2BDTW-P1Tablet

1 1 Introduction 1.1 Acknowledgement Thank you very much for choosing this product.ZQC-P1, is a 7-inch HD tablet. The main chip is MT8766 based on Android 9.0 or above operating system, can easily expand third-party applications. Built-in 4 G、WIFI、BT、 voice calls and other functions, easy to achieve wireless communication and wireless network functions, anytime, anywhere surfing; built-in a variety of sensors to allow you to have a new control and entertainment experience. This manual system introduces the various functions, usage techniques and precautions of the MID. Please read this manual carefully before using the MID. 1.2 Notes Maintenance and maintenance ⚫ Please keep the equipment dry. Do not let the equipment, battery, charger contact with water and water vapor, or use wet hands to operate the equipment or charger, so as not to cause equipment short circuit, failure caused by corrosion, personnel electric shock. ⚫ Do not cause equipment, batteries and chargers to be strongly impacted or vibrated to avoid causing equipment, batteries and chargers to fail. ⚫ Do not place this device, battery and charger in areas where the temperature is too high or too low, otherwise it may cause equipment, battery and charger failure. ⚫ Please do not impact, throw, prick this MID, and avoid falling, squeezing, bending MID. ⚫ Do not disassemble equipment and accessories without authorization, otherwise the equipment and accessories will not be covered by our warranty. 1.3 Safety information Before using the MID, please read this section information and let your child know the information. For more detailed information, please refer to the safety instructions and precautions. ⚫ Do not use MID, when driving a car so as not to interfere with safe driving. 2 ⚫ In medical places, please abide by the relevant regulations or regulations. Close the MID. near the medical facility ⚫ Close the MID or turn on the aircraft mode when boarding to avoid wireless interference with the aircraft control signal. ⚫ Close near the use of high-precision electronic equipment, please close MID, otherwise it may cause electronic equipment failure. ⚫ Please do not disassemble MID and accessories without authorization. Only authorized bodies can maintain this MID. ⚫ Please keep the MID away from the magnetic device, MID radiation will erase the information stored on the magnetic device. ⚫ Do not use MID. at high temperatures, in places with flammable gases, such as near gas stations ⚫ Please keep MID and accessories out of reach of children. Do not allow children to use MID. without supervision ⚫ For the use of this MID, please abide by the relevant laws and regulations, and respect the privacy and legal rights of others. ⚫ Please strictly follow the relevant instructions in this manual when using USB data lines, otherwise it may damage your MID or personal computer. ⚫ Please do not use this MID, in wet environment such as bathroom and avoid soaking or washing this MID by liquid. 1.4 Abbreviations/terms Abbreviations/t erms Full name Note MID Mobile Internet Device Mobile Internet terminals WIFI Wireless Fidelity Wireless LAN based on IEEE 802.11b standards 3 2MID Introduction 2.1 MID Accessories Packing list And your MID box contains the following items: ⚫ MID machine ⚫ Power adapter ⚫ USB connection ⚫ Instructions 2.2 MID use and preparation Battery charging Charge the battery before using the MID for the first time. 1. Charge the MID using a power adapter. 2.3 MID Status and Notification Notification Form When prompt information appears in your notification panel, click the column box and slide your hand on the screen to open the notification list. Click on the options you need to view to see the details. You can then click on the information box to slide up to close the information window. Here is the status bar icon diagram: 4 New mail Flight pattern USB connected Connect USB debug Return key Download Short Click View Use History H ome buttons, Battery power WIFI service connected, network available Notice Panel A notification will report new mail, open WIFI, and ongoing activities. You can open the notification panel for specific information. Open Notification Panel When a new notification icon appears in the notification bar, click the notification bar to open the notification panel. 5 3 Quick Start 3.1 Key function Key function description: Power Key (power) Short press hibernation/wake function, long press switch function HOME key (home) Click on any interface to return to the main interface Return key (back) Any interface click this button to return to the previous directory Set key Click to display user-browsed history 3.2 Boot and shutdown Boot After pressing the POWER button for 3 seconds, you can see the boot screen. After the system is turned on, enter the screen lock state, please unlock. Shutdown 1． After pressing the POWER button, the shutdown option will pop up. 2． Shutdown options include flight mode, restart and shutdown. 3． Click to turn off the machine. 3.3 Opening and closing of the screen When the screen is idle, it will turn off automatically 6 1. After the screen is idle for a period of time, the screen is automatically closed to save battery power. 2. At the screen open state, press the POWER key, the screen can be closed immediately. When the screen is closed If the screen is closed, you can press the POWER button to open the screen. Open will enter the lock state, click on the screen on the small lock head, appear as shown in figure 3.1, slide to the left to unlock into the camera, slide to the right to explain the screen unlock into the dial menu interface, sliding up is to unlock the screen, enter the standby interface Figure 3.1 3.4 Use of touch screens MID operation A variety of ways to browse the home screen, menus and applications on your MID. Point selection When you want to use the screen keyboard input, want to select the application and other items on the home interface, just touch the…

Text truncated - open the document above for the full version.

Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: March 9, 2026 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BDTW-P1 Zhongke Microelectronics Technology (Shenzhen) Co., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: YU LV Title: Manager Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Tel.: 18520826349 Email: [email protected]

Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Mar. 9, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2BDTW-P1 Product Name: Tablet This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: YU LV Title: Manager Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Tel.: 18520826349 Email: [email protected] Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check SBOM (Software Bill of Materials) [For Device is not Inherent compliance] Section Component Name Version Supplier 1 2 3

Attestation Statements 2026-03-04 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID:2BDTW-P1) Zhongke Microelectronics Technology (Shenzhen) Co., LTD, the undersigned, hereby authorize FCC US Agent, LLC to act as our designated U.S. agent for service of process, Zhongke Microelectronics Technology (Shenzhen) Co., LTD accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent, LLC accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Zhongke Microelectronics Technology (Shenzhen) Co., LTD Contact Name: YU LV Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China FRN: 0034548107 Telephone No: 18520826349 Email: [email protected] Signature: YU LV U.S. Agent Information: Company Name: FCC US Agent, LLC Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN: 0033402884 Contact Name: Tim Payne Telephone No: 708-571-3148 Email: [email protected] Signature: Tim Payne

Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China (March 9, 2026) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BDTW-P1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description ⎯ Tune-Up Procedure / Parts List ⎯ SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES ⎯ (Etc.) The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of (up to 180) days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOM in the event information regarding the product or the product is made available to the public before the requested period has expired. ⎯ User Manual ⎯ Internal Photos ⎯ External Photos ⎯ Test Setup Photos ⎯ (Etc.) Sincerely, (Signature) Title: Manager Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Tel.: 18520826349 Email: [email protected]

Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China (March 9, 2026) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BDTW-P1 I, the undersigned, hereby authorize (Shenzhen LGT Test Service Co., Ltd.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Shenzhen LGT Test Service Co., Ltd.)shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (Zhongke Microelectronics Technology (Shenzhen) Co., LTD). We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, (Signature) (Full name of contact person listed on FCC’s website) YU LV (Title) Manager Tel: 18520826349 Fax: 18520826349 Email: [email protected]

Zhongke Microelectronics Technology (Shenzhen) Co., LTD Declaration Letter of Model Difference Date: 2026-03-04 FCC ID: 2BDTW-P1 Tested Model Number: ZQC-P1 Adding Model Number(s): M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 All Adding Model Number(s) is/are same electrically identical as Tested Model Number. The only difference between product models color process. Different model names to meet market demand. Other power supply modes, internal structure, circuit, appearance and key components are the same, and do not affect safety and electromagnetic compatibility performance. Yours Sincerely, Applicant: Zhongke Microelectronics Technology (Shenzhen) Co., LTD Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Contact Person: YU LV Tel.: 18520826349 Email: [email protected] Sincerely, Signature:

Page 1 of 5 Report No.: LGT26A130 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26A130 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26A130 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT26A130 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26A130 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10

Label

Page 1 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 WWAN DIV ANT Page 4 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Wi-Fi/BT ANT WWAN MAIN ANT Page 5 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 7 Report No.: LGT26A130 Appendix - Internal Photographs of EUT Constructional Details Photo 13 Photo 14

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 86 SAR TEST REPORT Product Name: Tablet Model Number: ZQC-P1, M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 FCC ID: 2BDTW-P1 Issued For : Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26A130HA02 Sample Received Date: Jan. 20, 2026 Date of Test Jan. 20, 2026 ~ Mar. 02, 2026 Date of Issue Mar. 02, 2026 Max. SAR (1g) Body: 0.785 W/kg Reprot No.: LGT26A130HA02 Page 2 of 86 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 22 8.1 Define Two Imaginary Lines on the Handset 22 8.2 Hotspot mode exposure position condition 23 9. Uncertainty 24 9.1 Measurement Uncertainty 24 9.2 System validation Uncertainty 25 10. Conducted Power Measurement 26 10.1 Test Result 26 11. EUT and Test Setup Photo 45 11.1 EUT Photos 45 11.2 Setup Photos 48 12. SAR Result Summary 51 12.1 Body SAR and Hotspot 51 12.2 Simultaneous Multi-band Transmission Evaluation 55 13. Equipment List 57 Appendix A. System Validation Plots 58 Appendix B. SAR Test Plots 72 Appendix C. Probe Calibration and Dipole Calibration Report 86 Reprot No.: LGT26A130HA02 Page 3 of 86 Revision History Rev. Issue Date Contents 00 Mar. 02, 2026 Initial Issue Reprot No.: LGT26A130HA02 Page 4 of 86 TEST REPORT CERTIFICATION Applicant Zhongke Microelectronics Technology (Shenzhen) Co., LTD Address Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Manufacture Zhongke Microelectronics Technology (Shenzhen) Co., LTD Address Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Product Name Tablet Trademark N/A Model Number ZQC-P1, M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 Sample number LGT2601204 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-2019 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Deng Deng Engineer Vita Li Manager Reprot No.: LGT26A130HA02 Page 5 of 86 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Tablet Test Model Number ZQC-P1 Series Number M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 Model Difference The only difference between product models color process. Different model names to meet market demand. Other power supply modes, internal structure, circuit, appearance and key components are the same, and do not affect safety and electromagnetic compatibility performance. Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version V3.0 Software Version N/A Frequency Range GSM 850: 824 ~ 849 MHz PCS 1900: 1850 ~ 1910 MHz WCDMA Band II: 1850 ~ 1910 MHz WCDMA Band V: 824 ~ 849 MHz LTE Band 2:1850 ~1910MHz LTE Band 4:1710 ~1755MHz LTE Band 5:824 ~ 849MHz LTE Band 12:699~716MHz LTE Band 13:777~787MHz LTE Band 66:1710~1780MHz WLAN 802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 ~ 5850 MHz Bluetooth: 2402 ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Body:0mm Mode Body Worn and Hotspot (W/ kg) GSM 850 0.682 PCS 1900 0.785 WCDMA Band II 0.766 WCDMA Band V 0.639 LTE Band 2 0.656 LTE Band 4 0.641 LTE Band 5 0.547 LTE Band 12 0.469 LTE Band 13 0.626 LTE Band 66 0.587 2.4G WLAN 0.660 5.2G WLAN 0.498 5.8G WLAN 0.578 Bluetooth Note 0.084 1-g Sum SAR 1.426 Reprot No.: LGT26A130HA02 Page 6 of 86 Battery Rated Voltage: 3.8V Capacity:2800mAH Description test modes SIM 1 and SIM 2 is a chipset unit and tested as single chipset, SIM 1 is used to tested Operating Mode: GSM: GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN: 802.11b(DSSS): CCK, DQPSK, DBPSK 802.11g(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM 5G WLAN: 802.11a(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11ac (OFDM): BPSK, QPSK,16-QAM,64-QAM,256-QAM Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification GSM/WCDMA/LTE: FPC antenna Bluetooth: FPC antenna WLAN: FPC antenna Operating Mode Maximum continuous output SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot trans mitting at the same time Hotspot Mode Support DTM Mode Not Support Note 1: The BT value was …

Text truncated - open the document above for the full version.

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 72 RF TEST REPORT Product Name: Tablet Model Number: ZQC-P1, M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 FCC ID: 2BDTW-P1 Issued For : Zhongke Microelectronics Technology (Shenzhen) Co., LTD Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26A130RF01 Sample Received Date: Jan. 20, 2026 Date of Test: Jan. 20, 2026 ~ Feb. 27, 2026 Date of Issue: Feb. 27, 2026 Report No.: LGT26A130RF01 Page 2 of 72 TEST REPORT CERTIFICATION Applicant: Zhongke Microelectronics Technology (Shenzhen) Co., LTD Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Manufacturer: Zhongke Microelectronics Technology (Shenzhen) Co., LTD Address: Floor 4, Building A, Shimei Industrial Zone, Jinying New Village, Longhua District, Shenzhen, Guangdong, China Product Name: Tablet Trademark: N/A Model Number: ZQC-P1, M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826, H827, ZQC-T1 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26A130RF01 Page 3 of 72 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 29 4.1 LIMIT 29 4.2 TEST PROCEDURE 29 4.3 TEST SETUP 29 4.4 EUT OPERATION CONDITIONS 30 4.5 TEST RESULTS 30 5. NUMBER OF HOPPING CHANNEL 31 5.1 LIMIT 31 5.2 TEST PROCEDURE 31 5.3 TEST SETUP 31 5.4 EUT OPERATION CONDITIONS 31 5.5 TEST RESULTS 31 6. AVERAGE TIME OF OCCUPANCY 32 6.1 LIMIT 32 6.2 TEST PROCEDURE 32 6.3 TEST SETUP 32 6.4 EUT OPERATION CONDITIONS 32 6.5 TEST RESULTS 32 7. HOPPING CHANNEL SEPARATION MEASUREMEN 33 7.1 LIMIT 33 7.2 TEST PROCEDURE 33 Report No.: LGT26A130RF01 Page 4 of 72 7.3 TEST SETUP 33 7.4 EUT OPERATION CONDITIONS 33 7.5 TEST RESULTS 33 8. BANDWIDTH TEST 34 8.1 LIMIT 34 8.2 TEST PROCEDURE 34 8.3 TEST SETUP 34 8.4 EUT OPERATION CONDITIONS 34 8.5 TEST RESULTS 34 9. OUTPUT POWER TEST 35 9.1 LIMIT 35 9.2 TEST PROCEDURE 35 9.3 TEST SETUP 35 9.4 EUT OPERATION CONDITIONS 35 9.5 TEST RESULTS 35 10. ANTENNA REQUIREMENT 36 10.1 STANDARD REQUIREMENT 36 10.2 EUT ANTENNA 36 APPENDIX I - TEST RESULTS 37 1. DUTY CYCLE 37 2. BANDWIDTH 41 3. MAXIMUM CONDUCTED OUTPUT POWER 48 4. CARRIER FREQUENCY SEPARATION 52 5. NUMBER OF HOPPING FREQUENCIES 54 6. TIME OF OCCUPANCY (DWELL TIME) 56 7. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 59 APPENDIX II - MEASUREMENT PHOTOS 72 Report No.: LGT26A130RF01 Page 5 of 72 Revision History Rev. Issue Date Revisions 00 Feb. 27, 2026 Initial Issue Report No.: LGT26A130RF01 Page 6 of 72 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT26A130RF01 Page 7 of 72 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 Temperature ±0.5∞C 10 Humidity ±2% 11 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26A130RF01 Page 8 of 72 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Tablet Test Model Number: ZQC-P1 Series Number: M104, M105, M107, M108, M109, M20, H717, H719, H720, H821, H822, H823, H824, H825, H826,…

Text truncated - open the document above for the full version.

2024.01.15 13691865216 ZQC-P1-MB ZQC-P1-MB China Science Microelectronics Technology (Shenzhen) Co., Ltd. Product Approval Specification SPECIFICATION FOR APPROVAL Customer Approval Result (APPROVAL RESULT):  Qualified (OK) Not Qualified (NG) □Other (OTHER): Remarks (REMARK): Date:2024 Year Month Day Organized by Zhongke Microelectronics Technology (APPD): Reviewed by Zhongke Microelectronics Technology (CHKD BY): Approved by Zhongke Microelectronics Technology (APPROVAL BY): Supplier Name Shenzhen Shundacheng Technology Co., Ltd. DayPeriod PhoneChina Science Microelectronics Technology Project Model Supplier Model NumberChina Microelectronics Technology Product NameWIIFI/BT Antenna Supplier Contact PersonChen HuamingChina Microelectronics Technology Product Number Supplier Address4th Floor, Building B5, Xinfeng Industrial Park, Chongqing Road, Fuyong Town, Bao'an District, Shenzhen Prepared (PRE.): Huang Zongbao Reviewed (CHKD BY): Yang Yonghui Approval by: Chen Huami…

Text truncated - open the document above for the full version.
