2BDOP-LW-13Fashion Wireless Silent Mouse

-1- Productmanual ProductName:FashionWirelessSilentMouse Model:LW-13 specificationofproduct Comfortable,Revolutionary,PortableDesign   TheWirelessMouseoffersextremecomfortbutwiththeaddedconvenienceofextremeportability.its expandedsizeforeasystoragewhiletraveling.  ThestrongsteelhingeallowsyoutoWirelessMouseto60percentofitsfullsize.Themousewillsnap intobothopenandclosedpositions,soyou'llfeelsecurewhenusingitorputtingitaway.  TheWirelessMouseambidextrousdesignmakesitidealforeverydayuse.  Whetheryou'reright-orleft-handed,yourhandsandwristwillstaycomfortableandincompletecontrol evenafterhoursofheavyuse.  WirelessTechnologywithLessInterference2.4GHzwirelessopticaltracking ProductName:WirelessMouse Specifications:CPI:800-1200-1600 Mouse:110*62*28mm Receiver:18*15*6mm Wirelesstransmissionfrequency:2.403~2.476GHz Ratedvoltage:mouse1.5V Lifespanofkeys:2millionkeystrokes Effectivedistance:8~10meters Material:ABS 4D2.4gwirelessmouse -2- MouseCharacteristics: Buttonnumber:4keys: Battery:AA*1(notincludebattery)) .Interface:USB DPI:DPI:.800-1200-1600DPI ScanningSpeed:150-3000/second mousetype:wireless,withoutcable  Application:destop,laptop  canworkonanysurfaceincludingwooden,plastic.exceptglassormirror  Style:office  Workingdistance:6-10M  CompatiblewithWindows2000/NT/Me/XP//VISTA Radiofrequencyrange:2402MHz~2480MHz Plugandplay.noneeddriver. Ratingworkingcurrent:20mA Convenientscrollwheel,workingfreelyonusualsurfaces 16channelsandautomaticallychangingtoavoidinterference Maximumacceleration:14inch/second OperatingSystem:Win7/Win98/2000/ME/XP/VISTA  Workingonanysurfaceexceptglasssurface  AvailableforPCandnotebook  HandOrientation:Bothhand  lifeover3000,000times Usage:1.Removethebatterycoveratthebottomofmouse,thentakethereceiveroutandplugitintoaUSB porton computer.2.Install1AAbatterycorrectlyinthebatterycompartmentandturnthepowerswitchtotheON position.3.Put thebatterycoverbackon.Waitforyourmousetofinishconnecting.Onceitcompletes,youshouldbeableto movethe on-screencursorwithyourmouse. Caution:1.Theelectricalandelectronicequipmentshouldnotbedisposedoftogetherwithhousehold waste.2.When yourequipmentreachtheendofitsservicelife,consumersareobligedtotakeittothepointofsaleorthe publicrecycling pointdedicatedtoend-of-ifetreatmentofe-waste.Youmayrefertothedomesticlawinyourcountryfor moredetails.3. Usersshoulddisposeofoldequipmentorrecycleproperlytoprotectourenvironment. Storage:Storeinacoolanddryplace. Ambientconditions: Ambienttemp 0°C～+45°C Workingtemperature －20°C～60°C -3- WorkingHumidity ＜85%RH MOUSESETUP NOTES Inordertoconnectyourmousetoyourcomputer,follow thestepsbelow: 1.RemovetheUSBreceiverfromthestorageslotinside thebatterycompartmentonthebottomofyourmouse. 2.InserttheUSBreceiverintooneofyourcomputer’s USBports. 3.Makesurethatyourcomputerispoweredon. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Sincerely, Name/Title： Jessica xu/Sales manager Company: SHENZHEN STARWAVE INDUSTRIAL TECHNOLOGY CO.,LTD Address: 1505 Floor 15,Huaide International Building,No.73, Fuyong Section,Guangshen Road,Huaide Community,Fuyong Street, Bao'an District, Shenzhen China Phone: 86-13723405417 Fax: 0755-85270526 E-Mail: [email protected]

FCC ID: 2BDOP-LW-13 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BDOP-LW-13 Photo 4 Photo 5 Photo 6

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BDOP-LW-13

FCC ID: 2BDOP-LW-13 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BDOP-LW-13 Photo 4 Photo 5 Photo 6 2.4G PCB Antenna FCC ID: 2BDOP-LW-13 Photo 7 Photo 8

RF Exposure evaluation FCC ID: 2BDOP-LW-13 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.0 -1.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 1.0 1.2589 0.3941<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

ITEM SPEC. Antenna Type Type_2_single wiggle Center Frequency 2402 MHz 2441 MHz 2480 MHz 2.34 dBi 2.07dBi 1.45 dBi MAX. GAIN 2.34 dBi Polarization Horizontal Azimuth Beam PatternOmni-directional Impedance 50 Ω Antenna Length 3.1cm Antenna Specification Specifications Summary Antenna Antenna Photo & Length (mm) Test Address 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan Test Date 2009-04-14 Test Instrument vector network analyzer - R&S ZVB20 Average Gain(dBi) : -2.48 Mini mum Gain(dBi): -55.18 1. Main antenna : 2402 MHz 1.1 Horizontal Frequency(MHZ): 2402 Antenna Polarity: Horizontal Maximum Value(dBi): 2. 34 Average Gain(dBi) : -8.98 Mini mum Gain(dBi): -62.3 1.2 Vertical Frequency(MHZ): 2402 Antenna Polarity: Vertical Maximum Value(dBi): -4.51 Average Gain(dBi) : -2.54 Mini mum Gain(dBi): -66.98 2. Main antenna : 2441 MHz 2.1 Horizontal Frequency(MHZ): 2441 Antenna Polarity: Horizontal Maximum Value(dBi): 2.07 Average Gain(dBi) : -8.81 Mini mum Gain(dBi): -51.4 2.2 Vertical Frequency(MHZ): 2441 Antenna Polarity: Vertical Maximum Value(dBi): -4.29 Average Gain(dBi) : -3.34 Mini mum Gain(dBi): -53.4 2. Main antenna : 2480 MHz 2.1 Horizontal Frequency(MHZ): 2480 Antenna Polarity: Horizontal Maximum Value(dBi): 1.45 2.2 Vertical Frequency(MHZ): 2480 Antenna Polarity: Vertical Maximum Value(dBi): -4.95 Average Gain(dBi) : -9.06 Minimum Gain(dBi): -60.00

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA23102600901 2BDOP-LW-13 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Nov. 01, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : SHENZHEN STARWAVE INDUSTRIAL TECHNOLOGY CO.,LTD Address ............................................ : 1505 Floor 15, Huaide International Building, No. 73, Fuyong Section, Guangshen Road, Huaide Community, Fuyong Street, Bao 'an District, Shenzhen Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Fashion Wireless Silent Mouse Trade Mark ....................................... : MINISO Manufacturer .................................... : SHENZHEN STARWAVE INDUSTRIAL TECHNOLOGY CO.,LTD Model/Type reference....................... : LW-13 Listed Models .................................. : LW-3, LW-YZW-2 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Rating ............................................... : DC 1.5V From battery Result................................................ : PASS Report No.: CTA23102600901 Page 2 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Fashion Wireless Silent Mouse Model /Type : LW-13 Listed Models : LW-3, LW-YZW-2 Applicant : SHENZHEN STARWAVE INDUSTRIAL TECHNOLOGY CO.,LTD Address : 1505 Floor 15, Huaide International Building, No. 73, Fuyong Section, Guangshen Road, Huaide Community, Fuyong Street, Bao 'an District, Shenzhen Manufacturer : SHENZHEN STARWAVE INDUSTRIAL TECHNOLOGY CO.,LTD Address : 1505 Floor 15, Huaide International Building, No. 73, Fuyong Section, Guangshen Road, Huaide Community, Fuyong Street, Bao 'an District, Shenzhen Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23102600901 Page 3 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 9 3.6 Equipments Used during the Test 10 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 12 4.3 Maximum Peak Output Power 18 4.4 20dB Bandwidth 19 4.5 Frequency Separation 21 4.6 Number of hopping frequency 22 4.7 Time of Occupancy (Dwell Time) 23 4.8 Out-of-band Emissions 25 4.9 Pseudorandom Frequency Hopping Sequence 29 4.10 Antenna Requirement 30 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 31 6 P H O T O S O F T H E E U T ........................................................... 32 Report No.: CTA23102600901 Page 4 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA23102600901 Page 5 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1…

Text truncated - open the document above for the full version.

FCC ID: 2BDOP-LW-13 Test Setup Photos of the EUT
