2BDKK-B081200001CLlight strip

1. Please read the instructions carefully and verify that each item is in the list. 2. Please retain these installation instructions for further reference and parts ordering information. Use a flat-head screwdriver to pry open the cover at the indicated position. 1. Please read the installation instructions carefully before you start. 2. If the vehicle is clean and f ree of other debris, it will be easy to install. 3. For your safety and to ensure a satisfactory installation, please complete all the installation steps in the order shown below. PRODUCT MANUAL SKU: B0812-00001-CL Complete journey of dreams BEFORE YOU BEGIN PRODUCT INFORMATION INSTALLATION TIPS - Take adapting to Defender model as an example IMPORTANT www.kemimoto.com Designed by Kemimoto Group Kemimoto All Rights Reserved,Inf ringement must be prosecuted. KKK 1 2 1 of 3 1 1 1 Insert the wiring harness with LED strip [1] through the indicated hole below the switch. 2 23 Wiring Harness With LED strip Sealing Strip Tie x1 x1 x10 3 Estimated installation time: 15 minutes (to be prepared by oneself) Choose one www.kemimoto.com Designed by Kemimoto Group Kemimoto All Rights Reserved,Inf ringement must be prosecuted. KKK 2 of 3 Secure the switch in the indicated hole and insert the cigarette lighter into the cigarette lighter socket. 3 Remove the windshield of the vehicle and cut any excess sealing strip [2] based on the length of the bottom of the windshield. 4 Separate the sealing strip [2] and stick the LED strip [1] in the middle of the sealing strip [2], then tightly pinch the sealing strip [2] onto the windshield edge. (Please do not apply excessive force) 5 Reinstall the windshield. 6 Use zip ties to tidy up any excess wires. Use ties[3] to secure the Wiring harness. 7 The end of the LED strip [1] can be cut according to the length of the windshield. Three led lights in one unit, which can be cut f rom the middle of the metal part. (to be prepared by oneself) 9 NOTE FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio f requency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for anuncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Scan the QR code, download the control APP, then open the APP and connect to Bluetooth to control the RGB lights. Music Voice pickup Task RGB patternPaletteDream pattern 3 ALL Devices 2 The device list is automatically connected, and you can manually click to connect or disconnect. ALL Devices 1 Click to enter group management Note: When the color and mode do not match: 1. Settings in the upper right corner of the APP. 2. RGB sequence. RGB sequences Cancel OK RGB BGR BRG GBR RBG GRB Please select correct sequence of your RGB LED strip among the checks above, and verify the result by clicking R,G,B button. KEMIMOTO APP www.kemimoto.com Designed by Kemimoto Group Kemimoto All Rights Reserved,Inf ringement must be prosecuted. KKK 3 of 3

- Guangzhou Zaozhongwan E-Commerce Co., Ltd. - The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/15/2024 U.S. Agent Designation [Guangzhou Zaozhongwan E-Commerce Co., Ltd.] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: [2BDKK-B081200001CL]): Name and company of U.S. agent: Bouge Tech Inc Physical U.S. address of agent: 457 E MCGLINCY LN, CAMPBELL, CA 95008 FRN of U.S. agent: 0033768409 Email address of U.S. agent: [email protected] [Bouge Tech Inc] acknowledges their obligation to accept service of process on behalf of [Guangzhou Zaozhongwan E-Commerce Co., Ltd.]. [Guangzhou Zaozhongwan E-Commerce Co., Ltd.] with the FRN [0034480228] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanentl y te rminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm th e above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature [Name] Clarice Xie [Title] Manager [Company] Guangzhou Zaozhongwan E-Commerce Co., Ltd. Signature [Name of U.S. agent] Jason Zheng [Title of U.S. agent] GM [Company of U.S. agent] Bouge Tech Inc 48_[mo del] US_Agent_2.911(d)(7) - U, V04

Guangzhou Zaozhongwan E-Commerce Co., Ltd. The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/15/2024 To whom it may concern: We, [Guangzhou Zaozhongwan E-Commerce Co., Ltd.], hereby certif y that the equipment for which authorization is sought (FCC ID: [2BDKK-B081200001CL]) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the fi lin g of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist ) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature [Name] Clarice Xie [Title] Manager [Company] Guangzhou Zaozhongwan E-Commerce Co., Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

Page 1 of 3 Report No.: 8135EU012604W-AB ANNEX B EXTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 3 Report No.: 8135EU012604W-AB PHOTO 3 PHOTO 4 Page 3 of 3 Report No.: 8135EU012604W-AB PHOTO 5 PHOTO 6 --- End ---

Label Location On EUT Label Model No.: B0812-00001-CL FCC ID: 2BDKK-B081200001CL

Page 1 of 2 Report No.: 8135EU012604W-AC ANNEX C INTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 2 Report No.: 8135EU012604W-AC PHOTO 3 PHOTO 4 --- End --- PCB Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID: 2BDKK-B081200001CL EUT Specification EUT light strip Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.24GHz WLAN: 5.745GHz ~ 5.825GHz Others: 2.402GHz~2.480GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -10.73 dBm (0.0001W) Antenna gain (Max) 1.43 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Channel Frequency (MHz) Measured Power (dBm) Tune up tolerance (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) BLE 2402 -11.42 -11.42±1 -10.42 1.43 0.00003 1 2440 -10.73 -10.73±1 -9.73 1.43 0.00003 1 2480 -11.37 -11.37±1 -10.37 1.43 0.00003 1 Pass

TEST REPORT Report No.: 8135EU012604W Applicant: Guangzhou Zaozhongwan E-Commerce Co., Ltd. Address: Unit L3A05-1, No. 31-6 Xicha Road, Baiyun District, Guangzhou, China Product Name: light strip Model No.: B0812-00001-CL Trademark: YamagaHome FCC ID: 2BDKK-B081200001CL Test Standard(s): 47 CFR Part 15 Subpart C Date of Receipt: Dec. 26, 2023 Test Date: Dec. 26, 2023 – Jan. 10, 2024 Date of Issue: Jan. 15, 2024 ISSUED BY: SHENZHEN EU TESTING LABORATORY LIMITED Prepared by: Reviewed and Approved by: ____________________ _____________________ Mikey Zhu/ Engineer Sally Zhang/ Manager Page 2 of 30 Report No.: 8135EU012604W TRF No.: FCC Part 15 Subpart C_BLE (A01) Revision Record Report Version Issued Date Description Status V0 Jan. 15, 2024 Original Valid Page 3 of 30 Report No.: 8135EU012604W TRF No.: FCC Part 15 Subpart C_BLE (A01) Table of Contents 1 COVER PAGE .................................................................................................................................. 1 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 APPLICANT INFORMATION .................................................................................................................. 5 2.2 MANUFACTURER INFORMATION .......................................................................................................... 5 2.3 FACTORY INFORMATION ..................................................................................................................... 5 2.4 GENERAL DESCRIPTION OF E.U.T. ..................................................................................................... 5 2.5 TECHNICAL INFORMATION OF E.U.T. .................................................................................................. 6 3 TEST SUMMARY ...................................................................................................................................... 7 3.1 TEST STANDARD ............................................................................................................................... 7 3.2 TEST VERDICT ................................................................................................................................... 7 3.3 TEST LABORATORY ........................................................................................................................... 7 4 TEST CONFIGURATION .......................................................................................................................... 8 4.1 TEST ENVIRONMENT .......................................................................................................................... 8 4.2 TEST EQUIPMENT .............................................................................................................................. 8 4.3 DESCRIPTION OF SUPPORT UNIT ........................................................................................................ 9 4.4 TEST MODE ...................................................................................................................................... 9 4.5 MEASUREMENT UNCERTAINTY ........................................................................................................... 9 4.6 DEVIATION FROM STANDARDS ........................................................................................................... 9 4.7 ABNORMALITIES FROM STANDARD CONDITION ................................................................................... 9 5 TEST ITEMS ........................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT .................................................................................................................. 10 5.1.1 Test Requirement ........................................................................................................... 10 5.1.2 Antenna Anti-Replacement Construction ........................................................................ 10 5.1.3 Antenna Gain .................................................................................................................. 10 5.2 CONDUCTED EMISSION AT AC POWER LINE ..................................................................................... 11 5.2.1 Test Requirement ........................................................................................................... 11 5.2.2 Test Setup Diagram ........................................................................................................ 11 5.2.3 Test Procedure ............................................................................................................... 11 5.2.4 Test Data......................................................................................................................... 11 5.3 DTS BANDWIDTH ............................................................................................................................ 12 5.3.1 Test Requirement ........................................................................................................... 12 5.3.2 Test Setup Diagram ........................................................................................................ 12 5.3.3 Test Procedure ............................................................................................................... 12 5.3.4 Test Data......................................................................................................................... 12 5.4 MAXIMUM CONDUCTED OUTPUT POWER .......................................................................................... 13 5.4.1 Test Requirement ........................................................................................................... 13 5.4.2 Test Setup Diagram .................................................................................…

Text truncated - open the document above for the full version.

version01 Guangzhou Zaozhongwan E-Commerce Co., Ltd. Declaration concerning Antenna Specification It i s hereby declared that the product Model No.: B0812-00001-CL FCC ID: 2BDKK-B081200001CL fulfill s the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Model No. of antenna: B0812-00001-CL Type of antenna: PCB Antenna Gain of the antenna: 1.43 dBi Frequency range: 2390-2490 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Guangzhou Zaozhongwan E-Commerce Co., Ltd. Address: Unit L3A05-1, No. 31-6 Xicha Road, Baiyun District, Guangzhou, China City: Guangzhou ZIP / Postal code: Country: China Place: Place: Date: 2024-01-15 Signature:

ANTENNA SPECIFICATION Summary Item Describe Model No. Gain 1.43dBi(Max) Design By ITON Technology Corp. Tested By Shenzhen ZHONGTIAN XUN Co., Ltd. Antenna Type PCB Antenna Antenna Photo B0812-00001 -C L
