MANUAL [EN] E-MTB SANN Rev. 1.1 2 1. Introduction Hybridizer SANN Frame Manual Thank you for choosing the Hybridizer e-mountain bike. We hope to provide you with a completely new riding experience. To better understand and use this product, we recommend that you carefully read this manual. 3 • Package Contents NameQuantity Frame Set1 set Charger1 set 29-inch Frame Conversion Kit One pair (Left and Right) Bottom Bracket Height Adjustment Shims One pair (Left and Right) Cable Clips (3 lines)4 pieces Cable Clips (2 lines)4 pieces Control Button1 piece • Specifications Introduction Performance Parameters NameSANN ManufacturerHybridizer Frame CodeMP21 Frame MaterialAL6061 Rider Weight Limit *1 110kg *1: This weight includes the total weight of the rider and their carried equipment. Motor Performance Parameters Motor CodeM510 ManufacturerBafang Rated Power350 W Voltage48 V Maximum Torque95 N.m Maximum Supported Pedal Cadence 145 RPM Motor Weight2.9kg 4 Battery Performance Parameters Battery Pack CodeBT2472B0 ManufacturerSYSMAX Power technology Voltage48V Battery Capacity15Ah 720Wh Maximum Charging Current 6A Battery Weight3.4kg Charger Performance Parameters *1 Charger CodeS-164-546-03000H Manufacturer Dongguan Anju Electronic Technology Co., Ltd. Charging Voltage54.6V Charging Current3A Time to Full Charge 4h(90%),6h(100%) Charger Weight600g *1 ： These performance parameters are for the standard version. 5 • Geometry Introduction This product consists of frame components that require assembly. The data in the table below represents the geometric angles in the designed and set state. It's important to note that there may be some variation in these angles when installing other components, even if components of the same specifications are used. The actual geometric angles may deviate due to differences in tire size, front fork, and other factors between different brands and models. 6 Frame Geometry （ Mullet / 29er ） *1 Frame SizeSML User Height165-175170-178176-186 BB High Setup *2 LMHLMHLMH Head Tube Angle63.864.264.663.864.264.663.964.264.5 Head Tube Length100100100110110110122122122 Seat Tube Angle Effective76.67777.476.67777.476.67777.4 Seat Tube Length420420420430430430440440440 Seat post insert185185185195195195205205205 Top Tube Length Effective578.5577.2576605.6604.3603.1628.1626.8625.6 Chain stay Length (27.5 rear wheel) 437.1435432.8437.3435432.8437.1435432.8 Chain stay Length (29 rear wheel) 457.1455452.8457.3455452.8457.1455452.8 BB Drop12.17.32.412.27.32.312.37.32.3 Reach431.1435438.9456.2460463.8476.2480483.8 Stack619.6616.9614.2628.7625.9623.1639.6636.7633.8 *1: These geometric angles are under the following conditions: 1) Front fork travel is 170mm, A2C value is 582mm, offset value is 51mm. 2) In Mullet setup, the front wheel uses 29 x 2.35 (diameter 740.76mm), and the rear wheel uses 27.5 x 2.5 (diameter 710.51mm). 3) In 29er setup, both front and rear wheels use 29 x 2.35 (diameter 740.76mm). *2: This vehicle allows for adjustable bottom bracket height to suit your needs. L, M, H represent low, medium, and high settings respectively. For more details, please refer to the optional geometry angle section in the instruction manual. 7 • Frame Specifications Introduction Frame specification Rear Travel164mm Rear Shock Length210x55 *1 Shock Hardware (front frame)8x35 Shock Hardware (rear frame)8x30 Rear Spacing12x148 Rear Tire Clearance (27.5")2.8" *2 Rear Tire Clearance (29")2.6" Seatpost Diamater31.6mm HeadsetSemi-integrated 1 1/8" – 1,5" (44mm x 56mm) Number of chain eyes Dependent on capacity of rear derailleur and Cassette Size *3 *1: FOX Float X2 and ROCKSHOX VIVID AIR series cannot be used. *2: Please ensure that the tire does not exceed a maximum width of 68mm. *3: When determining chain length, make sure the rear derailleur is in the largest cassette cog position, and the rear shock is fully compressed, leaving some room for rearward positioning and tension. It is recommended not to exceed a maximum cassette cog size of 46T. If insufficient rearward positioning and tension cannot be avoided due to cassette selection, be cautious not to shift the chain to the largest cassette cog when the rear suspension is heavily compressed, as this may cause irreversible damage to the bike. 8 2. Setting up the bike Before assembling, maintaining, or servicing the bike, make sure to wear the necessary protective gear and use the correct tools. Ensure that the connector at the bottom of the battery is disconnected from the battery itself. Assembling and maintaining a bicycle should be done by individuals with some experience. If you lack sufficient experience, it is advisable to seek assistance from a local bicycle repair shop. Note: During the operation, Hybridizer will not assume any responsibility for personal injuries or property damage resulting from individual operation errors. Once again, before starting the operation, please confirm that the battery connector is disconnected from the battery itself. • Bicycle Component Compatibility Since we provide the frame assembly, other components need to be purchased and assembled by the rider to create a complete bike. To achieve optimal performance, we recommend using the following parts combination. Recommended setting Mullet29erMullet+27.5+ Front Wheel Size29 " 29 " 29 " 27.5 " Front Tire Wide2.1-2.52.1-2.52.6-2.82.6-2.8 Rear Wheel Size27.5 " 29 " 27.5 " 27.5 " Rear Tire Wide2.1-2.52.1-2.52.6-2.82.6-2.8 Front Fork Travel170170160180 BB High SetupL / M / HL / M / HL / M *1 L / M *1 *1 ： At this setup, we do not recommend a high BB setup. 9 • Cable Routing 1. Rear Brake Cable Routing (Recommended rear brake cable length: 1.55~1.6m) 1) Remove the rear-shock fender 2) From the brake cable exit hole on the left seat-stay, feed the brake cable through. 3) After passing through the left seat-stay, route it through the seat tube's lower side and into the top tube. 4) Depending on your brake setup preference, exit the cable from one of the cable exi…

Text truncated - open the document above for the full version.
