2BDNH-X50Helmet Bluetooth Headset

X50 USER MANUAL M Helmet Bluetooth Headset Please read this manual carefully before using the product Accessories content Installation steps Main unit*1Steel clip base*1 3M adhesive base*1 2-in-1 microphone*1 1. Large fuzzy Velcro Stick on inner ear grooves 4. Stick the fuzzy side Velcro of the microphone in the appropriate position inside, then install mic 5. Clip the clip - on base to left helmet, right spot 6. Insert the main unit into the base from top to bottom 2. Install the shorter wire in the helmet ear groove on the main unit side 3. Install the headphone speakers respectively M 【1】 M Velcro for Speaker & Mic*4 Type-C charging cable*1 Speaker heightening pad*2 Product manual M For correct insertion, the first line on the headphone plug should be flush with the shell. M Headphone plug has two raised lines. lf visible after inserting into main unit socket,insertion is wrong and headphones won't function. Attention Product Overview Product Specifications Bluetooth Name: X50 Bluetooth Version: 5.3 Charging Voltage: 5V 1A/2A Charging Time: 1-2 Hours Waterproof Rating: IP67 Standby Time: ≤ 300 Hours Working Time: ≤ 35 Hours Battery Capacity: 1000 mAh Charging Port: Type-C Battery Type: Lithium-polymer 3.7v Note: The parameters are laboratory data; Their use in different environments may vary. The product is constantly updated, so functions and images may differ slightly from the physical. Consult the physical product for accurate information. 【2】 M Power on/off Play/Pause Answer/Hang up Switch Prompt Language AI Voice Assistant Restore Factory Settings Rotating Switch Volume up / Volume down Previous track / Next track Turn on/off auto-answer Switch RGB light effects Status Light Bluetooth connected: Red-blue fast flash → blue slow flash Fully charged: Red light turns blue Headphone jack TYPE-C charging port “M” Function Usage Power on/off Press and hold " " for 3s to turn on/off (with power-on/off prompt). (The current battery level is announced automatically on power-on; status light flashes rapidly. Status light turns off when powered off) Press and hold " " for 10s to restart the device. (*Auto power-off if Bluetooth unconnected for 5 mins after startup) Bluetooth Connection After powering on, enable phone Bluetooth, search for and select the device named "X50" to connect. A slow blue flash of the status light indicates successful connection. Song switching / Volume adjustment Song Switching: Rotate the switch left " " once to skip to the next song; Rotate the switch right " " once to skip to the previous song. Volume Control: Rotate and hold the switch left " " to decrease volume; Rotate and hold the switch right " " to increase volume. Play/Pause: Short press " " to play or pause. Incoming Call Press and hold " " for 2s to reject the call; Short press " " to answer/end the call; Double click " " to call back the last dialed contact. Auto Answer for Incoming Calls Auto answer after 3s of ringing. Rotate the switch left " " twice in a row to enable/disable auto answer for incoming calls. (One "beep" prompt = disabled; two "beep-beep" prompts = enabled) 【3】 Prompt Language Switch When the headset is powered on and not connected to Bluetooth: Double click the " " button to switch the prompt language. Connect to Two Phones Simultaneously After powering on: Connect to the first phone’s Bluetooth then disconnect it, connect to the second phone’s Bluetooth (no need to disconnect), then re-enable Bluetooth on the first phone and connect it to complete the setup. Activate AI Voice Assistant Single press the " " button to activate the voice assistant. (Note: When using the voice assistant for the first time, you must allow access to your phone’s content; ignore this if no prompt appears.) RGB Light Effect Switch & Off (Default Open) Rotate the switch right " " twice in a row to switch RGB light effects (flowing light → blue → red → green → single color cycle → off). Status Indicator Light When charging: The " " button lights up red; turns blue when fully charged. After power-on: The " " button flashes red and blue quickly; turns off when powered off; flashes blue slowly once Bluetooth connection is successful. Factory Reset Press and hold the " " button for 5s to reset to factory settings and clear all Bluetooth pairing records. 1. Do not expose to high temperatures (contains a lithium battery). 2. Charge using a rated-voltage power source. 3. Secure the main unit to prevent damage from dropping. 4. Keep the waterproof/dustproof cover closed. 5. Do not disassemble/modify (no serviceable components). 6. For long-term storage: Keep dry; charge monthly; avoid extreme temps/dust. M M M M Warnings & Precautions 【4】 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions , may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separati…
