2BDVQ-ALW-R03-23Ally Screen device

Set -Up Guide Quick Start To use your Ally®, once mounted, simply: • Plug into power supply (5V / 2.1A) • Wait for Ally® to start up—MPC will auto-launch • C onnect to Wi-Fi • A djust time zone • Enter your personalized MPC key • Enter Stor e Credentials • Select product Package Contents This package contains fiv e (5) of each: • Ally® 4” touch screen player • USB A to C cable • Mounting bracket • Mounting tape • Mounting screw & anchor kit Mounting Ally® allows three (3) mounting options: Built-in stand: Use built-in 30-degree fold-out for tabletop display Mounting tape: A dhere to bracket (included), then adhere bracket to desired location. Use clips to attach Ally® to bracket Mounting screw & anchor kit: Use to rmly attach to surfac es where tape may not stick well 1234 80.00 mm 117.00 mm Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Warning: FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses and can radi- ate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful inter- ference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer- ence to radio or television reception, which can be deter- mined by turning the equipment off and on, the user is Warning: FCC Statement: encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit differ- ent from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The equipment complies with FCC Radiation exposure limit set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Warning: NOTE: This device complies with part 15 of the FCC Rules. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
