2BD57-SM009Engage Desk Display Unit

CMS Electracom

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 27, 2025
Application Purpose: Original Equipment
Equipment Note: Engage Desk Display Unit
Frequency Range: 2402.00000000 - 2480.00000000
Company: CMS Electracom
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SM009 User Manual This product uses the high-performance RK3562 chip in conjunction with the Debian 12 operating system to drive a 3.97-inch LCD screen for rich information display, and employs multi-color indicator lights to indicate the device's current status. It supports real-time information updates via WiFi and can connect to different devices via Bluetooth. Different card reader modules are supported. Details are as follows: SM009R: with non-HID RFID reader SM009H: with HID reader power supply : Input voltage: 100-240Vac Input frequency: 50-60Hz Rated output current: 2 A ( 10 W) Rated output voltage: 5 V (Type-C) Precautions - This product is suitable for non-tropical areas below 2000 meters above sea level. this product in environments with excessively high (<35°C) or low temperatures . Do not expose this product to strong sunlight, high temperatures , high humidity , or strong magnetic fields. - Prevent this product from being dropped or subjected to severe impact. - If this product gets wet with water or other liquids, please turn it off immediately and allow it to dry completely before use. this product with a wrung-out damp cotton cloth to avoid contact with other chemicals. FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

RF Exposure Info

Page 1 of 11 Report No.: AiTSZ-251010022FW5 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. RF Exposure evaluation Product Name : Engage Desk Display Unit Brand Name : CMS Model : SM009 Series Model : SM009R, SM009H FCC ID : 2BD57-SM009 Applicant : CMS Electracom Address : 24 Binney Road, Kings Park, NSW 2148, Australia Manufacturer : Levinko Technology Limited Address : Floor 4, Building 5, Xinhaosheng Industrial Park, Yonghe Road, Heping Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China. Standard(s) : 47CFR §1.1310, 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt : Oct. 10, 2025 Date of Test : Oct. 10, 2025~ Oct. 21, 2025 Issued Date : Oct. 22, 2025 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Aalen.Ye Allen Wang Page 2 of 11 Report No.: AiTSZ-251010022FW5 Report Revise Record Report Version Issued Date Notes M0 Oct. 22, 2025 Initial Release Page 3 of 11 Report No.: AiTSZ-251010022FW5 Contents 1 GENERAL INFORMATION .......................................................................................................................................... 4 1.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 4 1.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 6 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 6 2 METHOD OF MEASUREMENT ................................................................................................................................... 7 2.1 APPLICABLE STANDARD.................................................................................................................................................. 7 2.2 LIMIT ......................................................................................................................................................................... 7 2.3 MPE CALCULATION METHOD ......................................................................................................................................... 8 2.4 ANTENNA INFORMATION ............................................................................................................................................... 8 2.5 MANUFACTURING TOLERANCE ........................................................................................................................................ 8 2.6 MPE RESULT ............................................................................................................................................................. 11 2.7 CONCLUSION ............................................................................................................................................................. 11 Page 4 of 11 Report No.: AiTSZ-251010022FW5 1 GENERAL INFORMATION 1.1 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 25°C Relative Humidity: 55 % Air Pressure: 101 kPa 1.2 General Description of EUT Product Name: Engage Desk Display Unit Model/Type reference: SM009 Serial Model: SM009R,SM009H Model difference: All models are same as the samples except model name, all the models are electrical identical same mechanical structure and design. Power Supply: DC 5.0V 2A Hardware Version: V1.1 Software Version: Debain 12 Sample(s) Status: AiTSZ-251010022-1(Normal sample) AiTSZ-251010022-2(Engineer sample) Bluetooth : Supported type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: PCB antenna Antenna gain: 3.0dBi Bluetooth LE: Supported type: Bluetooth LE 1M/2M Modulation: GFSK Operation frequency: 2402MHz~2480MHz Channel number: 40 Channel separation: 2MHz Antenna type: PCB antenna Antenna gain: 3.0dBi 2.4G WIFI: Supported type: 802.11b/g/n(HT20)/n(HT40)/ax(HE20)ax(HE40) Modulation: 802.11b: DSSS 802.11g/n(HT20)/(HT40):OFDM Page 5 of 11 Report No.: AiTSZ-251010022FW5 802.11ax(HE20)ax(HE40) :OFDMA Operation frequency: 802.11b/g/n(HT20)/ax(HE20): 2412MHz~2462MHz 802.11n(HT40)/ax(HE40):2422MHz~2452MHz Channel number: 802.11b/g/n(HT20)/ax(HE20): 11 802.11n(HT40)/ax(HE40):7 Channel separation: 5MHz Antenna type: PCB antenna Antenna gain: 3.0dBi 5G WIFI: Supported type: 20MHz system 40MHz system 80MHz system 160MHz system 802.11a 802.11n 802.11ac 802.11ax 802.11n 802.11ac 802.11ax 802.11ac 802.11ax N/A Operation frequency: 5180-5240MHz 5745-5825MHz 5190-5230MHz 5755-5795MHz 5210MHz 5775MHz N/A Modulation: OFDM/OFDMA OFDM/OFDMA O…

Text truncated - open the document above for the full version.

Test Setup Photos

Page 1 of 2 FCC ID: 2BD57-SM009 Page 2 of 2 FCC ID: 2BD57-SM009

Test Report

Page 46 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 47 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 48 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 49 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 50 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 51 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 52 of 66 Report No.: AiTSZ-251010022FW3 5.2.2 CSE 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV Page 53 of 66 Report No.: AiTSZ-251010022FW3 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV Page 54 of 66 Report No.: AiTSZ-251010022FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 55 of 66 Report No.: AiTSZ-251010022FW3 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV Page 56 of 66 Report No.: AiTSZ-251010022FW3 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 57 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV Page 58 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV Page 59 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 60 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 61 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 62 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV Page 63 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV Page 64 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 65 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 66 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV

Test Report

Page 1 of 66 Report No.: AiTSZ-251010022FW3 Appendix RF test data for WIFI2.4G Page 2 of 66 Report No.: AiTSZ-251010022FW3 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) RU RU Pos T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11b SISO 2412 / / 12.227 22.244 54.97 2.60 0.00 2437 / / 12.224 22.244 54.95 2.60 0.02 2462 / / 12.223 22.246 54.94 2.60 0.02 802.11g SISO 2412 / / 2.033 14.440 14.08 8.51 2.81 2437 / / 2.033 2.150 94.56 0.24 3.27 2462 / / 2.033 2.253 90.24 0.45 4.58 802.11n (HT20) SISO 2412 / / 1.892 2.064 91.67 0.38 5.97 2437 / / 1.899 2.063 92.05 0.36 5.99 2462 / / 1.892 2.120 89.25 0.49 5.23 802.11n (HT40) SISO 2422 / / 0.932 1.094 85.19 0.70 7.67 2437 / / 0.932 1.142 81.61 0.88 7.71 2452 / / 0.932 1.161 80.28 0.95 5.34 802.11ax (HEW20) SISO 2412 SU / 1.462 1.624 90.02 0.46 5.29 2437 SU / 1.462 1.673 87.39 0.59 5.54 2462 SU / 1.462 1.637 89.31 0.49 3.60 802.11ax (HEW40) SISO 2422 SU / 0.763 0.915 83.39 0.79 11.19 2437 SU / 0.763 1.254 60.85 2.16 6.80 2452 SU / 0.763 0.933 81.78 0.87 11.73 Page 3 of 66 Report No.: AiTSZ-251010022FW3 1.2 Test Graph 1.2.1 Ant1 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 4 of 66 Report No.: AiTSZ-251010022FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 5 of 66 Report No.: AiTSZ-251010022FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 6 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 7 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 8 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 9 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 10 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 11 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 12 of 66 Report No.: AiTSZ-251010022FW3 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) RU RU Pos ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 / / 1 14.127 / Pass 2437 / / 1 14.234 / Pass 2462 / / 1 14.206 / Pass 802.11g SISO 2412 / / 1 19.843 / Pass 2437 / / 1 18.683 / Pass 2462 / / 1 18.696 / Pass 802.11n (HT20) SISO 2412 / / 1 19.573 / Pass 2437 / / 1 19.497 / Pass 2462 / / 1 19.515 / Pass 802.11n (HT40) SISO 2422 / / 1 37.523 / Pass 2437 / / 1 37.499 / Pass 2452 / / 1 37.456 / Pass 802.11ax (HEW20) SISO 2412 SU / 1 20.503 / Pass 2437 SU / 1 20.372 / Pass 2462 SU / 1 20.417 / Pass 802.11ax (HEW40) SISO 2422 SU / 1 39.741 / Pass 2437 SU / 1 39.835 / Pass 2452 SU / 1 39.483 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) RU RU Pos ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 / / 1 9.708 >=0.5 Pass 2437 / / 1 9.719 >=0.5 Pass 2462 / / 1 10.077 >=0.5 Pass 802.11g SISO 2412 / / 1 16.352 >=0.5 Pass 2437 / / 1 16.717 >=0.5 Pass 2462 / / 1 16.606 >=0.5 Pass 802.11n (HT20) SISO 2412 / / 1 17.782 >=0.5 Pass 2437 / / 1 17.770 >=0.5 Pass 2462 / / 1 17.772 >=0.5 Pass 802.11n (HT40) SISO 2422 / / 1 35.955 >=0.5 Pass 2437 / / 1 36.332 >=0.5 Pass 2452 / / 1 36.241 >=0.5 Pass 802.11ax (HEW20) SISO 2412 SU / 1 18.859 >=0.5 Pass 2437 SU / 1 18.978 >=0.5 Pass 2462 SU / 1 18.988 >=0.5 Pass 802.11ax (HEW40) SISO 2422 SU / 1 37.314 >=0.5 Pass 2437 SU / 1 37.710 >=0.5 Pass 2452 SU / 1 37.339 >=0.5 Pass Page 13 of 66 Report No.: AiTSZ-251010022FW3 2.2 Test Graph 2.2.1 OBW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 14 of 66 Report No.: AiTSZ-251010022FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 15 of 66 Report No.: AiTSZ-251010022FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 16 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 17 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 18 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 19 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 20 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 21 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 22 of 66 Report No.: AiTSZ-251010022FW3 2.2.2 6dB BW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 23 of 66 Report No.: AiTSZ-251010022FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 24 of 66 Report No.: AiTSZ-251010022FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 25 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 26 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 27 of 66 Report No.: AiTSZ-251010022FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 28 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 29 of 66 Report No.: AiTSZ-251010022FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _An…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 30 Report No.: AiTSZ-251010022FW2 Appendix RF test data for BLE Page 2 of 30 Report No.: AiTSZ-251010022FW2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 2.143 2.500 85.72 0.67 0.03 2440 2.144 2.501 85.73 0.67 0.03 2480 2.144 2.500 85.76 0.67 0.00 2M SISO 2402 1.087 1.875 57.97 2.37 0.02 2440 1.086 1.875 57.92 2.37 0.03 2480 1.087 1.875 57.97 2.37 0.03 Page 3 of 30 Report No.: AiTSZ-251010022FW2 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 4 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 5 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 6 of 30 Report No.: AiTSZ-251010022FW2 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 1.042 / Pass 2440 1 1.042 / Pass 2480 1 1.042 / Pass 2M SISO 2402 1 2.072 / Pass 2440 1 2.068 / Pass 2480 1 2.066 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.712 >=0.5 Pass 2440 1 0.702 >=0.5 Pass 2480 1 0.703 >=0.5 Pass 2M SISO 2402 1 1.271 >=0.5 Pass 2440 1 1.274 >=0.5 Pass 2480 1 1.276 >=0.5 Pass Page 7 of 30 Report No.: AiTSZ-251010022FW2 2.2 Test Graph 2.2.1 OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 8 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 9 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 10 of 30 Report No.: AiTSZ-251010022FW2 2.2.2 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 11 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 12 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 13 of 30 Report No.: AiTSZ-251010022FW2 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 0.76 <=30 Pass 2440 0.96 <=30 Pass 2480 1.15 <=30 Pass 2M SISO 2402 0.80 <=30 Pass 2440 1.00 <=30 Pass 2480 1.20 <=30 Pass Note1: Antenna Gain: Ant1: 3.00dBi; Page 14 of 30 Report No.: AiTSZ-251010022FW2 3.2 Test Graph 3.2.1 Power 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 15 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 16 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 17 of 30 Report No.: AiTSZ-251010022FW2 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit 1M SISO 2402 0.68 <=8 Pass 2440 0.88 <=8 Pass 2480 1.06 <=8 Pass 2M SISO 2402 0.51 <=8 Pass 2440 0.72 <=8 Pass 2480 0.89 <=8 Pass Note1: Antenna Gain: Ant1: 3.00dBi; Page 18 of 30 Report No.: AiTSZ-251010022FW2 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 19 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 20 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 21 of 30 Report No.: AiTSZ-251010022FW2 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 0.68 2440 1 0.87 2480 1 1.05 2M SISO 2402 1 0.50 2440 1 0.72 2480 1 0.90 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 0.68 -19.32 Pass 2440 1 0.87 -19.13 Pass 2480 1 1.05 -18.95 Pass 2M SISO 2402 1 0.50 -19.50 Pass 2440 1 0.72 -19.28 Pass 2480 1 0.90 -19.10 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 22 of 30 Report No.: AiTSZ-251010022FW2 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 23 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 24 of 30 Report No.: AiTSZ-251010022FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 25 of 30 Report No.: AiTSZ-251010022FW2 5.2.2 CSE 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV Page 26 of 30 Report No.: AiTSZ-251010022FW2 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV Page 27 of 30 Report No.: AiTSZ-251010022FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 28 of 30 Report No.: AiTSZ-251010022FW2 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV Page 29 of 30 Report No.: AiTSZ-251010022FW2 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 30 of 30 Report No.: AiTSZ-251010022FW2 6. Form731 6.1 Test Result 6.1.1 Form731 Lower Freq (MHz) High Freq (MHz) MAX Power (W) MAX Power (dBm) 2402 2480 0.0013 1.20

Test Report

Shenzhen Yingjiachuang Electronic Technology Co., Ltd. http://www.szsyjc.com 第 1 页共 11 页 Headquarters Address: Building C, Hongyu Guangming Valley, No. 11, Youmagang Road, Matian Street, Guangming District, Shenzhen City Dongguan Branch Factory: Yingjiachuang Industrial Park, No. 2, Yinhe 3rd Road, Shuishikou, Qiaotou Town, Dongguan City Hangzhou Office: Room 212, Building B, Dahua Jianghong International Innovation Park, No. 369, Internet of Things Street, Binjiang District, Hangzhou City Mianyang Office: No. 34, 4F, Wanxiang High-tech International, No. 35, Mianxing East Road, High-tech Zone, Mianyang City, Sichuan Province 电话：0755-27810060传真：0755-27810057网址：www.szsyjc.com CUSTOMER NAME 客户名称 CUSTOMER P/N 客户料号 C.G.5.8G-IPEX -YJC-15 PART NAME 品名 2.4G/5.8G 黑色 PCB 内置天线 L=150mm P/ N 料号 YJC-6N150-B32 APPROVAL REV. 版次 A1 DELIVERY DATE 送样日期 2022 年 11 月 21 日 PREPARED BY 承办吴佳雄 CHECKED BY 审核方文锋 APPROVED BY 核准肖汉深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 2 页共 11 页目录 1、封面··········································································1 2、目录··········································································2 3、履历表········································································3 4、天线平面图·································································4 5、天线技术参数及环境测试···············································5 6、环境性能测试······························································5 7、天线实物图····························································6 8、天线性能测试图···························································6 9、2D.3D（2.4G/5.8G）测试数据·······················································6-9 10、线材规格参数······························································10 11、ROHS物料控制报告···················································11 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 3 页共 11 页修订履历表：版本变更内容及更改原因日期发行 A0 初版发行 2020 年 03 月 06 日 A1 增加测试数据 2022 年 11 月 21 日深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 4 页共 11 页天线平面图：深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 5 页共 11 页天线技术参数及环境测试：电气技术参数电性能指标ElectricalSpecifications 频率范围2400-2500/5725-5850MHzFrequencyRange2400-2500/5725-5850MHz 电压驻波比＜1.92:1VSWR＜1.92:1 输入阻抗50ΩInputImpedance50Ω 方向全向DirectionAll 增益3dBiGain3dBi 机械指标MechanicalSpecifications 线材颜色黑色CableColorBlack 接口形式XDInputconnectorXD 线材长度150mmCablelength150mm 工作温度-20°C~+70°CWorkingTemperature-20°C~+70°C 工作湿度20%~80%WorkingHumidity20%~80% 环境性能测试: 项目测试条件规格储存环境在没有指定的情况下测试温度、湿度、气压如下： 1.温度为-20°C～+70°C 2.相对湿度为45%-85% 3.气压为86kpa-106kpa 电气机械性能正常高低温试验在70°C与-20°C之间进行5次循环，然后在正常条件下 1-2H，检查外观质量。尺寸应满足规定并应满足满足于机械、电气性能耐恒定湿热试验相对湿度95±3%，试验温度：40°C.持续2H作用后，试品取出后5min之内测定电气性能，试品在正常条件下1-2H，检查外观质量尺寸应满足规定并应满足满足于机械、电气性能振动试验振频范围10-55HZ，位移幅值：0.35MM，加速度幅值： 50.0M/S，扫频循环次数：30次电气机械性能正常跌落试验1M高空按照互相垂直的轴方向自由跌落3次电气机械性能正常深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 6 页共 11 页天线实物图和贴附位置图：天线性能测试图: 2D、3D测试数据(2.4G)： FrequencyEfficiency(%)Gain.(dBi) 2400MHz 53.72.71 2410MHz 54.582.49 2420MHz 54.082.52 2430MHz 522.76 2440MHz 49.892.74 2450MHz 50.35 3.0 2460MHz 49.662.3 2470MHz 50.932.79 2480MHz 50.582.47 2490MHz 54.952.7 2500MHz 53.72.92 天线贴附位置深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 7 页共 11 页 Phi02D图: Phi902D 图 Theta902D 图 3D2400 ： 3D2450 ： 3D2500 ：深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 8 页共 11 页 2D、3D测试数据(5.8G)： FrequencyEfficiency(%)Gain.(dBi) 5150MHz 54.423.0 5250MHz 56.222.83 5350MHz 55.312.45 5450MHz 53.682.41 5550MHz 51.382.14 5650MHz 54.572.27 5750MHz 55.772.71 5850MHz 55.922.33 Phi 0 2D图:Phi 90 2D图Theta 90 2D图 3D 515 0：深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 9 页共 11 页 3D5550： 3D5850：深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 10 页共 11 页产品规格ProductType1.13单银线结构图StructureDrawing 结构特性StructureCharacteristics 结构Structure项目Item标准值StandardValue 内导体 InnerConductor 材质Material镀银铜线Silverplatedcopperwire 构成(根/mm/Composition(No./mm) 7/0.08±0.005 标称外径Nom.Dia(mm)Φ0.24±0.01 绝缘层 Insulation 材质Material聚全氟乙丙烯/FEP 标称外径Nom.Dia(mm)Φ0.7±0.03 外导体 OuterConductor 材质Material镀锡铜线Tinnedcopper 形式From编织/Weaving 遮蔽率/Shieldingrate≧90% 标称外径Nom.Dia(mm)Φ0.92±0.03 护套 Jacket 材质Material聚全氟乙丙烯/FEP 标称外径Nom.Dia(mm)Φ1.13±0.05 电气性能ElectricalCharacteristics 项目Item 标准值 StandardValue 项目Item 频率 Frequency 标准值 StandardValue 阻抗Impedance（Ω）50±3 衰减 Attenuation@20 °C (dB/100m) 1GHz ≤2.23 电容Capacitance(pF/m)98 2GHz ≤3.15 抗拉强度 Tensilestrengthkgf/mm² 1.76 3GHz ≤3.96 驻波比VSWR ≤1.40@0-6GHz GHz 4GHz ≤4.6 耐压强度 DielectricStrength（A.CV/1min) 1000 5GHz ≤5.15 最大工作频率（MHz） Max.oper.frequency 6000 6GHz ≤5.7 可靠性Dependability 最小弯曲半径(单次)Min.BendingRadius/Singlemm4 最小弯曲半径（重复）Min.BendingRadius/Repeatedmm8 工作温度范围OperatingTemperature°C-20~+80 包装Packing 包装方式PackingMode1000（m/盘）成卷Reel 使用提示TripsforUse 存储环境StorageEnvironment温度：30°C以下，湿度：20-65% 铁氟龙收缩 TeflonShrink 绝缘层收缩≦0.2mm；护套层收缩≦0.3mm 加工温度 Processingtemperature 250°C~260°C的情况下，可短时间承受；300°C以上会出现热分解现象最佳保存周期 Thebestsavecycle 2个月，2个月以上锡效果变差,但电性能不受影响，夏季高温高湿环境开剥后需尽快流转深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 11 页共 11 页 ROHS物料控制报告兹证明向貴司交货的零組件、辅助材料所使用的原材料、以及生产工程中的添加剂等均符合RoHS限制使用有害物质指令的环保要求（RoHS指令 2011/65/EC) 关于零组件、辅助材料所使用的原材料、包装材料以及和产过程中使用的添加剂等的构成成份报告如下：组成物料名称Component /PartName 组成材料 Material Composition ICP报告编号 ICPreport# 测试机构 Test Org. 测试时间 TestDate 有害物质含量(ppm) 是否合格? PASS? CdPbHgCr 6+ PBBPBDEPASS PCBPCBCANEC2202816806SGS22/03/08ND8NDNDNDNDPASS 端子铜CANEC2201952008SGS22/02/18ND5NDNDNDNDPASS 金镀层A2220404860101001CCTI22/09/17NDNDNDNDNDNDPASS 胶芯A2220046361101002ER1SGS22/02/22NDNDNDNDNDNDPASS 线材 RG/RF系列同轴线缆 SZXEC2202766604SGS22/08/18NDNDNDNDNDNDPASS 环保锡丝环保锡丝SHAEC2206174502SGS22/06/13ND181NDNDNDNDPASS 双面胶EVA发泡胶CANEC2124348308SGS22/01/04ND8NDNDNDNDPASS

Test Report

Page 1 of 27 Report No.: AiTSZ-251010022FW3 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : Engage Desk Display Unit Brand Name : CMS Model : SM009 Series Model : SM009R, SM009H FCC ID : 2BD57-SM009 Applicant : CMS Electracom Address : 24 Binney Road, Kings Park, NSW 2148, Australia Manufacturer : Levinko Technology Limited Address : Floor 4, Building 5, Xinhaosheng Industrial Park, Yonghe Road, Heping Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China. Standard(s) : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Receipt : Oct. 10, 2025 Date of Test : Oct. 10, 2025~ Oct. 21, 2025 Issued Date : Oct. 22, 2025 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chon…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Andrew Peninton

[email protected]Fax: .

Test Firm

Guangdong Asia Hongke Test Technology LimitedDarren Ding

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.30 mW
2	15C	2.41 GHz - 2.46 GHz	33.40 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device supports 802.11b, 802.11g, 802.11n and 802.11ax with a 20 MHz and 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
