemission...............................................................................................................18 5.2.7.RadiatedSpuriousEmission(below1GHz).........................................................................................24 5.2.8.RadiatedSpuriousEmission(Above1GHz)........................................................................................28 6.TESTSETUPPHOTOS..................................................................................................................................36 7.EXTERNALANDINTERNALPHOTOS........................................................................................................36 7.1.ExternalPhotos.........................................................................................................................................36 7.2.InternalPhotos...........................................................................................................................................36 8.APPENDIXREPORT......................................................................................................................................36 ReportNo.:CISRR25090807002 Page 3 of 43 1.REPORTVERSION VersionNo.IssuedateDescription 00September15,2025Original ReportNo.:CISRR25090807002…

Text truncated - open the document above for the full version.

ShanWan 1.TestPrinciple Antenna data sheet s Antenna typePCB antenna Antenna model2.4G ANT Peak Gain-0.71dBi ManufacturerShenzhen Shanwan Technology Co., LTD Address5th Floor, Building 33, Chentian Industrial Zone, Chentian Community, Xixiang Sub-district, Bao 'an District, Shenzhen City,China ShanWan 2。TestingFacility name model equipmentnumber manufacturer Dateofcalibration nexttime Dateofcalibration OTAtestmacro RayZone- 5000 RFI-LAB-RF-D00 GTS2021.3.222023.3.21 networkanalyzer E5071CRFI-LAB-RF-C02KEYSIGHT 2022.5.132023.5.12 networkanalyzer E5071C RFI-LAB-RF-D01 KEYSIGHT 2022.5.132023.5.12 3。TestingEnvironment ambienttemperature 23.6°C relativehumidity 58%RH atmosphericpressure 100.14kPa ShanWan 5.SampleTestPlacementDiagra 4. Sample Physical Obje-cts m FrontView ShanWan 6.TestResult 6.1TestBasis Objectname ParameternameMethodname Accordingtothestandardnum- ber Mobilecommunication antenna antennapattern Generaltechnicalspecificationsformobilecommunication antennas GB/T9410-2008 antennagain voltagestanding-waveratio Circularityofdirection diagram antenna Gainanddirectionality IEEEantennateststandardprocess ANSI/IEEEStd 149-1979 radiationefficiency impedance 6.2TestUncertainty UncertaintyiscalculatedbasedonISO's"GuidetotheExpressionofUncertaintyinMeasurement" (GUM),usingaK=2inclusionfactoranda95%confidenceleveltorepresenttheextendeduncertainty. project uncertainty standing-wavera- tio ±0.3 Gain,efficiency ±0.72dB ShanWan 7。TestData 7.1NetworkAnalyzerTest 7.2Standing-WaveRatio frequency/MHz 240224402480 voltagestanding-waveratio 2.74572.67232.3064 7.3GainandEfficiency frequency/MHz 240224102420243024402450246024702480 maximumgain/dBi -1.97-1.95-1.63-1.49-1.27-1.06-0.89-0.71-0.95 productiveness/% 17.8818.3419.2019.8920.5820.8621.7822.1821.03 7.4CircularityofDirection Diagram frequency/MHz 240224102420243024402450246024702480 HTheta=90/dB 20.5520.5720.1519.1218.9320.1120.4919.2616.51 ShanWan 7.5DirectionalDiag- ram (1)XZplane(unit:dBi) (2)Y-Zplane(unit:dBi): ShanWan (3)X-YPlane(Unit:DBi): (4)3DPatternat2470MHz(inDBi): -------------------------------------------------End------------------------------------------------ (Thefollowingisblank)

ReportNo.:CISRR25090807001 Page 41 of 65 6.TESTSETUPPHOTOS ConductedEmissionatACpowerline Radiatedbandedgeemission RadiatedSpuriousEmission(Above1GHz) ReportNo.:CISRR25090807001 Page 42 of 65 RadiatedSpuriousEmission(below1GHz)
