2BDUQ-99231The clone motion decoy

MORE INFORMATION AT WWW.HIGDONOUTDOORS.COM DIRECTIONS: 1. Assembly: When attaching wings, be sure curve of wing strut is facing forward in direction bird would be flying. [FIG A] Install wing strut in bird trough wing slot in body. Square rod inserts into square hole in wing cam. [FIG B] 2. Secure wing to body by hooking shock cord hooks in small holes located on the bird’s back. [FIG. C]. Pull fabric down to cover the wing strut. 3. In the field: Install stake in ground at slight angle listing downwind. This will help to keep bird flying into the wind. In severe wind, loop elastic cord (located in breast of bird) over the 90-degree bend in the stake. 4. Hook up power cord by two-way connector. Connect to power source with positive and negative battery clamps. DIRECTIONS FOR REMOTE SYSTEM: Note: Transmitter and receiver will come already synced. If receiver loses connection with transmitter, follow these steps to sync the two again. 1. Remove foam belly plug from the bird. The receiver is adhered to the foam. 2. Remove lid from receiver box. 3. In corner of receiver, locate the small button with LED light next to it. [FIG. D] 4. While connected to power source, press and hold button for 2 seconds then release. LED will begin to flash. Press and release the “ON” button on the transmitter (remote). LED will flash 5 times when successfully synced. SPEED UP TRANSMITTER / RECEIVER REMOTE CONTROL SPEED DOWN POWER ONPOWER OFF MOMENTARY SYNC BUTTON B C D A MOTION DECOY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

Page 1 of 4 External Photos Page 2 of 4 External view Page 3 of 4 Page 4 of 4

Page 1 of 2 Label and Location Page 2 of 2 The Label of 99231 Remote Control: The location of the label: Model: 99231 FCC ID: 2BDUQ-99231 Rate Voltage: 3VDC Made In China Location 28mm 20mm

Page 1 of 3 Internal Photos Page 2 of 3 Page 3 of 3 Antenna

Higdon Outdoors LLC. SAR COMPLIANCE REPORT Report Type: FCC SAR assessment report Model: 99231 REPORT NUMBER 231100894SHA-002 ISSUE DATE December 07, 2023 DOCUMENT CONTROL NUMBER: TTRFFCCSAR-01_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCSAR-01_V1© 2018 Intertek Page 2 of 6 Report no.: 231100894SHA-002 Applicant: Higdon Outdoors LLC. 2800 Adams Street Paducah, KY 42001 Manufacturer: Nanjing Watt Electric Motors Co., Ltd Lishui Economic Development Zone, Nanjing City Factory1: Nanjing Watt Electric Motors Co., Ltd Lishui Economic Development Zone, Nanjing City Factory2: CHUZHOU WATT INTELLIGENT MANUFACTURING CO., LTD A1 Building No.188 Conch Ave, Shizi Town, Quanjiao County, Chuzhou City, Anhui Province FCC ID: 2BDUQ-99231 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D04 Interim General RF Exposure Guidance v01 FCC Part2.1091, FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Scout Gong Eric Li Project Engineer Reviewer Report No.: 231100894SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 3 of 6 Revision History Report No. Version Description Issued Date 231100894SHA-002 Rev. 01 Initial issue of report December 07, 2023 Report No.: 231100894SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 4 of 6 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: The remote control for the clone motion decoy Type/Model: 99231 Description of EUT: The EUT is a remoter control with 433.920 MHz wireless module. The EUT can transmit 433.920 MHz signal to the receiver device (The clone motion decoy). The worst data were listed in this report. Rating: 3V DC Category of EUT: Class B EUT type: Tabletop Floor standing Software Version: / Hardware Version: / Sample Identification No.: A231123-28-001 Sample received date: November 24, 2023 Date of test: November 24, 2023, to December 05, 2023 1.2 Technical Specification Operation Frequency: 433.920MHz Type of Modulation: ASK Product Type: Mobile Portable Fix Location Channel Number: 1 Antenna Designation: Integral PCB antenna, non-user removable Report No.: 231100894SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 5 of 6 1.3 Description of Test Facility Name: Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road (North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L0139 FCC Accredited Lab Designation Number: CN0175 IC Registration Lab CAB identifier.: CN0014 VCCI Registration Lab Member No: 3598 (Registration No.: R-14243, G-10845, C-14723, T-12252) A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 231100894SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 6 of 6 2 SAR Assessment Test result: Pass 2.1 SAR Test Exclusion Limit This method shall only be used at separation distances up to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by Formula below: f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula above. The example values shown in below are for illustration only. Frequency (MHz) Distance (mm) 5 10 15 20 25 30 35 40 45 50 300 39 65 88 110 129 148 166 184 201 217 450 22 44 67 89 112 135 158 180 203 226 835 9 25 44 66 90 116 145 175 207 240 1900 3 12 26 44 66 92 122 157 195 236 2450 3 10 22 38 59 83 111 143 179 219 3600 2 8 18 32 49 71 96 125 158 195 5800 1 6 14 25 40 58 80 106 136 169 2.2 Assessment Results As we can see from the test report 231100894SHA-001: The highest EIRP adjusted with tune-up tolerance is: 87.90 - 95.30 = -7.40 dBm = 0.182 mW. 0.182 mW < 22mW (Test Exclusion Thresholds of 450MHz at 5mm). Therefore, the SAR requirement is deemed to be satisfied without test. ************************************ END ************************************

Page 1 of 2 Antenna Construction Page 2 of 2 The length of wire antenna Antenna

Higdon Outdoors LLC. RF TEST REPORT Report Type: FCC Part 15.231 RF report Model: 99231 REPORT NUMBER: 231100894SHA-001 ISSUE DATE: December 07, 2023 DOCUMENT CONTROL NUMBER: TTRF15.231_V1 © 2020 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.231_V1 © 2018 Intertek Page 2 of 27 Report no.: 231100894SHA-001 Applicant: Higdon Outdoors LLC. 2800 Adams Street Paducah, KY 42001 Manufacturer: Nanjing Watt Electric Motors Co., Ltd Lishui Economic Development Zone, Nanjing City Factory1: Nanjing Watt Electric Motors Co., Ltd Lishui Economic Development Zone, Nanjing City Factory2: CHUZHOU WATT INTELLIGENT MANUFACTURING CO., LTD A1 Building No.188 Conch Ave, Shizi Town, Quanjiao County, Chuzhou City, Anhui Province FCC ID: 2BDUQ-99231 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2021): Radio Frequency Devices (Subpart C) ANSI C63.10 (2020): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices PREPARED BY: REVIEWED BY: Scout Gong Eric Li Project Engineer Reviewer Report No.: 231100894SHA-001 TEST REPORT TTRF15.231_V1 © 2018 Intertek Page 3 of 27 Content REVISION HISTORY................................................................................................................................................ 4 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 5 1 GENERAL INFORMATION ............................................................................................................................. 6 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 6 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 6 1.3 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 7 2 TEST SPECIFICATIONS ................................................................................................................................... 8 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................... 8 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................... 8 2.3 TEST SOFTWARE LIST ............................................................................................................................................ 8 2.4 TEST PERIPHERALS LIST ......................................................................................................................................... 8 2.5 TEST ENVIRONMENT CONDITION: ............................................................................................................................ 9 2.6 INSTRUMENT LIST .............................................................................................................................................. 10 2.7 MEASUREMENT UNCERTAINTY ............................................................................................................................. 11 3 FUNDAMENTAL & SPURIOUS EMISSION & RESTRICT BAND RADIATED EMISSION ...................................... 12 3.1 LIMIT .............................................................................................................................................................. 12 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 13 3.3 TEST CONFIGURATION ........................................................................................................................................ 14 3.4 TEST RESULTS OF RADIATED EMISSIONS ................................................................................................................. 16 4 POWER LINE CONDUCTED EMISSION ......................................................................................................... 20 4.1 LIMIT .............................................................................................................................................................. 20 4.2 TEST CONFIGURATION ........................................................................................................................................ 20 4.3 MEASUREMENT PROCEDURE ............................................................................................................................... 21 4.4 TEST RESULTS OF POWER LINE CONDUCTED EMISSION..............................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 3 Setup Photos Page 2 of 3 1. Conducted Emission NA 2. Radiated Emission RE 30MHz – 1 GHz Page 3 of 3 RE 1 GHz – 18 GHz 3. Conducted RF test NA
