2BDUIPA012.4G Bluetooth Module

2.4G Bluetooth Module Data Sheet (WS_D96_V1.1) 深圳市微智电子有限公司 官网：www.we-smart.cn 邮箱：[email protected] 地址：深圳市宝安区西乡街道航城大道塘东光电大厦1-1506 PROFILE Imprint 1 Product Introduction ................................................................................................... 3 1.1 Brief Introduction ............................................................................................ 3 1.2 Features ............................................................................................................ 3 1.3 Parameter ......................................................................................................... 4 1.4 Application ...................................................................................................... 5 2 Hardware Introduction ............................................................................................... 6 2.1 Module appearance and connector .................................................................. 6 2.2 Module connector defination .......................................................................... 7 2.3 Module photo .................................................................................................. 7 2.4 PCB Packaging size......................................................................................... 8 2.5 Design Specifaction ......................................................................................... 8 2.5.1 Antenna design specification ................................................................ 8 2.5.2 PCB design specification ..................................................................... 9 2.5.3 Reset circuit design .............................................................................. 9 2.6 Requirement of FCC KDB 996369 D03 for module certification........10 3 Antenna Information.................................................................................................13 4 Practical design reference ......................................................................................... 15 4.1 PWM Dimming scheme design specification ............................................... 15 4.2 LED driverd reference design ....................................................................... 16 5 Contact ...................................................................................................................... 17 2 Version Specification Version No. Revision Content Revisor Date V1.0 Based on WS_D95 to change to 2 layer board, delete some unused pin output We-smart 2023-7-14 V1.1 Additional shield We-smart 2023-10-20 3 1 Product Introduction 1.1 Brief Introduction WS_D96 intelligent lighting module is a Bluetooth module based on TLSR8250 chip, compatible with Bluetooth 5.0 low power (BLE) and Bluetooth mesh networking functions. Devices communicate through a peer-to-peer star network, using Bluetooth broadcast for communication, the module integrated power amplifier, can ensure multi-device, long-distance response in time, it is mainly used in intelligent light control. It can meet the requirements of low power consumption, low delay and short distance wireless data communication. 1.2 Product Feature ◆ Integrated power amplifier for longer communication distance ◆ stamp hole patch package, easy to attach ◆ Rich I/O resources can be expanded to other applications ◆ High performance onboard antenna, no additional design required 4 1.3 Parameter Sheet 1：Module Technical Specifications Category Items Parameter Standard Bluetooth 5.0 Data Rate 1Mbps Wireless Data Frequency Domain 2402MHz ~ 2483MHz Maximum transmitting power ﹢7.31dBm Maximum receiving sensitivity -96dBm Hardware Data data interface 5-way PWM storage 512KB internal storage service voltage DC 2.7V ~ 3.6V Recommend 3.3V，±5% supply current ≥20mA power dissipation Deep sleeping mode：0.4uA Sleep mode：1.4uA Mesh mode：13mA transmission distance Directly connected to the open sight range： ≥80 meters Cascaded open sight distance： ≥200 meters Working temperature ﹣40°C ~ ﹢75°C Module size 18.9mm x 11.6mm x 2.1mm 1.4 Application ◆ Intelligent light control system ◆ Home/Building Automation ◆ Home appliances wireless network control ◆ Industrial control ◆ Low power wireless sensor networks 5 2 Product Hardware Introduction 2.1 Module appearance and interface Module appearance is as follows, 24 external pins, detailed pin function refer to the following table; 6 2.2 Module interface definition Foot Posit ion Pin Name Description 1 PA_VDD It is recommended that you supply power to the module power amplifier separately from the module power supply 2 GND Modular ground input 3 GND Modular ground input 4 3V3 Module power input 5 GND Modular ground input 6 NC Nil 7 NC Nil 8 SWS System debugging interface 9 P4(R) Red PWM output, high efficiency 10 P5(G) Green PWM output, high efficiency 11 NC Nil 12 P0(W) Warm White PWM output, high efficiency 13 P1(B) Blue PWM output, high efficiency 14 P2(C) White PWM output, high efficiency 15 RST Reset pin, low effectiveness 16 GND Modular ground input 2.3 Module diagram 7 2.4 PCB packaging outline Remark： For detailed package information, please see file D02-core-smd.zip (D72 is the same package as D02) Download link: http://pan.baidu.com/s/1c1UEbz6 password: 9 m5v It contains PADS format package, as well as some compatible format package. 2.5 Design Specification 2.5.1 Antenna Design Specification The upper left part of the module is an antenna holder, which must be fastened when installing the antenna. The following antenna design rules should be observed when designing: ①The antenna must be at least 10 mm away from metal or high components; ② The antenna cannot be surrounded by any enclosure. All shell materials, including plastic, should be at least 10 mm away from the antenna area. 8 2.5.2 PCB Design Specification It is recommended that the LDO supply 3.3V DC and the PA supply at least 100mA driving current. It is recommended that a 10uF capacitor be plac…

Text truncated - open the document above for the full version.

The ipex antenna is connected to module through unique coupling(ipex connection) Modular Approval Request Letter Alliance Outdoor Lighting 951-375-7896 27461-B Diaz Rd, Temecula, CA Product Name: 2.4G Bluetooth Module Model Number: PA01 FCC ID:2BDUIPA01 Date: 2023.11.30 Requirement of Public Notice DA00‐1407 / part 15.212 1. The modular transmitter must have its own RF shielding. Yes. The module has its own RF shielding. 2. The modular transmitter must have buffered modulation/data inputs. Yes This module is not only used in our own specific products but also for OEM market. We have total control of the design and the data protocol through IC Chip “TLSR8250F512ET32”. The radio IC we use complies with FCC part 15. 3. The modular transmitter must have its own power supply regulation. Yes This module is not only used in our own specific products but also for OEM market, this module has its own voltage regular (IC2002). The radio IC complies with FCC part 15. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). Yes 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Yes This module has been tested in a stone-alone configuration as shown in the test setup photos. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. Yes This module will be labelled with its FCC ID number. When the module is installed in our products and it is not visible, an external label will be applied which refer to the modules FCC ID number inside. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the Yes This module is not only used in our own specific products but also for OEM market. The user manuals are based on the requirement specifications. And this module is compliance with RF exposure requirements. module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine Environmental evaluation for RF Exposure to demonstrate compliance. In addition spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Yes This module is not only used in our own specific products but also for OEM market. Thank you. Sincerely, Vincent Bowers Product Manager Nov.30th, 2023

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 Alliance Outdoor Lighting Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant:Alliance Outdoor Lighting FCC ID: 2BDUIPA01 To whom it may concern, Alliance Outdoor Lighting (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant [is not] identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] Vincent Bowers Product Manager Alliance Outdoor Lighting Nov.30th, 2023

Temecula, CA, 92590, USA Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Alliance Outdoor Lighting Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that Alliance Outdoor Lighting (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated below. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Alliance Outdoor Lighting Contact Name : Vincent Bowers Address : 27461-B Diaz Rd, Telephone No : 951-375-7896 Email : [email protected] FCC ID : 2BDUIPA01 Applicant FRN : 0034548677 Signature: ____________________________________ Date: ____________________________________ December 8, 2023

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room101/301/401/102/202/302/402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Job No.: 231114051GZU FCC ID: 2BDUIPA01 Version: 08 July 2020 Page 1 of 1 FCC RF Exposure-Portable RF Exposure Compliance Requirement Model no.: PA01 The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequencies of the device are between 100 MHz and 6 GHz. The worst case test separation distance is 5mm. The Max Conducted Output Power and SAR Test Exclusion Threshold (mW) are listed below: Transmit frequency (GHz) Max Conducted Output Power (mW) SAR Test Exclusion Threshold (mW) 2.402-2.480 5.4 9.5 The SAR Test Exclusion Threshold is calculated from: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation17 ⚫ The result is rounded to one decimal place for comparison According to SAR Exclusion Threshold in KDB 447498 (D01) General RF Exposure Guidance v06, the SAR report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Alliance Outdoor Lighting TEST REPORT SCOPE OF WORK EMC TESTING–PA01 REPORT NUMBER 231114051GZU-001 ISSUE DATE [REVISED DATE] 29-January-2024 [---------------------] PAGES 39 DOCUMENT CONTROL NUMBER FCC BT 4.0- f © 2017 INTERTEK TEST REPORT Room101/301/401/102/202/302/ 402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room101/301/401/102/202/302/402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 39 FCC BT 4.0-f Applicant Name & Address : Alliance Outdoor Lighting 27461-B Diaz Rd, Temecula, CA Manufacturing Site : Zhongshan Hai Deng 5 / F, No.10, Fuheng East Road, Yongxing Industrial Zone, Henglan Town, Zhongshan city, Guangdong Province Intertek Report No FCC ID : : 231114051GZU-001 2BDUIPA01 Test standards 47 CFR PART 15 Subpart C: 2021 section 15.247 Sample Description Product : 2.4G Bluetooth Module Model No. : PA01 Electrical Rating : DC 3.3V Serial No. : Not Labeled Date Received : 14 November 2023 Date Test Conducted : 10 January 2024-18 January 2024 Prepared and Checked By Ace Yao Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 231114051GZU-001 Version: 14 December 2022 Page 3 of 39 FCC BT 4.0-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 6 2.3 TEST METHODOLOGY ........................................................................................................... 6 2.4 TEST FACILITY ...................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 8 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 9 4.0 MEASUREMENT RESULTS ......................................................................................... 10 4.1 ANTENNA REQUIREMENT .................................................................................................... 10 4.2 6 DB BANDWIDTH (DTS BANDWIDTH) .................................................................................. 11 4.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ..................................................................... 14 4.4 PEAK POWER SPECTRAL DENSITY .......................................................................................... 17 4.5 OUT OF BAND CONDUCTED EMISSIONS ................................................................................. 20 4.6 OUT OF BAND RADIATED EMISSIONS .................................................................................... 23 4.7 RADIATED EMISSIONS IN RESTRICTED BANDS .......................................................................... 23 4.8 BAND EDGES REQUIREMENT ................................................................................................ 33 4.9 CONDUCTED EMISSION TEST ................................................................................................ 36 TEST REPORT Intertek Report No.: 231114051GZU-001 Version: 14 December 2022 Page 4 of 39 FCC BT 4.0-f 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth (DTS bandwidth) FCC PART 15 C section 15.247 (a)(2) ANSI C63.10: Clause 11.8 PASS Maximum Peak Conducted Output Power FCC PART 15 C section 15.247(b)(3) ANSI C63.10: Clause 11.9.1.2 PASS Peak Power Spectral Densi…

Text truncated - open the document above for the full version.

1 深圳市飞敏科技有限公司 ShenZhen City FeiMin Technology CO.,LTD. 产品承认书 SPECIFICATION FOR APPROVED 客户 CUSTOMER: 深圳市微智电子有限公司 产品名称 PRODUCTS: 铜管天线 客户料号 PART NO: 产品型号 Spec.: FM-S1845-F-WZ-TG1335-30（130mm） 日期 Data: 2023.11.28 备注：承认盖章后请回复一份承认书（或复印件）给我司，其余由贵公司存档 REMARK:Please send us one(or copy)of this approval with stamp after accepting,other copies filed by the customer. 地址：深圳市宝安区西乡街道固戍社区恒南一路C栋厂房303室 ADD:Room 303,Building C,Hengnan one Road,Gushu community,Xixiang Street,Bao’an District,Shenzhen City 电话Tel: 0755-23035723 传真Fax: 0755-23036702 邮箱E-mail: [email protected] 网址HTTP:www.fmant.cn 客户 CUSTOMER 承认 ACCEPTED BY 审核 CHECKED BY 批准 APPROVED BY 供应商 SUPPLIER 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY 马凡 夏兴喜 马冬冬 ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 2 目录 产品承认书 ............................................................................................................ 1 1. 项目信息Project Information.......................................................................... 4 1.1. 外观尺寸Appearance and Dimensions .................................................. 4 2. 电气性能 Electrical Characteristics ................................................................ 5 2.1. 测试环境条件Test Environment Conditions ......................................... 5 2.2. 测示方法Measurement method .............................................................. 5 2.2.1. 天线电压驻波比Antenna VSWR .................................................. 5 2.2.2. 天线回波损耗Antenna Return loss ............................................ 6 2.3. 天线无源测试数据 Antenna passive test data .............................. 6 2.3.1. 测试系统Test system ........................................................................ 6 2.3.2天线效率及增益Antenna efficiency and gain ............................. 7 2.3.2. 天线辐射方向图Antenna Radiation Pattern .................................... 7 3.备注Notes .......................................................................................................... 8 4.产品包装规范Product packaging specification ................................................ 8 ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 3 Revision history 版本 日期 状态 A1 2023-11-28 首版 变更内容： 第一次变更： 变更前：（如有必要，请添加相应的图片，此处变更明细要描述清楚） 变更后：（如有必要，请添加相应的图片，此处变更明细要描述清楚） ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 4 1. 项目信息Project Information 1.1. 外观尺寸Appearance and Dimensions ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 5 2. 电气性能 Electrical Characteristics 2.1. 测试环境条件Test Environment Conditions 物理性质physical features 温度Temperature Ordinary Temperature (5 to 35°C) 湿度Humidity Ordinary Humidity (25 to 85% RH) 2.2. 测示方法Measurement method 2.2.1. 天线电压驻波比Antenna VSWR ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 6 2.2.2. 天线回波损耗Antenna Return loss 2.3. 天线无源测试数据 Antenna passive test data 2.3.1. 测试系统Test system 深圳市飞敏科技有限公司（24探头OTA 微波暗室） ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 7 2.3.2天线效率及增益Antenna efficiency and gain Frequency (MHz) Gain (dBi) Efficiency (%) 2400 MHz 2.73 48.23 2410 MHz 2.81 49.49 2420 MHz 2.69 50.75 2430 MHz 2.56 48.22 2440 MHz 2.28 50.66 2450 MHz 2.71 51.3 2460 MHz 2.59 51.94 2470 MHz 2.56 49.36 2480 MHz 2.28 48.35 2490 MHz 2.76 48.61 2500 MHz 2.56 49.19 2.3.2. 天线辐射方向图Antenna Radiation Pattern ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 8 3.备注Notes 1、安装时注意不能离金属部分太近，以避免影响天线性能。 2、此款天线只适用此机型，天线的位置不可以随意改动，若用于其它机器上导致效果变差，与我司无 关。 3、本承认书所使用数据（如：天线效率、增益等）均为本承认项目/天线在深圳市飞敏科技有限公司 实验室测试所得出数据 4.产品包装规范Product packaging specification 产品名称:2.4G铜管天线 天线形式：屏蔽线+铜管+热缩管 一、标签要求 内标签长7CM，宽4CM左右 外标签长7CM，5CM左右 二、装箱流程 作业说明： 1.产品__PCS用PE开口袋装好，每小袋贴好内标签； 将__小袋装入大PE封口胶带袋中，尾数及备品除外。 2.每箱装__大袋产品，将箱子用胶纸以“工”字形封箱。 3.在箱子的右上角贴上外标签，不可有漏填、填错现象。 三、注意事项 装箱时要注意将天线平整放好，封胶后不可出现严重晃 动情况，未填满整箱的情况需塞入泡棉填充，避免运输 过程中造成产品不良的情况。 客户名称 供 应 商 深圳市飞敏科技有限公司 订单编号 ************* 物料编码 ************* 规格型号 ****** 产品名称 ******* 数 量 *****PCS 检验 备品 ***PCS 备注 供 应 商 深圳市飞敏科技有限公司 产品名称 ****** 物料编码 ************ 规格型号 ********** 数 量 ***PCS 产品

Note: EUT is positioned at the center of the turntable to keep 3m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz) Conducted Emissions
