LITE BT MEC LITE DRIVER MODULE RADIO FREQUENCY & BLUETOOTH RECEIVER Manuale d’uso User manual Benutzerhandbuch Manuel de l’Utilisateur Manual de usuario 035FIS24 2 035-FIS24 - LITE BT MODULE AVVERTENZE WARNINGS  WARNHINWEISE  AVERTISSEMENTS  ADVERTENCIAS IT - ATTENZIONE: la sicurezza dell’apparecchio è garantita solo con l’uso appropriato delle seguenti istruzioni; pertanto è necessario conservarle. L’installazione deve essere eseguita esclusivamente da personale tecnico qualificato nel rispetto delle normative elettriche e delle norme di sicurezza vigenti. Tutti i collegamenti devono essere eseguiti, servendosi di cavi adeguati, in assenza di tensione elettrica. L&S non risponde degli eventuali danni alle persone, agli animali domestici e alle cose causati da operazioni effettuate in modo non conforme alle norme vigenti sul collegamento elettrico. • L’apparecchio non deve essere manomesso in alcun modo, le uniche operazioni ammesse sono quelle indicate dall’istruzioni d’uso. Il prodotto non contiene parti riparabili dall’utente: in caso di guasti il prodotto deve essere sostituito esclusivamente dal costruttore o dal servizio assistenza. • Solo per uso interno: non posizionare vicino a fonti di calore. Tenere fuori dalla portata dei bambini. • Utilizzare un alimentatore elettronico per modulo LED di tipo indipendente protetto contro il cortocircuito e il sovraccarico, con uscita a bassissima tensione di sicurezza SELV conformi agli standard EN 61347-2-13. NOTA (per USA e CANADA): utilizzare esclusivamente alimentatori in CLASSE 2. Gli alimentatori elettronici che L&S utilizza sono Plug&Play. Ogni altra connessione alla linea principale (alimentatori diversi da quelli forniti da L&S, alimentatori L&S modificati) va verificata con un elettricista qualificato. EN - WARNING: the safety of the device is guaranteed only if it is used in compliance with these instructions that must be kept in a safe place. The installation must be carried out exclusively by qualified technical personnel in compliance with the electrical regulations and safety regulations in force. All connections must be made, using suitable cables, in the absence of electrical voltage. L&S cannot be held liable for any injury to persons or pets or damage to property due to work that is not in conformity with current regulations regarding electrical connection. • The device must not be tampered in any way what so ever; no operations other than those indicated in the instructions for use are allowed. The product does not contain any parts that should be repaired by the user: in the event of failures, the product must be replaced exclusively by the manufacturer or the assistance service. • For indoor use only: keep away from heat sources. Keep out of childrens reach • Use an electronic independent type driver for LED module protected against short-circuits and overload, with low voltage SELV safety output in compliance with EN 61347-2-13 standards NOTE (for USA and CANADA): USE ONLY WITH CLASS 2 POWER UNIT. L&S drivers are Plug and Play. All other connections to the primary line voltage (via drivers which are NOT supplied by L&S or those which have been modified) must be verified with a qualified electrician. DE - ACHTUNG: die Sicherheit des Geräts ist nur im Falle eines sachgemäßen Gebrauchs, unter Einhaltung der nachstehend aufgeführten Anweisungen gewährleistet. Die Installation darf nur von qualifiziertem Fachpersonal unter Beachtung der geltenden Elektro- und Sicherheitsvorschriften durchgeführt werden. Alle Anschlüsse müssen mit geeigneten Kabeln in Abwesenheit von elektrischer Spannung vorgenommen werden. L&S haftet nicht für Personen-, Tier- und Sachschäden, die durch Arbeiten befugten Personals aber unter Nichtbeachtung der geltenden. Das Gerät darf in keiner Weise verändert werden, die einzig zulässigen Vorgänge sind in der Gebrauchsanleitung beschrieben. Das Produkt enthält keine vom Benutzer zu reparierenden Teile: bei Störungen darf das Produkt ausschließlich vom Hersteller oder dem Kundendienst ersetzt werden. • Nur für Innenbereiche: von Wärmequellen fernhalten. Das Gerät außer Reichweite von Kindern halten. • Netzgerät für das LED-Modell vom unabhängigem Typ verwenden, gegen Kurzschluss und Überbelastung geschützt, mit einem Ausgang mit sehr niedriger SELV- Schutzspannung entsprechend den Standard EN 61347-2-13. HINWEIS (für USA und KANADA): VERWENDEN SIE HUR NETZGERÄTE IN KLASSE 2. Die elektronischen Netzgeräte, die L&S verwendet, arbeiten mit Plug&Play. Jeder andere Anschluss an die Hauptleitung (Netzgeräte, die sich von den von L&S gelieferten unterscheiden, veränderte Netzgeräte von L&S) muss durch einen Fachelektriker geprüft werden. 3 035-FIS24 - LITE BT MODULE AVVERTENZE WARNINGS  WARNHINWEISE  AVERTISSEMENTS  ADVERTENCIAS FR - ATTENTION: La sécurité de l’appareil n’est garantie que si les instructions ci-après sont parfaitement respectées ; il est donc impératif de conserver soigneusement la notice. L’installation ne doit être effectuée que par du personnel technique qualifié, conformément aux normes électriques et de sécurité en vigueur. Toutes les connexions doivent être effectuées, à l’aide de câbles appropriés, en l’absence de tension électrique L&S ne répondra pas des éventuels dommages sur les personnes, les animaux domestiques et les biens, provoqués par des opérations effectuées de manière non conforme aux normes en vigueur en matière de branchement électrique. • L’appareil ne doit être altéré en aucune manière, les seules opérations admises sont celles indiquées dans le mode d’emploi. Le produit ne contient aucune pièce à réparer par lutilisateur: en cas de panne, lle produit doit être remplacé exclusivement par le fabricant ou le service d’assistance. • Réservé à un usage interne: tenir à l’écart des sources de chaleur. Gardez l’appareil hors de portée des enfants. • Utiliser un alimentateur électronique pour module LED de type indépendant protégé contre les courts-circuits et les surchar…
