2BDR8-24SIXSOLO424Six Solo 4

Product and Brand24Six TypeSolo 4 Operating system 2.4GHz / 5.0GHz Bluetooth5.0 Volt age5V Power SourceLi-Polymer 2000mah Batt er y IncludedYes Audio Jack3.5mm Int ernal Memory128GB RAM4GB SIMN/ A Product Dimension113.6x63.5x12mm Product Weight200g Sreen Size4.0" Device Over view 2 24Six Solo 4 Quick Guide24Six Solo 4 Quick Guide 3 OS Wifi Welcome to the 24Six Solo MP3 Music Player . How to use 24Six: → Create your account at www.2 4six.app. → Login to the app on the device to → for each person using 24Six, so you can customize the experience for them. → The 24Six Solo 4 can only do one thing: Play 24Six Music. There is no phone, camera, calculator, messaging, or int ernet on this device. When you turn on the device, connect to Wi-Fi, you can also connect to a Bluetooth speak er if you choose. → Login once to the 24Six app with the parental password, and then each user unique 4-digit passcode. → login using the account pass word. → If you have any questions, feel free to email support anytime at [email protected]. Getting Star ted24SixOS Aut omatic Updates 24Six Solo 4 runs on the exclusive 24SixOS. 24SixOS is a custom operating system that locks the entire device, ensuring a user experience that is 100% safe. The only thing the 24SixOS does is play 24Six, and it gives you access to the settings you need. You can connect to Wi-Fi, Bluetooth, set the Date & Time, change the language to Hebrew from English, and restar t the device. You cannot add additional apps. There is no SD card slot or SIM card. There are no other apps, and no home screen. 24Six Solo 4 is a solo device with a solo purpose: to play 24Six Music! When turning on 24Six Solo 4, connect to Wi-Fi and the device will automatic ally update to ensure you have the latest updates of both 24SixOS and the 24Six Solo 4 app. 24Six Solo 4, when connected to Wi-Fi, will always check for the latest updates, and automatic ally update in the background, so you will always have the latest, most up-to-date app and features! 4 24Six Solo 4 Quick Guide24Six Solo 4 Quick Guide 5 Subscribe and Play! 1. Scan QR Code or visit www.2 4Six.app/register 2. Create an account 3. Log in to 24Six 4. Enjoy! Get star ted in 4 easy steps 24Six is a registered trademark. Copyright © 24Six Inc. All rights reserved. CE Maintenance 1.The product shall only be connected to a USB interface of version USB2.0. Power supply and ADP(rating): Input: DC 5V 2A Declaration of Conformity 24Six Player LLC hereby declares that this 24Six Solo 4 is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU. In accordance with Article 10(2) and Article 10(10),This product is allowed to be used in all EU member states. For CE: operating temperature：0°C- 40°C This device is restricted to indoor use only when operating in 5150 to 5350 MHz. The maximum results of SAR as follows: Body-worn (with 0mm separation): 0.211W/Kg limbs (with 0mm separation): 0.211W/Kg BR+EDR: 2402~2480 MHz 3.61dBm (EIRP) BLE: 2402~2480 MHz -3.09 dBm (EIRP) 2.4G WIFI: 2412~2472MHz 13.78dBm (EIRP) 5.2G RLAN: 5180~5240MHz 13.25dBm (EIRP) 5.3G RLAN: 5260~5320MHz 13.97dBm (EIRP) 5.6G RLAN: 5500~5700MHz 14.11dBm (EIRP) For FCC: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RF Exposure Warning Statement: This equipment has been tested for SAR compliance. This equipment should be installed and operated with minimum distance 0 mm between the radiator and your body. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter. For USA: The frequency stability of all transmission frequencies of U-NII-1, U-NII 2A, U-NII 2C meets the requirements of 47 CFR FCC Part15.407(g), and the manufacturer declares that their transmission is maintained at Band U-NII-1, U-NII 2A, U-NII 2C.
