2BDLL-100020E-Traveler Device

使用手册 User Manual V3.0 电子墨水显示屏使用手册 1.产品外观 2.产品信息和基本参数 项 目 参数 产品名称 电子墨水显示屏 产品型号 ET007 产品尺寸 210mmX155mmX26mm 产品重量 420 克+/-5% 屏 幕 7.5 inch, 640(H)*384(V) pixel, Black & White 电池容量 6000mAh 无 线 WiFi 2.4GHz 3.产品使用说明 •收到产品后，拔出电池隔离片使电池开始对系统供电； •产品自动进 行 WiFi 热点搜索，并自动按照系统提供的 SSID 信息连接到可用网络； 使用手册 User Manual V3.0 •使用人员将产品放置到物料架上并与系统数据绑定； •后台系统定期推送物料信息，通过无线网络传递到产品上后，产品系统将刷新屏幕 显示内容； •后台系统控制产品的 LED 灯，根据设定的程序发出不同的颜色。使用人员查找特定 物料架时，可以通过 LED 灯发出特定的颜色来加快位置识别； •如遇连接不稳定，产品无法正常刷新屏幕时，请通过产品顶端右侧的复位键对产品 进行重置，终端会重新自动连接网络。 4.电池和充电说明 （1） 充电指引： •电池电量不足时(<20%)，电量指示灯会显示红色，需要及时对产品进行充电； •充电过程中，电源指示灯将显示蓝色，电量指示灯变成绿色，即为电池满充状态； 充电要求：该终端支持最高 5V/3A 快充，请使用合规充电器，避免产品因此受到损坏。 （2） 其它安全说明： •更换类型不正确的电池可能会破坏安全措施（例如，在某些锂电池类型的情况下）; •将电池放入火中或热烤箱中处理，或机械压碎或切割电池，可能导致爆炸； •将电池置于极高温度环境中,可能导致爆炸或易燃液体或气体泄漏； •电池承受极低的空气压力，可能导致爆炸或易燃液体或气体泄漏。 5.软体更新和调试说明 本品提供两种软件更新方式： （1）OTA 方式，由客户自行开发支持软件； （2）使用 Arduino 更新软件，步骤如下： i.取出电池仓螺丝并取出电池； ii.使用 Micro-USB 连接到电池仓侧边隐藏的接口，同时检查接口下方 “拨动开关”是否位于 Boot 侧。 iii.打开 Arduino 读取需要更新的软件； iv.软件信息配置； v.点击下载按钮开始软体下载； vi.需要进入 COM 调试模式时，需要将“拨动开关”拨动到另一侧即可。 6.合规说明 •FCC合规声明 该设备符合FCC规则第15部分的规定。操作受以下两个条件约束：（1）此设备可能不会造 成有害干扰，以及（2）此设备必须接受接收到的任何干扰，包括可能导致不期望操作的干 扰。 未经合规负责方明确 批准的变更或修改可能会使用户失去操作设备的权限。 根据 FCC规则第15部分的规定，该设备经过测试，符合B类数字设备的限制。这些限制旨在 提供合理的保护，防止住宅安装中的有害干扰。该设备产生、使用并可以辐射射频能量， 如果不按照说明安装和使用，可能会对无线电通信造成有害干扰。但是，不能保证在特定 使用手册 User Manual V3.0 安装中不会发生干扰 。 如果该设备确实对无 线电或电视接收造成有害干扰，可以通过关闭和打开设备来确定，则 鼓励用户尝试通过以下一种或多种措施来纠正干扰： --重新定向或重新定位接收天线。 --增加设备和接收器之间的间距。 --将设备连接到与接收器连接的电路不同的电路上的插座。 --请咨询经销商或有经验的收音机/电视技术人员以获得帮助。 FCC SAR 声明 本设备符合 FCC 规定的不受控制环境下的辐射暴露限值。最终用户必须遵守具体的操作说 明，以满足射频暴露合规性要求。本发射机不得与任何其他天线或发射机共置或一起运 行。便携式设备的设计符合美国联邦通信委员会规定的无线电波暴露要求。这些要求将一 克组织的平均 SAR 限制在 1.6 W/kg。在产品认证期间，根据该标准报告的最高 SAR 值为 正确佩戴在身体上使用时的 SAR 值。 使用手册 User Manual V3.0 E-Traveler Device User Manual 1.Product Overview 2.Information and Parameter Item Parameter Product Name E-Traveler Device Model Number ET007 Dimension 210mmX155mmX26mm Weight 420g+/-5% Screen 7.5 inch, 640(H)*384(V) pixel, Black & White Battery 6000mAh Wireless WiFi 2.4GHz 使用手册 User Manual V3.0 3.User Instructions •Upon receiving the device, pull out the battery isolator and battery starts power supply; •E- traveler device automatically searches for WiFi hotspots and connects to available networks according to the SSID information provided by the system; •Users attach the E-traveler to the material cart and connect the device to the system; •Backend system regularly pushes material information and reaches E-traveler through the wi reless network, and device system refreshes the screen display content; •With the different LED light definition which is controlled by backend system, users can easily locate the material cart; •Under the circumstances that the connection is unstable and E-traveler cannot refresh the s creen normally, it can be reset via the Reset button, and the device will automatically re- connect to the network system. 4.Battery Charging Instructions 4.1 Battery Charging •Device needs to be charged when the battery power capacity is low (<20%) and the power indicator turns to red; •Device is under charging process and the power indicator turns to blue; •Device is fully charged when the power indicator turns to green. R equirements: The E-traveler supports up to 5V/3A fast charge, please use a compliant charger to avoid damage to the device. 4 .2 Battery safety statement •Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types); •Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting a battery, that can result in an explosion; •Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; •A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. 5.Software Refreshing and Debugging Instructions This product provides two software update methods: i.OTA mode, supporting software developed by user; ii.Using Arduino to update the software with steps as followed: •Unfasten the battery cover screws and take out the battery; •Use Micro-USB to connect to the inner interface on the side of the battery compartment, and check whether the "switch button" under the interface is on the Boot side. •Turn on the Arduino to read the software to be refreshed; •Set the configuration. •Click the download button to start downloading the software; •To enter COM debugging mode, switch the "switch button" to the opposite direction. 6.Compliance statement 6.1 FCC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two 使用手册 User Manual V3.0 conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. C hanges or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. T his equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. I f this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to whi…

Text truncated - open the document above for the full version.

UNITED STATES DESIGNATED AGENT LETTER TO: Federal Communication Comm1ss1on Equipment Authorization B「anch 7435 Oakland Mills Road Columbia, MID 21046 Applicant Company Name Grantee Code Contact Name Address City/Province/Zip. Sophintech Manufacturing Co., Ltd 2BDLL Zhong Huang Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District Zhuha1 City, Guangdong Province, 519170 China Telephone: +86 18926981855 Fax· Email: [email protected] Applicable Equipment: FCC ID: 2BDLL-100020 ATTN· Director of Certification Date: 11/15/2023 U.S. designated agent Company Name: United Consulting Technology Services Co., Ltd FRN 0033495714 Contact Name Address City/Province/Zip Telephone Fax Email David Wu 17800 CASTLETON ST STE 665 CITY OF INDUSTRY CA 91748 United States (626)217 -4022 United Consulting Technology Services Co., Ltd [email protected] We, Sophintech Manufacturing Co., Ltd. and United Consulting Technology Services Co., Ltd. understand and acknowledge the applicants consent and the designated agent's obligation to accept service of P「ocessin the United States fo「matte「s related to the applicable equipment, and at the physical U.S address and e-mail of the designated agent listed above We, Sophintech Manufacturing Co., Ltd. and United Consulting Technology Services Co., Ltd acknowledge the applicant's acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after eithe「theg「anteehas permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative o「judicialproceeding involving the equipment, whicheve「is late「 Applicant Name (Printed): Zhong Huang Title: Technical Director Signature: �h勺日吁 U.S. designated agent Name (Printed): David Wu Title: CEO Signature 31 INTERNATIONAL BUSINESS PARK #03-01 SII\JGAPORE 609921 TEL: (65) 6895 4000 FAX: (65) 6895 4999 COMPANY REG NO: l 99905094R

Tune up procedure

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 4 Appendix External Photos for SZCR2310003469AT FCC ID:2BDLL-100020 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 4 - End of the Appendix -

Version Date/Sign CR No. Check Appd Drw. No: 6XXXXX Sys AI CS6 Units mm Scale 1:1 Product: E-Traveler Device Title: Certification Label_Black Material: See Material description Colour: See Note CONFIDENTIAL Code: Review Design Change Description/Ref. 01 Zhong 09.31.2023 B 1:3 A 1:3 2:1 Model: Code (8 digits), ET007 P/N: Code (3 digits -11digits), 001-10002023090 FCC ID: (3 digits -10digits), 2BDLL-100020 MCMC: (12 digits), XXXXXXXXXXXX Manufacturing Date: 2021.08, 2021.09..........3023.11........ Zhong Huang Sky Yang 09.31.2023 09.31.2023 First draft type marking creation 2：1

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 6 Appendix Internal Photos for SZCR2310003469AT FCC ID:2BDLL-100020 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 6 of 6 Antenna location: - End of the Appendix - Antenna

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZSAR-TRF-01 Rev. A/0 May15,2023 Report No.: SZCR231000346903 Page: 1 of 39 Keny Xu EMC Laboratory Manager FCC SAR TEST REPORT Application No.: SZCR2310003469AT Applicant: Sophintech Manufacturing Co., Ltd. Address of Applicant: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Manufacturer: Sophintech Manufacturing Co., Ltd. Address of Manufacturer: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Factory: Sophintech Manufacturing Co., Ltd. Address of Factory: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Product Name: E-Traveler Device Model No.(EUT): ET007 Trade mark: Sophintech FCC ID: 2BDLL-100020 Standard(s) : FCC 47CFR §2.1093 Date of Receipt: 2023-12-14 Date of Test: 2023-12-15 Date of Issue: 2023-12-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZSAR-TRF-01 Rev. A/0 May15,2023 Report No.: SZCR231000346903 Page: 2 of 39 REVISION HISTORY Revision Record Version Description Date Remark 00 Original 2023-12-19 / Authorized for issue by: Roman Pan / Project Engineer Eric Fu / Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZSAR-TRF-01 Rev. A/0 May15,2023 Report No.: SZCR231000346903 Page: 3 of 39 TEST SUMMARY Frequency Band Maximum Reported SAR(W/kg) Body WI-FI (2.4GHz) 0.19 SAR Limited(W/kg) 1.6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZSAR-TRF-01 Rev. A/0 May15,2023 Report No.: SZCR231000346903 Page: 4 of 39 CONTENTS 1 GENERAL INFORMATION .............................................................................................................................. 6 1.1 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 1.2 DUT ANTENNA LOCATIONS .......................................................................................................................... 7 1.3 TEST SPECIFICATION ................................................................................................................................... 8 1.4 RF EXPOSURE LIMITS .................................................................................................................................. 9 1.5 TEST LOCATION ........................................................................................................................................ 10 1.6 TEST FACILITY .......................................................................................................................................... 10 2 LABORATORY ENVIRONMENT ................................................................................................................... 11 3 SAR MEASUREMENTS SYSTEM CONFIGURATION .................................................................................. 12 3.1 THE SAR MEASUREMENT SYSTEM ............................................................................................................ 12 3.2 ISOTROPIC E-FIELD PROBE EX3DV4 ......................................................................................................... 13 3.3 DATA ACQUISITION ELECTRONICS (DAE) ................................................................................................... 14 3.4 SAM TWIN PHANTOM ................................................................................................................................ 14 3.5 ELI PHANTOM ........................................................................................................................................... 15 3.6 DEVICE HOLDER FOR TRANSMITTERS ......................................................................................................... 16 3.7 MEASUREMENT PROCEDURE ...................................................................................................................... 17 3.7.1 Scanning procedure ........................................................................................................................... 17 3.7.2 Data Storage ...................................................................................................................................... 19 3.7.3 Data Evaluation by SEMCAD ............................................................................................................. 19 4 SAR MEASUREMENT VARIABILITY AND UNCERTAINTY ........................................................................ 21 4.1 SAR MEASUREMENT VARIABILITY ............................................................................................................... 21 4.2 SAR MEASUREMENT UNCERTAINTY ............................................................................................................ 22 5 DESCRIPTION OF TEST POSITION ............................................................................................................. 23 5.1 THE TEST POSITION .................................................................................................................................. 23 6 SAR SYSTEM VERIFICATION PROCEDURE .............................................................................................. 24 6.1 TISSUE SIMULATE LIQUID ........................................................................................................................... 24 6.1.1 Recipes for Tissue Simulate Liquid .................................................................................................... 24 6.1.2 Test Liquids Confirmation ................................................................................................................... 25 6.1.3 Measurement for Tissue Simulate Liquid .................…

Text truncated - open the document above for the full version.

Small Size 2.4GHz PCB Antenna-Model no.:AN043 1 KEYWORDS  PCB antenna  Average Gain 2dBi  ESP32  IOT application  2.4 GHz  Inverted F Antenna  Manufacturer name  Address: Espressif; 5/F, Building 2, No. 500, Zuchongzhi Road, Zhangjiang Hi-Tech Park, Pudong New Area, Shanghai, China 2 INTRODUCTION The PCB antenna described in this application note is now used on ESP32 module reference design. However, it can also be used in all 2.4 GHz designs, especially small space is required for the antenna. This application note describes the antenna dimensions, the RF performance and considerations for complying with regulatory limits when using this design. The suggested antenna design requires no more than 15.2 x 5.7 mm of space and ensures a VSWR ratio of less than 2 across the 2.4 GHz ISM band when connected to a 50 ohm source. 3 ANTENNA DESIGN The PCB antenna on the ESP32 Module reference design is a meandered Inverted F Antenna (IFA). The IFA was designed to match an impedance of 50 ohm at 2.45 GHz. Thus, no additional matching components are necessary. 3.1 Design Goals The reflection at the feed point of the antenna determines how much of the applied power is delivered to the antenna. A reflection of less than -10 dB across the 2.4 GHz ISM band, when connected to a 50-ohm source, was a design goal. Reflection of less than -10 dB, or VSWR less than 2, ensures that more than 90% of the available power is delivered to the antenna. Bandwidth is in this document defined as the frequency band where more than 90% of the available power is delivered to the antenna. Another design goal was to fit the size of the PCB antenna on the esp32 Module and to obtain good performance also when it is used in IOT applications. 3.2 Simulation IE3D from Zeland, which is an electromagnetic simulation tool, was used to design the antenna. The accuracy of the simulation is controlled by the mesh. An increase of the mesh increases the simulation time. Thus, for initial simulations mesh = 1 should be used. When a fairly good result is achieved a higher mesh should be used to obtain more accurate results. Comparison of simulation and measurement results shows that the measured reflection is between the result obtained with mesh = 5 and mesh = 1; see Figure 1 for details. Figure 1: Comparison of Simulation and Measurements Results 3.3 Layout and Implementation Small changes of the antenna dimensions may have large impact on the performance. Therefore, it is strongly recommended to make an exact copy of the reference design to achieve optimum performance. It is also recommended to use the same thickness and type of PCB material as used in the reference design. To compensate for a thicker/thinner PCB the antenna could be made slightly shorter/longer. Figure 2: Antenna Dimensions（mm) L1 3.94 L2 2.70 L3 5.00 L4 2.64 L5 2.00 L6 4.90 W1 0.90 W2 0.50 D1 0.50 D2 0.30 D3 0.30 D4 0.50 D5 1 .40 D6 1 .70 Table 1: Antenna Dimensions 4 TEST RESULTS Reflection, radiation pattern and variation of output power across a wide frequency band were measured to verify the performance of the PCB antenna. 4.1 Reflection All the reflection measurements were performed with a network analyzer connected to a semi-rigid coax cable, which was soldered to the feed point of the antenna. Because of the small size antenna and the small ground plane this kind of measurements is heavily affected by the presence and placement of the coax cable. This influence can result in a small uncertainty in resonance frequency and measured reflection. Typically different placement of the semi-rigid coax cable could change the resonance frequency with 5 -10 MHz and the reflection with 3 - 4 dB. Figure 3: Influence of Plastic Encapsulation and Test Pins The size of the ground plane affects the performance of the PCB antenna. Soldering esp32 to a test board increases the size of the ground plane and thus the performance is affected. However, bandwidth still can be enough to cover the whole 2.4 GHz ISM band. 4.2 Radiation Pattern The radiation pattern for the antenna implemented on the esp32 reference design has been measured in an anechoic chamber. Figure 5 through Figure 11 shows radiation patterns for three planes, XY, XZ and YZ, measured with vertical and horizontal polarization. All measurements were performed with 0 dBm output power. Figure 4 shows how the different radiation patters are related to the positioning of the antenna. Figure 4: How to Relate the Antenna to the Radiation Patterns Figure 5:AN043 XY Plane Figure 6:AN043 XZ Plane Figure 7:AN043 YZ Plane 4.3 Output Power To make a realistic bandwidth measurement of the antenna a small test program was used. The test program stepped the center frequency of a carrier from 2.3 to 2.8 GHz. This bandwidth measurement was also done to verify the result from the reflection measurements, described in section 5.1. The output power was measured using max hold on a spectrum analyzer. CC2511 was programmed for 0 dBm output power and the antenna was horizontally oriented and directed towards the receiving antenna. This corresponds to 0° in the XY plane on Figure 6. The bandwidth measurements were not performed with a correction factor on the spectrum analyzer. Thus, the results in Figure 15 and Figure 16 only show the relative changes in output power and not the actual level. Figure 15 shows the bandwidth of the antenna when the dongle is not connected to a computer. The result shows that the antenna has a variation in output power of less than 3 dB across a frequency band of more than 350 MHz. This demonstrates that the antenna has a broadband characteristic. Maximum output power is measured to be at 2.54 GHz. Thus if the same antenna is implemented on a PCB with similar size and if the application is only intended for stand alone usage the antenna could be made slightly longer to obtain best performance at 2.42 GHz. Figure 8:OUTPUT POWER,esp32 5.4 Spurious Emission and Harmonics Table 2 shows measured output power …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231000346902 Page: 1 of 137 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2310003469AT Applicant: Sophintech Manufacturing Co., Ltd. Address of Applicant: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Manufacturer: Sophintech Manufacturing Co., Ltd. Address of Manufacturer: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Factory: Sophintech Manufacturing Co., Ltd. Address of Factory: Room 303, Floor 3, Plant 1, No.13 Fuwan Road, Qianwu Town, Doumen District, Zhuhai City, Guangdong Province, 519170 China Equipment Under Test (EUT): EUT Name: E-Traveler Device Model No.: ET007 Trade Mark: Sophintech FCC ID: 2BDLL-100020 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-10-31 Date of Test: 2023-11-02 to 2023-11-29 Date of Issue: 2023-12-04 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231000346902 Page: 2 of 137 Revision Record Version Chapter Date Modifier Remark 01 2023-12-04 Original Authorized for issue by: Benson Wang/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231000346902 Page: 3 of 137 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231000346902 Page: 4 of 137 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 6 4.4 Test Location ...................................................................................................................................... 7 4.5 Test Facility ........................................................................................................................................ 7 4.6 Deviation from Standards ................................................................................................................... 7 4.7 Abnormalities from Standard Conditions ........................................................................................... 7 5 Equipment List .......................................................................................................................................... 8 6 Radio Spectrum Technical Requirement ............................................................................................. 12 6.1 Antenna Requirement ...................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................... 12 7 Radio Spectrum Matter Test Results .................................................................................................... 13 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ............................................................. 13 7.1.1 E.U.T. Operation .......................................................................................................................... 13 7.1.2 Test Mode Description ................................................................................................................. 13 7.1.3 Test Setup Diagram …

Text truncated - open the document above for the full version.

Report No.: SZCR231000346903 Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 2450 MHz Head Date: 2023-12-15SGS-SAR Lab System Performance Check 2450 MHz Head D2450V2-SN 733 Communication System: D2450; Frequency: 2450.000 Medium: HSL. Medium parameters used: f= 2450.000 MHz; σ= 1.79 S/m; ε r = 40.3 DASY8 Configuration: - Probe: EX3DV4 - SN7838; ConvF(7.4, 7.32, 7.42); Calibrated: 2023-09-11 - Sensor-Surface: 1.4 mm - Electronics: DAE4ip Sn1830; Calibrated: 2023-09-12 - Phantom: Twin-SAM V8.0 (30deg probe tilt); Serial: 2256 - Measurement Software: cDASY8 V16.2.4.2524 Area Scan (96.0 mm x 120.0 mm): Measurement Grid: 12.0 mm x 12.0 mm SAR (1g) = 13.2 W/kg; SAR (10g) = 6.07 W/kg; Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 5.0 mm x 5.0 mm x 5.0 mm Power Drift = 0.04 dB SAR (1g) = 13.6 W/kg; SAR (10g) = 6.32 W/kg;

Report No.: SZCR231000346903 Appendix B Detailed Test Results WIFI 2.4G for Body Date: 2023-12-15SGS-SAR Lab ET007 WIFI 2.4G 802 11b 11CH Back side 0mm ET007 Communication System: WLAN 2.4GHz; Frequency: 2462.000 Medium: HSL. Medium parameters used: f= 2462.000 MHz; σ= 1.81 S/m; ε r = 40.3 DASY8 Configuration: - Probe: EX3DV4 - SN7838; ConvF(7.4, 7.32, 7.42); Calibrated: 2023-09-11 - Sensor-Surface: 1.4 mm - Electronics: DAE4ip Sn1830; Calibrated: 2023-09-12 - Phantom: Twin-SAM V8.0 (30deg probe tilt); Serial: 2256 - Measurement Software: cDASY8 V16.2.4.2524 Area Scan (96.0 mm x 240.0 mm): Measurement Grid: 12.0 mm x 12.0 mm SAR (1g) = 0.152 W/kg; SAR (10g) = 0.076 W/kg; Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 5.0 mm x 5.0 mm x 5.0 mm Power Drift = 0.05 dB SAR (1g) = 0.167 W/kg; SAR (10g) = 0.080 W/kg;

Report No.: SZCR231000346903 Appendix C Calibration certificate 1. Dipole D2450V2-SN 733 2. DAE DAE4-SN 1830 3. Probe EX3DV4-SN 7838

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix Test Setup Photos for SZCR2310003469AT FCC ID:2BDLL-100020 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Conducted Emiss…
