2BDHG-Q1carplay

CP/AA-WiFi Box Manual Device name: carplay Product specifications Model :Q1 Voltage: 5V Current: 210mA Working temperature: 28° Support temperature : -25-8 Contains: one equipment, one Type C cable, one Manual, one package Function Convertthe originalcar wired CarPlay/AndroidAutoto wireless CarPlay/AndroidAuto. Instructions 1. Insertthis productinto the USBport of the originalcar , turn on the Bt of your iPhone,searchfor devicename,and connectsmartBox-xxxx,,agreeto pairing,realizethe CarPlayfunctionof the productunderthe promptsand guidanceof your i Phone. 2. Insertthis productinto the USBport of the originalcar , turn on the Bt of your SmartPhone,searchfor devicename, and connectsmartBox-xxxx,,agreeto pairing,realizethe AndroidAuto functionof the productunderthe promptsand guidanceof your smart phone. l. Beforeconnecting,pleasemakesure that the Bt and WiFiof the mobile phoneare not connectedto other devices.If thereis a connection,please disconnectthe Bt and WiFiof other deviceson the mobilephone.Before changingthe mobilephoneconnection, pleaseturn of f the WIFIand Bt of the mobilephonethat has beenconnected to the devicebefore. 2.Restartthe iPhone. 3. If WiFiand Bt are connectingto otherdevices,pleaseignorethe Bt and WIFIof otherdeviceson the mobile phone,and connectthe Bt and WiFiof our device,If you can'tconnect,please ignorethe Bt nameof this product,and keepthe Bt of f for 5 seconds,and then reconnectto the Bt. 4. The deviceWiFidoesnot needto entera password.The backup passwordis1 2345678.maybesome versionneedto enterthe WiFi password.If the passwordis not enteredor the WiFiis occupiedby otherdevices,the connectionwill not succeed. 5. If the connectionis unsuccessful, pleaseunplugthe box and try again. 6. This productdoesnot supportall originalcars with wired CarPlay/AndroidAutofunction 7. The USBwire of this producthas beenupdated,but it is possiblethat usingthe productin a special environmentwill causeCarPlay /AndroidAutoto disconnect(Suchas the phoneheatsup,causing disconnectionor experience degradation) 8. The sourceof the networkdata (includingnetworkcontentsuchas audioand videodata,map data,call data,etc.) generatedby this function has not hing to do with this product 9. If you are in the processof connecting,the mobilephonepopsup "AllowCarPlay/AndroidAuto"and you select"Later",the connectionwill not be successful,you needto select "devicename"on the mobilephone "General"- "CarPlay/AndroidAuto"- "CarPlay/AndroidAuto"open lO.T o turn of f the CarPlay/Android Auto,youneedto disconnectthe Bt and WiFiof the deviceon the mobile phone,Orunplugthe box 10. If thereis a problemwith the connection,pleaserestartthe car or restorethe factorysettingsof the car 11. If the wirelessCarPlay/Android Autofunctionis usedundernormalor specialenvironment,and the other partycan not hearclearlyor has an echowhenreceivingand receiving calls,pleaseturn on the handsfree of the mobilephone 12. Due to the limitationof the wireless function,theremay be a delayin the audiodatacomingout of the speaker duringuse, that is, thereis a delayin the soundplayedby the speaker,or thereis a delayin the squarecontrol. 13. Afterthe CarPlay/AndroidAuto connectionis successful,the Bt of the mobilephonewill be disconnectedfrom our device.Atthis time,if the Bt of the mobilephoneis connectedto other audiodevices,the soundwill not come fromthe originalcar speaker 14. The wirelessCarPlay/AndroidAuto functionmay not be enabledwhenthe car is startedagain.At this time,you can re-establishthe connectionby pluggingand unpluggingthe box Article (1 )(3 ) abovecomplieswith someFCC directives Onlineproductupgrademethod Connectto CarPlayor poweron the device5V, iPhoneto the deviceWiFi, the WiFipasswordis 12345678 Please enterthe URLin the Applephone browser: 192.1 68.3 .9 4 Note : Pleasedo not powerof f duringthe upgrade process,if the productcan be used normally, pleasedo not upgrade. After the upgradeis successful,thedevice WiFinamewill change.Oryou can checkand learnaboutdownloadingthe latestsoftware.Ifthereis a problem with the product,youcan give us feedback. Notice Equipmentinterference exemption The mainfunctionsof this productmay be subjectto electromagnetic interferencefromsomeautomobiles, causingpartialdataloss or small electromagneticsounds Riskinfringementexemption: This productis not an Apple product,Therisk of traf fic safetyand infringement(includingbrand, technology, networkcontentsource) and otherrisksarisingfromthe use of this producthas nothingto do with the company. Lossoffunctionexemption: Basedon the defectsof iOS itselfor improperupgradeof the mobilephone (includingbut not limitedto jailbreak)or dif ferencesin mobilephoneequipment of variousmodelsor regional dif ferences,or improperoperationor improperoperationof the originalcar and vehiclesystem,or improper upgradeof this product,it may cause the experienceof this product.Decline or loss of function(partiallyor completely). Devicedisconnectionexemption: This productmay causethe disconnectionphenomenonduringuse, suchas the connectiontime is too long or the connectiondisconnection problemof the originalcar'swired CarPlay/AndroidAutoitself.This phenomenonis af fectedby external conditionsor the environment.Impact, This producthas beenoptimized,that is, whenit detectsa disconnection,the deviceimmediatelyRebootor Manually plug and unplugthe box. Usernotice Usersshouldcomplywith safety, complianceand legalityduringuse. Combinedwith its own premises,the actualactionsor factsof usingor not usingthe productare generate Disclaime Suchas actionsor factscausedby the user'suse or non-useof the product,or securityriskscausedby the use of the product,or infringementcausedby the use of this product,or legalriskssuch as intrusionor damageto the computer informationsystemcausedby the use of the product,or The use of this productinfringesthe intellectual propertyrightsof othersor the trade marksof others,the developerof this productor the copyrightownerof this productor the compan…

Text truncated - open the document above for the full version.

SHENZHEN LESHIDA ELECTRONICS CO., LTD. 501,Building A1,Weiye Innovation Industrial Zone Nanchang Baoyuan Road, Nanchang Community Xixiang Street, Baoan District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-16 To whom it may concern: We, SHENZHEN LESHIDA ELECTRONICS CO., LTD., hereby certify that the equipment for which authorization is sought (FCC ID: 2BDHG-Q1) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature liying lan Manager SHENZHEN LESHIDA ELECTRONICS CO., LTD. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Shenzhen Leshida Electronics Co., Ltd 501, Building A1, Weiye Innovation Industrial Zone, Nanchang BaoyuanRoad, Nanchang Community, Xixiang Street, Bao'an District, Shenzhen,China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/07/10 U.S. Agent Designation Shenzhen Leshida Electronics Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BDHG-Q1): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Shenzhen Leshida Electronics Co., Ltd Shenzhen Leshida Electronics Co., Ltd with the FRN [0034448928] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature liying lan General Manager Shenzhen Leshida Electronics Co., Ltd Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

SHENZHEN LESHIDA ELECTRONICS CO., LTD. Add: 501,Building A1,Weiye Innovation Industrial Zone Nanchang Baoyuan Road, Nanchang Community Xixiang Street, Baoan District, Shenzhen China Date: 2024-7-16 FCC ID: 2BDHG-Q1 Dear Sir/Madam, We, SHENZHEN LESHIDA ELECTRONICS CO., LTD. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: carplay Model no.: Q1, Q1S, Q1D, Q1M, Q2, Q2S, Q2D, Q2M, A11, A11S, A11M, A11D, T11, T11S, T11D, T11M, G8, Q8S, G6225, G6225S, G8M, Q1B, Q1BS, Q1BC, Q1BM, Q1BG, Q1BZ, Q1Y, Q1A, Q1F, Q1J, Q1H, Q1K, Q1P, Q1X, Q1L, Q2Y, Q2F, Q2X, Q2H, Q2K, Q2P, Q2M Sincerely, Name/Title： liying lan/Manager Company: SHENZHEN LESHIDA ELECTRONICS CO., LTD. Address: 501,Building A1,Weiye Innovation Industrial Zone Nanchang Baoyuan Road, Nanchang Community Xixiang Street, Baoan District, Shenzhen China Phone: 15172321362 Fax: N/A E-Mail: [email protected]

SHENZHEN LESHIDA ELECTRONICS CO., LTD. 501,Building A1,Weiye Innovation Industrial Zone Nanchang Baoyuan Road, Nanchang Community Xixiang Street, Baoan District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-16 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BDHG-Q1 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： liying lan/Manager Company: SHENZHEN LESHIDA ELECTRONICS CO., LTD. Address: 501,Building A1,Weiye Innovation Industrial Zone Nanchang Baoyuan Road, Nanchang Community Xixiang Street, Baoan District, Shenzhen China Phone: 15172321362 Fax: N/A E-Mail: [email protected]

FCC ID: 2BDHG-Q1 External Photos of the EUT FCC ID: 2BDHG-Q1 FCC ID: 2BDHG-Q1

Label and Location Size: L: 1.0cm*W: 0.2cm Label and Location FCC ID : 2BDHG-Q1

FCC ID: 2BDHG-Q1 Internal Photos of the EUT FCC ID: 2BDHG-Q1 FCC ID: 2BDHG-Q1 ANT

RF Exposure evaluation FCC ID: 2BDHG-Q1 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information L4K1 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BT/2.4GWIFI / PCB antenna 0.72dBi for 2400-2500MHz; 5. Manufacturing Tolerance BT GFSK(Peak) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 0.0 0.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 00 Channel 39 Channel 78 Target (dBm) -2.0 -1.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK (Peak) Channel Channel 00 Channel 39 Channel 78 Target (dBm) -2.0 -1.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 WIFI(Peak) Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 14.0 15.0 15.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 13.0 14.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 13.0 14.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2422 2437 2452 Target (dBm) 13.0 14.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 0.72dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BT 2.0 1.5849 0.72 1.1803 0.0004 1.0000 2.4GWIFI 16.0 39.8107 0.72 1.1803 0.0094 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type PCB antenna Model Q1 Frequency range 2400-2500MHz Manufacturer Shenzhen QianYao Electronic Co., Ltd ANT Peak Gain 0.72 dBi 2. Antenna Photo: Length: 17.9mm Width: 5.68mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA24062800901 2BDHG-Q1 Compiled by ( position+printed name+signature) . : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) . : Project Engineer Xudong Zhang Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jul. 04, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Shenzhen Leshida Electronics Co., Ltd Address ............................................ : 501, Building A1, Weiye Innovation Industrial Zone, Nanchang Baoyuan Road, Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : carplay Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Leshida Electronics Co., Ltd Model/Type reference ...................... : Q1 Listed Models .................................. : Q1S, Q1D, Q1M, Q2, Q2S, Q2D, Q2M, A11, A11S, A11M, A11D, T11, T11S, T11D, T11M, G8, Q8S, G6225, G6225S, G8M, Q1B, Q1BS, Q1BC, Q1BM, Q1BG, Q1BZ, Q1Y, Q1A, Q1F, Q1J, Q1H, Q1K, Q1P, Q1X, Q1L, Q2Y, Q2F, Q2X, Q2H, Q2K, Q2P, Q2M Modulation ....................................... : GFSK, Π/4DQPSK, 8DPSK Frequency ......................................... From 2402MHz to 2480MHz Rating ............................................... : DC 5.0V From external circuit Result ............................................... : PASS Report No.: CTA24062800901 Page 2 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : carplay Model /Type : Q1 Listed Models : Q1S, Q1D, Q1M, Q2, Q2S, Q2D, Q2M, A11, A11S, A11M, A11D, T11, T11S, T11D, T11M, G8, Q8S, G6225, G6225S, G8M, Q1B, Q1BS, Q1BC, Q1BM, Q1BG, Q1BZ, Q1Y, Q1A, Q1F, Q1J, Q1H, Q1K, Q1P, Q1X, Q1L, Q2Y, Q2F, Q2X, Q2H, Q2K, Q2P, Q2M Applicant Shenzhen Leshida Electronics Co., Ltd Address : 501, Building A1, Weiye Innovation Industrial Zone, Nanchang Baoyuan Road, Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, China Manufacturer : Shenzhen Leshida Electronics Co., Ltd Address : 501, Building A1, Weiye Innovation Industrial Zone, Nanchang Baoyuan Road, Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24062800901 Page 3 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 14 4.3 Maximum Peak Output Power 20 4.4 20dB Bandwidth 21 4.5 Frequency Separation 25 4.6 Number of hopping frequency 27 4.7 Time of Occupancy (Dwell Time) 29 4.8 Out-of-band Emissions 33 4.9 Pseudorandom Frequency Hopping Sequence 42 4.10 Antenna Requirement 43 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 44 6 P H O T O S O F T H E E U T ........................................................... 45 Report No.: CTA24062800901 Page 4 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.24…

Text truncated - open the document above for the full version.

Report No.: CTA24062800901 Page 40 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn π/4DQPSK Left Band edge hoping off Right Band edge hoping off Left Band edge hoping on Right Band edge hoping on Report No.: CTA24062800901 Page 41 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 8DPSK Left Band edge hoping off Right Band edge hoping off Left Band edge hoping on Right Band edge hoping on Report No.: CTA24062800901 Page 42 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 4.9 Pseudorandom Frequency Hopping Sequence TEST APPLICABLE For 47 CFR Part 15C section 15.247 (a) (1) requirement: Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hop-ping channel, whichever is greater. Alternatively, frequency hopping systems operating in the 2400–2483.5 MHz band may have hopping channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 125 mW. The system shall hop to channel frequencies that are selected at the system hopping rate from a pseudo randomly ordered list of hopping frequencies. Each frequency must be used equally on the average by each transmitter. The system receivers shall have input bandwidths that match the hop-ping channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization with the transmitted signals. EUT Pseudorandom Frequency Hopping Sequence Requirement The pseudorandom frequency hopping sequence may be generated in a nice-stage shift register whose 5 th and 9 th stage outputs are added in a modulo-two addition stage. And the result is fed back to the input of the first stage. The sequence begins with the first one of 9 consecutive ones, for example: the shift register is initialized with nine ones. ● Number of shift register stages:9 ● Length of pseudo-random sequence:29-1=511 bits ● Longest sequence of zeros:8(non-inverted signal) An example of pseudorandom frequency hopping sequence as follows: Each frequency used equally one the average by each transmitter. The system receiver have input bandwidths that match the hopping channel bandwidths of their corresponding transmitter and shift frequencies in synchronization with the transmitted signals. Report No.: CTA24062800901 Page 43 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 4.10 Antenna Requirement Standard Applicable For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (c), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. Refer to statement below for compliance The manufacturer may design the unit so that the user can replace a broken antenna, but the use of a standard antenna jack or electrical connector is prohibited. Further, this requirement does not apply to intentional radiators that must be professionally installed. Antenna Connected Construction The maximum gain of antenna was 0.72 dBi. Remark:The antenna gain is provided by the customer , if the data provided by the customer is not accurate, Shenzhen CTA Testing Technology Co., Ltd. does not assume any responsibility. Report No.: CTA24062800901 Page 44 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 5 T e s t S e t u p P h o t o s o f t h e E U T Report No.: CTA24062800901 Page 45 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 6 P h o t o s o f t h e E U T Report No.: CTA24062800901 Page 46 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA24062800901 Page 47 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA24062800901 Page 48 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA24062800901 Page 49 of 49 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn ********************** End of Report **********************

FCC ID: 2BDHG-Q1 Test Setup Photos of the EUT
