2BDRQ-RTP403RuxTek 3G WCDMA Fixed Wireless Phone without WiFi
RuxTek Co.,Ltd
Click to zoom
Application Details
- Equipment Class
- PCB - PCS Licensed Transmitter
- Date of Grant
- Jan 04, 2024
- Application Purpose
- Original Equipment
- Date of Application
- Jan 03, 2024
- Equipment Note
- RuxTek 3G WCDMA Fixed Wireless Phone without WiFi
- Frequency Range
- 1852.40000000 - 1907.60000000
- Company
- RuxTek Co.,Ltd
- Country
- Taiwan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Cover Letter(s)
RuxTek Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: December 25, 2023 Subject; Request for Confidentiality FCC ID: 2BDRQ-RTP403 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, X X
External Photos
Page 1 of 6 Report No.: LGT23K084 Appendix - External Photographs of EUT Constructional Details FCC ID: 2BDRQ-RTP403 Model: RTP-403 Photo 1 Photo 2 Page 2 of 6 Report No.: LGT23K084 Photo 3 Photo 4 Page 3 of 6 Report No.: LGT23K084 Photo 5 Photo 6 Page 4 of 6 Report No.: LGT23K084 Photo 7 Photo 8 Page 5 of 6 Report No.: LGT23K084 Photo 9 Photo 10 Page 6 of 6 Report No.: LGT23K084 Photo 11 Photo 12 ANT
ID Label/Location Info
Label RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Mode: RTP-403 Rating: 5V⎓1A FCC ID: 2BDRQ-RTP403 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Internal Photos
Page 1 of 6 Report No.: LGT23K084 Appendix - Internal Photographs of EUT Constructional Details FCC ID: 2BDRQ-RTP403 Model: RTP-403 Photo 1 Photo 2 Page 2 of 6 Report No.: LGT23K084 Photo 3 Photo 4 Page 3 of 6 Report No.: LGT23K084 Photo 5 Photo 6 Page 4 of 6 Report No.: LGT23K084 Photo 7 Photo 8 Page 5 of 6 Report No.: LGT23K084 Photo 9 Photo 10 Page 6 of 6 Report No.: LGT23K084 Photo 11
RF Exposure Info
SAR Dipole Performance Measurement Report If dipoles are verified in return loss<-20dB, (within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 835 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2022.02.11 -25.67 - 54.4 - 2023.02.08 -27.048 5.37 56.211 1.81 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 835MHz Head 1900 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2022.02.11 -25.33 - 52.4 - 2023.02.08 -23.790 -6.08 49.567 -2.83 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 1900 MHz ※※※※※END OF THE REPORT※※※※※
RF Exposure Info
!! " !#$ %# &'()*+,$ ! )$ ! - %./-0 10/2 $ !#''/ 3- 3-%% /!0%$ 4- 0 !3 3 . -" 2 -.)%-/- $1- 0 5%-/- $ $.0 %! $ - 0 36 !3!0/%!-3 /- (7- %1/!) /-0 !#8 +9:** 1!';9 <=>?@<ABC<A36 #-#CB=<DE>FABCGC><?=B BHIFEDJ=B)@BKA-@E>KBL*M,<NBFGB0=BO>KCB/EHIEF *M*P+1!. 0 (7/0 <=>?@<A>EFC<AB8+*:&+:*+*' QQR STUVUTWXYZ[\]^_ QW` VaVTbVcb WXdddQW RVQ R IBGKBEeAIB Ee@<H?@<FC<FCAIB<HH@BC>A<A>EF@BeB@BFHBK>KD@EI>?>ABCe@Ef<Fg@BD@ECGHA>EF# hijjkl mnTYSWQop XU`R Y XUYUn p UnWSVXSR YobUY RWpVXVQQR STU Sqrq [sT bStRWc QVbTcRVUTWX` R WRp SVUruvwoYTXxUn yzt qU YUc XQnw WRoY dTUnVruvqrq Y{YU pWXb{mn U YUR YobUYQWa R Sc{VQQR STUVUTWXVR URVQ Vcb UWUn zXU RXVUTWXVb{YU pW |XTUY}z~ !3 !0/ (7>B=C1@E?B <=>?@<A>EF/BDE@A Ref : ACR.41.6.23.BES.A !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ M" _LNKOGJN ` O" aG!N OLR" R"S R"I Q] # bcdef ghi jiklmino pnlnqd uF"Kv"I Q] # bcdef ghi jiklmino pnlnqd wSSRJX"I Q] xnll jyhznml gn{ydnzyd| }mdizyd uLHOJM"R ^ M" `GHORGQLOGJN # g~j klkl jz jiklyoyq| y gz HHL" ^ M" ` O" YJIGVGK OGJNH bcdef ghi lmzmno don Ref: ACR.41.6.23.BES.A 2/10/2023 2/10/2023 2/10/2023 2/10/2023 !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ _`ab cdef ghi jfkelbi _hbfamiakd ^ ndfop qdkfroiakd sssssssssssssssssssssssssssssssssssssssssssssssssssssss t uohlfrdi uivke t^ wadofaix ssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss t dhaia`aix sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss tt wkyf _ibiakd warai sssssssssssssssssssssssssssssssssssssssssssssssssssss t qhkifkmx sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss t^ kldeofx bi ssssssssssssssssssssssssssssssssssssssssssssssssssssssssss uohlfrdi cdbfioadix z opa{foiakd uohlfrdi hlpih z ^ dhaia`aix ad oaf ssssssssssssssssssssssssssssssssssssssssssssssssssssssssss z wadofaix ssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss | t dhaia`aix ad pa}lae ssssssssssssssssssssssssssssssssssssssssssssssssssssssss ~ qhkifkmx sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss z wahi k }lamrdi ^ Ref: ACR.41.6.23.BES.A !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ _ ` abcdeb fghbi jbkl mnop qrs tut mt vu qv wv xm yt uz{|zp}|~~ u u ~oz | ~ yt y~|p} {o}o{ { | w~|{pr z{ y~ o}z{p q~ mos z} {{p}~ mos u mos u mos u ` x vwtuqvt ¡¢ £ ¤¥¦§ ̈ ©ª«¬¦ ª¦ ¬®¥§ ̄ ¥° zpp~z{p } } v v ±² z{ w ³m ² m }z{z~ ́μ¶· ̧ ^ ¹ YZ[ º»Y»¼½¾ ¿JHGM"ORGK À VG"PI RJQ" y~ x{} x{} v{ono|z mos uzÁo | Á}~{z oz }~ ² y~ qos Á}~{z moz }~ mo}z{p }{ os s~ Á}~ o}r  ` à q v v ±² z{ w ³m ² m }z{z~ s~no ~p { s~zp}op ~ } s~ pzo~z}o{Ä o{p|o{ } s~~ z{p pz~zp}~o}op o{}~} z{ } r op } z }o~ zp} pzo~z}o{ z|~ {} s~~ } } ~ {}o{ }z{z~ xv vqÅ q nz|z}o{ } o{z~o}r z { o{ ~ szp |o{ } zn|oÄ s~~ o{ z s~ s } pn~ } ~z{ ÆÇ } ÆÇ vqvvqÅ q {o}ono}r zp}~ } }~ os ~ }~ o{ |o{ z } }s pzo~z}o{ } zo~ z { }o| o |z}o{ o|o |o{ zn|o z |}o{ o{ } }z{z~ Ref: ACR.41.6.23.BES.…
Text truncated - open the document above for the full version.
Test Report
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China SAR TEST REPORT Product Name: RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Model Name: RTP-403 FCC ID: 2BDRQ-RTP403 Issued For : RuxTek Co.,Ltd 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035 , Taiwan Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23K084HA01 Sample Received Date: Nov. 29, 2023 Date of Test: Nov. 29, 2023 ~ Dec. 19, 2023 Date of Issue: Dec. 20, 2023 Max. SAR (1g): Body: 1.089 W/kg Reprot No.: LGT23K084HA01 Page 2 of 43 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Antenna Location Sketch 15 7.1 SAR test exclusion consider table 16 8. EUT Test Position 18 8.1 Body-worn Position Conditions 18 9. Uncertainty 19 9.1 Measurement Uncertainty 19 10. Conducted Power Measurement 20 10.1 Test Result: 20 11. EUT and Test Setup Photo 22 11.1 EUT Photos 22 11.2 Setup Photos 28 12. SAR Result Summary 33 12.1 Body-worn and Hotspot SAR 33 13. Equipment List 35 Appendix A. System Validation Plots 36 Appendix B. SAR Test Plots 40 Appendix C. Probe Calibration and Dipole Calibration Report 43 Reprot No.: LGT23K084HA01 Page 3 of 43 Revision History Rev. Issue Date Contents 00 Dec. 20, 2023 Initial Issue Reprot No.: LGT23K084HA01 Page 4 of 43 TEST REPORT CERTIFICATION Applicant RuxTek Co.,Ltd Address 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035 , Taiwan Manufacture RuxTek Co.,Ltd Address 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035 , Taiwan Product Name RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Trademark RuxTek Model Name RTP-403 Sample number LGT2311090-1 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Zane Shan Engineer Vita Li Manager Reprot No.: LGT23K084HA01 Page 5 of 43 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Trademark RuxTek Model Name RTP-403 Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version L3500_117-4G_MB REV:A/0 Software Version QX_W3600_SA_BW_T107_N44_0002 Frequency Range GGSM 850: 824 ~ 849 MHz PCS 1900: 1850 ~ 1910 MHz WCDMA Band II: 1850 ~ 1910 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance:0mm Mode Body (W/kg)) GSM 850 1.012 PCS 1900 1.089 WCDMA Band II 1.050 Battery Rated Voltage:3.7V Capacity: 1000mAh Operating Mode: GSM: GSM Voice; GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 Antenna Specification GSM/WCDMA: Paddle Antenna Operating Mode Maximum continuous output SIM Card Only Support single SIM card. Hotspot Mode Not Support DTM Mode Not Support Reprot No.: LGT23K084HA01 Page 6 of 43 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate FCC Registration No.: 746540 A2LA Certificate No.: 6727.01 IC Registration No.: CN0136 Reprot No.: LGT23K084HA01 Page 7 of 43 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 941225 D01 v03r01 SAR Measurement Procedures for 3G Devices (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General Population/Uncontrolled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.08 1.6 4.0 NOTE: Whole-Body SAR is averaged over the entire body, partial-body SAR is averaged over any 1 gram of tissue defined as a tissue volume in the shape of a cube. SAR for hands, wrists, feet and ankles is averaged over any 10 grams of tissue defined as a tissue volume in the shape of a cube. Population/Uncontrolled Environments: Are defined as locations where there is the exposure of individuals who have …
Text truncated - open the document above for the full version.
Test Report
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Model Name: RTP-403 FCC ID: 2BDRQ-RTP403 Issued For : RuxTek Co.,Ltd 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035, Taiwan Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT23K084RF02 Sample Received Date: Nov. 23, 2023 Date of Test: Nov. 23, 2023 – Dec. 07, 2023 Date of Issue: Dec. 07, 2023 Report No.: LGT23K084RF02 Page 2 of 69 TEST REPORT CERTIFICATION Applicant: RuxTek Co.,Ltd Address: 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035, Taiwan Manufacturer: RuxTek Co.,Ltd Address: 4F., No. 61, Sanfu St., Shulin Dist., New Taipei City 238035, Taiwan Product Name: RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Trademark: RuxTek Model Name: RTP-403 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 22H and 24E, 27 KDB 971168 D01 v03r01, ANSI C63.26( 2015) PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT23K084RF02 Page 3 of 69 Table of Contents Page 1 SUMMARY OF TEST RESULTS 5 2 INTRODUCTION 6 2.1 TEST FACTORY 6 2.2 MEASUREMENT UNCERTAINTY 6 3. PRODUCT INFORMATION 7 4 TEST CONFIGURATION OF EQUIPMENT UNDER TEST 8 5 MEASUREMENT INSTRUMENTS 9 6 TEST ITEMS 10 6.1 CONDUCTED OUTPUT POWER 10 6.2 PEAK TO AVERAGE RATIO 11 6.3 TRANSMITTER RADIATED POWER (EIRP/ERP) 12 6.4 OCCUPIED BANDWIDTH 13 6.5 FREQUENCY STABILITY 14 6.6 SPURIOUS EMISSIONS AT ANTENNA TERMINALS 15 6.7 BAND EDGE 16 6.8 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 17 APPENDIX I. TESTRESULT 19 2G 19 CONDUCTED OUTPUT POWER 19 FREQUENCY STABILITY 21 PEAK-TO-AVERAGE RATIO 24 OCCUPIED BANDWIDTH 31 BAND EDGE 38 OUT-OF-BAND EMISSIONS 43 RADIATED SPURIOUS EMISSION 50 3G 56 CONDUCTED OUTPUT POWER 56 FREQUENCY STABILITY 57 PEAK-TO-AVERAGE RATIO 58 OCCUPIED BANDWIDTH 60 BAND EDGE 62 OUT-OF-BAND EMISSIONS 64 RADIATED SPURIOUS EMISSION 66 APPENDIX II- PHOTOS OF TEST SETUP 69 Report No.: LGT23K084RF02 Page 4 of 69 Revision History Rev. Issue Date Contents 00 Dec. 07, 2023 Initial Issue Report No.: LGT23K084RF02 Page 5 of 69 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of KDB 971168 D01 v03r01 and ANSI C63.26-2015 FCC Rules Test Description Test Limit Test Result Reference 2.1046 Conducted Output Power Reporting Only PASS 22.913d 24.232d Peak-to-Average Ratio < 13 dB PASS 2.1046 22.913 24.232 27.50 Effective Radiated Power/Equivalent Isotropic Radiated Power < 7 Watts max. ERP(Part 22) < 2 Watts max. EIRP(Part 24) <1 Watts max. EIRP(Part 27) PASS 2.1049 22.917 24.238 27.53 Occupied Bandwidth Reporting Only PASS 2.1055 22.355 24.235 27.54 Frequency Stability < 2.5 ppm (Part 22) Emission must remain in band (Part 24) Emission must remain in band (Part 27) PASS 2.1051 22.917 24.238 27.53 Spurious Emission at Antenna Terminals < 43+10log10(P[Watts]) PASS 2.1053 22.917 24.238 27.53 Field Strength of Spurious Radiation < 43+10log10(P[Watts]) PASS 2.1051 22.917 24.238 27.53 Band Edge < 43+10log10(P[Watts]) PASS Report No.: LGT23K084RF02 Page 6 of 69 2 INTRODUCTION 2.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 2.2 MEASUREMENT UNCERTAINTY The measurement uncertainties shown below were calculated in accordance with the requirements of ANSI C63.26. All measurement uncertainty values are shown with a coverage factor of k = 2 toindicate a 95% level of confidence. The measurement data shown herein meets or exceeds the UCISPRmeasurement uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly tospecified limits to determine compliance. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Note: The measurement uncertainty is not included in the test result. Report No.: LGT23K084RF02 Page 7 of 69 3. PRODUCT INFORMATION Product Name: RuxTek 3G WCDMA Fixed Wireless Phone without WiFi Trademark: RuxTek Model Name: RTP-403 Series Model: N/A Model Difference: N/A Tx Frequency: GSM/GPRS/EDGE: 850: 824 MHz ~ 849MHz 1900: 1850 MHz ~ 1910MHz WCDMA: Band II: 1850 MHz ~ 1910 MHz Rx Frequency: GSM/GPRS/EDGE: 850: 869 MHz ~ 894 MHz 1900: 1930 MHz ~ 1990MHz WCDMA: Band II: 1930 MHz ~ 1990 MHz Modulation Characteristics: GMSK for GSM/GPRS; GMSK and 8PSK for EDGE WCDMA: QPSK; HSDPA: QPSK/16QAM; HSUPA: BPSK SIM Card: Olny one SIM card. Antenna: Paddle Antenna Antenna gain: GSM 850: -0.53dBi GSM 1900: 1.6dBi WCDMA B2: 1.6dBi Adapter: Input: 100-240V, 50/60Hz, 0.2A Max Output: 5.0V, 1.0A 5.0W Battery: Capacity: 1000mAh Rated Voltage: 3.7 V GPRS Class: Multi-Class12 Extreme Vol. Limits: 3.4V to 4.2V (Nominal 3.7V) Extreme Temp. Tolerance: -0°C to +50°C Hardware version: L3500_117-4G_MB REV:A/0 Software version: QX_W3600_SA_BW_T107_N44_0002 ** Note: The High Voltag…
Text truncated - open the document above for the full version.
Test Report
Report No.: LGT23K084RF02 Page 49 of 69 EGPRS1900 Channel=512 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No.: LGT23K084RF02 Page 50 of 69 RADIATED SPURIOUS EMISSION GSM 850: (30-9000)MHz The Worst Test Results Channel 128/824.2 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1648.31 -33.84 7.40 4.75 -31.19 -13.00 -18.19 H 2472.70 -31.03 8.20 8.39 -31.22 -13.00 -18.22 H 3296.88 -24.69 7.20 11.79 -29.28 -13.00 -16.28 H 1648.15 -27.09 7.40 4.75 -24.44 -13.00 -11.44 V 2472.58 -29.77 8.20 8.39 -29.96 -13.00 -16.96 V 3296.63 -23.56 7.20 11.79 -28.15 -13.00 -15.15 V The Worst Test Results Channel 190/836.6 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1672.94 -34.20 7.40 4.76 -31.56 -13.00 -18.56 H 2509.55 -32.12 8.20 8.40 -32.32 -13.00 -19.32 H 3346.36 -29.23 7.20 11.80 -33.83 -13.00 -20.83 H 1673.27 -30.41 7.40 4.75 -27.76 -13.00 -14.76 V 2509.81 -29.23 8.20 8.39 -29.42 -13.00 -16.42 V 3346.13 -23.98 7.20 11.82 -28.60 -13.00 -15.60 V The Worst Test Results Channel 251/848.8 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1697.27 -33.77 7.40 4.77 -31.14 -13.00 -18.14 H 2546.30 -33.36 8.20 8.50 -33.66 -13.00 -20.66 H 3395.21 -26.12 7.20 11.90 -30.82 -13.00 -17.82 H 1697.40 -26.82 7.40 4.77 -24.19 -13.00 -11.19 V 2546.38 -29.02 8.20 8.50 -29.32 -13.00 -16.32 V 3395.33 -24.49 7.20 11.90 -29.19 -13.00 -16.19 V Report No.: LGT23K084RF02 Page 51 of 69 GPRS 850: (30-9000)MHz The Worst Test Results Channel 128/824.2 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1648.20 -35.06 7.40 4.75 -32.41 -13.00 -19.41 H 2472.58 -31.15 8.20 8.39 -31.34 -13.00 -18.34 H 3296.80 -29.31 7.20 11.79 -33.90 -13.00 -20.90 H 1648.09 -28.66 7.40 4.75 -26.01 -13.00 -13.01 V 2472.61 -29.05 8.20 8.39 -29.24 -13.00 -16.24 V 3296.63 -23.23 7.20 11.79 -27.82 -13.00 -14.82 V The Worst Test Results Channel 190/836.6 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1673.16 -31.80 7.40 4.76 -29.16 -13.00 -16.16 H 2509.85 -33.02 8.20 8.40 -33.22 -13.00 -20.22 H 3346.42 -28.28 7.20 11.80 -32.88 -13.00 -19.88 H 1673.08 -29.18 7.40 4.75 -26.53 -13.00 -13.53 V 2509.88 -29.70 8.20 8.39 -29.89 -13.00 -16.89 V 3346.29 -25.69 7.20 11.82 -30.31 -13.00 -17.31 V The Worst Test Results Channel 251/848.8 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1697.59 -35.30 7.40 4.77 -32.67 -13.00 -19.67 H 2546.43 -33.08 8.20 8.50 -33.38 -13.00 -20.38 H 3394.86 -24.52 7.20 11.90 -29.22 -13.00 -16.22 H 1697.51 -29.15 7.40 4.77 -26.52 -13.00 -13.52 V 2546.32 -29.09 8.20 8.50 -29.39 -13.00 -16.39 V 3395.33 -22.74 7.20 11.90 -27.44 -13.00 -14.44 V Report No.: LGT23K084RF02 Page 52 of 69 EGPRS 850: (30-9000)MHz The Worst Test Results Channel 128/824.2 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1648.31 -33.08 7.40 4.75 -30.43 -13.00 -17.43 H 2472.62 -29.43 8.20 8.39 -29.62 -13.00 -16.62 H 3296.44 -25.24 7.20 11.79 -29.83 -13.00 -16.83 H 1648.19 -29.95 7.40 4.75 -27.30 -13.00 -14.30 V 2472.69 -29.98 8.20 8.39 -30.17 -13.00 -17.17 V 3296.59 -21.49 7.20 11.79 -26.08 -13.00 -13.08 V The Worst Test Results Channel 190/836.6 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1673.10 -32.56 7.40 4.76 -29.92 -13.00 -16.92 H 2509.80 -29.89 8.20 8.40 -30.09 -13.00 -17.09 H 3346.19 -29.22 7.20 11.80 -33.82 -13.00 -20.82 H 1673.15 -30.32 7.40 4.75 -27.67 -13.00 -14.67 V 2509.62 -30.45 8.20 8.39 -30.64 -13.00 -17.64 V 3346.36 -21.25 7.20 11.82 -25.87 -13.00 -12.87 V The Worst Test Results Channel 251/848.8 MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 1697.27 -32.17 7.40 4.77 -29.54 -13.00 -16.54 H 2546.24 -30.86 8.20 8.50 -31.16 -13.00 -18.16 H 3395.03 -25.73 7.20 11.90 -30.43 -13.00 -17.43 H 1697.21 -29.22 7.40 4.77 -26.59 -13.00 -13.59 V 2546.52 -29.05 8.20 8.50 -29.35 -13.00 -16.35 V 3394.91 -23.84 7.20 11.90 -28.54 -13.00 -15.54 V Report No.: LGT23K084RF02 Page 53 of 69 PCS 1900: (30-20000)MHz The Worst Test Results for Channel 512/1850.2MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 3700.26 -25.70 7.00 12.93 -31.63 -13.00 -18.63 H 5550.53 -24.87 8.40 17.11 -33.58 -13.00 -20.58 H 7400.58 -24.02 8.30 22.20 -37.92 -13.00 -24.92 H 3700.51 -24.26 7.00 12.93 -30.19 -13.00 -17.19 V 5550.69 -26.24 8.40 17.11 -34.95 -13.00 -21.95 V 7400.55 -19.72 8.30 22.20 -33.62 -13.00 -20.62 V The Worst Test Results for Channel 661/1880.0MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 3759.91 -26.07 7.00 12.93 -32.00 -13.00 -19.00 H 5639.82 -26.61 8.40 17.11 -35.32 -13.00 -22.32 H 7519.91 -25.68 8.30 22.20 -39.58 -13.00 -26.58 H 3759.99 -21.73 7.00 12.93 -27.66 -13.00 -14.66 V 5639.86 -22.04 8.40 17.11 -30.75 -13.00 -17.75 V 7520.08 -24.15 8.30 22.20 -38.05 -13.00 -25.05 V The Worst Test Results for Channel 810/1909.8MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 3819.24 -25.66 7.00 12.93 -31.59 -13.00 -18.59 H 5729.35 -23.22 8.40 17.11 -31.93 -13.00 -18.93 H 7638.94 -26.32 8.30 22.20 -40.22 -13.00 -27.22 H 3819.71 -24.28 7.00 12.93 -30.21 -13.00 -17.21 V 5729.27 -21.87 8.40 17.11 -30.58 -13.00 -17.58 V 7639.17 -20.03 8.30 22.20 -33.93 -13.00 -20.93 V Report No.: LGT23K084RF02 Page 54 of 69 GPRS1900: (30-20000)MHz The Worst Test Results for Channel 512/1850.2MHz Frequency(MHz) S G.Lev (dBm) Ant(dBi) Loss PMea Limit Margin Polarity (dBm) （dBm） (dBm) 3700.25 -25.94 7.00 12.93 -31.87 -13.00 -18.87 H 5550.20 -23.81 8.40 17.11 -32.52 -13.00 -19.52 H 7400.73 -27.74 8.30 22.20 -41.64 -13.00 -28.64 H 3700.30 -21.07 7.00 12.93 -27.00 -13.00 -14.00 V 5550.48 -24.02 8.40 17.11 -32.73 -13.00 -19.73 V 7400.59 -19.25 8.30 22.20 -33.15 -13.00 -20.15 V The Worst Test Resu…
Text truncated - open the document above for the full version.
Test Setup Photos
Report No.: LGT23K084RF02 Page 69 of 69 APPENDIX II- PHOTOS OF TEST SETUP Set-up for Transmitter & Receiver Spurious Emissions, Below 1GHz Set-up for Transmitter & Receiver Spurious Emissions, Above 1GHz ※※※※※END OF THE REPORT※※※※※
Test Setup Photos
Page 1 of 4 Report No.: LGT23K084 2BDRQ-RTP403_SAR Setup photos Front Side Antenna Horizontal 0° (separation distance is 0mm) Front Side Antenna Vertical 90° (separation distance 0mm) Page 2 of 4 Report No.: LGT23K084 Front Side Antenna Horizontal 180° (separation distance 0mm) Back Side Antenna Horizontal 180° (separation distance 0mm) Page 3 of 4 Report No.: LGT23K084 Right Side Antenna Horizontal 180°(separation distance is 0mm) Left Side Antenna Horizontal 180°(separation distance is 0mm) Page 4 of 4 Report No.: LGT23K084 Top Side Antenna Horizontal 180°(separation distance is 0mm) Bottom Side Antenna Horizontal 180°(separation distance is 0mm)
