2BDDO-0910Laser Level

Bu Xiyue(Shanghai) industrial.,Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 19, 2023
Application Purpose: Original Equipment
Date of Application: Nov 19, 2023
Equipment Note: Laser Level
Frequency Range: 2402.00000000 - 2480.00000000
Company: Bu Xiyue(Shanghai) industrial.,Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Product instructions Improper use leading to human damage Damage due to improper transportation after sale Damage caused by failure to use the original accessories of the company as required Any selfmodified, disassembled and repaired product Replacement of wear parts Any natural wear During the warranty period, the following situations are not covered by the warranty V. common problems VI. Safety precautions 1. After the receiving switch is turned on, the blisters backlight will flash, which is a working signal indicating that it is in the receiving state, which is a normal phenomenon; 2. The laser line flashes to prove that the machine is not in the setting range, please adjust the level through the legs; 3.The laser line appears blurred. Please wipe the outer glass with a clean cotton cloth. 1. Because of Laser radiation should not look directly at the laser beam; 2. Class 2 laser crystal, harmless to human body; 3. Strictly forbidden to heavy press or vibrate; 4. The product shall be placed in the warehouse with ventilation, drying, heat-insulated and fireproofing, and it is strictly prohibited to contact with corrosive materials; 5. Loading, unloading and use of products shall be handled gently, and shall not be thrown or dropped; 6. Quality inspection certificate and packing list are attached in the packing box. VII. Daily maintenance and attentions 1. Daily maintenance 1) Please store the machine in a dry, ventilated, constant temperature and dust-free place; 2) please wipe the shell glass frequently to ensure the light transmission; 3) when not in use for a long time, please release the locking switch for half an hour regularly to ensure that the bearing swings flexibly. 2. Attentions 1) non professionals, do not disassemble the machine; 2) please avoid severe vibration, collision and falling of the machine; 3) please pay attention to lock the locking switch after use; 4) do not leave the battery in the machine to avoid leakage of battery liquid; 5) do not look directly at the laser line. It should be used with protective glasses; 6) do not wipe the instrument with organic solvent. Certificate Name Examiner ModelDate No. User manual Product instructions User save copy (please save this part properly) Warranty Card The user must present a copy of the card and an official invoice at the time of warranty to confirm your warranty. service. Receipt (please fill it in and send back) To ensure that you can enjoy the above warranty service, please fill in all forms and send the "receipt" back to our company within 7 days, which will take effect on the date of receiving the receipt! Please note that the conditions listed on the back are not guaranteed. User name Mr./Ms. Age Name of the work unit Occupation Student Worker Woodworking Metalworking Concreteworking Renovation Hardware Hydropower Engineering Others Address Province City Road / Street No. Zip code Tel. Fax Mobile phone Product number Date of purchase Invoice receipt number Purchase company name Purchaser's address Purchaser's phone Purchaser's seal User name Mr./Ms. Age Name of the work unit Occupation Student Worker Woodworking Metalworking Concreteworking Renovation Hardware Hydropower Engineering Others Address Province City Road / Street No. Zip code Tel. Fax Mobile phone Product number Date of purchase Invoice receipt number Purchase company name Purchaser's address Purchaser's phone Purchaser's seal Product instructionsProduct instructionsProduct instructions Instrument specifications Laser ray Laser ray 360° X 3 12 lines (30) 360° X 4 16 lines (40) Wavelength 650nm, red light Wavelength 515nm, blue light Wavelength 532nm, green light Red light working temperature: -20°C~ 50°C (requires a personalized custom) Horizontal / vertical accuracy: ± 0.2mm / 10m Automatic leveling range: ±3 Waterproof grade: IP-54 Working range: about 25m in diameter Working time: about 5 hours Green light working temperature: -5°C~ 50°C Blue light working temperature: -20°C~ 50°C Laser schematic3D omnidirectional ground and wall sticker Safety Precautions 1. Because of Laser radiation should not look directly at the laser beam; 2. Class 2 laser crystal, harmless to human body; 3. Forbidden to heavy press or vibrate; 4. The product shall be placed in the warehouse with ventilation, drying, heat-insulated and fireproofing, and it is strictly prohibited to contact with corrosive materials; 5. Loading, unloading and use of products shall be handled gently, and shall not be thrown or dropped; Daily maintenance and attentions 1. Daily maintenance 1) Please store the machine in a dry, ventilated, constant temperature and dust-free place; 2) please wipe the shell glass frequently to ensure the light transmission; 3) when not in use for a long time, please release the locking switch for half an hour regularly to ensure that the bearing swings flexibly. 2. Attentions 1) check whether the horizontal line and vertical line are accurate before each use, otherwise the construction loss caused by inaccurate laser line has nothing to do with our company; 2) non professionals, do not disassemble the machine; 3) please avoid severe vibration, collision and falling of the machine; 4) please pay attention to lock the locking switch after use; 5) do not wipe the instrument with organic solvent. Functions and features Functions: 1. The machine is inclined for 3° and automatically leveled; 2. Alarm function beyond the safe range; 3. The magnetic damping compensation system ensures fast leveling time; 4. 360° rotatable base, and equipped with fine adjustment mechanism, can make the machine quickly find the target; 5. It can be used with tripod to adjust the working height of the machine. Features: 1. A 360° horizontal line can be drawn on the wall; 2. Two 360° vertical lines can be drawn on the wall; (the 2D model has only one 360° vertical line) Instructions 1) Place the instrument on the tripod, T-type wall mounting bracket or lifting platform as needed; 2) Push the …

Text truncated - open the document above for the full version.

Cover Letter(s)

Sincerely, Name/Title： Hu Wang/CEO Company: Bu Xiyue(Shanghai) industrial.,Ltd Address: 3F/4F,Building 2, No 598 Guanghua Road Minhang District Shanghai China Phone: 18918090714 Fax: N/A E-Mail: [email protected]

External Photos

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202311108 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 4 Product Name: Laser Level Model No.: BL3001 EUT Constructional Details External Photo Report No.: HTT202311108 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 4 Report No.: HTT202311108 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 4 Report No.: HTT202311108 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 4 ------End------

ID Label/Location Info

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BDDO-0910

Internal Photos

RF Exposure Info

RF Exposure evaluation FCC ID: 2BDDO-0910 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 4.0 4.0 4.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 5.0 3.1623 0.9899<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

Test Report

Antennaspecification APPlications ※BluetoothHomeRF ※ISMband2.4GHzapplications 1.Dimensions 2.Specifications numberItemSpecifications 1WorkingCentralFrequency2441MHz 2BandWidth(2402-2480)MHz 3Gain0dBi 4VSWR≤2.0 5AntennatypePCBantenna 6AzimuthBeamwidthOmni‐directional 7Impedance50ohm 8ModulationmodeGFSK ‣CompanyName : ‣ Companyaddres Nantong Otara Import and Export Trading Co., Ltd. s : 221 Tonglv Road, Qidong, Nantong, Jiangsu Province, China 3.simulationparameter ①VSWR Mkr1:2397MHz1.47Mkr2:2450MHz1.51Mkr3:2482MHz1.59 ②SmithChar Mkr1:2397MHz73.4Mkr2:2450MHz62.7Mkr3:2482MHz66.8 ③ReturnLoss Mkr1:2397MHz-15Mkr2:2450MHz-18Mkr3:2482MHz-16 ④SmithChar Mkr1:2400MHz1.234Mkr2:2500MHz1.051Mkr3:2600MHz1.322 ⑤ReturnLoss Mkr1:2400MHz-19.59Mkr2:2450MHz-27.70Mkr3:2500MHz-31.97Mkr4: 2550MHz-21.83 ` ⑥Phase Mkr1:2400MHz-54.89Mkr2:2500MHz-82.03Mkr3:2600MHz-102.6 4.RadiationPattems XY-plane XZ-plane YZ-plane  3DRadiationpattern

Test Report

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202311108F01 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 TEST Report Applicant: Bu Xiyue(Shanghai) Industrial Co.,Ltd. Address of Applicant: 3F/4F, Building 2, No. 598 Guanghua Road, Minhang District, Shanghai, China Manufacturer : Nantong Otara Import and Export Trading Co., Ltd. Address of Manufacturer : 221 Tonglv Road, Qidong, Nantong, Jiangsu Province, China Equipment Under Test (EUT) Product Name: Laser Level Model No.: BL3001 Series model: BL2001, BL5001, BL800G, BL3002, BL5002, BL2003, BL3003, BL5003, BL200G, BL300G, BL500G, BL-D112G, BL-D116R, BL-D116G, BL-D112R-F, BL-D112G-F, BL-D112R, BL-D212R, BL1200 Trade Mark: N/A FCC ID: 2BDDO-0910 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Nov. 06, 2023 Date of Test: Nov. 06, 2023~Nov. 10, 2023 Date of report issued: Nov. 10, 2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202311108F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 30 1. Version Version No. Date Description 00 Nov. 10, 2023 Original Tested/ Prepared By Date: Nov. 10, 2023 Project Engineer Check By: Date: Nov. 10, 2023 Reviewer Approved By : Date: Nov. 10, 2023 Authorized Signature Report No.: HTT202311108F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 30 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 8 6. TEST RESULTS AND MEASUREMENT DATA ............................................................................................ 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED OUTPUT POWER .................................................................................................................. 12 6.3. CHANNEL BANDWIDTH ............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 15 6.5. BAND EDGES ........................................................................................................................................... 17 6.5.1 Conducted Emission Method .......................................................................................................... 17 6.5.2 Radiated Emission Method ............................................................................................................. 18 6.6. SPURIOUS EMISSION ................................................................................................................................ 20 6.6.1 Conducted Emission Method .......................................................................................................... 20 6.6.2 Radiated Emission Method ............................................................................................................. 22 6.7. ANTENNA REQUIREMENT .......................................................................................................................... 29 7. TEST SETUP PHOTO .................................................................................................................................. 30 8. EUT CONSTRUCTIONAL DETAILS ...........…

Text truncated - open the document above for the full version.

Test Setup Photos
