2BDPX-FAB01Finelntelli Advanced Indoor Bike

FineIntelli Advanced Indoor Bike User Manual Catalogue 2 3Important Safety Information Operating Instructions 5 Product Warranty Card18 4 FCC Compliance Important Safety Information 3 Thank you for choosing our products. To ensure your safety and health, please use this equipment correctly and obey the following warnings: 1. Please do not let children or pets near to the bike alone, keep a certain distance to avoid injury. 2. To ensure safety, the equipment should have at least 1 meter of free space all around it. 3. Please set up and operate this equipment on a solid, level, horizontal surface. 4. Before each use, please ensure that the moving components are tightened, e.g. seat, handlebar,pedals, crank and so on. 8. This equipment is designed for indoor and home use only, please do not use it outdoors or in a wet or moist location. 5. Do not overwhelm during the exersice. If you feel unwell, please stop exercising immediately and go to the hospital for examination in case. 7. Do not try to change the design or functionality of this equipment, Otherwise it would not work correctly or cause potential vulnerabilities. 11. Please keep this manual well for future reference of operation. 9. This equipment is not intended for use by anyone under 14 years of age or above 60 years of age. 6. Do not put fingers or other objects into moving parts of the exsercie equipment to avoid injury or damage. 10. Maximum user weight limit: 100 kg (220 lbs.). Do not use if you are over this weight. 4 The machine and power supply comply with part 15 of the FCC rules.Op- eration is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)this device must accept any interfer- ence received, including interference that may cause undesired operation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interfer- ence by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This product complies with the European Radio Equipment Directive 2014/53/EU. * RF warning for Portable device: The device has been evaluated to meet general RF exposure require- ment.The device can be used in portable exposure condition without restriction. This machine and power supply have been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential instal- lation. Thisequipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communi- cations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Note: Tap "New User" to enter the page for creating a new user. After set the user name, click "Save" button to create a new user. Home page 1 Tap the user setting icon to enter the user setting page. For details, see p6. Users list. Local time. It's available when connected to the internet via WiFi. Status bar. It indicates the connections, e.g. "Wearable device Connection", "Mobile phone Connection", "WiFi connection". The grey color of the icon means disconnected while the white means connected. Local time. It's available when connected to the internet via WiFi.If there is an exception, there is a corresponding exception icon here. Tap the flag icon to enter the goal setting page. See the p9 for details. Click the button to start a new workout, first it will load the preset heights of the user's handlebar and seat, and then enter the workout page. Tap "Have A Try" to quickly start a workout without any setting, and the workout data will not recorded. Page indicator. When navigate to the adjacent page by sliding left or right on the screen, it indicates the active page and the page's location. 2 3 6 5 4 9 7 8 10 Operating Instructions 1 2 3 6 5 4 7 8 9 10 5 Operating Instructions Tap the setting icon to pop up setting page which presents the settings of the brightness, voice, volume, fan. See p7 for details. 1 Tap the minus icon to lift down the handlebar, and touching any area of the screen will stop lifting. Height indicator. It shows the current position of the handlebar in a scope between minimum and maximum height. Scroll through the listbox to quickly choose a height you want to set. Tap the plus icon to lift up the handlebar, and touching any area of the screen will stop lifting. User name, and tap it to modify. 2 3 5 4 6 7 Tap the heart icon to set the max heart rate. See p8 for details. Click "Cancel" to exit the page without saving the settings; Click "Save" to save all the individual settings and exit the page. 8 User Settings 6 2 1 5 7 8 4 3 6 Move the slider's knob to control the fan speed. It's only available in Manual mode. Operating Instructions 1 Move the slider's knob to control the speaker volume. Move the slider's knob to control the screen brightness. Select the work mode of the voice assistant. "Standby" means the user should wake up the voice assistant before use it by speaking wake word, "Working" means the voice assistant is able to receive the command all the time, "Off" means the voice assistant falls asleep and won't receive any command.; The fan mode can be "Auto" or "Manual". Auto (A) :The fan speed will adapt to the bike's velocity. The higher the velocity goes,the faster the fan runs. Manual (…

Text truncated - open the document above for the full version.

(ShenzhenFineIntelliTechnologyCo.,LTD) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023-12-25 FCCID:2BDPX-FAB01 Ref.#1:AttestationStatementsPart2.911(d)(5)(i)Filing (“ShenzhenFineIntelliTechnologyCo.,LTD”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Ref.#2:AttestationStatementsPart2.911(d)(5)(ii)Filing (“ShenzhenFineIntelliTechnologyCo.,LTD”) certifiesthat,asofthedateofthefilingof theapplication,theapplicant[isnot]identifiedontheCoveredListasanentity producing“covered”equipment. Applicant:ShenzhenFineIntelliTechnologyCo.,LTD Address:201,BuildingD,No.472-5,JinbiRoad,BilingCommunity,PingshanDistrict, Shenzhen ContactPerson:AnikChen Tel.:ProjectManager Email:[email protected] Sincerely, Signature:

ShenzhenFineIntelliTechnologyCo.,LTD Address：201,BuildingD,No.472-5,JinbiRoad,BilingCommunity,PingshanDistrict, Shenzhen FRN:0034520874 Date:2023-12-25 FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2BDPX-FAB01 (“ShenzhenFineIntelliTechnologyCo.,LTD”)certifiesthat,asofthedateofthefilingofthe application,(JOCAustraliaInc)isourdesignatedU.S.agentforserviceofprocessforthe abovereferencedFCCID.(“ShenzhenFineIntelliTechnologyCo.,LTD”)acceptsto maintainanagentfornolessthanoneyearafterthegranteehasterminatedallmarketing andimportationorthe conclusionofanyCommission-relatedproceedinginvolvingtheequipment. (JOCAustraliaInc)accepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:JOCAustraliaInc Address:18351ColimaRoadSte585RowlandHeights,California,91748UnitedStates ofAmerica ContactPerson:Benjamin.Smith/VicePresident Tel.:+1(626)2174778 Email:[email protected]/[email protected] FRN:0033379421 GC: Sincerely, ShenzhenFineIntelliTechnologyCo.,LTDJOCAustraliaInc Name:AnikChen Name:Benjamin.Smith Title:ProjectManagerTitle:VicePresident Date:2023-12-25Date:2023-12-25

Persisting in Technology antenna solutions for wireless technologies Prepared By: caichengweiDate of Report: 2023-9-13 Fab01 Antenna Evaluating Report Auden Communications & Multimedia Techno (Kunshan) Co., Ltd Shenzhen branch Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications 報告紀錄/ Report History Description Rev Date TEST Ant Efficiency and Gain 01 2023-9-13 Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications 测试设备/ Equipment  Chamber：GTS Rayzone1800  网络分析仪：Agilent E5071C  2G/3G综测仪：Agilent 8960  LTE综测仪：Anritsu MT8820  TD综测仪：StarPoint SP6010  WIFI综测仪：Anritsu MT8860  GPS信号源：Agilent E4438C Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications 整机环境说明/ Fixture Environment 天线频段 Band 使用系统 Band 使用系统 2.4G WIFI / BT - GSM - GPS - WCDMA - FM - TD-SCDMA - Others - CDMA FDD LTE TDD LTE Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications Ant TEST Gain Eff. Frequency(MHz) 1.07 40.86 2400 1.22 43.54 2410 1.11 42.75 2420 1.32 44.54 2430 1.46 45.49 2440 1.51 46.18 2450 1.81 49.7 2460 1.71 50.52 2470 1.35 46.98 2480 1.58 47.75 2490 1.61 47.49 2500 Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications Ant TEST E1 Plant Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications Ant TEST E2 Plant Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications Ant TEST H plant Company Confidential, Auden Many aspects of this presentation are protected by US, TW, CN a nd international patents and patent applications Ant TEST 3D Radiation 1.Antenna Antena describe: describe Antenna plate Pcb antenna Make name/model name FAB01 Antenna gain 1.81 dBi Frequency range 2.4GHZ-2.483GHZ connector type PCB Location of measement (company name) Auden Communications & Multimedia Techno (Kunshan) Co., Ltd Shenzhen branch 2.External view drawing: picture of antenna mm mm mm mm mm mm mm

ShenzhenFineIntelliTechnologyCo.,LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:December26,2023 Subject;RequestforConfidentiality FCCID:2BDPX-FAB01 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket.  SchematicDiagram  BlockDiagram OperationalDescription Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:AnikChen Title:ProjectManager

EffectiveDate:April2,2020QSF7.6.4-8–AgentAuthorizationLetterTemplatePage1of1 RevisionDate:Revision:0 ShenzhenFineIntelliTechnologyCo.,LTD Date ProductModelNumber:FineIntelliAdvancedIndoorBike FCCID:2BDPX-FAB01 Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C.CanadaV5J5K5to actonourbehalfonallmattersconcerningtheabovenamedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatORGANIZATION.isallowedtoforwardallinformationrelatedtotheapproval projecttotheappliedcertificationbodyandtothenotificationentitiesandtodiscussanyissues concerningtheapprovalapplication.AnyandallactscarriedoutbyORGANIZATION.onour behalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:ProjectManager Email:[email protected] Telephone:(+86)13724279227 Onbehalfof:ShenzhenFineIntelliTechnologyCo.,LTD

ExternalPhotograph BLEEmitter WIFIEmitter

FCCID:2BDPX-FAB01 LabelLocation

InternalPhotograph BLE ANT WIFI ANT

ReportNo.:TH2306285-C04-R02FCCID:2BDPX-FAB01Page 1 of 22 FCCTestReport Applicant : ShenzhenFineIntelliTechnologyCo.,LTD Address: 201,BuildingD,No.472-5,JinbiRoad,Biling Community,PingshanDistrict,Shenzhen ProductName:FineIntelliAdvancedIndoorBike ReportDate:12.25,2023 ShenzhenTianHaiTestTechnologyCo.,Ltd. ReportNo.:TH2306285-C04-R02FCCID:2BDPX-FAB01Page 2 of 22 Contents 1.GeneralInformation................................................................................................................................4 1.1.ClientInformation..........................................................................................................................4 1.2.DescriptionofDevice(EUT).........................................................................................................4 1.3.AuxiliaryEquipmentUsedDuringTest.........................................................................................4 1.4.DescriptionofTestMode..............................................................................................................5 1.5.TestSummary...............................................................................................................................5 1.6.TestEquipmentList......................................................................................................................6 1.7.MeasurementUncertainty............................................................................................................6 1.8DescriptionofTestFacility.............................................................................................................7 2.PowerLineConductedEmissionTest....................................................................................................8 2.1.TestStandardandLimit................................................................................................................8 2.2.TestSetup.....................................................................................................................................8 2.3.TestProcedure..............................................................................................................................9 2.4.TestResults...................................................................................................................................9 3.RadiatedEmissionTest(Below1GHz)................................................................................................12 3.1.TestStandardandLimit..............................................................................................................12 3.2.TestSetup...................................................................................................................................13 3.3.TestProcedure............................................................................................................................14 3.4.TestResults................................................................................................................................14 4.RadiatedEmissionTest(Above1GHz)................................................................................................17 4.1.TestStandardandLimit..............................................................................................................17 4.2.TestSetup...................................................................................................................................18 4.3.TestProcedure............................................................................................................................19 4.4.TestResults................................................................................................................................19 APPENDIXI--TESTSETUPPHOTOGRAPH........................................................................................22 APPENDIXII--EXTERNALPHOTOGRAPH..........................................................................................22 APPENDIXIII--INTERNALPHOTOGRAPH...........................................................................................22 ReportNo.:TH2306285-C04-R02FCCID:2BDPX-FAB01Page 3 of 22 TESTREPORT Applicant:ShenzhenFineIntelliTechnologyCo.,LTD Manufacturer: 201,BuildingD,No.472-5,JinbiRoad,BilingCommunity, PingshanDistrict,Shenzhen ProductName:FineIntelliAdvancedIndoorBike ModelNo.:FAB01 TradeMark:Fineintelli Rating(s): Input::100~240V50-60Hz Output:24V4A TestStandard(s): FCC47CFRPart15SubpartB:2022 TestMethod(s): ANSIC63.4-2014 ThedevicedescribedaboveistestedbyShenzhenAnbotekComplianceLaboratoryLimitedTo determinethemaximumemissionlevelsemanatingfromthedevice.Themaximumemissionlevels arecomparedtotheFCC47CFRPart15SubpartBlimitsbothradiatedandconductedemissions. ThemeasurementresultsarecontainedinthistestreportandShenzhenAnbotekCompliance LaboratoryLimitedIsassumedfullresponsibilityfortheaccuracyandcompletenessofthese measurements. Thisreportappliestoabovetestedsampleonly.Thisreportshallnotbereproducedinpartwithout writtenapprovalofShenzhenAnbotekComplianceLaboratoryLimited DateofReceipt: Nov.02,2023 DateofTest:Nov.02~Dec.25,2023 Testedby : (SunyZhuo) Reviewedby : (BlueHu) Approved&AuthorizedSigner : (Binglee) ReportNo.:TH2306285-C04-R02FCCID:2BDPX-FAB01Page 4 of 22 1.GeneralInformation 1.1.ClientInformation Applicant:ShenzhenFineIntelliTechnologyCo.,LTD Address: 201,BuildingD,No.472-5,JinbiRoad,BilingCommunity,PingshanDistrict, Shenzhen Manufacturer:ShenzhenFineIntelliTechnologyCo.,LTD Address: 201,BuildingD,No.472-5,JinbiRoad,BilingCommunity,PingshanDistrict, Shenzhen Factory:ShenzhenFineIntelliTechnologyCo.,LTD Address: 201,BuildingD,No.472-5,JinbiRoad,BilingCommunity,PingshanDistrict, Shenzhen 1.2.DescriptionofDevice(EUT) ProductName:FineIntelliAdvancedIndoorBike ModelNo.: FAB01 TradeMark:Fineintelli TestPowerSupply: Input::100~240V50-60Hz Output:24V4A TestSampleNo.:1-2-1(NormalSample) Adapter : MODEL:SPF-2404 Input::100~240V50-60Hz Output:24V4A Remark:(1)Foramoredetail…

Text truncated - open the document above for the full version.

TestSetupPhotograph PhotoofConductedEmissionMeasurement PhotoofRadiationEmissionTest
